Kogan KASNSRWFTHA User manual

KOGAN SMARTERHOME™ SMART
TEMPERATURE & HUMIDITY SENSOR
(WI-FI)
KASNSRWFTHA

Read all instructions and safety notes before first use. Retain this guide for future
reference.
• Do not use in an environment with humidity over 90%.
• Do not use in an environment with temperature lower than -10°C.
• To conserve battery this product has been set with a 30 second upload delay.
Power
SAFETY & WARNINGS
OVERVIEW
Temperature
Humidity
WI-FI Signal

Install App
Download the “Kogan SmarterHome” app from the Play Store (Android) or App Store (iOS).
Register
If you do not have a Kogan SmarterHome™ account, register or sign in with a verification
code sent by SMS.
To R e g i s t e r
1. Ta p t o e n t e r r e g i s t r a t i o n p a g e .
2. The system automatically recognises your country/area. You can also select your
country code manually. Enter your email address and tap ‘Next.’
3. Alternatively, you can select ‘Register by mobile number' and enter the verification
code sent to you by SMS.
4. Create a profile on the next page to define your location and room.
CONNECT TO SMARTERHOME™ APP

Set device in pairing mode
Open the battery compartment and install two (2) AAA batteries and close. Alternatively,
this product can be powered using a USB cable.
When the device is first turned on, it may automatically enter pairing mode (device will
beep).
If not automatically in pairing mode, you can manually set the device in pairing mode by
using a pin to press the reset button for 5 seconds until the Wi-Fi icon begins flashing or
the device ‘Beeps’.
Reset

Add device through network
5. Once registered, tap “+” in the upper right corner of the app’s home page to add a
new device through the network.
6. Select the product type from the list of options in the app (Sensor > Thermostat).
7. Ensure that the device is in pairing mode, with the Wi-Fi icon flashing rapidly and
tap “Confirm indicator rapidly blink”.

8. Upon successfully confirming pairing mode, enter your Wi-Fi details. It is important
that your SmarterHome™ device and the app are connected to the same Wi-Fi
network during setup.
9. The device will commence the pairing process and connect to the app. Ensure your
Wi-Fi router, mobile phone, and the SmarterHome™ device are kept close until
connection is complete.
10. After successfully being added, you will have the option to rename the device and
assign it to a location. It will now be listed on the app’s home page. Tap the device
listing to enter its control page.
Notes:
• The device and the app have to use the same Wi-Fi network.
• The device is only compatible with 2.4Ghz networks.

Add device through Bluetooth
5. Ensure that the device is in pairing mode (Wi-Fi icon flashing or the device ‘Beeps’).
6. Connect your smart phone to your 2.4GHz Wi-Fi network.
7. Ensure that Bluetooth is enabled on your smart phone.
8. Open the “Kogan SmarterHome” app.
9. Tap “+” in the upper right corner of the app’s home page to add a new device
through the network.
10. The app will automatically detect the device, tap “Go to add”.
11. If the device doesn't appear automatically, please select it in the device list and
follow the prompt to detect/connect your device.
12. The device will commence the pairing process and connect to the gateway and
app. Ensure your Wi-Fi router, mobile phone, and the SmarterHome™ device are
kept close until connection is complete.
13. After successfully being added, you will have the option to rename the device and
assign it to a location. It will now be listed on the app’s home page. Tap the device
listing to enter its control page.

If the above two methods aren’t successful, use ‘AP Mode’ to add device
5. Remove and re-insert the batteries then use a pin to press the reset button for 5
seconds until the Wi-Fi icon begins flashing rapidly. Press the reset button for
another 5 seconds until the Wi-Fi icon begins flashing slowly.
6. Once registered, tap “+” in the upper right corner of the app’s home page to add a
new device through the network.
7. Select the product type from the list of options in the app (Sensor > Thermostat),
and then select “Other Mode” from the top-right corner when asked to reset the
device.

8. Select “AP Mode” for the set-up type.
9. Ensure that the device is in pairing mode, with the Wi-Fi icon flashing slowly and
tap “Confirm indicator slowly blink”.
10. Enter your Wi-Fi details. It is important that your SmarterHome™ device and the
app are connected to the same Wi-Fi network during setup.

11. Follow the in-app prompts to continue AP Mode connection, which will pair your
mobile phone to the device’s Wi-Fi hotspot to ensure a connection.
12. The device will commence the pairing process and connect to the app. Ensure your
Wi-Fi router, mobile phone, and the SmarterHome™ device are kept close until
connection is complete.
13. After successfully being added, you will have the option to rename the device and
assign it to a location. It will now be listed on the app’s home page. Tap the device
listing to enter its control page.
Notes:
• The device and the app have to use the same Wi-Fi network.
• The device is only compatible with 2.4Ghz networks.
Note:
If the Wi-Fi hotspot does not appear on your phone in the list of available
networks, your device may not be set in AP Pairing Mode correctly. Try repeating
the steps outlined above to ensure your device is ready for connection.

Setting up automation
1. Tap the Temperature and Humidity sensor icon in the app’s device list.
2. Tap “Smart”’ then click “+” at ‘Condition (Any Condition is Met)’
OPERATION

3. When prompted tap “When device status changes”.
4. Select the desired function and set the condition. For example, set 'Temperature
alarm' > choose 'High Temperature alarm'.
5. Tap “+” in the ‘Task’ section or “Add Task” then select “Run the device”.
6. Choose your desired smart device from the list.

7. Select the desired function of the device tap “Save” and then “Next”.
8. Follow the prompts on the app and rename the automation by tapping ‘Name’.
9. Tap “Style” and select a colour for the automation then tape “Save”.
10. When prompted ‘Automation created. Start using it?’, tap “Yes” to finish.

Turning automation on and off
1. Tap the Temperature and Humidity sensor icon in the app’s device list.
2. Tap “Smart”, the switch on the lower right corner of the automation window is ON
by default. Use the button to toggle between the ON and OFF state.
Editing and delete the automation
Tap “Smart” on the sensor’s control page, at the upper right corner of the automation
window then tap “...” in circle to edit or delete the automation.

Wi-Fi reset
Press and hold the ‘RESET’ button for 5 seconds or until till the device emits a ‘Beep’.
Alarm switch
The alarm switch is used to turn the alarm tone ON or OFF.
Firmware upgrade
• When new firmware is available, the app will display ‘new device firmware found’, tap
“Upgrade now”, the device will turn on the ‘Automatically keep the device up to date’
option and begin updating.
• If the device goes to sleep, press the reset button to wake up the device. The update
should finish in approximately 30 seconds.
• If the update fails, press and hold the reset button until you hear a ‘Beep’. The device
will resume updating.
• Once the update is successful, the device will display the current temperature and
humidity.

USB input
DC 5V/2A
Dry battery input voltage
x2 AAA Batteries
Resting current
≤75uA
Alarm current
≤60mA
Low voltage and undervoltage
≤2.2V
Wi-Fi
802.11b/g/n
Temperature detection range
-10°C ~+55°C
Humidity detection range
0-99%RH
Alarm volume
55dB
Installation method
Wall-mounted
Operating temperature
-10°C ~+55°C
Operating humidity
Maximum 90%RH
SPECIFICATIONS

NOTES

Need more information?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com
