LCN 4600 Series User manual

*28101*
28101
Table of Contents
General Information....................................................................................................................................................................................... 2
Install Mounting Plate .................................................................................................................................................................................... 3
4630 Template ............................................................................................................................................................................................... 4
4640 Template ............................................................................................................................................................................................... 5
Installing Closer Assembly............................................................................................................................................................................. 6
4600 Series Arm Installation.......................................................................................................................................................................... 7
Closer Regulation & Power Adjustment......................................................................................................................................................... 9
Controller Installation................................................................................................................................................................................... 10
Electrical Connections ................................................................................................................................................................................. 11
Typical Wiring .............................................................................................................................................................................................. 12
Auxiliary Electrical Device Wiring ................................................................................................................................................................ 14
Controller Setting Adjustment ...................................................................................................................................................................... 15
Controller Programming............................................................................................................................................................................... 16
Basic Operation & Cover Installation........................................................................................................................................................... 18
Illustrated Parts List ..................................................................................................................................................................................... 19
The 4600 Series electric Auto-Equalizer™ series combines all door operator and door control functions in one package. This versatile, easy-to-
install system is low maintenance and offers the following features:
Top jamb mounting on either side of an interior door allows 90° of power opening. (Mounting for exterior door on the inside only)
• Manual opening up to 170° (4630) or 100° (4640).
• Easy access to on / off and hold open switches.
• Quiet, reliable operator delivers consistent performance.
• No expensive service contracts or periodic maintenance required.
• Fail safe operator acts as a standard door closer in event of power outage.
• Low energy operator does not require guard rails or safety mats.
• Advanced, easy-to-install controller module allows independent adjustment of:
a. Door Opening Speed » Delay / Trigger Time for Sequential Option
b. Door Opening Force » Electric Strike Delay Time
c. Hold Open Time » 90° Slow Down
d. Alternate Action Timeout » Safety Scanner Lockout Time
4630, 4640 Electric Auto Equalizer Series
4600 Electronic Low
Energy Operator
Installation Instructions
Customer Service
1-877-671-7011 www.allegion.com/us
4640
PUSH SIDE MOUNT
4630
PULL SIDE MOUNT

2
This installation instruction sheet is a valuable reference and
should not be discarded. It should be given to building owner
or maintenance supervisor after installation is complete.
General Information
The 4600 series Auto-Equalizer™ is designed to meet the
following codes & standards:
• ANSI A156.19, section 2.1
• ANSI A117.1, section 4.13.11 requirements.
• ADA law section 4.13.12
• UL listed for use on labeled doors.
• Complies with UL & NEC requirements for Class 1 (high
voltage) & Class 2 (low voltage) by providing separate conduit
connections for each.
Both the 4631 & 4642 are non-handed, non-sized door operators
that provide all the standard features of a heavy duty LCN door
closer; including independent adjustment of backcheck, main
speed and latch speed functions as well as adjustable closing
power: 4631 (size 1 to 4) / 4642 (size 2 to 5). Both models are
shippedwithLCN’s“UltraX”all-weatherhydraulicuidforreliable
operation at a wide range of temperatures. Requirements for
installation are as follows:
• The 4631 is designed for pull side installation on the top
jamb and requires a minimum door width of 36” and a 2” min.
head frame. Top rail of door must be 1 Z\,” min. and butt hinge
size should not exceed 5”. Maximum pull side reveal of Z\,”.
Maximum door weight is 225 lbs.
• The 4642 is designed for push side installation on the top jamb
forbothstandardandushceilingconditions.Itrequiresa
minimum door width of 36” and a 1 C\v” min. head frame. Top
rail of door must be at least 1 C\v” and butt hinge size should
not exceed 5”. The 4642 accommodates reveals up to 4 Z\x”.
For reveal depths of 4 Z\x” - 8”, requires 4642 L (Long Arm). For
reveal depths greater than 8” - consult factory. Maximum door
weight is 225 lbs.
The 4600 series can accommodate both surface and concealed
wiring applications. It requires 120VAC supplied to the
operator. Maximum AC current load is 1 amp. A built-in 12VDC &
24VDC power supply (rated for 1 amp combined current load) can
power peripheral actuators, electronic strikes or mag-lock devices.
The 4600 series is compatible with all LCN 8300 series actuators
and scanners. High-security card readers or keypads may also be
used as actuators. The 4600 series will accept inputs from a wide
variety of security systems, allowing security personnel to regulate
accessability.A4600willacceptarealarminputtodeactivate
unitwhenrealarmistriggered.Acircuitbreakerandresettable
fuses protect high-voltage inputs and low-voltage output circuits,
respectively. To ensure proper electrical functions, installation
should be made when temperature is between 35° F up to 120° F.
The 4600 series installation has three sections:
Section 1 - Fastening mounting channel to frame / electrical
connections.
Section 2 - Installing closer body & arm assembly
Section 3 - Installation of controller and adjustment of settings.
IMPORTANT
Follow all instructions carefully. Failure to do so may
result in personal injury or property damage. Use extreme
caution when dealing with high voltage. High voltage
connections should be made by a qualied professional.
Closer and controller adjustments might be necessary
to meet ANSI A156.19 requirements. To verify the force
requirements, a force gauge is needed. If you have any
questions, call LCN at 1 - 877 - 671 - 7011.

3
NOTICE:
The following procedures involve electrical connections and
running conduit for both high & low voltage wiring. Electrical
power must be disconnected during the installation of the 4600
series door operator. It is also important to examine the proper
template for your installation to determine the mounting channel
position and correct conduit location.
SECTION 1
SECURING MOUNTING PLATE
ASSEMBLY TO FRAME
NOTE: Before beginning installation, determine which conduit
connection option is to be used.
CONCEALED WIRING:
Both high & low voltage conduit lines should be run to door
frame and made accessible through two holes to be drilled in
frame per proper template on page 4 or 5.
SURFACE WIRING:
Mounting channel must be mounted to frame BEFORE running
high & low voltage conduit lines to the operator.
1. Prepare door and frame per template on page 4 for 4630/
page 5 for 4640. Be sure all holes are located correctly
before drilling and/or tapping. Mounting surface of frame
must be vertically level. Conduit access holes in frame
are for CONCEALED WIRING ONLY! If using concealed
wiring option, see step 2 below. FOR SURFACE WIRING,
proceed to step 3.
2. Refer to correct template to determine proper location
for conduit. Remove appropriate conduit plugs, exposing
conduit holes in back of mounting channel, as shown in
Fig 1. Attach 1/2” conduit to mounting channel, as shown in
Fig 2. Place mounting channel into position on frame. Once
mountingchannelisinpositionandushonframe,insert
fasteners and tighten securely.
NOTE: The conduit set-up shown is for a 4630 mounting. Conduit
location will vary with other mountings.
CONNECTIONS
HIGH VOLTAGE
LOW VOLTAGE
CONNECTIONS
END CAP
REMOVED
FROM
THIS END
Fig. 1
HIGH
VOLTAGE
LOW
VOLTAGE
HIGH VOLTAGE
CONNECTIONS
LOW VOLTAGE
CONNECTIONS
END CAP
REMOVED
FROM
THIS END
Fig. 2
3. Position mounting channel on frame, connect conduit and
tighten securely.
CONDUIT THROUGH TOP OF MOUNTING CHANNEL:
After mounting plate is attached to frame, run 1/2” conduit to
access holes in top of mounting channel. Conduit should be
connected to channel as shown here in Fig. 3.
LOW VOLTAGE
CONNECTION
HIGH VOLTAGE
CONNECTION
Fig. 3

4
4630 GNINEPOMUMIXAM°071
GNINEPOREWOP°09
RAILIXUA DEDNEMMOCERPOTSY
RESOLCDNAROODDNAHTFEL
ETISOPPODNAHTHGIR,NWOHS
SEIRES0364
T/EDISLLUP DETNUOMBMAJPO
ADEDNAH-NON ™REZILAUQE-OTU

5
LEFT HAND SHOWN, RIGHT HAND OPPOSITE
LEFT HAND SHOWN, RIGHT HAND OPPOSITE
4640 SERIES PUSH SIDE/TOP JAMB MOUNTED
NON-HANDED AUTO-EQUALIZER™
REGULAR/FLUSH CEILING MOUNTS
1. VOLTAGE SUPPLIED TO FRAME MUST CORRESPOND TO VOLTAGE OF OPERATOR.
2. MAXIMUM BUTT SIZE IS 5”.
3. MINIMUM DOOR WIDTH IS 36”.
4. MAXIMUM STOP THICKNESS IS 5/8”.
5. MAXIMUM REVEAL DEPTH IS 4 ½”UP TO 8” REVEALS WITH LONG ARM OPTION, CONSULT FACTORY.
6. AUXILIARY STOP RECOMMENDED AT MAXIMUM OPENING POINT (100°).
7. LOCATE OPERATOR & SHOE FROM THE CENTERLINE OF SWING CLEAR HINGE PIN IF USED.
8. CONSULT FACTORY IF DOOR IS HUNG ON PIVOTS OR WIDE-THROW HINGES.
9. REINFORCING PER ANSI/SDI-100 RECOMMENDED FOR HOLLOW METAL DOORS & FRAMES.
10. OVERALL OPERATOR SIZE: 33 ½”X 4 3/8” X 5 3/16”.

6
SECTION 2
INSTALLING CLOSER ASSEMBLY
1. At this point of the installation, the mounting channel
assembly should be attached securely to door frame. All
electrical connections at the unit should be hooked up, but
UNPOWERED.
2. CLOSING FORCE ADJUSTMENT: (See Fig. 4). Turn spring
adjustment clockwise the required number of turns to match
door width as shown in Tables 1 & 2. Maximum adjustments:
14 turns clockwise.
TO INCREASE
SPRING POWER
TO DECREASE
SPRING POWER
Fig. 4
C.W.
Verify that closing force is not more than 15 lbs when measured
one inch from door edge to comply with ANSI A156.19.
TABLE 1
INTERIOR DOOR
MAXIMUM
DOOR WIDTH
NUMBER
OF TURNS
36” 0
48” 2 TURNS C.W.
54” 7 TURNS C.W.
TABLE 2
EXTERIOR DOOR
MAXIMUM
DOOR WIDTH
NUMBER
OF TURNS
36” 2 TURNS C.W.
42” 7 TURNS C.W.
NOTE: Do not allow any form of lubricant to come into contact with any part of clutch assembly.
NOTE: Electrical components not shown.
3. Mount closer to mounting channel assembly. Closer and clutch gear coupler’s should mesh loosely as shown in Fig. 5 above. Line
closer mounting holes up with holes in stand-offs attached to mounting channel. Fasten with (4) 1/4 - 20 x 2 B\zn”machine screws
provided and tighten securely.
4. It is extremely important that closer is properly aligned with motor/clutch assembly.
CLUTCH
Fig. 5

7
4630 Series Arm Assembly
NOTE: Right hand door shown, left hand will be opposite.
5/16" LOCK WASHER
EXTENSION
ARM SET
SCREW
ROLLER
END CAP
TRACK
PLUG
ARM
SHAFT
SCREW
Fig. 6
SHAFT
SPACER
(2) 1/4 - 20 x 1 1/2" M.S.
OR
(2) No. 14 x 2 1/2" W.S.
ARM
ASSY
30°
1. Insert (4) track plugs into bottom of track, as shown in Fig. 6 above. Remove track end cap, insert track roller and replace end cap.
2. Mount track assembly to door, attaching securely with either (2) 1/4-20 x 1 Z\x” machine screws or (2) No. 14 x 2 Z\x” wood screws
provided.
3. Locate SHAFT EXTENSION, LOCK WASHER, SPACER & ARM SHAFT SCREW in fastener box. Fit arm and spacer onto shaft
extension. Place lock washer into the shaft extension so it locates between closer shaft and shaft extension. Place wrench on top
closer shaft and rotate approx. 30°, as shown above. Fit arm assembly over closer shaft and fasten with arm shaft screw as shown in
Fig. 6 above.
4. Open door partially. Pull closer arm away from frame. Fit hole in end of arm over the stud of track roller. Tighten arm set screw,
attaching arm to track.
5. Proceed to REGULATION INFORMATION on page 9.

8
4640 Series Arm Assembly
NOTE: Left hand door shown, Right hand will be opposite.
Fig. 7
Fig. 8
5/16 " LOCK WASHER
EXTENSION
ARM
SHAFT
SCREW
ARM SET SCREW
ROD & SHOE
Preload to 90°
as shown
FOREARM
TUBE
MAIN
ARM
1. Locate SHAFT EXTENSION, LOCK WASHER & ARM SHAFT SCREW in fastener box. Fit arm onto shaft extension. Place lock
washer into shaft extension so it will rest between closer shaft and shaft extension. Fit arm assembly over closer shaft so main arm is
positioned at approx. 90° to operator assembly and fasten with arm shaft screw, as shown in Fig. 7 above.
2. Attach rod & shoe assembly to door with (2) 1/4 - 20 x B\,”” machine screws or (2) No. 14 x 1 Z\x” wood screws provided. The longer
end of shoe should point towards hinge edge, as shown above.
3. Open door partially, insert rod into forearm tube, then close the door.
4. Insertarmsetscrewintorodandngertighten.Preloadarmto90°,asshowninFig. 8 above. Holding arm in this position, place a
wrench on arm set screw and tighten securely.
5. Proceed to REGULATION INFORMATION on page 9.

9
DOOR CLOSER HYDRAULIC REGULATION &
POWER ADJUSTMENT
1. CLOSING SPEED ADJUSTMENT: (See Fig. 9)
The hydraulic regulation of the 4600 series has been adjusted
prior to shipment. To meet ANSI A156.19 table 1 requirements,
open door to 90° and determine the closing time. Make sure
the spring power and closing speed are correct. If adjustments
are necessary, use 3/32 allen wrench provided and refer to
door diagram shown in Fig. 9. Turn MAIN SPEED & LATCH
SPEED screws clockwise to slow door speed, counter-
clockwise to increase speed. The installation of the controller
will make the MAIN and LATCH SPEED regulating screws
inaccessible.
NOTE: Do not back regulating screws out of closer or an oil leak
will occur
Fig. 9
LATCH SPEED
MAIN SPEED
BACKCHECK
2. BACKCHECK ADJUSTMENT:
Backcheck slows the door swing as it approaches full opening.
Adjust the backcheck setting only if necessary. Increase
backcheck strength by turning BACKCHECK screw clockwise
by quarter turns. Make sure backcheck adjustments conform to
ANSI A156.19 sections 4.2, 4.4, 4.5, and tables I & II. DO NOT
USE AN ABRUPT BACKCHECK SETTING.
a. Remove forearm set screw and open door, separating rod
from forearm tube.
b. Removeshoescrewsandipshoe180°asshowninFig.
10. Re-attach shoe to door.
c. Re-assemble arm, as in steps 3 & 4 on page 8.
d. Verify that closing force is no more than 15 lbs when
measured one inch from door edge to comply with ANSI
A156.19.
For 4640 series only
Fig. 10
STANDARD
INSTALLATION
SHOE POSITIONED
FOR INCREASED
POWER AT LATCH
LOCATING CAUTION / AUTOMATIC DOOR DECAL
1. Locate one decal on each side of door, near latch area to meet
ANSI A156.19-2007 code requirements. Decal must be located
at50”(+/-12”)fromtheoortothecenterlineofthesign.The
decal location must be visible without interference from door
trim or auxiliary door hardware.
2. Clean the 6” x 6” area where decal is to be placed. Apply decal
by removing the backing and “rolling” it onto door. This will help
prevent air bubbles from being trapped under decal.
AUTOMATIC
DOOR
CAUTION

10
SECTION 3
INSTALLATION & ADJUSTMENT
OF CONTROLLER BOARD
NOTE: Be sure electrical power source is disconnected.
1. MOUNT CONTROLLER TO OPERATOR ASSEMBLY:
Locate controller assembly in shipping carton. Position the
controller as shown in Fig. 11. Slide onto mounting plate
assembly, guiding cut-outs in controller onto mounting pins as
shown.
2. Oncethefrontofcontrolleristtedontopins,pushentire
controller into position, as shown in Fig. 12. With controller in
proper position, insert (1) unpainted #8-32x3/8”athead
screw into bottom of mounting plate, as shown.
Fig. 11
Fig. 12
NOTE: For adjustments to door closer regulating screws,
controller must be removed. Do this by: Removing power to
operator, unplugging the electrical connections, removing screw,
tilting controller away from operator and disengaging controller
from mounting pins. Follow steps 1 & 2 above to reattach.
WIRING CONNECTIONS:
1. There will be 3 key wiring harness connectors shipped in the
hardwarebox.Therstisaribboncableconnector.Itshould
bettedintoreceptaclesonrearboardassemblyandthe
controller as shown in CONNECTION #1 of Fig. 13.
Fig. 13
CONNECTION #1
CONTROLLER
RIBBON CABLE CONNECTION #2
120VAC POWER
CONNECTION #3
MOTOR / CLUTCH
2. The second connector is a 2 wire lead for the 120 VAC
power and should be tted rmly into into receptacles
on rear board assembly and the controller as shown in
CONNECTION #2 of Fig. 13.
3. The third connector is for the motor / clutch. The connector
shouldbettedrmlyintoreceptacleonthecontrolleras
shown in CONNECTION #3 of Fig. 13.
4. Electrical power can now be safely supplied to the 4600 series
operator. The controller settings have been pre-set prior to
shipment. Adjustment information is detailed on pages 15-17.
It will be necessary for the 4600 series door operator to be
functional while adjustments and settings are made. Trigger
actuator device(s) and check to make sure that door opens
freely. Arm assembly motion and door travel should not make
contact or have interference with any object.
