STE-9000 Series NetSensors
Installation Guide
REMOVE BACKPLATE
1. Turn the hex screw 1clockwise into the
sensor until the screw clears the cover.
1
NOTE: The hex screw 2should remain in the
backplate.
2
2. Pull the cover off the backplate.
CONNECT ETHERNET CABLE
3. Feed the Ethernet patch cable 3from the
Conquest controller through the center of the
backplate 4.
NOTE: The Ethernet patch cable should be a
maximum of 150 feet (45 meters).
3
4
INTRODUCTION
Complete the following steps to mount a KMC
Conquest STE-9000 Series Digital NetSensor
and connect it to a Conquest BAC-59xx/9xxx
Controller.
STE-90xx/93xx STE-9xxxW-NDL
(no display)
KMCConquestTM
Automation Hardware
NOTE: See the Conquest NetSensors STE-
9000 Series Digital Room Sensors
data sheet and the Conquest Selection
Guide at kmccontrols.com for
specifications and other information.
NOTICE
OBSERVE PRECAUTIONS
FOR HANDLING
ELECTROSTATIC
SENSITIVE DEVICES
SELECT MOUNTING LOCATION
See the Room Sensor and Thermostat Mounting
Location and Maintenance Application Guide for
cautions, troubleshooting, and best practices.
NOTE: Complete rough-in-wiring at each
location before installing a sensor.
STE-92xx/95xx
with Motion Sensor

7. Turn the hex screw 9counterclockwise until
it engages the cover.
9
OPERATE
The STE-9000 Series NetSensor becomes
operational after it is connected to a powered
Conquest controller.
NOTE: To change setpoints or configuration,
see the KMC Conquest Controller
Application Guide.
NOTE: For continued maximum NetSensor
efficiency, see the maintenance section
in the Room Sensor and Thermostat
Mounting Location and Maintenance
Application Guide.
4. Mount the backplate on an electrical box using
the provided screws.
NOTE: If additional thermal insulation is
needed, install the optional HPO-9002
gasket between the backplate and the
electrical box. For more information,
see the Room Sensor and Thermostat
Mounting Location and Maintenance
Application Guide.
5. Plug the Ethernet cable 5into the modular
jack 6of the sensor.
6
5
INSTALL SENSOR COVER
6. Place the cover 7over the top of the
backplate 8and swing it down.
NOTE: Be careful not to pinch the Ethernet
cable.
8
7
© 2021 KMC Controls, Inc. Specifications and design subject to change without notice 923-019-01F
