Keys Fitness Leg Press Hack Squat KF-LPHS User manual

Leg Press Hack squat
Owner’s Manual
KF-LPHS
215-00132
11/06 Rev A

2
Table of Contents
Before You Start 3
Important Safety Information 4
Assembly 5-10
Parts List 11
Exploded View 12
Warranty Information 13

KEYS FITNESS SERIES
MODEL: KF-LPHS
QUESTIONS?
CALL
1-888-340-0482
Monday-Friday
8:30-5:30 Central Time
When calling please have the following product information available:
3
Model Name :
Date Mfg.:
PO # :
Serial #:
Model Name Decal Location
THANK YOU for making this unit a part of your exercise program.
Keys Fitness assures the very best in value, appearance, durability
and biomechanics.
This manual will guide you through the assembly process. If at any time you are
having trouble with the assembly or use of this product, then please contact us
at our Keys Fitness Help line. We have trained service technicians on site to take
care of you, our valued customer.
REGISTRATION CARD
To avoid unnecessary delays in warranty parts and to ensure that a permanent
record of your purchase is on file with our company, be sure to send in the war-
ranty registration card or register on-line at www.keysfitness.com within 10 days
of purchase.
Before You Start

4
Important Safety Information
Prior to assembly, remove components from the box and verify that all the listed parts were
supplied.
WARNING!
Before using this unit or starting any exercise program, consult your
physician. This is especially important for persons over the age of
35 and/or persons with pre-existing health problems. Keys Fitness
Products LP assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.
It is the owner’s responsibility to ensure that all users of this unit have
read the Owner’s Manual and are familiar with safety information and
precautions.
SAFETY PRECAUTIONS
• This unit should only be used on a level surface and is intended for
indoor use only. Keys Fitness recommends an equipment mat be
placed under the unit to protect the floor or carpet and for easier
cleaning.
• Wear comfortable, good-quality walking or running shoes and appro-
priate clothing. Do not use this unit with bare feet, sandals, socks or
stockings!
• Always examine your unit before using to ensure all parts are in
working order.
• Do not leave children unsupervised near or on the unit.
• Service to your unit should only be performed by an authorized
service representative, unless authorized and/or instructed by a
Keys Fitness technician. Failure to follow these instructions will void
the warranty.
NOTE:Hand tighten bolts and nylon nuts until machine is fully assembled.
Read all precautions and instructions in this manual before using this equipment.

5
Assembly

6
Assembly

Step 1
Connect Left and Right Support Frames (17,18) to main Base Frame (19) using:
2 x (57) Bolt 4 x (49) Washer 2 x (61) Nylon Lock Nut
Attach Rear Base Frame (25) and Upright Frame (1) to Main Base Frame (19) using:
2 x (57) Bolt 4 x (49) Washer 2 x (61) Nylon Lock Nut
Attach Left and Right Slide Frames (3,4) to Left and Right Support Frames (17,18) using:
4 x (56) Bolt 8 x (49) Washer 4 x (61) Nylon Lock Nut
Secure Top Cross Frame (2) to Left and Right Slide Frames (3,4) and Upright Frame (1) using:
2 x (59) Bolt 2 x (49) Washer 4 x (61) Nylon Lock Nut
2 x (65) Bolt 4 x (67) Washer
4 x (53) Bolt 4 x (48) Washer
67
67
67
3
17
56
57
49
57
49
49
67
61
49
61
61
56
49
67
4
18
19
25 149 57
49
48
49
49
61
61
2
59
59 67
67
49
65
49
61
61
65
61
67
53
53 48
49
61
61
49
7
Assembly
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.

8
Assembly
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
Step 2
Complete Big Foot Plate (22) assembly using:
1 x (20) Telescope Frame for Adj. Foot Plate 1 x (21) Adj. Support
1 x (57) Bolt 2 x (49) Washer
1 x (61) Nylon Lock Nut
Attach Big Foot Plate (22) assembly to main unit using:
3 x (57) Bolt 6 x (49) Washer 3 x (61) Nylon Lock Nut
Attach Left and Right Safety Bar Catches (12,13) using:
2 x (16) Safety Bar Mount 1 x (15) Right Safety Bar Mount w/Pin
1 x (14) Left Safety Bar Mount w/Pin 8 x (55) Bolt
16 x (48) Washer 8 x (60) Nylon Lock Nut

CARRIAGE UNDERSIDE
9
Assembly
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
Step 3
Complete underside of Carriage (5) assembly using:
1 x (7) Weight Holder 1 x (6) Connecting Tube
4 x (56) Bolt 4 x (49) Washer 3 x (61) Nylon Lock Nut
2 x (55) Bolt 6 x (48) Washer 2 x (60) Nylon Lock Nut
4 x (67) Washer 2 x (66) Washer 1 x (8) Plate
8 x (73) Bolt 8 x (72) Washer
2 x (60) Nylon Nut 2 x (54) Screw
Attach Left and Right Handle Bars (10,11) to Carriage (5) using:
2 x (55) Bolt 4 x (48) Washer 2 x (53) Bolt
2 x (60) Nylon Lock Nut 2 x (66) Washer
Attach Linear Shaft (32) to Right and Left Frame (3,4) using:
2 x (70) Bolt 2 x (71) Washer
2 x (33) Spacer 2 x (68) Plug 38

22
3
4
8
63
63
26
38
62
48
62
62
11
28
50
48
53
10
5
48
40
51
38
48
48
62
37
Step 4
Attach Shoulder Pads (37) to Left and Right Handle Bars (10,11) using:
2 x (28) Shoulder Connector 8 x (53) Bolt
8 x (48) Washer 2 x (50) Screw
Attach remaining Pads (40,38,26) using:
1 x (51) Screw 4 x (48) Washer
2 x (63) Screw 4 x (62) Bolt
10
Assembly
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
