Life Gear 20570 User manual

MERCURY,
MAGNETIC UPRIGHT BIKE
ITEM NO: 20570
OWNER’S MANUAL
IMPORTANT: Read all instructions carefully before using this product. Retain this
owner’s manual for future reference.
The specifications of this product may vary from this photo, subject to change without notice.
2012, May

1
TABLE OF CONTENTS
WARRANTY ------------------------------------------------------------------------------- 2
IMPORTANT SAFETY INSTRUCTIONS ------------------------------------------- 3
PARTS LIST ------------------------------------------------------------------------------- 4
HARDWARE PACKING LIST --------------------------------------------------------- 5
TOOLS -------------------------------------------------------------------------------------- 5
OVERVIEW DRAWING -----------------------------------------------------------------6
ASSEMBLY INSTRUCTIONS --------------------------------------------------------- 7
OPERATING THE COMPUTER ------------------------------------------------------ 12
ADJUSTMENTS -------------------------------------------------------------------------- 13
MAINTENANCE -------------------------------------------------------------------------- 14
TROUBLESHOOTING ------------------------------------------------------------------ 14
WARM UPAND COOL DOWN ROUTINE ----------------------------------------- 15

2
ONE YEAR LIMITED WARRANTY
LifeGear Inc. warrants to the original purchaser that this product is free from defects in
material and workmanship when used for the purpose intended, under the conditions that it
has been installed and operated in accordance with LifeGear's Owner's Manual. LifeGear's
obligation under this warranty is limited to replacing or repairing free of charge, any parts
which may prove to be defective under normal home use. This warranty does not include
any damage caused by improper operation, misuse or commercial application.
From the date of purchase, the frame is warranted to be free from defects for 1 (one) year.
This warranty is offered only to the original owner and is not transferable. Proof of
purchase is required.
When ordering replacement parts please have the following information ready:
1. Owner's Manual
2. Model Number
3. Description of Parts
4. Part Number
5. Date of Purchase

3
IMPORTANT SAFETY INSTRUCTIONS
Basic precautions should always be followed, including the following important
safety instructions when using this equipment: Read all instructions before using this
equipment.
1. Read all instructions and follow it carefully before using this equipment. Make sure the
equipment is properly assembled and tightened before use.
2. Before exercise, in order to avoid injuring the muscle, warm-up exercise is necessary.
Refer to the Warm Up and Cool Down Routine pages. After exercise, relaxation of the
body is suggested for cool-down.
3. Please make sure all parts are not damaged and fixed well before use. This
equipment should be placed on a flat surface when using. Using a mat or other
covering material on the ground is recommended.
4. Please wear proper clothes and shoes when using this equipment; do not wear clothes
that might catch any part of the equipment; remember to tighten the pedaling straps.
5. Do not attempt any maintenance or adjustments other than those described in this
manual. Should any problems arise, discontinue use and consult your local dealer.
6. Do not use the equipment outdoors.
7. This equipment is for household use only.
8. Only one person at a time should use this equipment.
9. If you feel any chest pains, nausea, dizziness, or short of breath, you should stop
exercising immediately and consult your physician before continuing.
10. Care should be taken in mounting or dismounting the equipment.
11. Do not allow children to use or play on the equipment. Keep children and pets away
from the equipment while in use. This machine is designed for adults use only. The
minimum free space required for safe operation is not less than two meters.
12. The maximum weight capacity for this product is 110 kgs.
WARNING:Before beginning any exercise program consult your physician.
This is especially important for the persons who are over 35 years old or who have
pre-existing health problems. Read all instructions before using any fitness
equipment.
CAUTION:Read all instructions carefully before operating this product.
Retain this Owner’s Manual for future reference.

4
PARTS LIST
No. Description Qty No. Description Qty
001 Main Frame 1 030 Eyebolt 2
002 Handlebar 1 031 Tension Bracket 2
003 Handlebar Post 1 032 Bolt M8x10 1
004 Rear Stabilizer 1 033 Nylon Nut M6 4
005 Flywheel Ø190 1 034 Cap Nut M10 2
006 Front Stabilizer Ø50x1.5x380 1 035 Bolt M10x57 2
007 Tension Control Knob 1 036 Big Curve Washer Ø10 2
008 Seat Post Knob M16x1.5 1 037 Bolt M8x25 1
009 Belt PJ 330J6 1 038 Washer Ø8 8
010 Computer JVT-29140 1 039 Big Curve Washer Ø16xØ8 2
011 Nut M10x1x10 2 040 Screw ST4.2x18 4
012 Seat Post Bushing 1 041 Bolt M6x10 1
013 Left Cover 1 042 Nylon Nut M8 3
014 Right Cover 1 043 Big Washer Ø20xØ6x1.5 1
015 Screw ST2.9x10 2 044 Idler Arm 1
016 Washer 1 045 Bearing 6000Z 2
017 Bearing Nut I 15/16” 1 046 Seat Post Cover 1
018 Hexagon Nut 7/8" 1 047 Bolt M8x20 2
019 Belt Pulley with Crank 240J6 1 048 Bolt M5x20 1
020 Right Foot Pedal YH-30X 1 049 Bearing Nut II 7/8” 1
021 Left Foot Pedal YH-30X 1 050 Handlebar Foam Grip
Ø30xØ24x455 2
022 Bearing Cup 2 051 Screw ST4.2x20 2
023 Bearing 2 052 Transport Wheel Ø23xØ6x32 2
024 Bolt M8x15 9 053 Hand Pulse Sensor with Wire
L=750mm 2
025 Seat Post 1 054 Washer Ø5 1
026 Sensor with Wire L=450mm 1 055 Crank Cover Ø50xØ26x10 2
027 Seat Cushion DADI 98-2-B 1 056 Bolt M6x48 2
028 Front Stabilizer End Cap
Ø50x1.5 2 057 Curve Washer Ø20xØ8 4
029 Rear Stabilizer End Cap Ø50x1.5 2 058 Tension Cable L=750mm 1

5
PARTS LIST
HARDWARE PACKING LIST
TOOLS
No. Description Qty No. Description Qty
059 Extension Sensor Wire
L=850mm 1 062 Washer 7/8" 1
060 Handlebar End Cap Ø25 2 063 Pan Head Phillips Self Drilling
Screw ST4.2x18 4
061 Bolt M5x10 4 064 Handlebar Post Cover 1
(34) Cap Nut M10
2 PCS (35) Bolt M10x57
2 PCS (36) Big Curve Washer Ø10 2 PCS
Multi Hex Tool
1 PC
Multi Hex Tool with Phillips Screwdriver
S13, S14, S15
1 PC
Allen Wrench 5mm
1 PC

6
OVERVIEW DRAWING
15
26
40
33
27
10
2
53
39
47
53
54
48
38
24
24 38
63
53
60
7
3
59
61
51
51
50
50
38 42
25
46
12
20
55
40
63
14
37
3832
44
45
43
41
24
64
58
28
56
52
52
56
28
6
4
29
29
49
62
23
22
19
36 34
1
23
16
18 17
22
5
30
11
31
11 33
13
21
55
63
63
9
8
30 31
33
26
59
35 35
24 57
24
57

7
ASSEMBLY INSTRUCTIONS
1. Front and Rear Stabilizers Installation
Position the Front Stabilizer (6) in front of the Main Frame (1) and align bolt holes.
Attach the Front Stabilizer (6) onto the front curve of the Main Frame (1) with two M10 Cap
Nuts (34), two M10x57 Bolts (35), and two Ø10 Big Curve Washers (36). Tighten cap
nuts with the Multi Hex Tool provided.
Remove four M8x15 Bolts (24) and four Ø20xØ8 Curve Washers (57) from the Rear
Stabilizer (4). Remove bolts with the 5mm Allen Wrench provided.
Insert the Rear Stabilizer (4) into the tube of the Main Frame (1) and align bolt holes.
Attach the Rear Stabilizer (4) into the tube of the Main Frame (1) with four M8x15 Bolts (24)
and four Ø20xØ8 Curve Washers (57) that were removed. Tighten bolts with the 5mm
Allen Wrench provided.
Hardware:
(34) Cap Nut M10
2 PCS (35) Bolt M10x57
2 PCS (36) Big Curve Washer Ø10 2 PCS
Multi Hex Tool
Allen Wrench 5mm
Tool:
24
57
24
57
35
4
6
36 34
1

8
2. Left and Right Foot Pedals Installation
The Cranks, Pedal Shafts, and Foot Pedals are marked “R” for Right and “L” for Left.
Insert the pedal shaft of Left Foot Pedal (21) into threaded hole in the left Crank (19). Turn
the pedal shaft by hand in the counter-clockwise direction until snug.
Note: DO NOT turn the pedal shaft in the clockwise direction, doing so will strip the
threads.
Tighten the pedal shaft of Left Foot Pedal (21) with the Multi Hex Tool with Phillips
Screwdriver provided. Insert pedal shaft of Right Foot Pedal (20) into threaded hole in right
Crank (19). Turn the pedal shaft by hand in the clockwise direction until snug. Tighten
pedal shaft of Right Foot Pedal (20) with the Multi Hex Tool with Phillips Screwdriver
provided.
Multi Hex Tool with Phillips Screwdriver
Tool:
20
21
19
19

9
3. Seat Post, Seat Post Cover, and Seat Cushion Installation
Remove three Ø8 Washers (38) and three M8 Nylon Nuts (42) from underside of the Seat
Cushion (27). Remove nylon nuts and washers with the Multi Hex Tool with Phillips
Screwdriver provided. Guide bolts on underside of the Seat Cushion (27) through holes on
top of the Seat Post (25), attach with three removed Ø8 Washers (38) and three M8 Nylon
Nuts (42). Tighten nylon nuts and washers with the Multi Hex Tool with Phillips Screwdriver
provided.
Slide the Seat Post Cover (46) onto the tube of the Main Frame (1). Insert the Seat Post
(25) into the Seat Post Bushing (12) on the tube of the Main Frame (1) and then attach the
Seat Post Knob (8) onto the tube of the Main Frame (1) by turning it in a clockwise direction
to lock the Seat Post (25) in the suitable position.
Multi Hex Tool with Phillips Screwdriver
Tool:
1
25
46
12
8
27
38
42

10
4. Handlebar Post and Handlebar Post Cover Installation
Remove five M8x15 Bolts (24) and four Ø8 Washers (38) from the Main Frame (1).
Remove bolts with the 5mm Allen Wrench provided.
Slide the Handlebar Post Cover (64) up to the Handlebar Post (3).
Connect the Sensor Wire (26) from the Main Frame (1) to the Extension Sensor Wire (59)
from the Handlebar Post (3).
Put the cable end of resistance cable of Tension Control Knob (7) into the spring hook of
Tension Cable (58), see Figure A. Pull the resistance cable of Tension Control Knob (7) up
and force it into the gap of metal bracket of Tension Cable (58), see Figure B.
Insert the Handlebar Post (3) onto the tube of the Main Frame (1) and secure with five
M8x15 Bolts (24) and four Ø8 Washers (38) that were removed. Tighten bolts with the
5mm Allen Wrench provided.
Slide the Handlebar Post Cover (64) down to the Handlebar Post (3).
Allen Wrench 5mm
Tool:
A B
7
7
58
58
38
24
24 38
24
64
58
26
59
7
3
1
A B
7
7
58
58

11
5. Handlebar and Computer Installation
Remove two Ø16xØ8 Big Curve Washers (39) and two M8x20 Bolts (47) from the Handlebar
Post (3). Remove bolts with the 5mm Allen Wrench provided.
Insert the Hand Pulse Sensor Wires (53) into the hole on the Handlebar Post (3) and then
pull them out from the top end of the Handlebar Post (3).
Attach the Handlebar (2) onto the Handlebar Post (3) with two Ø16xØ8 Big Curve Washers
(39) and two M8x20 Bolts (47) that were removed. Tighten bolts with the 5mm Allen
Wrench provided.
Remove four M5x10 Bolts (61) from the Computer (10). Remove bolts with the Multi Hex
Tool with Phillips Screwdriver provided.
Connect the Hand Pulse Sensor Wires (53) and Extension Sensor Wire (59) to the wires that
come from the Computer (10). Tuck wires into the Handlebar Post (3). Attach the
Computer (10) onto the top end of the Handlebar Post (3) with four M5x10 Bolts (61) that
were removed. Tighten bolts with the Multi Hex Tool with Phillips Screwdriver provided.
Allen Wrench 5mm
Multi Hex Tool with Phillips Screwdriver
Tool:
3
2
39
47
53
59
61
53
10
3
3

12
OPERATING THE COMPUTER
SPECIFICATIONS:
TIME --------------------------------------------------- 0:00-99:59 MIN: SEC
SPEED ------------------------------------------------ 0.0-999.9 KM/H
DIST (DISTANCE) ---------------------------------- 0.00-99.99 KM
CAL (CALORIES) -----------------------------------0.0-999.9 KCAL
ODO (ODOMETER) --------------------------------0.0-999.9 KM
PULSE ------------------------------------------------ 40-240 BEATS/MIN
USING YOUR COMPUTER
The computer can be activated by pressing the button or by pedaling. If you leave the
equipment for 4 minutes, the power will turn off automatically.
BUTTON FUNCTIONS:
Press the MODE button to select each function of the computer.
Press and hold the MODE button for 3 seconds to reset all data values to zero except the
ODOMETER data values.
COMPUTER FUNTIONS:
SCAN: Automatically scans each function in sequence with change every 6 seconds.
NOTE: If you do not want to use the SCAN function, press the MODE button to select one of
the other functions.
TIME: Displays your elapsed workout time in minutes and seconds.
SPEED: Displays the current training speed.
DIST (DISTANCE): Displays the cumulative distance traveled during workout.
CAL (CALORIES): Displays approximate amount of calories burned during workout.
(This data is a rough guide for comparison of different exercise sessions and should not be
used in medical treatment).
ODO (ODOMETER): Displays the total accumulative distance traveled. The ODOMETER
data values can not be clear to zero by pressing and holding the MODE button for 3 seconds.
If you take out the batteries from the computer, the ODOMETER data values will clear to
zero.
PULSE: Displays your current heart rate figures after you grip the handlebar pulse sensors
with both your hands during exercise. To ensure the pulse readout is more precise, please
always hold on to the handlebar pulse sensors with two hands instead of just with one hand
only when you try to test your heart rate figures.
HOW TO INSTALL THE BATTERIES:
1. Remove the battery cover on the back of the computer.
2. Place two "SIZE-AA" batteries into the battery housing.
3. Insure batteries are correctly positioned and battery springs are proper contact with
batteries.
4. Re-install the battery cover.
5. If the display is illegible or only partial segment appear, remove batteries and wait 15
seconds before reinstalling.

13
ADJUSTMENTS
Adjusting the Tension Control Knob
To increase the load, turn the tension control knob in a
clockwise direction.
To decrease the load, turn the tension control knob in a
counterclockwise direction.
Adjusting the Rear Stabilizer End Cap
Turn the rear stabilizer end cap on the rear stabilizer as
needed to level the upright bike.
Adjusting the Seat Height
Turn the seat post knob in a counterclockwise direction
until it can be pulled out. Pull out the seat post knob and
then slide the seat post up or down direction to the suitable
position. Lock the seat post in place by releasing the seat
post knob and sliding the seat post up or down slightly until
the seat post knob "pops" down into the locked position.
For added safety, tighten the seat post knob in a clockwise
direction.
NOTE: When adjusting the height of seat post, make
sure the seat post bushing does not exceed the mark
line on the seat post.
Tension Control Knob
Rear Stabilizer End Cap
Seat Post Knob

14
MAINTENANCE
Cleaning
The upright bike can be cleaned with a soft cloth and mild detergent. Do not use abrasives
or solvents on plastic parts. Please wipe your perspiration off the upright bike after each
use. Be careful not get excessive moisture on the computer display panel as this might
cause an electrical hazard or electronics to fail.
Please keep the upright bike, specially, the computer console, out of direct sunlight to
prevent screen damage.
Please inspect all assembly bolts and pedals on the machine for proper tightness every
week.
Storage
Store the upright bike in a clean and dry environment away from children.
TROUBLESHOOTING
PROBLEM SOLUTION
The upright bike wobbles when in use. Turn the rear stabilizer end cap on the rear
stabilizer as needed to level the upright bike.
There is no display on the computer
console.
1. Remove the computer console and verify
the wires that come from the computer
console are properly connected to the
wires that come from the handlebar post.
2. Check if the batteries are correctly
positioned and battery springs are in
proper contact with batteries.
3. The batteries in the computer console may
be dead. Change to new batteries.
There is no heart rate reading or heart rate
reading or is erratic / inconsistent.
1. Make sure that the wire connections for
the hand pulse sensors are secure.
2. To ensure the pulse readout is more
precise, please always hold on to the
handlebar grip sensors with two hands
instead of just with one hand only when
you try to test your heart rate figures.
3. Gripping the hand pulse sensors too tight.
Try to maintain moderate pressure while
holding onto the hand pulse sensors.
The upright bike makes a squeaking noise
when in use. The bolts may be loose on the upright bike, please inspect the bolts and tighten the loose
bolts.

15
WARM UP AND COOL DOWN ROUTINE
The WARM-UP is an important part of any workout. The purpose of warming up is to
prepare your body for exercise and to minimize injuries. Warm up for two to five minutes
before aerobic exercising. It should begin every session to prepare your body for more
strenuous exercise by heating up and stretching your muscles, increasing your circulation
and pulse rate, and delivering more oxygen to your muscles.
COOL DOWN at the end of your workout, repeat these exercises to reduce soreness in tired
muscles. The purpose of cooling down is to return the body to its resting state at the end of
each exercise session. A proper cool-down slowly lowers your heart rate and allows blood
to return to the heart.
HEAD ROLLS
Rotate your head to the right for one count, you should feel a
stretching sensation up the left side of your neck. Then rotate your
head back for one count, stretching your chin to the ceiling and
letting your mouth open. Rotate your head to the left for one count,
then drop your head to your chest for one count.
SHOULDER LIFTS
Lift your right shoulder toward your ear for one count. Then lift your
left shoulder up for one count as you lower your right shoulder.
SIDE STRETCHES
Open your arms to the side and lift them until they are over your head.
Reach your right arm as far toward the ceiling as you can for one
count. Repeat this action with your left arm.

16
QUADRICEPS STRETCH
With one hand against a wall for balance, reach behind you and pull
your right foot up. Bring your heel as close to your buttocks as
possible. Hold for 15 counts and repeat with left foot.
HAMSTRING STRETCHES
Extend your right leg. Rest the sole of your left foot
against your right inner thigh. Stretch toward your toe
as far as possible. Hold for 15 counts. Relax and then
repeat with left leg.
CALF/ACHILLES STRETCH
Lean against a wall with your left leg in front of the right and
your arms forward. Keep your right leg straight and the left
foot on the floor; then bend the left leg and lean forward by
moving your hips toward the wall. Hold, then repeat on the
other side for 15 counts.
TOE TOUCHES
Slowly bend forward from your waist, letting your back and
shoulders relax as you stretch toward your toes. Reach as far as
you can and hold for 15 counts.
INNER THIGH STRETCH
Sit with the soles of your feet together and your knees pointing
outward. Pull your feet as close to your groin as possible.
Gently push your knees toward the floor. Hold for 15 counts.
