Legacy FLEXZILLA PRO User manual

The color CHARTREUSE as applied to the body of the air hose is a registered trademark of Weems Industries, Inc. Flexzilla is a registered trademark of Weems Industries, Inc.
The color CHARTREUSE as applied to the body of the air hose reel is a trademark of Weems Industries, Inc.
The Flexzilla Stylized X is a trademark of Weems Industries, Inc.
SAFETY INSTRUCTIONS
• Do not allow tools to hang on the end of the hose when not
in use.
• Do not allow the hose to contact hot, sharp or heated
surfaces that could damage it.
• Always recoil hose back into the reel when work is completed.
• Do not allow hose to retract uncontrolled.
INSTALLATION AND MOUNTING OPTIONS
Choose fasteners suitable for the mounting surface, the weight
of the reel, and the force of pulling the hose. Use a leveling
device for proper positioning. Use hex head fasteners up to
5/16" (8 mm) in diameter, with a minimum 1/2” (12.5 mm) hex
head. Mounting fasteners not included. See mounting diagram
on last page.
Wall Mounting Option:
Recommended height is 5 ft. (1.5 m) to 8 ft. (2.5 m)
Ceiling Mounting Option:
Recommended ceiling height is 8 ft. (2.5 m) to 10 ft. (3 m)
Installation:
1. Locate 3 holes on mounting bracket
2.Observe both sides of reel housing and remove screws
that hold bracket pivots in reel. Remove pivots and bracket
from reel.
3.Mount bracket to surface.
4. Re-install reel to bracket with the pivots. Re-install screws.
SAVE THESE INSTRUCTIONS! READ ALL INSTRUCTIONS!
CAUTION: Read all instructions and warnings before operating this product.
CAUTION: Inspect hose before each use. Do not exceed 150 psi working pressure. Do not kink, twist, knot or abrade hose. Do not
wrap hose around body. Keep hose away from hot surfaces and/or chemicals. KEEP CHILDREN AWAY FROM WORK AREA!
Part No.: L8251FZP
Retractable Air Hose Reel, 50 ft.
Owner’s Instructions
OPERATION
The reel can lock the air hose at approximately 17-inch intervals.
Each latching interval is announced by a series of five "clicks."
This "ratcheting" sound lets you know that the reel is in the
latching zone as the air hose is pulled out.
1. Latching Hose -
After pulling out the desired length of hose, allow it to
retract slightly until you feel it stop. The reel is now latched.
2. Rewinding Hose -
Pull out approximately one extra foot from latch position and
allow hose to retract. The reel will continue rewinding until
hose is fully retracted. Do not allow the hose to rewind
uncontrolled back into the reel. Personal injury can result.
3. Hose Stopper Adjustment -
To modify the hose stopper position, pull out hose to the
desired length and latch reel. Loosen screws holding the
two halves of the hose stopper together, slide stopper to
opening of reel and tighten screws.
NOTE: ENSURE THE REEL IS COMPLETELY LATCHED
BEFORE LOOSENING THE HOSE STOPPER.
4. Do not extend hose beyond the indicator shown in the image below.
Legacy Manufacturing Company
Marion, IA, 52302 USA
Ph: 319.373.7305 [email protected]
legacymfg.com
INS8251FZP
(Published 10/21/2021)
Bracket
mounting holes
Red label indicator located at end of hose

Bend restrictor
Old reel hose
to be replaced
REMOVE OLD HOSE BY
PULLING THIS DIRECTION
Hose clamp
C-clip
Washer
Swivel body, with
hose, hose clamp
and bend restrictor
Screw
Swivel cover
Screw
Belt cover
Belt
Small gear
Old reel hose
to be replaced
Old reel hose
to be replaced
Old reel hose
to be replaced
ST
E
P
1
ST
E
P
2
ST
E
P
3
And through
opening in drum
Extend as needed for
swivel re-installation
Insert replacement reel hose RP005051-FZ from
this direction,
through layering window rollers
Bend restrictor
Replacement
reel hose
RP005051-FZ
Hose clamp
Replacing Extension Hose (part 3):
1.
Remove C-Clip
2. Washer
3. Swivel body, with hose, hose clamp and bend restrictor
Replacing Extension Hose (part 4):
1.
Slide bend restrictor away from hose clamp
2. Loosen hose clamp and slide away from swivel
3. Remove hose from swivel
4. Remove hose from reel
Replacing Extension Hose (part 6):
1.
Slide bend restrictor on hose
2. Slide clamp on hose
3. Insert swivel into hose
Replacing Extension Hose (part 2):
1. Remove:
1. 4 screws
2. swivel cover
REPAIR INSTRUCTIONS
Replacing Extension Hose (part 1):
1.
Pull on extension hose to complete extension
2. Slowly allow reel to retract hose back into reel
approximately
1/2 of a full rotation
3.
Pull on extension hose slowly until reel is in a latched position
4. Remove:
1.
3 screws
2.
belt cover
3. gear cover
4. belt
5. small gear
Replacing Extension Hose (part 5):
1.
Install replacement reel hose RP005051-FZ

Screw
Swivel cover
Screw
Belt cover
Belt
Small gear
Replacement
reel hose RP005051-FZ
C-clip
Washer
Swivel body, with
hose, hose clamp
and bend restrictor
Replacement
reel hose RP005051-FZ Replacement
reel hose RP005051-FZ
Axle shaft
Pull on reel hose when installing swivel on axle shaft
Cover alignment slot
DETAIL C
small
gear
A
C
B
DETAIL B DETAIL A
Replacing Extension Hose (part 10):
1.
Install belt
2. Install gear cover
3. Install belt cover
4. Install all 3 screws
5. Pull on reel hose
RP005051-FZ to release from latch
6. Slowly allow reel spring to retract reel hose into reel
Replacing Extension Hose (part 9):
Before releasing reel lock to retract new hose into reel:
1. Remove hose stopper from old hose
2. Re-install hose stopper on new hose
3. Position stopper approximately 2 ft. from end of hose
4. Re-install the small gear (see DETAIL A)
5. Rotate gear clockwise ONLY!
6. Rotate until the layering window's right edge is aligned
with left side of housing mid section rib (see DETAIL B)
Replacing Extension Hose (part 8):
1. Install swivel cover
2. Align tab on cover to slot on drum (see DETAIL C)
3. Install all 4 screws
REPAIR INSTRUCTIONS (CONT.)
Replacing Extension Hose (part 7):
1.
Pull on reel hose RP005051-FZ
2. Guide swivel toward axle shaft
3. Slip swivel onto axle shaft
4. Install washer
5. Install c-clip

7.283”
(185 mm)
10.094”
(256.4 mm)
1.181”
(78 mm)
SEE INSTRUCTIONS FOR IMPORTANT
MOUNTING INFORMATION
TOP
Locking finger
Replacement L8251FZLI
Cover
Screw
REPAIR INSTRUCTIONS
Replacing Lead-in Hose:
1.
Remove the 4 screws
2. Remove cover
3. Lift locking finger on fitting
4.
Rotate counter clockwise
5.
Pull fitting out of the reel
6.
Replace with new L8251FZLI
5 YEAR LIMITED WARRANTY
For warranty information visit flexzilla.com/warranty
or call 800-645-8258
REPLACEMENT PARTS
Part # Description
L8251FZLI Lead-in air hose 3/8in. x 5ft.
RP005051-FZ Replacement air hose 3/8in. x 50ft.
RP018251 Hose stopper
