Koplus KOLO DUO User manual

acoustic collection - kolo duo
[right hand open - outlet on right - without furniture - type A]
koplus b.v. | koplus.eu
[email protected]
version120919
Assembly
Instructions.
KOLO
DUO

Outlet on Right
Type A/B Plug
Right Hand
Open Door
No Furniture

Before we start, here are some things to be aware of:
This is the assembly instruction for right hand opening door
with no stool.
A packaged Duo unit weights 550 kg and will require 2-3
persons to install. It takes an average of 45 - 90 min to
install Duo.
Please assemble with caution and make sure that the
installation site is protected to prevent any injuries or risks of
damaging the product and surrounding.
Position and assemble Duo as close to its final placement
as possible. If needed, a fully assembled Duo can be lifted
and moved with a pallet jack. When moving the unit,
please make sure to follow the moving instruction “Kolo
Moving Instruction Guide”. DO NOT push the unit! You
may risk tipping Duo or damaging its leveling feet.
Make sure you have all the required tools listed (pg. 03).
We recommend leaving atleast 30 cm of space between the
wall or between multiple units of Duo.
Make sure that the Duo power source can safely load
10amp. When the ventilation is on, LED light is at its full
lumination, and the power charging station is not in use, the
wattage usage is 24W. The power cord fuse is set at 7amp
to prevent overloading.
Duo comes with 2 AC power outlest and 2 charging
outlets. DO NOT plug in any electronic devices that uses
over 5amp.
1.
2.
3.
4.
5.
6.
7.
8.

Required Tools
Drill 90 Degree Drill Adaptor
**Please confirm the adaptor specification
with a Koplus sale ahead of time**
Rubber Mallet
Ratchet Wrench - Metric Socket Phillips Screw Driver Allen Key Set
Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 03

Part List
Tool Kit: Screw Pack Tool Kit: Power Cord Bottom Corners
Bottom Finishing Panels
Nº1-1 Nº1-2 Nº2-1
Nº2-2
x1 x2x1
x2
Top Finishing Panels
Nº3-2
x2 Side Wall + ElectricTile
Nº4
x1 Side Wall
Nº5
x1
Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 04
1
2
Nº8-1
x1Bottom
Nº6-1
Top Corners
Nº3-1
x2
1
2
Bottom Center Tile
Nº6-2
x1 Top
Nº7
x1
Bottom Side Tiles
Nº2-3
x2

Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 05
Horizontal Frames
Nº8-1
x4
Vertical Frame Covers
Nº9-2
x4
Horizontal Frame Covers
Nº8-2
x4 Vertical Frames
Nº9-1
x4
Frame Corners
Nº10
x8 Narrow Glass Walls
Nº11
x4
Glass Wall
Nº12
x1 Glass Door
Nº13
x1

Tool Kit: Screw Pack List
M8 x 35 M8 x 50 M8 x 25
Spring Washer M4 x 25
A B C
D E
x8 x48x16
x11x48
Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 06

Step 1.
Nº6-1
Bottom
M8 x 35
Ax4
Bottom Corners
Nº2-1
Bottom Corners
Nº2-1
Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 07
2
1
2
1
Bottom Corners
Nº2-1
Installer Tip for Bottom Corners:
Remove the fixing screws before
installation. There should be two floor
corners in carton Nº2-1.

Step 2.
Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 08
Nº4
Side Wall + Electric
Nº5
Side Wall
M8 x 35
Ax4

M8 x 35
Ax4
Step 3.
Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 09
Installer Tip for Top Corners:
Remove the fixing screws before
installation. There should be two floor
corners in carton Nº3-1.
Top Corners
Nº3-1
2
1
Top Corners
Nº3-1
Top Corners
Nº3-1
Top
Nº7

Step 4.
Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 10
M8 x 35
Ax2
Installer Tip for Easier Lifting:
Carefully tip and lay the unit
sideways. Use inner carton
buffers or any platform to
slightly prop up the unit.
M8 x 50
Bx8

Step 5.
Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 11
Nº1-2
M8 x 35
Ax2
Installer Tip for Power Connection:
Plug in the unit and check if all electronic
devices turn on normally. If not, check if all
power cords are properlly connected
before proceeding.
Tool Kit: Power Cord

Step 6.
Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 12
M8 x 25
Cx7
Spring Washer
Dx7
Horizontal Frame
Nº8-1

Step 7.
Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 13
M8 x 25
Cx5
Spring Washer
Dx5
Frame Corner
Nº10
Vertical Frame
Nº9-1

Step 8.
Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 14
Narrow Glass Wall
Nº11 x2
Glass Wall
Nº12
Installer Tip for Narrow Glass Wall Orientation:
Make sure that the stickers are facing outwards
and the arrows are pointing towards the center
glass wall or glass door.

Step 9.
Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 15
Nº8-2
Horizontal Frame Cover
Vertical Frame
Nº9-1
Frame Corner
Nº10

Step 10.
Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 16
M8 x 25
Cx5
Dx5
Spring Washer

Step 11.
Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 17
Frame Corner
Nº10
Vertical Frame Cover
Nº9-1
Nº8-2
Horizontal Frame Cover
Nº8-1
Horizontal Frame

Step 12.
Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 18
M8 x 25
Cx5
Dx5
Spring Washer
