STE-1421/1422 1 Installation Guide
Installation Guide
Sensor, Immersion
STE–1421/1422
Mounting and Wiring
Immersion type probes are designed to measure
the temperature inside pipes carrying liquid or
steam. They are installed in a brass (for noncorrosive
liquids) or 304 stainless-steel (for corrosive liquids)
thermowell.
Mount the thermowell horizontally or with the open
end facing down, to allow any condensation to drain.
Position the thermowell to prevent contact with the
inside of the pipe.
1. Installthepipeingsrequired,bylocalcode,
for a thermowell into the dry/drained pipe. If the
system is pressured, use a hot tap.
2. Install the thermowell. (See the Accessories
section.)
3. Fill the well with thermal compound to ensure
complete conductivity from well to probe.
Note: The probe can slide within its collar on the case
as it is inserted into the thermowell.
4. Remove the screws holding the cover to the case
and remove the cover.
5. Insert the probe into the well and tighten the
threaded connection on the case.
6. From inside the case, push the probe as far as it
will go into the well.
7. Feed the thermistor wire leads through the
conduit or hole opening.
Note: The two-wire sensor is polarity insensitive.
8. Connect the thermistor wires to the cable with
bu-splicesorsoldering(wirenutsarenot
recommended).
9. Reinstall the cover and screws.
Accessories
The following thermowells are available for the
STE–1421 and STE–1422:
HMO–4533 4" brass well
HMO–4534 4" 304 stainless-steel well
HMO–4543 6" brass well
HMO–4544 6" 304 stainless-steel well
Note: NPT Thread Size = 1/2"
Thermowells Installed

STE-1421/1422 2 Installation Guide© 2005 KMC Controls, Inc. 717-019-17B
KMC Controls, Inc.
19476 Industrial Drive
New Paris, IN 46553
574.831.5250
www.kmccontrols.com
[email protected]
Maintenance
No routine maintenance is required. Each compo-
nent is designed for dependable, long-term reliability
and performance. Careful installation will also
ensure long-term reliability and performance.
Specifications
Standard Lengths 4" (STE–1421), 6" (STE–1422)
Sensor Type III, 10K ohm @ 77° F (25° C)
Accuracy ± 0.36° F (± 0.20° C)
Temperature Limits –4° to 221° F (–20° to 105° C)
Wiring 22 AWG wire leads
Case Black plastic standard;
metal optional
BACstage
1. IntheBACstagesowaremainmenu,select
Objects > Inputs.
2. Click Edit.
3. Type in a name in the Descriptioneld(upto32
characters) and/or Labeleld(upto16characters).
Note: No two labels or descriptions in a controller can
be identical.
4. Select Object Type: Analog if it is not the default.
5. Select Device Type: KMC10K Type III.
6. Select Units: °F or °C.
7. Click End Edit.
8. Click Yesfor“SendUpdateNoticationNow?”
9. IntheBACstagesowaremainmenu,select
Device > Device Tables > KMC10K Type III Table.
10. Click Edit.
11. Click Defaults(valueswillllin).
12. Click End Edit.
13. Click Yesfor“SendUpdateNoticationNow?”
14. Click OK.
WinControl
1. IntheWinControlsowaremainmenu,select
Control > Inputs.
2. Click Edit.
3. Type in a name in the Descriptioneld(upto20
characters) and/or Labeleld(upto8characters).
Note: No two labels or descriptions in a controller can
be identical.
4. Click Units(whichopenstheCongureInputs
screen).
5. Select Type: Analog if it is not the default.
6. Select Deg F (or C) KMC10K Type III.
7. Optionally, adjust the Calibration value.
8. Optionally, change Format from 0 to the desired
number of temperature decimal places.
9. Optionally, change the Average to the desired
number of thermistor readings averaged before
displaying the result.
10. Click OK.
11. Click End Edit.
12. Click OK.
Controller Configuration
Note: Controller conguration instructions are given for both WinControl and BACstage. See the relevant soware
section.
