O
OWNER’S
WNER’S MANU
MANUAL
AL
KPS-SPC
SEATED PREACHER CURL
Questions?
Call our toll free Keys Fitness Helpline
1-800-683-1236

V
THANK YOU for making this Power System unit a part of
your exercise program. Keys Fitness and our Power System
Series assures the very best in value, appearance, durability
and biomechanics.
This manual will guide you through the assembly process. If at any time
you are having trouble with the assembly or use of this product, then
please contact us at our Keys Fitness Helpline. We have trained service
technicians on site to take care of you, our valued customer.
POWER SYSTEM SERIES
MODEL: KPS-SPC
QUESTIONS?
CALL
1-800-683-1236
Monday-Friday
8:30-5:30 Central Time
When calling please have the following product information available:
• Product Series
• Model #
• Part Number
• Part Description
REGISTRATION CARD
To avoid unnecessary delays in warranty parts and to insure that a perma-
nent record of your purchase is on file with our company, be sure to send
in the warranty registration card or register on-line at www.keysfitness.com
within 10 days of purchase.

X
BEFORE YOU START
Prior to assembly, remove components from the box and verify that all the listed parts
were supplied.
Before using this unit or starting any exercise program, consult your physician. This is
especially important for persons over the age of 35 and/or persons with pre-existing
health problems. Keys Fitness Products LP assumes no responsibility for personal
injury or property damage sustained by or through the use of this product.
It is the owner’s responsibility to ensure that all users of this unit have read the Owner’s
Manual and are familiar with safety information and precautions.
SAFETY INFORMATION WARNING!
SAFETY PRECATIONS
• This Power System unit should only be used on a level surface and is intended for
indoor use only. Keys Fitness recommends an equipment mat be placed under the
unit to protect the floor or carpet and for easier cleaning.
• Wear comfortable, good-quality walking or running shoes and appropriate clothing.
Do not use this unit with bare feet, sandals, socks or stockings!
• Always examine your unit before using to ensure all parts are in working order.
• Do not leave children unsupervised near or on the unit.
• Service to your Power System unit should only be performed by an authorized serv-
ice representative, unless authorized and/or instructed by a Keys Fitness technician.
Failure to follow these instructions will void the warranty.

ASSEMBLY
STEP 1
Y
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
Connect Seat Frame (3) to Rear Base (4) and Weight Support
(1) using:
1 x (16) Bolt
2 x (18) Bolt
6 x (13) Washer
3 x (19) Nylon Nut

Z
ASSEMBLY
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
STEP 2
Attach Pads (7,8) using:
1 x (11) Plastic Sleeve
1 x (1) Telescoping Arm Support
2 x (17) Bolt
2 x (15) Bolt
4 x (13) Washer
Use Pop Pin (5) to select height of Arm Pad. Secure with Knob (12).
