Kimball Office Transcend Master Packet Complete Series User manual

Proper product installation, in accordance with these instructions, is the responsibility of the installing agent.
If you have any questions concerning these instructions, please call Kimball Office Customer Service.
© 2008 Kimball International, Inc. T 800.482.1818 F 812.482.8300
Transcend®
Assembly Instructions
2041397 Revision B-10
Complete Series Master Packet

Assembly Instructions
Universal
Pri ted i U.S.A. © 2010 Kimball I ter atio al, I c. T 800.482.1818 F 812.482.8300
Page 1 of 1
Proper product installation, in accordance with these instructions, is the responsibilit of the installing agent.
If ou have an questions concerning these instructions, please call Kimball Office Customer Service.
Part No. 1741615 Revisio D-10
Tack oards and/or
Powered Tack oards
Tools Required
■Drill/Screw Gun ■Level
■#2 Phillips Head Bit ■Small Blade Screwdriver
Hardware Required
■#8 x ⁵⁄₈" Flathead
Installation
1. Tack oards can e attached to any high ack organizer to
provide a tacka le surface. Tack oards can also e wall
mounted. The tack panel is provided with routed
channels on the ack side to help manage cords. (Figure A).
2. Insert a screw into the hole of each loose Dual Lock™ pad,
4 or 6, as required. (Figure B).
3. Press pads with screw protruding against the pads which are
already mounted to the ack of the tack oard, locking the
pads together. Position tack oard on mounting surface,
making sure it is level. Apply pressure on oard over pads
to mark surface with screw points. (Figure C).
4. Carefully detach pads with small lade screwdriver and
fasten in locations previously marked in step 3. Position
tack oard against mounting surface, making sure it is level,
and engage until each pair of pads snap together.
5. Wall Mount Caution: Pads should be located on wall studs,
or secured to wall with anchors (not provided).
Figure A
Figure B
Figure C
Ca le
Routes
Dual Lock

Casegoods Assembly Instructions
Transcend™
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent.
If you have any questions concerning these instructions, please call Kimball Office Customer Service.
Part No. 1998776 Revision A-07
Page 1 of 2
Wall Mounted
Overhead Bracket
Tools Required
■Pencil ■Variable Speed Drill
■Tape Measure with Torque Option
■Level ■Drill Bits
(4 feet or greater) ■Screw Bits
■Metal Saw
Package Contents
■1 Hanger Rail
Installation
Note: Kimball International defines a structural wall as a
load-bearing wall constructed of materials such as: poured
concrete, concrete block, or studs.Wood studs must be a
nominal 2" x 4" size minimum. Metal studs must be “C” channel,
20-gauge thick minimum. Metal or wood studs must be on
centers no greater than 24" and have maximum height of 14'
restrained at floor and ceiling. Interior walls shall be designed
to resist not less than a force of 5 lbs. per square foot applied
perpendicular to wall. The deflection of such wall under a load
of 5 lbs. per square foot shall not exceed 1⁄240 of the span for
walls with brittle finishes, and 1⁄120 of the span for walls with
flexible finishes (per Uniform Building Code Section 2309b).
If you have any questions concerning your load-bearing
structures, please consult your architect or structural engineer.
1. Place overhead cabinet against structural wall in the desired
location. Mark the top edge of the overhead and set it aside.
Measure down 43⁄8" from the top edge mark and draw a level
line. (Figure A).
2. Locate the wall substructure along the line drawn in step 1.
For proper attachment of Hanger Rail to the wall, fasteners
must tie directly into the substructure of the wall (studs,
blocks, solid masonry).
3. Prepare wall for Hanger Rail attachment by pre-drilling for
and/or installing fasteners along the line drawn in Step 1
per the fastener manufacturer’s guidelines.
Figure A
Figure B
Mark center of each
stud/fastener location
Mark height of
top of overhead
43⁄8 "
Draw level line
for Hanger Rail
3. (continued)
Recommended spacing of fasteners is 16", but should not
exceed 24" on center. DO NOT extend the Hanger Rail
more than 6" beyond the last anchor attachment.
Note: It is the responsibility of the installer and/or the
contractor to select and install the proper fasteners in the
structural wall. Kimball International does not furnish
fasteners or assume liability for their use.
■36" wall cabinets must attach to three (3) studs
■54" wall cabinets must attach to three (3) studs
■66" wall cabinets must attach to four (4) studs
■72" wall cabinets must attach to four (4) studs
4. Place the Hanger Rail on the wall, centered in the
desired location of the overhead, transfer the fastener
locations from the wall to the Hanger Rail. (Figure B).
Hanger
Rail

Casegoods Assembly Instructions
Transcend
Printed in U.S.A. © 2007 Kimball International, Inc. T 800.482.1818 F 812.482.8300
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent.
If you have any questions concerning these instructions, please call Kimball Office Customer Service.
Part No. 1998776 Revision A-07
Page 2 of 2
Installation
5. Drill the appropriate diameter hole in the Hanger Rail per
the fastener manufacturer’s guidelines, 3⁄8" above the bottom
edge of the rail at the locations marked in Step 4. (Figure C).
Note: Hole sizes are dependent on the size of the fastener
selected.
Figure C
Figure D
Cut rail 2"
shorter than
overhead
Centerline of
stud/fastener
Bore through
this side
Level line
from
Step 1
Centerline
of stud
Figure E
Hanger Bracket
Hanger Rail
Overhead
Recommended Fastener Size Model No.
Steel Stud (for 1⁄2 " to 3⁄4" drywall):
Hilti Toggler anchor toggle bolt 1⁄4"-20 x 2" 374494
Grade 5 or
equivalent
with maximum
head height
of .134"
Wood Stud (for 1⁄4" to 1⁄2" drywall;
meets or exceeds ANSI/ASME
B18.6.4 and SAE J933):
Panhead sheet metal screw 10-2 PHPMS
Solid Masonry:
Crown Bolt lag shields 1⁄4" x 11⁄2"
Buildex Tapcon concrete 1⁄4" x 23⁄4"
anchor screw
Masonry Block:
Hilti Toggler anchor toggle bolt 1⁄4"-20 x 2" 374494
Grade 5 or
equivalent
with maximum
head height
of .134"
Crown Bolt lag shields 1⁄4" x 11⁄2"
Buildex Tapcon concrete 1⁄4" x 23⁄4"
anchor screw
6. Attach Hanger Rail to wall aligning bottom edge of rail
with level line drawn in Step 1. Ensure that each fastener is
securely attached to wall substructure. (Figure D).
7. Place overhead cabinet flush against the wall so that the
hanger brackets attached to the overhead are above the wall
Hanger Rail and is between the end panels of the overhead.
Carefully lower the overhead cabinet until the cabinet
hanger brackets engage the wall Hanger Rail. Make sure
the cabinet hanger brackets are firmly seated on the wall
Hanger Rail. (Figure E).
Fastener
(not supplied)
3⁄8"

Assembl Instructions
Transcend™
Proper product installation, in accordance with these instructions, is the responsibilit of the installing agent.
If ou have an questions concerning these instructions, please call Kimball Office Customer Service.
Part N . 1998778 Revisi n B-10
Page 1 of 2
108" Highback Organizer
Tools Required
■Phillips Screwdriver ■Tape Measure or Ruler
or Allen Wrench ■Scissors or tility Knife
Package Contents
■Double-sided Adhesive ■Connecting Bolts
Tape
Installation
Note: The 108" Highback Organizer is shipped as wo pieces:
a righ and a lef .
Note: I is recommended ha more han one person be used
o assemble and ins all his uni .
1. Lay both organizer halves on their backs. Cut a piece of
double-sided adhesive tape for each outer end panel. Peel
off one side of the protective backing and attach the tape to
the underside of each end panel. (Figure A).
2. Lift the first highback half into its desired location on the
worksurface. Lift the second highback half into position
against the first unit. Make sure units align and are flush on
all sides. (Figure B).
Caution: Make sure firs uni is held s eady while loca ing
second uni .
3. Align connecting holes in highbacks and attach highbacks
together using the six (6) provided connecting bolts. Insert
half of a connector bolt into one connecting hole, and insert
the other half into the opposite connecting hole. Tighten all
bolts securely, making sure both highback halves are flush
against each other with no gaps. (Figure C).
Figure A
Figure B
Attach double-sided tape
to each outer end panel
Align
Figure C
Attach units using
six connector bolts

Assembl Instructions
Transcend
Printed in U.S.A. © 2010 Kimball Internati nal, Inc. T 800.482.1818 F 812.482.8300
Proper product installation, in accordance with these instructions, is the responsibilit of the installing agent.
If ou have an questions concerning these instructions, please call Kimball Office Customer Service.
Part N . 1998778 Revisi n B-10
Page 2 of 2
Installation (continued)
4. Make sure assembled unit is in its final desired position.
Carefully tilt unit forward and remove remaining protective
backing from each piece of double-sided adhesive tape.
(Figure D).
5. Set unit upright and press down to ensure good bond with
adhesive. (Figure E).
Caution: Double-sided ape has a powerful adhesive which
permanen ly bonds o any surface.
Figure D
Figure E
Peel protective
backing from
double-sided
adhesive tape

Casegoods Assembly Instructions
Transcend™
Printed in U.S.A. © 2007 Kimball International, Inc. T 800.482.1818 F 812.482.8300
Page 1 of 1
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent.
If you have any questions concerning these instructions, please call Kimball Office Customer Service.
Part No. 1998779 Revision A-07
Decorative Top
Tools Required
■Drill ■Screw Gun
■Tape Measure ■³⁄₁₆" Drill Bit
■#2 Phillips Head Bit
Hardware Required
■#8 x 11⁄2 " Panhead
Installation
1. Decorative tops can be added to the top of a storage unit.
Longer tops can be used to span multiple storage units.
All decorative tops are equipped with spacer rails and foam
tape to create a 1⁄8" reveal line between the storage unit and
top. (Figure A).
2. Tops (18" to 72" wide) are shipped with two loose spacers.
Longer tops (78" to 108" wide) are shipped with four loose
spacers. These spacers can be positioned underneath the top
to help support the weight of the top. Peel off the double
stick tape and position as needed.
Note: Spacer needs to be attached to top panel, not end panels.
(Figure A).
3. To attach top to cabinets, measure inside of the cabinet 3"
from sides. Bore thru the inside of top panel using ³⁄₁₆" drill
bit. Attach top using 11⁄2 " panhead screws. (Figure A).
Figure A
3"
3"
3"
3"

Casegoods Assembly Instructions
Transcend™
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent.
If you have any questions concerning these instructions, please call Kimball Office Customer Service.
Part No. 1998780 Revision A-07
Page 1 of 1
Desk and Return or Bridge
Tools Required
■Screw Gun ■Tape Measure
■#2 Phillips Head Bit ■Pencil
■Level
Package Contents
■#10 x 1" Panhead Screw ■Flat Brackets
Installation
1. Install flat brackets to the desk approximately where shown.
Center the brackets with the edges of the desk worksurface.
Attach brackets using the #10 x 1" panhead screws provided.
(Figure A).
2. Move desk into desired position. Level desk. (Figure B).
3. Align the bridge/return worksurface to the desk. Position
the worksurface on the desk and credenza so their edges are
tight against each other and flush with no gaps. Fasten
credenza worksurface to the flat brackets using the #10 x 1"
panhead screws provided. (Figure C).
Figure A
Figure B
Printed in U.S.A. © 2007 Kimball International, Inc. T 800.482.1818 F 812.482.8300
Figure C

Casegoods Assembly Instructions
Transcend™
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent.
If you have any questions concerning these instructions, please call Kimball Office Customer Service.
Part No. 1998781 Revision A-07
Page 1 of 1
Hinge Adjustment
Tools Required
■Phillips Screwdriver
Installation
1. Side Adjustment:
Turn front screw clockwise to increase door overlay,
counterclockwise to decrease overlay. (Figure A).
2. Depth Adjustment:
Loosen back screw. Adjust door to desired position and
tighten screw. (Figure B).
3. Height Adjustment:
Loosen screws on the mounting plate. Adjust door to
desired position and tighten screws. (Figure C).
4. Door Removal and Installation:
Release lever under the hinge arm, pull to remove.
To re-install, place the hinge on the mounting plate and
push the rear of the hinge with finger pressure. The snap
sound confirms a secure attachment. (Figure D).
Figure B
Figure C
Figure D
Figure A
Printed in U.S.A. © 2007 Kimball International, Inc. T 800.482.1818 F 812.482.8300
Side Adjustment
Depth Adjustment
Removal
Height Adjustment

Assembly Instructions
Transcend™
Proper product installation, in accordance with these instructions, is the responsibilit of the installing agent.
If ou have an questions concerning these instructions, please call Kimball Office Customer Service.
Part N . 1998782 Revisi n B-09
Pa e 1 of 1
Lateral File Drawer Removal
and Anti-Tip Mechanism
Tools Required
■Phillips Screwdriver
Installation
1. Lateral files are equipped with an anti-tip mechanism. This
consists of a nylon or polyester cord strun in such a
manner that only one drawer can be fully opened at one
time. This applies to both 2 and 4 drawer lateral files.
2. To remove the drawers, unlock the unit and extend the
TOP DRAWER fully forward. Remove the two (2) screws
from the inside of the drawer in the back. This will release
the square eyelet block attached to the back of the drawer.
Make sure rope does not exit eyelet. The drawer is now
ready to be removed (Fi ures A & B).
3. Press the quick-disconnect tabs on each side of the drawer
and pull forward and upward to remove the drawer from
the slide assemblies. (Fi ure C).
4. To reinstall the drawer follow Steps 2 and 3 in reverse order.
Test the file drawers to insure the anti-tip mechanism is
functionin properly. Not more than one drawer should
open completely at one time.
WARNING: If the square eyelet block is not reinstalled
correctly, the anti-tip mechanism will not function as
designed and could result n injury if the unit would tip.
Figure A
Figure B
Figure C
Unscrew eyelet block
from back of drawer
(see Fi ure B)
Remove these
two (2) screws
Printed in U.S.A. © 2009 Kimball Internati nal, Inc. T 800.482.1818 F 812.482.8300
Rope
Second knot
to untie
Eyelet block
First knot
to untie

Assembly Instructions
Transcend™
Printed in U.S.A. © 2010 Kimball Internati nal, Inc. T 800.482.1818 F 812.482.8300
Page 1 of 1
Proper product installation, in accordance with these instructions, is the responsibilit of the installing agent.
If ou have an questions concerning these instructions, please call Kimball Office Customer Service.
Part N . 1998783 Revisi n B-10
Leveling
Tools Required
■⁷⁄₃₂" Nut Driver ■Level
Installation
Note: All floor units MUST be leveled as described below
for appearance and proper function of doors and drawers.
1. Desk, Credenza, Return, Lateral File, Drawer Storage:
Remove all drawers as required for access to leveling glide
ad ustment holes.
Note: To remove drawers, refer to the Pedestal Drawer
Removal Assembl Instruction sheet or the Lateral File Drawer
Removal Assembl Instruction sheet.
Turn the glides fully “in” (counterclockwise) prior to
leveling. Level the unit from front to back by first extending
the glides on the outside corners (turn clockwise), then level
the unit from side to side. Check ad ustments by placing the
level in the four positions shown. Ad ust inside glides if
applicable, to help support the desk/credenza. (Figure A).
2. Bookcase, Cabinet Storage:
The lower shelf has holes which access the leveling glides.
Turn the glides fully “in” (counterclockwise) prior to
leveling. Level the unit from front to back by extending the
glides (turn clockwise). Level the unit from side to side.
Check ad ustments by placing the level in the four positions
shown. (Figure B).
Figure A
Figure B
⁷⁄₃₂" Nut
Driver
Level; check
four positions
Leveling Glides
Level; check
four positions
Leveling glide
ad ustment hole
⁷⁄₃₂" nut driver

Assembly Instructions
Transcend™
Proper product installation, in accordance with these instructions, is the responsibilit of the installing agent.
If ou have an questions concerning these instructions, please call Kimball Office Customer Service.
Part N . 1998784 Revisi n B-10
Page 1 of 1
Pedestal Drawer Removal
Tools Required
■None
Installation
1. Extend the box or file drawer to its full extension and
remove shipping screw from drawer slide.
2. Locate the drawer slide release tab on each side of the
drawer box. Press the tabs in and pull drawer up and
out until slide drawer members disengage from cabinet
members. (Figures A and B).
3. To reinstall drawer, extend slide cabinet members to full
extension. Set drawer slide member on extended slide
ma ing sure bac end of drawer slide member is under
locator tab on extended slide. Push drawer down until release
tabs snap into place. Gently push drawer closed. Chec for
proper alignment by inspecting drawer front margins for
spacing and squareness. (Figure B).
Figure A
Printed in U.S.A. © 2010 Kimball Internati nal, Inc. T 800.482.1818 F 812.482.8300
Locator Tab
Figure B
Release tab
typical each
side
Release tab
typical each
side
Shipping Screw

Casegoods Assembly Instructions
Transcend™
Printed in U.S.A. © 2007 Kimball International, Inc. T 800.482.1818 F 812.482.8300
Page 1 of 1
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent.
If you have any questions concerning these instructions, please call Kimball Office Customer Service.
Part No. 1998785 Revision A-07
Highback Organizer
Tools Required
■Screw Gun ■⁷⁄₃₂" Drill Bit
■#2 Phillips Head Bit
Installation
1. The highback organizer sets on top of a worksurface.
It can be attached to the worksurface using the double
faced tape provided.
2. Attach double faced tape to the bottom of the highback
organizer end panels. Position highback unit flush to back
and side edges of the worksurface on unit without rim.
Note: Double faced tape will create a strong bond. Make sure
highback unit is positioned in desired location prior to final
attachment. (Figure A).
Figure A
flush
unit with rim inset 1⁄2";
unit without rim flush

Assembly Instructions
Transcend™
Proper product installation, in accordance with these instructions, is the responsibilit of the installing agent.
If ou have an questions concerning these instructions, please call Kimball Office Customer Service.
Part No. 1998786 Revisio B-10
Page 1 of 1
Pri ted i U.S.A. © 2010 Kimball I ter atio al, I c. T 800.482.1818 F 812.482.8300
Set-on-Surface Bookcase
Tools Required
■Pencil or Erasable Marker ■Scissors or Utility Knife
Package Contents
■Double-sided Adhesive Tape
Installation
Note: I is recommended ha wo (2) persons be used o lif
and place he se -on surface bookcase.
1. To securely attach a set-on-surface bookcase to a
worksurface, carefully turn the bookcase upside down on
a s ooth, hard surface. Cut two strips of double-sided
adhesive tape and place the along the botto panel as
shown. DO NOT re ove the fil backer to expose the
adhesive at this ti e. (Figure A).
2. Carefully turn the bookcase upright and place it on the
worksurface in its desired position. Mark this location.
Note: The worksurface MUST be clean, dry, and free of any
dir or residue o assure adequa e adhesion. Lif he bookcase
and remove he film backers from he double-sided adhesive
ape. Adhere he bookcase o he marked loca ion on he
worksurface. (Figure B).
Caution: The ape is a very s rong adhesive and bonds
ins an ly o any surface i is applied o.
Figure A
Figure B
Mark desired
location
Peel off
fil backer
Apply
double-sided
adhesive tape
(Botto )
(Top)

Casegoods Assembly Instructions
Transcend™
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent.
If you have any questions concerning these instructions, please call Kimball Office Customer Service.
Part No. 1998787 Revision A-07
Page 1 of 1
Support Panel
Tools Required
■Screwgun ■Tape Measure
■#2 Phillips Head Bit ■Level
Package Contents
■#8 x 3⁄4" Panhead Screws ■L Brackets
■#8 x 1" Panhead Screws
Installation
1. An undersurface support panel is used to provide added
support in the center of long worksurfaces where
conventional support methods are not possible. These are
required when kneespace area is 48" or more. (Figure A).
2. The undersurface support panel comes with (5) L brackets.
The brackets can be attached to either side of the panel
using the #8 x 3⁄4" panhead screws provided. It is then
attached to the underside of the worksurface using #8 x 1"
panhead screws. (Figure B).
3. L brackets along back edge are only needed if support is
used with modesty panel.
Figure A
Figure B
Printed in U.S.A. © 2007 Kimball International, Inc. T 800.482.1818 F 812.482.8300
#8 x 3⁄4"
L Bracket
Back edge

Casegoods Assembly Instructions
Transcend™
Printed in U.S.A. © 2007 Kimball International, Inc. T 800.482.1818 F 812.482.8300
Page 1 of 1
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent.
If you have any questions concerning these instructions, please call Kimball Office Customer Service.
Part No. 1998788 Revision A-07
Tables
Tools Required
■Level ■1⁄2" Socket
■Socket Wrench
Installation
1. Table legs are shipped with two hangar bolts already
installed in the table leg. Align the two hangar bolts through
the table corner bracket and attach with 1⁄2 " nuts and
washers provided. (Figure A).
Figure A
Apron Rail
Table Top
Apron Rail
Table Leg

Casegoods Assembly Instructions
Transcend™
Printed in U.S.A. © 2007 Kimball International, Inc. T 800.482.1818 F 812.482.8300
Page 1 of 1
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent.
If you have any questions concerning these instructions, please call Kimball Office Customer Service.
Part No. 1998789 Revision A-07
Traxx®Mounted Overhead
Tools Required
■None
Installation
1. Overhead cabinets can be hung from Traxx using the
Traxx attachment bracket. (Figure A).
2. Insert the hook on top of the bracket into the Traxx at
a 15˚ angle. (Figure B).
3. Pull downward on bracket allowing bracket to hang off the
Traxx. Install the remaining brackets required to hang the
overhead. 30", 36", 42" and 48" cabinets require two
brackets. 60", 66", and 72" cabinets require 4 brackets.
(Figure C).
4. Install the overhead by tilting the bottom of the cabinet
approximately 15˚ away from the wall and engaging the
cabinet bracket onto the Traxx attachment bracket located
on the Traxx. (Figure D).
5. Let the cabinet rest against the spacer block or tiles.
Repeat procedure for any additional overhead cabinets.
6. To level the cabinets, loosen the screws on the cabinet
bracket and adjust accordingly. Tighten all screws after
leveling.
Figure A
Figure B
Figure C
Figure D
Traxx Attachment
Bracket
Cabinet
Bracket
Traxx
15°

Casegoods Assembly Instructions
Transcend™
Printed in U.S.A. © 2007 Kimball International, Inc. T 800.482.1818 F 812.482.8300
Page 1 of 1
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent.
If you have any questions concerning these instructions, please call Kimball Office Customer Service.
Part No. 1998791 Revision A-07
Suspended Overhead Storage
Tools Required
■Drill ■⁷⁄₃₂" Drill Bit
■#2 Phillips Screwdriver
Installation
1. A suspended overhead storage unit mounts between two
set-on storage units or between a set-on storage unit and
a vertical storage unit.
2. With main units set in place and level in all directions,
place the overhead storage unit between the adjoining
storage cabinets. Align the overhead unit with adjoining
units and fasten together using the ganging bolts provided,
4 bolts per side. (Figure A).
3. A suspended unit should not be connected to another
suspended unit! (Figure B).
Figure A
Figure B
Suspended
Overhead
Storage
Set-on
Storage
