Kohler 2273W User manual

P3999005
Bateau, Crucible and Timpani
Vessels
Installation and User Guide
MODEL NUMBERS
2273W 2271D 2277D
Important :- Please quote the above model number(s) when ordering spares.
IMPORTANT!
Installer: This manual is the property of the customer and must
be retained with the product for maintenance and operational
purposes.

P3999
CONTENTS
DESCRIPTION ......................................................................... 3
SAFETY : WARNINGS ............................................................. 3
DIMENSIONS ........................................................................... 4
SPECIFICATION ...................................................................... 7
Plumbing Connections ..................................................... 7
INSTALLATION ......................................................................... 7
Before You Begin ............................................................. 7
Install the Vessel - All ....................................................... 8
Install the Vessel - Timpani .............................................. 9
Install the Vessel - Bateau ............................................... 11
Install the Vessel - Crucible .............................................. 12
Install the Plumbing ......................................................... 13
USER MAINTENANCE ............................................................ 13
Cleaning ........................................................................... 13
SPARE PARTS ......................................................................... 15
CUSTOMER SERVICE ............................................................ 16
Guarantee of Quality ........................................................ 16
Commercial / Business Use ............................................. 16
Not Covered by this Guarantee ........................................ 16
To Contact Us .................................................................. 16
2

P3999
DESCRIPTION
The Bateau and crucible Vessels are vitreous china washbasins and the
Timpani Vessel is a stainless steel washbasin.
SAFETY : WARNINGS
Kohler products are precision-engineered and should give continued
superior and safe performance, provided:
1. They are installed, commissioned, operated and maintained in
accordance with the recommendations given in this Manual.
2. Periodic attention is given, as necessary, to maintain the product in
good functional order. Recommended guidelines are given in the
MAINTENANCE section.
Carefully inspect the new fixture for any signs of damage.
When installing Kohler Products, manufacturers guidelines for power tool
safety should be followed.
3

P3999
DIMENSIONS
P3999010
464mm
152mm
138mm
365mm
171mm
203mm
BATEAU
4

P3999
P3999020
420mm
210mm
178mm
159mm
321mm
267mm
298mm
CRUCIBLE
5

P3999
TIMPANI
127mm
6

P3999
SPECIFICATION
Plumbing Connections
Hot (H) and Cold (C) inlets must be connected to the correct inlet supplies.
INSTALLATION
Before You Begin
1. Turn off the water supply.
2. The plumbing installation must comply with Water Supply
Regulations/Bye-laws (Scotland), Building Regulations or any
particular regulations and practices, specified by the local water
company or water undertakers. The installation should be carried out
by a plumber or contractor who is registered with, or is a member
of an association such as:
Institute of Plumbing (IOP), throughout the UK.
National Association of Plumbing, Heating and Mechanical Services
Contractors (NAPH & MSC), England and Wales.
Scottish and Northern Ireland Plumbing Employers’ Federation
(SNIPEF), Scotland and Northern Ireland.
3. Before installation carefully inspect the new fixture for any signs of
damage.
7

P3999
Install the Vessel - All
P3999040
Outside Edge
of Vessel
Cut-out
Line
Backsplash
Note! The tap spout should be at least 205mm long for adequate
clearance into the vessel.
1. Use the installation template to mark the outline for cutting.
2. Position the template on the counter.
3. Use a pencil to trace the outline on the counter.
4. Using a suitable power tool, cut out the opening for the vessel.
5. Temporarily position the vessel into the counter cutout and check for
fit.
6. Remove the vessel from the counter cutout and carefully set aside.
7. Install the taps in accordance with the manufacturer’s instructions.
8

P3999
Install the Vessel - Timpani
P3999050
Silicone
Sealant
Bolt
Mounting
Ring
Wing
Nut
1. Apply silicone sealant around the counter cutout hole.
2. Carefully position the vessel into place over the counter cutout.
3. Position the vessel so the “Kohler” logo is clearly visible at the back.
4. Position the mounting ring holes over the vessel bolts.
5. Securely hand tighten the wing nuts to ensure the vessel is level, but
do not overtighten.
9

P3999
P3999060
Gasket
Drain
Flange
Tube
Tapered
Gasket
Flat
Washer
Nut
Apply
Sealant
6. Install the drain in accordance with the manufacturer’s instructions.
7. Clean the vessel and surround with a suitable non-abrasive cleaner.
10

P3999
Install the Vessel - Bateau
P3999070
Cut-out
Hole
Rim of
Vessel
10mm
76mm
76mm
Silicone
Sealant
76mm
1. Apply silicone sealant to the counter top in the areas shown.
2. Carefully position the vessel into the counter cutout and press down
gently.
3. Clean the vessel and surround with a suitable non-abrasive cleaner.
11

P3999
Install the Vessel - Crucible
P3999080
6mm
35mm
Cut-out
Hole
3mm Thick Bead
of Sealant
1. Apply a bead of silicone sealant approximately 6mm from the edge of
the cutout hole.
2. Apply another bead of silicone sealant approximately 35mm from the
first bead.
3. Position the vessel into the counter cutout and press down gently.
4. Clean the vessel and surround with a suitable non-abrasive cleaner.
12

P3999
Install the Plumbing
P3998170
1. Install the drain in accordance with the manufacturer’s instructions.
Caution! Make sure a watertight seal exists on all basin drain connections.
Caution! Provide access to the plumbing connections for future plumbing
maintenance.
2. Connect the hot and cold water supplies.
3. Open the hot and cold water valves, and check the supply connections
for leaks.
4. Run water into the vessel, and check the drain connections for leaks.
USER MAINTENANCE
Cleaning
Caution! Risk of product damage. Many cleaners contain abrasive and
chemical substances, and should not be used for cleaning stainless steel,
enamel, plated or plastic fittings. These finishes should be cleaned using
13

P3999
a mild washing up detergent or soap solution, rinsed and then wiped dry
with a soft clean cloth.
14

P3999
SPARE PARTS
P3999090
2277D
2271D 2273W
TIMPANI
CRUCIBLE BATEAU
15

P3999
CUSTOMER SERVICE
Guarantee of Quality
Kohler UK guarantee products against any defect of materials or workmanship for the following periods
Ceramic ware and cast products Stainless steel products, Acrylic baths and shower
trays
Shower valves, shower
enclosures, taps, cistern fittings,
toilet seats, bath panels, bathroom
furniture and accessories
Bathroom Furniture Whirlpool / Spa baths
Our confidence in the quality and reliability of our superior products enables us to offer a comprehensive
guarantee for all products.
To register and fully benefit from this guarantee you must return the enclosed product registration card indicating the
Kohler items you have purchased.
Within the guarantee period we will undertake to resolve any material defects, by providing replacement parts, modules
or complete product, as we deem appropriate. To be free of charge, work must only be undertaken by Kohler UK
approved personnel.
To ensure that any problems can be promptly resolved you must contact Kohler UK directly.
Proofofpurchasemustbeprovidedwithanyclaims.
This guarantee covers products in domestic use, installed, operated and maintained in accordance with the instructions. It
covers the purchaser only and is not transferable.
Commercial / Business Use
Any Kohler Bathroom product used within a commercial / business premise is guaranteed for 1Yearagainst any defect of
materials or workmanship
Not Covered by this Guarantee
Damage or defects arising from incorrect installation, improper use or lack of maintenance.
Installed product damaged in transit Consequential loss, damage or product removal and installation costs.
General wear and tear.
This guarantee is in addition to your statutory and other legal rights.
Applies to the UK only.
To Contact Us
Tel: [phone]
Fax: [phone]
email: [e-mail]
Website: www.kohleruk.com
Kohler Mira Ltd
Cromwell Road,
Cheltenham GL52 5EP.
The company reserves the right
to alter product specifications
without notice.
© Kohler Mira Limited, July 2002
