Kimball Office Fluent User manual

Highback Shelf
Tools Required
Package Contents
Installation
Note: It is recommended that two (2) persons be used to lift
and flip highback shelf units.
Without Workwall
1. Place the shelf on a clean, soft surface, underside
facing up. Align leg assembly centered front to back
and press flush up against edge of pan . Attach legs using
nine (9) #10 x 1" panhead screws provided. (Figure A).
2. The wire manager is attached with double-sided adhesive
tape. Peal off film backer from tape and apply wire manager
to inside of leg. To securely attach a highback shelf to a
worksurface, cut four pieces of double-sided adhesive tape
and place on bottom of all four legs. Remove the film
backer to expose the adhesive. (Figure B).
3. Flip assembled highback right side up and place on desk
unit. (Figure C).
Note: The worksurface MUST be clean, dry, and free of any
dirt or residue to assure adequate adhesion.
Caution: The tape is a very strong adhesive and bonds
instantly to any surface it is applied to.
Assembly Instructions
Fluent
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent.
If you have any questions concerning these instructions, please call Kimball Office Customer Service.
Part No. 2205357 Revisio B-10
Page 1 of 2
Figure A
Doudle Sided
Adhesive Tape
#10 x 1"
Panhead Screw
Scissors
Screw Gun
#2 Phillips Head Bit
Figure C
Press Leg Assemby
Flush against Pan
Shelf
Leg Assembly
Figure B Peel off
film backer
Wire
Manager
Felt
Pan Slight Offset

Assembly Instructions
Fluent
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent.
If you have any questions concerning these instructions, please call Kimball Office Customer Service.
Part No. 2205357 Revisio B-10
Page 2 of 2
Installation (continued).
With Workwall
4. Place the shelf on a clean, soft surface, underside facing up.
Flip the legs and workwall upside down, and slide the
workwall into legs. (Figure D).
Important: The top and bottom of workwall is determined
by a feature inside the tool rail. The surface in the tool rail
that has a V” goes to the top, the flat surface goes to bottom.
5. Align leg assembly centered front to back and flush up
against edge of pan. Attach legs using nine (9) #10 x 1"
panhead screws provided. (Figure E).
6. Apply felt along bottom edge of workwall. The wire
manager is attached with double-sided adhesive tape.
Peal off film backer from tape and apply wire manager to
inside of leg. To securely attach a highback shelf to a
worksurface, cut four pieces of double-sided adhesive tape
and place on bottom of all four legs. Remove the film
backer to expose the adhesive. (Figure F).
7. Flip assembled highback right side up and place on desk
unit. (Figure G).
Note: The worksurface MUST be clean, dry, and free of any
dirt or residue to assure adequate adhesion.
Caution: The tape is a very strong adhesive and bonds
instantly to any surface it is applied to.
Figure D
Figure E
“ ” is on
Top Side
Pri ted i U.S.A. © 2009 Kimball I ter atio al, I c. T 800.482.1818 F 812.482.8300
Bottom
Figure F
Top
Felt
Wire
Manager
Figure G
Peel off
film backer
