High-precision cross-line laser with 8 super-bright laser lines,
plumb laser and additional slope function.
The 4 horizontal laser diodes project a homogeneous 360° laser line, the 4 verti-
cal laser lines are aligned at right angles to one another. Special high-performance
laser diodes project extremely visible laser lines. Manual mode can be used to set
slopes by means of a motor. The laser cross at the top and the plumb laser allow
a plumb line to be drawn from the ceiling to the floor. Electronic positioning
motors controlled by temperature-stable sensors for automatic alignment,
2.5° self-levelling range. The pivoted housing can be turned with a vernier
adjustment mechanism and horizontal circle to permit exact positioning of laser
lines. Precision 1 mm/10 m. RX-Ready: The laser receiver, which is available as
an optional extra, can detect laser lines in a range of up to 50 m.
General safety instructions
Caution: Do not look directly into the beam. Lasers must be kept out of
reach of children. Never intentionally aim the
device at people. This is a quality laser measu-
ring device and is 100% factory adjusted within
the stated tolerance. For reasons of product
liability, we must also draw your attention to
the following: Regularly check the calibration before use, after transport and
after extended periods of storage. We also wish to point out that absolute
calibration is only possible in a specialist workshop. Calibration by yourself is
only approximate and the accuracy of the calibration will depend on the care
with which you proceed.
ENGLISH
Laser radiation!
Do not stare into the
beam or observe it directly
with optical instruments.
Class 2M laser
< 5 mW · 635-650 nm
EN 60825-1:2007-10

EvolutionCross-Laser 8P PowerBright
12
1
3
3
2
5
6
7
12
91011
1516
13
14
4
8
1 Laser emitting window
2 Battery compartment
3 Continuous horizontal
360° laser line
4 Knob for precision adjustment
5 5/8” thread (underside)
6 Window for plumb laser
(underside)
7 Adjustable feet with removable
rubber caps
8 Tripod adapter
9 Vertical laser line/
slope function: set the slope
10 LED Hand receiver mode
11 Hand receiver mode
12 Vertical laser line/
slope function: set the slope
13 Status indicator/
low battery charge LED
14 ON/OFF button
15 Automatic mode (auto)/slope
function (slope) LED indicator
16 Horizontal laser lines/ slope
function: activate/deactivate
(press and hold for 3 seconds);
axis switch-over
ENGLISH

EvolutionCross-Laser 8P PowerBright
13
Anti-shake function
The automatic sensor continuously levels the devices, even if they are in motion.
This makes device alignment easier, as it enables the laser to be set to a
required height by means of a crank tripod or a wall bracket, for example.
It also means that the laser can be used on vibrating surfaces and in windy
conditions. IMPORTANT: Precision is adversely affected during the set-up phase.
L
Note: If the unit is placed at an excessive angle (out of its 2,5° range),
the lasers will blink. If this should be the case, align the unit roughly with
the levelling feet (7) or place it on a more level surface.
Setting up
• Press the „ON/OFF“ switch (14).
• The automatic sensor aligns the device without any need for
operator intervention. To accomplish this, two electronic sensors
are used to detect the X and Y axes. The working angle ist ±
2,5°. During the set-up phase, the auto LED (15) flashes rapidly.
When levelling is complete, the auto LED lights up continuously.
• Switch the lasers on using the H slope, V1 or V2 buttons (press
briefly). Maximum visibility of the laser line is obtained when
hand receiver mode is switched off (button 11, indicator
light 10 off).
L
Attention: Only insert rechargeable batteries into the charger – risk of
explosion! Used batteries must not be disposed of with regular domestic
waste; instead, they can be deposited at a collection point for batteries or
hazardous waste.
Battery (NiMH) charging
• Charge the batteries (NiMH) fully before using the laser unit. Insert only
rechargeable (i.e. secondary) batteries into the charging unit. Be sure that the
batteries are marked with the label „RECHARGEABLE“.
• Insert the rechargeable batteries into the charger and connect the charger to the
mains power supply. Observe the charger operating instructions. As soon as the
rechargeable batteries are charged up, disconnect the charger from the mains
power supply.
• Insert the rechargeable batteries (NiMH) into the laser unit. Do this by opening the
battery compartment (2) and inserting the batteries according to the symbols. If
the status indicator (13) flashes, the rechargeable batteries need to be replaced.
ENGLISH

EvolutionCross-Laser 8P PowerBright
14
(16)
(16)
(16)
(9,12)
(9,12)
± 2,5°
± 2,5°
auto
slope
3 sec
3 sec
(16)
(16)
(16)
(9,12)
(9,12)
± 2,5°
± 2,5°
autoslope
3 sec
3 sec
Manual Slope function
This function deactivates the automatic sensor, which enables slopes to be
set. Press the H slope button and hold it down for 3 seconds until the auto
LED starts to flash very rapidly. The V1, V2 buttons are used to re-adjust the
slope by means of a motor. The H slope button (pressed briefly) is used to
switch over between axes. IMPORTANT: Since the automatic sensor is not
active, horizontal and/or
ENGLISH

EvolutionCross-Laser 8P PowerBright
15
(16)
slope
3 sec
auto LED status indicator
Automatic mode (auto) Slope function (slope)
auto auto auto auto
Continuous Rapid Every second Very rapid
OK Set-up phase X axis Y axis
TIP: Switch the required laser lines on before you activate the slope function.
Positioning laser lines
The top section of the laser unit can be turned on the plinth to align the
lasers approximately. The vernier adjustment mechanism (4) can be used to
position the lasers precisely. The freely rotatable horizontal circle (3) makes
it easy to turn the device to the required angle. Simply set the scale to zero,
then rotate the device to the angle you want.
Manual re-adjustment:
Steeper slopes can be set using the angle plate, which is available as an
optional extra (product ref. 080.75). To this end you need to use a crank
tripod, such as the 300 cm professional crank tripod, product ref. 080.34.
TIP: Allow the device to align itself automatically and set the angle plate to
the zero position. Next, deactivate the automatic sensor by pressing the H
slope button (and holding for 3 seconds). Finally, incline the device to the
angle you require.
ENGLISH

EvolutionCross-Laser 8P PowerBright
16 ENGLISH
Preparing the calibration check:
It is possible for you to check the calibration of the laser. To do this, position
the device midway between 2 walls, which must be at least 5 metres apart.
Switch the device on (Laser cross ON). The best calibration results are achie-
ved if the device is mounted on a tripod. 1. Mark point A1 on the wall.
2. Turn the device
through 180° and
mark point A2.
You now have a
horizontal reference
between points A1
and A2.
Checking the vertical line: Position the device about 5 m from a wall. Fix a
plumb bob with a line of 2.5 m length on the wall, making sure that the bob
can swing freely. Switch on the device and align the vertical laser to the plumb
line. The precision is within the specified tolerance if the deviation between the
laser line and the plumb line is not greater than ± 1.5 mm.
Checking the horizontal line:
Position the device about 5 m from a wall and
switch on the cross laser. Mark point B on the wall.
Turn the laser cross approx. 2.5 m to the right and
mark point C. Check whether the horizontal line
from point C is level with point B to within ± 2 mm. Repeat the process by
turning the laser to the left.
Performing the calibration check:
3. Position the device as near as possible to the wall at the height of
point A1.
4. Turn the device
through 180° and
mark point A3. The
difference between
points A2 and A3 is
the tolerance.
A1
A2
2.
1.
L
Note: If points A2 and A3 are more than 2 mm / 10 m, the device is in
need of calibration. Contact your authorised dealer or else the UMAREX-
LASERLINER Service Department.
BC
2,5 m
< 2 mm = OK
A3
A2 A2
A1
4.
3.
A3
A2
< 2 mm / 10 m = OK

EvolutionCross-Laser 8P PowerBright
17ENGLISH
B
AC
DE
G
F
I
H
Working with the laser receiver RX (optional):
For levelling over longer distances or in conditions of bright light, use the
laser receiver RX. Switch on with button D; control lamp A will light up.
IMPORTANT: Set the laser unit to hand receiver mode (button 11).
The laser lines now pulsate at a high frequency (5 kHz) and become darker.
The pulsation allows the laser receiver to detect the laser lines.
Now move the receiver field (F) of the laser receiver through the laser lines
upwards and downwards (horizontal laser line) and/or sideways (vertical laser
line) until the centre LED (G) lights up. Now mark the horizontal and/or
vertical reference dimension.
Adjust the sensitivity of the laser receiver with button B.
The sound can be switched on or off with button E.
A Power indicator
B Switch accuracy
short range / long range
C Sensitivity indicator light
RX 51:
Close range max. 15 m green –
Long range max. 50 m red
D ON / OFF switch
E Sound ON / OFF
F Receiver field for laser beam
G LED’s for Laserindication
(front, side, backside)
H Universal mount
I Battery compartment (backside)
RX 51
Note: The light intensity of the laser lines is greatest at their midpoints and
less toward their ends. Therefore at line ends the distance range for the
laser receiver is reduced somewhat. An even distribution of brightness can
be achieved by switching on all 4 horizontal laser lines. When this is done
the maximum range for laser reception is remains constant.

EvolutionCross-Laser 8P PowerBright
18 ENGLISH
L
Note: Regularly check the calibration before use, after transport and after
extended periods of storage
Technical data
Self-levelling range ± 2,5°
Precision + 1 mm / 10 m
Working range with laser receiver RX 51 max. 50 m
Laser wavelengths, line lasers / plumb laser 635 nm / 650 nm
Laser class/line laser output power 2M / < 5 mW
Laser class/plumb laser output power 2 / ÷1 mW
Power supply ECL 8P 3 x type AA
Battery/rechargeable battery life ca 5 Std. / ca. 8 h
Power supply laser receiver RX 51 1 x 9V Block
Weight ECL 8P (incl. battery) 1,3 kg
Dimensions (W x H x D) 195 x 130 x 130 mm
Operating temperature 0°C ... + 50°C
Storage temperature -10°C ... + 70°C
Article-No. (ECL)
EvolutionCross-Laser 8P PowerBright RX 048.200A
Subject to technical alterations 06/2009
Universal mount (optional):
The laser receiver RX can be fitted on measuring
staffs with the universal mount. The Flexi measuring
staff (Art. No. 080.50) is always recommended when
measuring from floor heights. It also allows you
to determine heights directly without any need for
calculation.

Art.-Nr: 080.30
max. ca. 330 cm
www.laserliner.com
Art.-Nr: 023.61A
Art.-Nr: 033.20-1
ECL 8P PowerBright: optional
ECL 8P PowerBright RX: inclusive
Zubehör (optional)
Accessories (optional)
Accessoires (optioneel)
Accessoires (en option)
GB
DE
NL
FR
max. 160 cm
min. 93 cm max. 154 cm
Art.-Nr: 090.120A
35

EvolutionCross-Laser 8P PowerBright
Umarex GmbH & Co KG
— Laserliner —
Donnerfeld 2
59757 Arnsberg, Germany
Tel.: [phone], Fax: -333
www.laserliner.com
Service- und Versand-Anschrift
Service- and Shipping Address
Service- en verzendadres
Livraison et expédition
DE
GB
NL
FR
Umarex GmbH & Co KG
— Laserliner —
Möhnestraße 149,
59755 Arnsberg, Germany
Tel.: [phone], Fax: -333
[email protected]
Laserstrahlung!
Nicht in den Strahl blicken
oder direkt mit optischen
Instrumenten betrachten.
Laser Klasse 2 M
EN60825-1:2007-10
Laser radiation!
Do not look into the
beam or observe it directly
with optical instruments.
Laser class 2 M
EN60825-1:2007-10
8.048.96.01.1 / Rev.0609
