lbx H03D User manual

H03D Digital magnetic stirrer with heating
S03 Magnetic stirrer without heating
S03D Digital magnetic stirrer without heating
Please read the User Manual carefully before use, and follow all operating and safety instructions!
user manual
english / español / français

2
User Manual
H03D Digital magnetic stirrer with heating
S03 Magnetic stirrer without heating
S03D Digital magnetic stirrer without heating
Preface
Users should read this Manual carefully, follow the instructions and procedures, and beware of all
the cautions when using this instrument.
Service
If help is needed, you can always contact your dealer or Labbox via www.labbox.com
Please, provide the customer service representative with the following information:
Serial number
Description of the problem
Your contact information
Warranty
This instrument is guaranteed to be free from defects in materials and workmanship under normal
use and service, for a period of 24 months from the date of invoice. The warranty is extended only
to the original purchaser. It shall not apply to any product or parts which have been damaged on
account of improper installation, improper connections, misuse, accident or abnormal conditions of
operation.
For claim under the warranty, please contact your supplier.

3
1. Safety Instructions
Warning!
•Read the operating instructions
carefully before use.
•Ensure that only trained staff works
with the instrument.
Risk of burn!
•Caution when touch the housing
parts and the hotplate, which can
reach temperatures of 280°C.
•Pay attention to the residual heat
after switching off the equipment.
Protective ground contact!
•Make sure that the socket is
earthed (with protective ground
contact) before use.
When working, wear personal protective equipment to avoid the risks from:
-Splashing and evaporation of liquids
-Release of toxic or combustible gases
Set up the instrument on a spacious, stable, clean, non-slip, dry, and fireproof surface. Do not
operate the instrument in explosive atmospheres, with hazardous substances, or under water.
Gradually increase the speed. Reduce the speed if:
-Stirring bar breaks due to high speed
-The instrument is not running smoothly or the container moves on the base plate
Temperature must always be set at least 50 ºC below the flash point of the media used.
Be aware of hazards due to:
-Flammable materials or media with a low boiling temperature
-Overfilling of media
-Unsafe container
If the stirring bar contains PTFE, please note:
-Elemental fluorine, trifluoride ion, and alkali metals will corrode PTFE. Halogen
hydrocarbons expand PTFE at room temperature.
-Molten alkali, alkaline earth metals or their solution, as well as elements on second and
third column of the Periodic Table of elements will react with PTFE when temperature
reaches 300 ~ 400 ºC.

4
Process pathogenic materials only in closed vessels.
Check the instrument and the accessories prior to each use. Do not use damaged components.
Safe operation is only guaranteed with the accessories described in the “Accessories” chapter.
Accessories must be securely attached to the device and cannot come off by themselves. Always
disconnect the plug before the assembly of any accessory.
If the external temperature sensor is needed, the tip of the measuring sensor must be at least
5-10 mm away from the vessel bottom and wall.
The instrument can only be disconnected from the main power supply by pulling out the mains
plug or the connector plug.
The voltage stated on the label must correspond to the main power supply.
Ensure that the cable does not touch the hotplate. Do not cover the device.
The instrument may only be opened by experts.
Keep away from high magnetic fields.
Observe the minimum distances between devices, between the device and the wall, and above
the assembly (min. 100 mm)
>100mm
Figure 1

5
2. Proper Use
The instrument is designed for mixing and/or heating liquids in schools, laboratories, or factories.
This device is not suitable for use in residential areas or other restrictions mentioned in Chapter 1.
Not tested for continuous work (24h/7days).
3. Inspection
3.1 Unpacking
Unpack the equipment carefully and check for any damages which may have arisen during
transportation. Please contact the manufacturer/supplier for technical support.
Note:
If there is any apparent damage to the system, please do not
plug it into the power line.
3.2 Listing of Items
The package includes the following items:
Items
Qty
Main unit
1
Power cable
1
Stirrer bar
1
User Manual
1
Table 1
4. Control
4.1 Control elements
Figure 2: H03D series
LED Display
Speed Control Knob
Temperature Control Knob
Probe

6
Figure 3: S03D series
Figure 4: S03 series
Figure 5: S03, S03D, H03D series
Speed Control Knob
Speed Control Knob
LED Display

7
Figure 6 : H03D series
Items
Descriptions
H03D
series
Temperature
Control
Knob “Heat”
Set the temperature parameters. The function “heating”
is switched ON or OFF by pushing the ON/OFF knob. To
increase the value turn the knob clockwise.
Speed Control
Knob “Stir”
Set the rotary speed. The function “Stirring” is switched
ON or OFF by pushing the ON/OFF knob. To increase
the value turn the knob clockwise.
LED Display
The LED screen displays the real working state and all
the settings.
Probe
When the external temperature sensor PT1000 is
plugged in, the sensor icon lights up.
Power Switch
Switch the instrument ON or OFF.
S03D
series
Temperature
Control Knob
“Stir”
Set the rotary speed. The function “Stirring” is switched
ON or OFF via push ON/OFF knob. To increase the
value turn the knob clockwise.
LED Display
LED displays the real working state and all settings.
Power Switch
Switch the instrument ON or OFF.
S03
series
Speed Control
Knob “Stir”
The stirring function is switched ON by rotating the
knob. To increase the value turn the knob clockwise.
The stirring function is switched OFF by rotating the
knob all the way clockwise.
Power Switch
Switch the instrument ON or OFF.
Table 2
Connection PT1000
Socket

8
4.2 Display
Temperature display area Speed display area
Figure 7: H03D series
Characters
Descriptions
Temperature
display area
When heating function is switched
ON, LED displays the temperature
setting value and shifts to real value
in 5 seconds.
When the heating function is
switched OFF and the hotplate
temperature is still above 50°C, LED
displays “Hot”, otherwise LED
displays “OFF”.
Speed display
area
When stirring function is switched
ON, LED displays the speed setting
value and flashes. The setting value
does not flash until real speed
reaches the set point.
Table 3
Speed display area
Figure 8: S03D series
Characters
Descriptions
Speed display
area
While stirring function is on, the LED
screen displays the speed setting
value and flashes. The set value does
not flash until the real speed reaches
the set point.
Table 4

9
5. Trial Run
•Make sure the required operating voltage and power supply voltage match.
•Ensure that the socket is properly grounded.
•Plug in the power cable, ensure the power is on, and begin initializing.
•Add the medium into the vessel with an appropriate stirring bar.
•Place vessel on the work plate.
•Set the target stirring speed and begin.
•Observe the stirring bar and LED display (S03D series and H03D series).
•Set the target temperature and start heating.
•Observe the LED display (H03D series).
•Stop the heating and stirring functions.
If the operations above cause no abnormalities, the device is ready to operate. Otherwise, the device
may have been damaged during transportation, please contact manufacturer/supplier for technical
support.
Warning!
Forbidden to transfer the vessel while
the instrument is working.
6. Function: Heating (H03D series)
The device is controlled by digital temperature control technology, which has two separate safe
circuits. The hotplate is kept at a constant temperature by a digital control circuit. The hotplate
temperature can also be monitored from a separate, adjustable safe circuit. The two internal
temperature sensors for temperature control are built into the hotplate. The single external PT1000
can monitor the temperature of the sample.
•If using an external sensor PT1000: Always connect it to the device BEFORE turning the power
on and insert it into the sample BEFORE heating (see section 6.1).
•Set the temperature by rotating the temperature control knob slowly towards the target value.
•While the heating function is on, the LED screen displays the temperature value on the left-hand
side.
•The heating function is switched on or off by pushing the heating knob.
The heating function will be stopped automatically under abnormal conditions. The safe circuit
keeps the hotplate temperature under 320°C.

10
Please, in that case, follow the instructions below:
•Switch OFF the instrument.
•Ensure the external temperature sensor is inserted in the media heated.
•Switch ON the instrument and run heating function.
If the heating function does not work, please contact manufacturer/supplier for technical support.
Once turned on, the instrument automatically displays the last running speed and temperature
parameters.
Generally, the LED screen cannot display the actual temperature of sample in the vessel or hotplate
surface. Temperature differences exist between:
•Hotplate center and outer edge.
•The sample in the vessel and hotplate surface.
In order to ensure the accuracy of the temperature inside the container, please use the external
temperature sensor PT1000.
6.1 Working with external temperature sensor
Figure 9
The external temperature sensor PT1000 is the manufacture’s standard accessory. Compared to the
temperature control of the hotplate, the external temperature sensor can control the medium’s
temperature more precisely.
•If an external temperature sensor is needed, it must be plugged in before turning on the device
(fig. 6).
•Ensure the external temperature sensor is connected firmly and inserted into the media before
heating.
•Switch on the instrument and start heating.
•The LED screen displays the temperature setting value for 5 seconds and then shifts to the real
value.
Warning!
Forbidden to plug in/pull out external
temperature sensor in heating.

11
6.2 Residual heat warning (HOT)
In order to prevent burns from the hotplate, the digital hotplate has a residual heat warning
function. When the heating function is switched off and the heating plate temperature is still above
50°C, “Hot” will flash on the LED screen to warn that there is a hazard of burns from the hotplate.
When the unit is powered off, the LED screen alternates the temperature of the hotplate and “Hot”.
When the hotplate temperature drops to below 50°C, the unit will automatically switch off. If users
want to turn off the LED immediately, just pull out the plug directly. When the plug is pulled out, the
residual heat warning function stops running.
7. Function: Stirring
The function “stirring” of LED digital model (H03D and S03D):
•Turn on the device by pressing the switch ON/OFF.
•Start the function "stirring" by pressing the "STIR" knob and adjust the speed slowly until the set
value.
•When starting the function "stirring", the display shows set value and then blinks. This blinking
will stop only when the actual speed reaches the set value.
•At the end of the manipulation, turn the knob to the left to slow down and turn off "stirring" by
pressing the knob.
•Turn off the device by pressing the switch ON/OFF.
The function “stirring” of classic model (S03):
•Turn on the device by pressing the switch ON/OFF.
•Activate and adjust the speed of stirring by slowly turning the speed control to the set value.
•At the end of the manipulation, turn the knob fully counterclockwise to turn off the stirring.
•Turn off the device by pressing the switch ON/OFF.
8. Faults
•Instruments cannot be power ON.
Check whether the power line is unplugged.
•Fault in power on self-test
Switch OFF the unit and then switch back ON.
•Stir speed cannot reach set point
Excessive medium viscosity may cause abnormal speed reduction of the motor
•Unit cannot be powered off by pressing the switch on / off.
Check if the residual heat warning function is still ON and hotplate temperature is above
50ºC (the LED screen still works and “Hot” appears on the screen).
If these faults are not resolved, please contact manufacturer/supplier.

12
9. Maintenance and Cleaning
•Proper maintenance can keep instruments working properly and lengthen their lifetime.
•Do not spray cleanser onto the instrument when cleaning.
•Unplug the power line when cleaning.
•Only use recommended cleansers:
Dyes
Isopropyl alcohol
Construction materials
Water containing surfactants
/ Isopropyl alcohol
Cosmetics
Water containing surfactants
/ Isopropyl alcohol
Foodstuffs
Water containing surfactants
Fuels
Water containing surfactants
Table 5
•Before using any other cleaning or decontamination method, the user must verify with the
manufacturer that the method will not harm the instrument. Wear proper protective gloves
during the cleaning of the instrument.
Note:
•Electronic devices cannot be
cleaned with cleanser.
•If maintenance service is needed,
the instrument must be cleaned in
advance to avoid pollution from
hazardous substances, and sent
back in the original packing.
•If the instrument will not be used
for a long time, please switch off
and place in a dry, clean location,
at room temperature, and on a
stable surface.

13
10. Standards and Regulations
Construction in accordance with the following
safety standards:
EN 61010-1
UL 3101-1
CAN/CSA C22.2(1010-1)
EN 61010-2-10
Construction in accordance with the following
EMC standards:
EN 61326-1
Associated EU guidelines:
EMC-guidelines: 2004/108/CE
Instrument guidelines: 73/023/EWG
Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
NOTE: This equipment has been tested to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference. In that case,
the user will be required to correct the interference at his own expense.

14
11. Specifications
Items
Specifications
H03D / S03D
series
S03
series
Voltage [VAC]
*100~120/200~240
100~240
Frequency [Hz]
50/60
50/60
Power [W]
*515/15
10
Stirring point position quantity
1
1
Max. stirring quantity (H2O) [l]
3
3
Recommended magnetic bar [L, mm]
30 - 50
30 - 50
Motor type
DC motor
Max. power input of motor [W]
5
5
Max. power output of motor [W]
3
3
Speed range [rpm]
100 –1500, increment:10
0 –1500
Rotary speed display
LED
Scale
Plate material
*Ceramic coated/Plastic
Dimensions of workplate (mm)
Ø135
Ø135
*Heating power [W]
500
-
*Temperature range [°C]
RT-280, increment:1
-
*Temperature display [°C]
LED
-
*Temperature display accuracy [°C]
1
-
*The safe temperature of hotplate [℃]
320
-
*Temperature sensor in medium
PT1000
-
*Control accuracy of heating
temperature with temperature sensor
[℃]
±0.5
-
*Residual heat warning
50℃
-
Dimensions (mm)
*220×160×95
220×160×75
Weight [kg]
*1.4/0.7
0.7
Permitted ambient temperature [°C]
5 - 40
Permitted relative humidity
80%
Protection class acc. to DIN 60529
*IP21/IP42
*H03D series
Table 6

15
12. Accessories
Please contact our company to order the following accessories available for these devices: magnetic
stirring bars, PT1000 temperature sensor with and without glass coated, and fixation support for
the temperature sensor.

16
Manual de usuario
H03D Agitador magnético digital con calefacción
S03 Agitador magnético sin calefacción
S03D Agitador magnético digital sin calefacción
Introducción
Los usuarios deben leer este manual cuidadosamente, seguir las instrucciones y los procedimientos,
y estar informados de todas las precauciones antes de usar este equipo.
Servicio
Cuando necesite ayuda, puede contactar con su distribuidor o con Labbox a través de:
www.labbox.com
Por favor proporcione al personal de Atención al Cliente la siguiente información:s
Número de serie del equipo (en el panel trasero o debajo del equipo)
Descripción del problema
Sus datos de contacto
Garantía
Este equipo está garantizado contra cualquier defecto en los materiales y de fabricación bajo un uso
normal, por un período de 24 meses a partir de la fecha de la factura. La garantía se extiende
solamente al comprador original. La garantía no se aplicará a ningún producto o piezas que se
hayan dañado a causa de una instalación incorrecta, de conexiones incorrectas, de un uso erróneo,
de accidente o de condiciones anormales de operación.
Para las reclamaciones bajo garantía, por favor póngase en contacto con su proveedor.

17
1. Instrucciones de seguridad
¡Advertencia!
•Lea el manual de instrucciones
detenidamente antes de usar el
equipo.
•Asegúrese de que solamente
personal debidamente formado
utiliza el equipo.
¡Riesgo de quemaduras!
•Tenga cuidado cuando toque
partes del chasis del equipo y el
plato calefactor puesto que puede
alcanzar temperaturas de hasta
280°C.
•Preste atención al calor residual
después de apagar el equipo.
¡Contacto a tierra de protección!
•Asegúrese de que la toma esté
conectada a tierra (toma a tierra de
protección) antes de usar.
Durante el uso del equipo utilizar protección de seguridad personal para evitar riesgos
debidos a:
-Salpicaduras y evaporación de líquidos
-Emisión de gases tóxicos o combustibles
Coloque el equipo en una superficie espaciosa, estable, limpia, antideslizante, seca y a
prueba de fuego. No utilice el equipo en atmósferas explosivas, con sustancias peligrosas o
debajo del agua.
Aumente gradualmente la velocidad. Reduzca la velocidad si se producen las siguientes
situaciones:
-La varilla magnética se rompe debido a una elevada velocidad de agitación
-El funcionamiento del equipo es irregular, o el chasis se mueve sobre la base de la placa
La temperatura debe ajustarse siempre al menos 50 ºC por debajo del punto de combustión
de los medios utilizados.

18
Sea consciente de los riesgos debido a:
-Materiales o medios inflamables con una temperatura de ebullición baja
-El llenado excesivo del recipiente
-Recipiente inseguro
Materiales de proceso patógeno sólo en recipientes cerrados.
En caso de que la varilla magnética sea de PTFE, por favor tenga en cuenta:
-El flúor elemental, el ión trifluoruro, y los metales alcalinos provocan la corrosión del
PTFE y los hidrocarburos halogenados lo hacen expandir a temperatura ambiente.
-Los metales alcalinos fundidos, los alcalinotérreos o sus soluciones, así como los
elementos de la segunda y tercera columna de la Tabla Periódica de los Elementos en
polvo tendrán reacción química con el PTFE cuando la temperatura alcanza los 300 ~ 400
ºC.
Compruebe el equipo y los accesorios antes de cada uso. No utilice componentes en mal
estado. El funcionamiento seguro del equipo está garantizado solamente con los accesorios
descritos en el capítulo de “accesorios”. Los accesorios deben estar firmemente sujetos al
equipo y no pueden soltarse por sí mismos. Desconecte siempre la alimentación antes de
montar los accesorios.
Cuando necesite trabajar con el sensor de temperatura externo, el extremo del sensor debe
estar al menos a 5-10 mm de distancia del fondo del recipiente y de la pared.
El equipo sólo puede desconectarse de la línea eléctrica retirando el cable de alimentación de
la toma de red.
Comprobar que la toma eléctrica es del voltaje y potencia suficiente para este equipo.
Asegúrese que el cable de alimentación principal no esté en contacto con la placa. No cubra
el equipo.
Este equipo solo podrá ser abierto por técnicos electrónicos autorizados expertos.
Mantener el equipo alejado de campos electromagnéticos elevados.
Tenga en cuenta las distancias mínimas entre los equipos, entre el equipo y la pared y sobre
el montaje (mín. 100 mm)

19
>100mm
Figura 1
2. Normas de uso
Este equipo está diseñado especialmente para mezclar y calentar líquidos para propósitos
educacionales, laboratorios o fábricas.
Este aparato no es adecuado para trabajar fuera del laboratorio u otras restricciones mencionadas
en el capítulo 1. No testado para trabajo en continuo (24h/7días).
3. Inspección
3.1 Desembalaje
Desembale cuidadosamente el instrumento y verifique que el equipo y /o los accesorios hayan
llegado sin daños aparentes. En caso necesario póngase en contacto con el fabricante o el
proveedor del equipo para solicitar ayuda técnica.
Nota:
Si detecta cualquier daño aparente, por
favor no enchufe el equipo.
3.2 Lista de embalaje
El paquete incluye los siguientes elementos:
Contenido
Cantidad
Unidad principal
1
Cable de alimentación
1
Varilla magnética
1
Manual de usuario
1
Tabla 1

20
4. Control
4.1 Elementos de control
Figura 2: Modelo H03D
Figura 3: Modelo S03D
Botón de control de
velocidad
Pantalla LED
Pantalla LED
Botón de control de velocidad
Botón de control de
temperatura
Icono del
Sensor
