keilhauer Sguig User manual

Sguig
with Invisi-syncroTM mechanism
1450 Birchmount Road, Toronto, Ontario, Canada M1P 2E3
tel [phone] fax [phone] 724 5665
www.keilhauer.com [e-mail]

0
Use this
(to raise or lower seat)
1. Seat Height Adjustment
Use the paddle shaped lever on the right side underneath the seat
To raise lift your weight off the seat while lifting the front of the lever
To lower sit on the seat while lifting the front of the lever
Sit down. Please. The only way to know if you are
adjusting your chair to provide you with maximum
comfort, is to make these adjustments while you
are seated.

0
Use this
(to increase or decrease the
tilt tension)
1. Tension Adjustment
Use the big round knob undeneath the centre of the seat
To increase tension turn the knob clockwise
To decrease tension turn the knob counter-clockwise

0
Use this
(to lock or unlock tilt)
3. Tilt Lock
Use the paddle shaped lever on the left side underneath the seat
To unlock tilt pull the front of the lever up and tilt back slightly
To lock tilt recline to your desired position and push the front of the
lever down

0
Use this area
(to adjust arm height)
4. Arm Height Adjustment/Sliding Seat Pan
Use the buttons on the outside of the arm rests
To raise or lower push the button in and raise or lower the arm rest
and release button to lock
Use the lever located underneath the seat on the right hand side of
the chair, above the seat height adjustment paddle
Pull the lever out to activate the sliding seat pan and slide your seat
forwards, release the lever to lock the seat into the desired depth.
Pull the lever again and slide backwards to return the start position.

0
Use these
(to adjust arms rests)
5. Arm Adjustments
Arm Rest Pivot - Grasp the front of the arm rest firmly to pivot in or
out
Arm Rest Rotation - Press the buttons located under the front of the
arm rests to rotate up to 180°
Arm Width - Push lever down to release arm. Grasp arm and pull in
or out to desired width. Pull lever up to lock in position.
Use these
(to adjust arm width)

0
Use this area
(to raise or lower back)
6. Back Height Adjustment
Use the sides of the back just above the seat and grab with both
hands
To raise lift the back up - you will hear a click for each height
increment
To lower lift the back to the highest setting and it will disengage
allowing it to drop down to the starting (lowest) height: the back
must return to the starting position to reengage the height adjust-
ment mechanism
