KStrong AFS510015 Operator's manual

EN 360:2002
USER INSTRUCTION MANUAL
RETRACTABLE FALL ARRESTERS
THESE INSTRUCTIONS APPLY TO THE FOLLOWING MODEL:
AFS510003.5, AFS510006, AFS510010, AFS510015, AFS510020, AFS510025 & AFS510030,
AFS550003.5, AFS550006, AFS550012
AFS510003.5SS, AFS510006SS, AFS510010SS,AFS510015SS, AFS510020SS,
AFS510025SS, AFS510030SS

The Brute Range of Retractable Fall Arrester is classed as a Personal Protective Equipment (PPE) by the European PPE
Regulation (EU) 2016/425 and has shown to comply with this Regulation through the Harmonized European Standard EN
360:2002.
This Retractable Fall Arrester is designed to minimise the risk of/provide protection against the danger of falling from heights.
However, always remember that no item of PPE can provide full protection and care must always be taken while carrying
out the risk related activity.
The equipment has been tested in accordance with EN 360:2002 and has achieved the following performance levels :
1. PERFORMANCE AND LIMITATIONS OF USE:
Result/Comment
Achieves required performance as stated in EN 360:2002 (PASS).
Lanyard free from sharp or excessively abrasive surface (PASS).
Lanyard end terminated with a loop, for connection to harness and fall arrest
system (PASS).
Lanyard meets static strength requirment (PASS).
12kN sustained for 3 minutes without failure (Wire) (PASS).
15kN sustained for 3 minutes without (Webbing) (PASS).failure
When tested with the test mass of 140 kg,
The Arrest force <6.00 kN, Arrest distance <2.00 m (PASS).
Corrosion test in accordance with ISO 9227:1990-24 hours (PASS).
No unnecessary features which add significantly to overall mass ( Pass).
EN 360:2002 test
Clause 4.1
Design & Ergonomics
Clause 4.2
Materials & Construction
Clause 4.4
Static Strength
(EN 364:1993)
Clause 4.5
Dynamic Performance
(EN 364:1993)
Clause 4.7
Corrosion Resistance
(EN 364:1993)
Please read and understand the manufacturer's instructions for each component or part of the complete system. Manufacturer's instructions
must be followed for proper use, care, and maintenance of this product. These instructions must be retained and be kept available for the user's
reference at all times. Alterations or misuse of this product, or failure to follow instructions, may result in serious injury or death.
Note: The user is advised to keep this user instructions document for the life of the product.
01
2. POSSIBLE USAGE: This Retractable Fall Arrester can be used as a part of a fall arrest system or as a part of a
restraint system. If using as a part of fall arrest system, a suitable anchor point (Above the user’s head, at least 12kN)
shall be used. Attachments to the anchor points and other equipment shall be made using oval karabiners to EN 362.
The equipment is to be used specifically in vertical condition.
3. MATERIAL OF THE RETRACTABLE FALL ARRESTER -
•for wire rope block - 4.5mm Galvanized Steel Wire & Hooks & 4.5mm Stainless Steel Wire & Hooks.
•for webbing block - 25mm polyester textile webbing .

4. INSTRUCTIONS FOR USES:
5. WARNING :
ŸEnsure the medical condition of the user does not affect his safety in normal and emergency use.
ŸThe Retractable Fall Arrester shall only be used by a person trained and competent in its safe use.
ŸA rescue plan shall be in place to deal with any emergencies that could arise during the work.
ŸDo not make any alterations or additions to the Retractable Fall Arrester without the manufacturer’s prior written
consent and that any repair shall only be carried out by personnel trained by the manufacturer & duly authorized by
him.
ŸThe Retractable Fall Arrester shall not be used out side its limitation, or for any purpose other than that for which it is
intended.
6. ADVICE & INFORMATION :
ŸThe Retractable Fall Arrester should be the personnel property of the user.
ŸEnsure that the Retractable Fall Arrester is compatible with other items when assembled into a system.
ŸUsage with other non compatible items may be dangerous & hazardous as the safe function of one item may be
affected or interferes with the safe function of another.
ŸThe user should carry out a pre-use check of the Retractable Fall Arrester, to ensure that it is in a serviceable condition
and operates correctly before it is used.
ŸThe pre-use check shall involve checking of any wear or abrasion on wire ropes/webbing and sign of corrosion if any on
metal parts or any breakage of the casing.
ŸWithdraw from use immediately if there is any doubt about its safe condition or if it has already arrested a fall, the
equipment shall not be used again until confirmed in writing by a competent person that it is acceptable to do so.
ŸEnsure that the strength of the anchor device is greater than 12kN.
ŸUse karabiners conforming to EN 362 for connecting to the anchor points.
ŸIt is advisable to use the dorsal attachment D-Ring of the harness for connection to the Retractable Fall Arrester.
ŸHowever if it is not possible for any reason, the chest attachment element may also be used.
ŸIt is essential to verify that a minimum 4ms height of free space is available below the user's feet & the ground level at
the work place, so that in case of a fall, there will be no collision with the ground or other obstacle in the fall path.
ŸUser is advised to keep the User Instructions document for the life of the product.
ŸFollowing conditions may be hazardous & may affect the performance of Retractable Fall Arrester:-
ŸExtreme temperature
ŸTrailing or looping of Lanyards over sharp edges.
ŸExtreme acidic or basic environments.
ŸAbrasive or sharp edge structures which can damage the equipment.
ŸPendulum falls.
STEP 1 : Connect the anchorage eye at the top of the Retractabel Fall Arrester to a suitable anchorage point situated
above the user’s head using karabiners as per EN 362 & ensure the karabiners are locked.
STEP 2 : Now connect the swivel hook of the equipment to the attachment element of your full body harness and ensure
that it is locked. You are now safe to move up & down in normal speed. In the event of a fall, the Retractable Fall
Arrester locks & also minimises the impact forces on the body of the user.
02

ŸEnsure that manufacturer’s packing is used during transportation to prevent damage. In case original packing is
not available, use polybag which is sealed to prevent moisture.
ŸIt is essential for the safety of the user that if the product is resold outside the original country of destination, the reseller
shall provide instruction for use, for maintenance, for periodic examination and for repair in the language of the country
in which product is to be used.
ŸThis is advised that annual inspection should be done by a competent person & if any discrepancy is found in product
service will be done at authorized service center only.
7. INSTRUCTION FOR MAINTENANCE :
ŸIn case of minor soiling, wipe the equipment with cotton cloth or soft brush. Do not use any abrasive material. For
0 0
intensive cleaning wash in water at a temperature between 25 C to 50 C using a neutral detergent. It should be allowed
to dry by itself and be kept away from open fire or any other source of heat, Avoid direct sunlight.
ŸStore in cool dry place, preferably away from moisture, direct sunlight, extra acidic or basic conditions & sharp edges.
03
MARKING:
140kg Max
o
50 C
o
-30 C
o
122 F
o
-22 F
o
40 max
Min 12kN
EN 795
(vii)
(i)
(iii)
(i )v
( )vi
(ii)
(viii)
MARKING EXPLANATION (iv) Wire Rope Length
The Retractable Fall Arrester is marked with: (v) UID for traceability
(i) The CE mark showing that the product meets the (vi) Month/Year of Manufacture
requirements of the (vii) Norm & Year
(ii) Identification of manufactures (viii) Atex marking
(iii) Type or product code
PPE Regulation (EU) 2016/425

04
Min 12kN
EN 795
140kg Max
o
50 C
o
-30 C
o
122 F
o
-22 F
o
40 max
ICON EXPLANATION
Keep away from sunlight or heavy rains.
Ensure that the anchorage point has strength of min 12kN.
0
Ensure that the max angle between the vertical & the lanyard is 40 .
Ensure that wire rope has no cuts or abrasion marks before use
Once the wire rope has been reeled out, do not leave it suddenly to retract inside on its own, let
it go inside gradually by guiding it slowly inside.
Can not be used for horizontal applications.
Connect the lanyard to the Dorsal attachment element of your harness.
0 0
Use between temperature range of -30 C to + 50 C.
To be used by person weighing upto than 140 kgs.
Do not attempt repair unless trained by the manufacturer.
Can not be use at foot level.
Read the instructions carefully before use

140kg Max
o
50 C
o
-30 C
o
122 F
o
-22 F
o
40 max
Min 12kN
EN 795
05
140kg Max
o
40 max
Min 12kN
EN 795
o
50 C
o
-30 C
o
122 F
o
-22 F
WEBBING LENGTH
140kg Max
o
40 max
Min 12kN
EN 795
o
50 C
o
-30 C
o
122 F
o
-22 F

06
o
40 max
140kg Max
o
50 C
o
-30 C
o
122 F
o
-22 F
Min 12kN
EN 795
o
40 max
140kg Max
o
50 C
o
-30 C
o
122 F
o
-22 F
Min 12kN
EN 795
o
40 max
140kg Max
o
50 C
o
-30 C
o
122 F
o
-22 F
Min 12kN
EN 795
o
40 max
140kg Max
o
50 C
o
-30 C
o
122 F
o
-22 F
Min 12kN
EN 795

AKS/ /140821/V3AFS510003
Certification Body :
Ongoing Assessment Body:
SGS Fimko Oy, Takomotie 8, FI-00380 Helsinki, Finland (Notified Body 0598)
SATRA Technology Europe Ltd, Bracetown Business Park, Clonee, Dublin D15 YN2P Ireland (Notified Body 2777)
LIFESPAN: The estimated product Lifespan is 10 years from the date of manufacture. The following factors can reduce the Lifespan of the product:
intense use, contact with chemical substances, specially aggressive environments, extreme temperature exposure, UV exposure, abrasions, cuts,
violent impacts, bad use or maintenance.
DISCLAIMER: Prior to use, the end user must read and understand the manufacturer's instructions supplied with this product at the time of
shipment and seek training from their employer's trained personnel on the proper usage of the product. Manufacturer is not liable or responsible for
any loss, damage or injury caused or incurred by any person on grounds of improper usage or installation of this product.
Periodic examination
next due date
Product
Model & type/Identification
Trade Name
Address
Identification number
Manufacturer
Tel, email into use
Year of manufacture
Purchase Date
Date first put into use
Other relevant information (eg. document number)
PERIODIC EXAMINATION AND REPAIR HISTORY
Date Name and signature
of competent person
Reason for entry
(periodic examination
or repair)
Defects noted, repairs
relevant information
carried out and other
EQUIPMENT RECORD
