kincrome K7799 User manual

1
TOOLS & ASSISTANCE NEEDED
2 People Lift 10mm Spanner
8 x Liners
Non-Locking
Swivel Castors (2)
Locking Swivel
Castors (2)
Trolley Handle x 1
Keys x 2 16 x 12mm Bolts
for Castors
4 x 10mm Bolts
for Handle
TOOL TROLLEY
7 DRAWER WIDE BODY
12mm Spanner
or 5mm Hex Key
or
Castor Handle
Operation Manual
Parts List
K7799
40kg+
This product requires a two person lift
- use proper lifting techniques
Bunnings Weight Icons (2676) 30/3/04 10:11 AM Page 3

Handle Installing
• Position the trolley side handle behind the
holes on the trolley.
• Attach with (4) bolts and washers and
tighten with an adjustable wrench.
Note: The side handle can be mounted
to either side of the trolley.
Castor Installing (If applicable)
• Be sure the drawers are locked and lay
the trolley on its side.
• Secure castors to the unit using the
12mm bolts provided.
• Tighten with a 12mm spanner or
5mm hex key.
• Repeat this process for the castors on
the opposite of the trolley.
• Return the trolley to its upright position.
Caution: Do not over tighten the bolts.
Caution: Both locking castors must be tted
to front of trolley.
Removing the Drawers
• Fully extend the empty drawer.
• Push up the right grey release lever while
pushing down the left grey release lever.
• Pull the drawer outward until it is released
from the drawer slide.
Re-Inserting The Drawers
• Extend the drawer slides.
• Insert the brackets on each side of the
drawer into the slots on the slides, being
careful that they are properly positioned.
• Once properly inserted, completely close
the drawer to set the slides in their proper
positions.
MAINTENANCE
• Periodically tighten all hardware
• Periodically lubricate castors
• Lubricate the slides twice a year
• Lubricate the lock with graphite annually
• Use a damp Microbre cloth to clean all surfaces
Assembly Instructions
2
Push up the
right grey release lever
Pull down the
left grey release lever
1
1
2
2
3
3
4
4
TOOL TROLLEY
7 DRAWER WIDE BODY
K7799

ITEM PART NO. DESCRIPTION QUANTITY
1K7888 Key Only (Specify Key
Number) X 1 1
2K7787-1 Lock & Key 1
3K7787-3 Trolley Handle 1
4K7787-4 Ball Bearing Slides (Pair) 7
5K7799 -1 Drawer Grip (Large) 7
6K7799-2 EVA Mat Pack 7 Piece 1
ITEM PART NO. DESCRIPTION QUANTITY
7K7799-3 Large Drawer (Shallow) 5
8K7799-4 Large Drawer (Deep) 2
9K7787-12 Castor Swivel X 1 2
10 K7787-10
Castor Swivel X 1 (Brake)
2
11 K7787-11 Castor Bolt Pack 1
7
8
6
9
5
4
11
10
3
1 & 2
Replacement Parts
3
