Life Span CORTEX PR-2 User manual

NOTE: This manual may be subject to updates or changes. Up to date manuals are available through our website at www.lifespanfitness.com.au
Product may vary slightly from the item pictured due to model upgrades
Read all instructions carefully before using this product. Retain this owner’s manual for future
reference.
PR-2 HALF RACK

2
PR-2 HALF RACK
TABLE OF CONTENTS
1. IMPORTANT SAFETY INSTRUCTIONS 3
2. PARTS LIST 4
3. ASSEMBLY INSTRUCTIONS 6
4. WARRANTY 13

3
PR-2 HALF RACK
1. IMPORTANT SAFETY INSTRUCTIONS
WARNING - Read all instructions before using this machine.
Install the product on a flat level surface
Place your unit on a solid, level surface when in use
Never allow children on or near the machine.
Keep hands away from all moving parts.
Never drop or insert any object into any openings.
Care must be taken when lifting or moving the equipment so as not to injure your back. Always use
proper lifting techniques and/or seek assistance if necessary.
Keep children and pets away from the machine at all times. DO NOT leave children unattended in the
same room with the machine.
Only 1 person at a time should use the machine.
If the user experiences dizziness, nausea, chest pain, or any other abnormal symptoms, STOP the
workout at once. CONSULT A PHYSICIAN IMMEDIATELY
Do not use the machine near water or outdoors.
Keep hands away from all moving parts.
Always wear appropriate workout clothing when exercising. DO NOT wear robes or other clothing that
could become caught in the machine. Running or aerobic shoes are also required when using the
machine.
Use the machine only for its intended use as described in this manual. DO NOT use attachments not
recommended by the manufacturer.
Do not place any sharp objects around the machine.
Disabled person should not use the machine without a qualified person or physician in attendance.
Never operate the machine if the machine is not functioning properly.
A spotter is recommended during exercise.
2. PARTS LIST

4
PR-2 HALF RACK
KEY
NO.
ITEM NO.
NAME
Qty.
N.W
1
PR2-1
Main Base Frame
1
4.948
2
PR2-2
Right Base Frame
1
4.489
3
PR2-3
Left Base Frame
1
4.489
4
PR2-4
Tall Vertical Frame
2
6.611x2
5
PR2-5
Short Vertical Frame
2
2.827x2
6
PR2-6
Lat Support
1
4.033
7
PR2-7
Center Cross Support
2
1.498x2
8
PR2-8
Plate Support
2
0.725x2
9
PR2-9
Dip Frame
1
2.967
10
PR2-10
Strengthen Board
12
0.158x12
11
60 Middle Sheet
2
12
50 End Cap
4
13
32 Handle Cover
2
14
Washer Ф10
28
15
M10mm Aircraft Nut
24
16
Carriage Bolt M10x70mm
24
17
60×50 Middle Sheet
2
18
Lock Knob
1
19
PR2-11
Bar Support
2
2.193x2
20
PR2-12
Lat Handle A
1
0.837
21
PR2-13
Lat Handle B
1
0.837
22
Allen Bolt M10x20mm
4
23
Handle Cover
2
24
Plate Rest
4
25
Ball Pin
1

5
PR-2 HALF RACK

6
PR-2 HALF RACK
3. ASSEMBLY INSTRUCTIONS
STEP 1
1. Attach the Tall Vertical Frame
(4#) and Short Vertical Frame (5#) to
the Right Base Frame (2#).
Secure it with:
- 2x Strengthen Board (10#)
- 4x Carriage Bolt M10*70mm
(16#)
- 4x Washer 10 (14#)
- 4x M10mm Aircraft Nut (15#)
2. Attach the Tall Vertical Frame
(4#) and Short Vertical Frame (5#) to
the Center Cross Support (7#).
Secure it with:
- 2x Strengthen Board (10#)
- 4x Carriage Bolt M10*70mm
(16#)
- 4x Washer 10 (14#)
- 4x M10mm Aircraft Nut (15#).
3. Tighten all the bolts and nuts.
4. Loosen the screw (M) on the
Plate Rest (24#) and push them onto
the 25 Circular Steel Tube of the
Short Vertical Frame (5#) then
tighten the screw (M).
4
5
16
16
24
24
14
15
7
15
14
14
14
15
15
15
15
15
15
14
14
14
16
16
16
16
16
16
10
10
10
M
M
10
14
2

7
PR-2 HALF RACK
STEP 2
1. Attach the Tall Vertical Frame (4#) and
Short Vertical Frame (5#) to the Left Base
Frame (3#).
Secure it with:
-2x Strengthen Board (10#)
-4x Carriage Bolt M10*70mm (16#)
-4x Washer 10 (14#)
-4x M10mm Aircraft Nut (15#)
2. Attach the Tall Vertical Frame (4#) and
Short Vertical Frame (5#) to the Center
Cross Support (7#).
Secure it with:
-2x Strengthen Board (10#)
-4x Carriage Bolt M10*70mm (16#)
-4x Washer 10 (14#)
-4x M10mm Aircraft Nut (15#)
3. Tighten all the bolts and nuts.
4. Loosen the screw (M) on the Plate
Rest (24#) and push them onto the 25
Circular Steel Tube of the Short Vertical
Frame (5#) then tighten the screw.
15
4
24
24
15
15
15
15
15
15
15
M
M
14
14
14
14
14
14
14
14
15
5
10
10
10
10
16
16
16
16
16
16
16
16
3

8
PR-2 HALF RACK
STEP 3
1. Attach P and Q to the Main Base Frame (1#).
Secure it with:
-2x Strengthen Board (10#)
-4x Carriage Bolt M10*70mm (16#)
-4x Washer 10 (14#)
-4x M10mm Aircraft Nut (15#)
2. Tighten all nuts and bolts.
Q
P
16
16
16
16
10
10
14
14
14
14
15
15
15
15
1

9
Power Rack PR-2
STEP 4
1. Plug the Dip Frame (9#) into the Tall Vertical Frame (4#). You can choose the left side or right side.
Secure with Lock Knob (18#) and Push the Ball Pin (25#) into the holes on Tall Vertical Frame (4#).
4
4
18
25
9

10
Power Rack PR-2
STEP 5 1. Attach the Lat
Support (6#) to the left
and right Tall Vertical
Frame (4#).
Secure it with:
-2x Strengthen Board
(10#)
-4x Carriage Bolt
M10*70mm (16#)
-4x Washer 10 (14#)
-4x M10mm Aircraft Nut
2. Tighten all the bolts
and nuts.
3. Attach the Lat Handle
A, B (20#, 21#) to the Lat
Support (6#).
Secure it with:
-4x Allen Bolt
M10*20mm (22#)
-4x Washer 10(14#)
22
22
22
22
14
14
14
14
14
14
14
14
15
15
15
15
6
21
20
10
10
16
16
16
16
4
4

11
Power Rack PR-2
STEP 6
1. Plug the 2x Bar Support (8#) into the Left and Right Tall Vertical Frame (4#).
2. Plug the 2x Bar Rest (19#) into the Left and Right Tall Vertical Frame (4#).
19
19
4
4
8
8

12
Power Rack PR-2
4. WARRANTY
AUSTRALIAN CONSUMER LAW
Many of our products come with a guarantee or warranty from the manufacturer. In addition, they come with
guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or
refund for a major failure and compensation for any other reasonably foreseeable loss or damage.
You are entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure. Full details of your consumer rights may be found at www.consumerlaw.gov.au
Please visit our website to view our full warranty terms and conditions:
http://www.lifespanfitness.com.au/warranty-repairs
Warranty and Support:
Please email us at suppor[email protected]om.au for all warranty or support issues.
For all warranty or support related enquiries an email must be sent to lodge a support case in our system.
Head Office and Customer Service:
Global Fitness and Leisure Pty Ltd
17 Fordson Rd
Campbellfield
VIC, 3061
Australia
PH: 03 9357 2166
