L.L.Bean OTNR6 User manual

1 of 4 6/27/17
Pntd Frmhs Storage Console
Painted Farmhouse Storage Console - OTNR6 &
OTNR7
Thank you for purchasing our Pie Safe / Bookcase. Assembly of this product requires a phillips screwdriver. It is helpful to have a second
person availble during the assembly of this product.

2 of 4 6/27/17
Pntd Frmhs Storage Console
STEP 1
STEP 2
Identify and count hardware.
Lay out parts on a non-abrasive surface to avoid scratching finish.
Identify and count all parts using diagram above.
1
QTY.DRAWING DESCRIPTIONNO.
12
K
M6*30MM
BOLT
L
SHELF
SUPPORT
M
1
J8
8
M6*35MM
BOLT
I
E

3 of 4 6/27/17
Pntd Frmhs Storage Console
STEP 3
Lay top panel (A) upside down on non-abrasive
surface and attach left side panel (B) to top panel
(A) using 2 M6 * 35MM Bolts (I). Use Wrench (L)
to install Bolts.
Do not over tighten Bolts at this time.
Assemble Loose.
STEP 4
Attach Vertical Dividers (H) to Center Support
Rails on under side of top using 4 M6 * 30MM
Bolts (J). Use Wrench (L) to install Bolts.
Do not over tighten Bolts at this time.
Assemble Loose.
STEP 5
Position Back Panel (D) in to grooves on Left Side
Panel (B) and in Back Rail on Top (A).
Align groove in Right Side Panel (C) with Back
Panel. Attach Right Side Panel (C) to top panel (A)
using 2 M6 * 35MM Bolts (I). Use Wrench (L) to
install Bolts.
Do not over tighten Bolts at this
time. Assemble Loose.
I
I

4 of 4 6/27/17
Pntd Frmhs Storage Console
STEP 6
Position Bottom Panel (E) between the Left and
Right Ends. Align the Groove in the Bottom with
the Back Panel. Attach bottom panel to Vertical
Dividers (H) using 4 M6 * 30MM Bolts (J) and to
the Right and Left End Panels (B) and (C) with 4
M6 * 35MM Bolts (I). Use Wrench (L) to install
and tighten all bolts.
At this point tighten all assembly
bolts.
STEP 6
Position assembled case upright. Insert 12 Shelf
Supports (K) in to predrilliled holes in the Left,
Center and Right hand openings in Console. Place
Shelves (F) on the Shelf Supports in the Left and
Right sides of Console. Place Shelf (G) on the
Shelf Supports in center of Console. Make sure the
Shelves are seated down firmly on the Shelf
Supports.
CARE: Clean with mild soap and wipe dry.
www.llbean.com
Product Support 1 800 341 4341
