LifeSize®Express 200TM Installation Guide

2 LifeSize Express 200 Installation Guide
November 2009
Copyright Notice
©2005 - 2009 LifeSize Communications Inc, and its licensors. All rights reserved.
LifeSize Communications has made every effort to ensure that the information contained in this
document is accurate and reliable, but assumes no responsibility for errors or omissions. Information
in this document is subject to change without notice. Companies, names, and data used in examples
herein are fictitious unless noted. This document contains copyrighted and proprietary information,
which is protected by United States copyright laws and international treaty provisions. No part of the
document may be reproduced or transmitted, in any form or by any means, electronic or mechanical,
for any purpose, without the express written permission from LifeSize Communications.
Trademark Acknowledgments
LifeSize® is the trademark of LifeSize Communications Inc. All other trademarks are the property of
their respective owners.
Patent Notice
For patents covering LifeSize® products, refer to http://www.lifesize.com/support/legal.
Contacting Technical Services
If you have questions, concerns, or need assistance, contact your LifeSize Partner.
Providing Customer Feedback
LifeSize Communications welcomes your comments regarding our products and services. If you have
feedback about this or any LifeSize product, please send it to [e-mail]. Contact
information for LifeSize Communications is as follows:
Method Address
Internet http://www.lifesize.com
Email [email protected]
Phone (877) LIFESIZE or [phone]
[phone]
Fax [phone]

LifeSize Express 200 Installation Guide 3
Preparing for Installation
As you prepare to install a LifeSize video communications system, consider the physical
conditions of the room, compatibility with displays and your network configuration and
settings. LifeSize recommends you collect your network settings and system identification
information before you begin installation. Refer to “Initial Configuration” on page 5, which
explains what information you need to collect and provides space to record it.
Room Configuration
The size, shape, layout and occupancy of the room dictate where you place your video
conferencing components. For example, in a small office installation, LifeSize Focus can be
placed at one end or corner of the room, as its beam forming microphone array cancels out
echo from wall reflections behind it and picks up clear sound up to 2.7 meters (9 feet) in front
of it; in a multi-user conference room, place a LifeSize MicPod or LifeSize Phone at the
center of the participants as their detection patterns are omnidirectional.
Warning: Avoid routing cables from the codec across foot-traffic areas as tripping on
the cables can cause both personal injury and permanent damage to the connectors in
the cables and codec. If cables must cross foot-traffic areas, use some form of cable
management system or strategy to avoid the possibility of tripping.
The lighting in your environment affects image quality. The optimal lighting for LifeSize
systems is 300 to 500 LUX. If light levels are too low, consider adding artificial lighting.
Indirect light from shaded sources or reflected light from pale walls often produces excellent
results. Avoid the following:
• direct sunlight on the subject matter, the background, or the camera lens
• direct illumination of the subject matter and camera lens
• colored lighting
• harsh side lighting or strong light from above
Consult your administrator or LifeSize Partner for specific lighting requirements for your
environment.

4 LifeSize Express 200 Installation Guide
Supported Display Types and Resolutions
LifeSize Express 200 can connect to HD displays (720p minimum) through an HDMI cable,
including:
• Plasma, LCD, and LED flat panel displays
• Large screen rear projection TV displays (720p displays)
• Front projection displays
• Rear projector A/V room configurations
Supported display resolutions include the following:
• Display 1:
-1280 x 720p60
-1280 x 768p60
Note: The Display 1 Resolution preference in Administrator Preferences :
Appearance : Displays defaults to Auto if you select an option for this preference that
is not supported by the connected display.
• Display 2:
-1280 x 720p60
Placement Behind a Firewall
LifeSize recommends that you place your system behind a firewall and block, at minimum,
the following ports:
• 22 (SSH)
• 23 (Telnet)
• 80 (HTTP)
• 443 (HTTPS)
If you require these ports remain open, ensure that you change the default administrator and
command line interface passwords to be very secure. For information about changing the
default administrator password, refer to the LifeSize Video Communications Systems
Administrator Guide.
For information about changing the command line interface password, refer to the LifeSize
Automation Command Line Interface document available on the Support page of
www.lifesize.com.

LifeSize Express 200 Installation Guide 5
You can also disable SSH and web access on the system by configuring preferences in the
user interface. By default, Telnet access is disabled. For more information, refer to the
LifeSize Video Communications Systems Administrator Guide.
Network Bandwidth
Poor audio and video quality may result from insufficient bandwidth on your network.
LifeSize recommends that your network be capable of at least 1 Mb/s (incoming and
outgoing) for a high definition video call. During video calls with lower bandwidths, LifeSize
systems automatically select the best resolution that can be achieved with the available
bandwidth.
Domain Name Service Server
If you intend to use domain addresses for placing calls you must configure a Domain Name
Service (DNS) server, or use a Dynamic Host Configuration Protocol (DHCP) server that
automatically sets a DNS server.
Initial Configuration
During the installation process, your LifeSize system prompts you to configure it for the first
time. LifeSize recommends that you gather all the necessary information prior to installation.
The following sections provide guidelines for collecting and a means of recording this data.
You may need to consult your network administrator for network settings and system
identification information.
Note: The initial configuration screens also appear when you perform a system reset. For
more information, refer to “Restoring Default Settings” in the LifeSize Video
Communications Systems Administrator Guide.
Language
Select the language to display in the user interface. The default is English.

6 LifeSize Express 200 Installation Guide
Administrator and User Passwords
Some functions and preferences available from the user interface are accessible only to
administrative users with a password. For security reasons, LifeSize recommends that you
change the default administrator password (1 2 3 4) during the initial configuration.
Optionally, you can set a user password to control access to user preferences that enable
the user to do the following:
• Change the appearance of the user interface.
• Specify how calls are answered.
• Configure audio settings.
• Change cameras and DVI-I input settings.
• Reboot the system.
The administrator and user passwords can contain any combination of the numbers 0-9 and
the symbols * (star) and # (pound) up to 16 characters in length.
Note: If you set a user password, you can also use the administrator password to access
user preferences.
Administrator Password: ________________________________________________
User Password: _______________________________________________________
System Identification
Information that identifies the system to users appears throughout the user interface.
Set the Location preference to your location. The default is the United States. The Time
Zone preference sets the system time that appears in the status bar on the main page of the
user interface. It defaults to Greenwich Mean Time. You must set this preference even if you
specify an NTP server during the initial configuration (refer to “Network Settings” on page 7).
The System Name, Video Number, and Voice Number appear in the user interface on the
main screen. The system name may also appear in the local and corporate directories.
LifeSize recommends that you change the default system name to one that meaningfully
identifies the system to your users.
System Name: (to identify this installation in the network): ______________________
Video Number: ________________________________________________________
Voice Number: ________________________________________________________

LifeSize Express 200 Installation Guide 7
Video and Voice Dialing Preferences
LifeSize systems support either the IP or ISDN protocol for video dialing. The default setting
for the Video Dialing preference is Auto which enables the system to determine the best
method to use to place calls.
LifeSize Express 200 supports VoIP and ISDN for voice calls. VoIP uses H.323 or SIP.
When placing a call using the Voice button on a LifeSize Phone connected to the system,
you can dial IP addresses as well as VoIP or ISDN phone numbers.
When placing a call using the remote control or using the Video button on the phone you
can dial IP addresses. This enables systems inside a corporate network without access to a
gateway to call other LifeSize systems in the network using system IP addresses.
Network Settings
By default, DHCP is enabled on LifeSize systems. If you choose Disabled for the DHCP
preference, you must enter an IP address (the locally configured IP address if not assigned
by a DHCP server), Subnet Mask (used to partition the IP address into a network and host
identifier), and Default Gateway (the IP address of the default gateway the system uses).
IP Address: ___________________________________________________________
Subnet Mask: _________________________________________________________
Default Gateway: ______________________________________________________
You can enter the Hostname of the system. If you do not have a DHCP server that
automatically sets a DNS server, you can enter the IP addresses to configure DNS Servers.
You can also define the domain names to search when resolving hostnames. DNS
translates names of network nodes into addresses; specify this preference to use DNS to
resolve the hostnames of devices to IP addresses.
Hostname: ____________________________________________________________
DNS Servers:__________________________________________________________
Name Search Domains: _________________________________________________
If you choose an option other than Auto (the default) for the Network Speed preference,
ensure that the option matches the speed and duplex configured on your network switch.
Network Speed: ________________________ Network Duplex: _________________
You can enter the hostname or IP address of a Network Time Protocol (NTP) server to set
the system date and time automatically. The LifeSize system ignores the value you specify
for the NTP Server Hostname if the DHCP preference is set to Enabled and the DHCP
server can pass an NTP server address to the LifeSize system.
Network Time Protocol (NTP): ____________________________________________

8 LifeSize Express 200 Installation Guide
Audio Preferences: Active Microphone
The default for the Active Microphone preference is Auto. The system detects attached
audio input devices and selects one to be the active microphone in the following order:
• phone
• microphone in
• camera 1
If you wish to use a device connected to line in on the codec as the active microphone, you
must choose line in manually for Active Microphone.
The Active Microphone field in the System Information page shows which device is
functioning as the active microphone. When the value is None, the No Active Microphone
indicator appears in the status bar on the main screen of the user interface indicating
that no active microphone is available. You can view the System Information page after
you install the system and complete the initial configuration. From the main screen, press
the button on the LifeSize remote control.
Note: If you choose Line In or Line In (No AEC) as the active microphone, and a device is
not connected to line in on the codec, the System Information page shows line in
as the status for Active Microphone. The No Active Microphone indicator does not
appear in the user interface.
The Microphone In (No AEC) and Line In (No AEC) options for the Active Microphone
preference are for use with a microphone that has its own acoustic echo canceller (AEC).
Audio Preferences: Active Microphone Volume
You can adjust the audio level for the active microphone by selecting Active Microphone
Volume and pressing OK on the LifeSize remote control.
Note: A built-in acoustic echo canceller and noise reducer are active when Microphone In,
Camera 1, or Line In is the active microphone. The built-in acoustic echo canceller
automatically attempts to adjust audio volume for optimum levels.

LifeSize Express 200 Installation Guide 9
An audio meter appears below Active Microphone Volume when you access the
preference. The audio meter follows the digital signal processing, Automatic Gain Control
(AGC), and volume and tone controls on the transmitted voice path as depicted in the
following illustration.
The dotted line illustrates the audio path when Microphone In (No AEC) or Line In (No AEC)
is selected as the active microphone. This mode is useful for setting up system gains but
should never be used during calls unless the installation includes audio inputs with external
AEC. Echo may occur if no AEC is employed.
If you choose LifeSize Phone as the active microphone, the Active Microphone Volume
preference is not available. The LifeSize Phone microphones adjust volume automatically.
The voice stream bypasses all processing in the LifeSize system, including the volume and
tone controls, and is fed directly into the transmitted voice path.
The audio meter displays the level of the transmitted voice in decibels (dB) root mean
square (RMS) below digital full scale (DFS). The meter is accurate to ± 1 dB. The maximum
level is 0 dB. Levels below –50 dB are not displayed, and indicate a very quiet or inactive
input. Typical levels during a call peak around –28 to –22 dB DFS. The AEC and AGC
attempt to keep the RMS transmit level below –20 dB DFS. The following images show what
appears in an audio meter at various levels.
LifeSize Phone
Line In
LifeSize
MicPod
Other Digital Inputs
Volume and
Tone Control
Transmitted
Voice/Audio
DSP, AGC,
Echo Canceller
A/D
Audio Meter
A/D

10 LifeSize Express 200 Installation Guide
Very Quiet or Inactive Input below -50 dB (no bars)
-20 db DFS Level (Last Green Bar)
-10 db DFS Level (Last Yellow Bar)
0 db DFS Level (Maximum Possible Level; First Red Bar is -9 dB)
Typical Transmit Voice Level in a Call
When setting Active Microphone Volume for LifeSize MicPod or LifeSize Focus, place
someone where a participant in a call would normally sit in the conference room and ask the
person to speak at a normal volume facing the active microphone.
Use the audio meter to visually verify that the transmit level peaks in the desired -28 to -22
dB range.
LifeSize recommends a volume setting of 5 to 8 for Active Microphone Volume for most
LifeSize MicPod applications.

LifeSize Express 200 Installation Guide 11
LifeSize recommends a volume setting of 5 to 10 for Active Microphone Volume for most
LifeSize Focus applications.
If you set Active Microphone Volume to line in when using an external mixer or amplified
microphone, follow these steps:
1. Select Line in (no AEC) for Active Microphone.
2. Position someone approximately one meter from the microphone, facing it, speaking at
a normal volume.
3. Adjust the Active Microphone Volume and the external mixer output level until the
meter peaks in the -28 to -22 dB range. LifeSize recommends you adjust the external
mixer volume so that you achieve peak levels in the -28 to -22 dB range of the audio
meter with the Active Microphone Volume control set to no less than 5 or greater than
15.
4. If the microphone or mixer you use employs an echo canceller, no further adjustments
are necessary. Otherwise, select Line In for Active Microphone. This turns on the
LifeSize system’s echo canceller, noise reduction, and automatic gain control functions.
If you do not use an echo canceller, you may experience severe echo effects.
5. After the adjustment, check that the peak levels when speaking normally one meter from
the microphone are in the -28 to -22 dB range. The AGC attempts to keep the transmit
level below -20 dB, which is the green range of the bar graph.
An audio meter is also available for the Line In Volume preference for setting an audio level
for a device connected to line in on the codec when line in is not selected as the active
microphone.
Audio Preferences: Video and Voice Call Output
If you plan to use external speakers other than LifeSize Phone for audio output in both video
and voice calls, ensure that the Video Call Audio Output and Voice Call Audio Output
preferences are set to Line Out. By default, Video Call Audio Output is set to Line Out;
Voice Call Audio Output is set to Phone. If you are using LifeSize Phone for audio, set
these preferences to Phone.
Audio Preferences: Testing Speakers
You can also test the primary output speakers for the appropriate audio level or to ensure
they are working properly. Select Auto for Primary Audio Output Test to cycle through a
test on your available speakers. The test continues until you select Off. You can also send
the tone to either the left or right channel by choosing Test Left or Test Right. The tone is
sent simultaneously to both line out and the HD video out of display 1.

12 LifeSize Express 200 Installation Guide
LifeSize Express 200 Components
Your LifeSize Express 200 package contains the following components:
• One of the following audio components:
-LifeSize Focus
-LifeSize MicPod—see “Optional Peripherals” on page 17 for the dual
LifeSize MicPod option
-LifeSize Phone
• One of the following cameras and cables:
-LifeSize Focus
• Standard 2.9 meter (9.5 foot) cable, optional 7.5 meter (24.6 foot) or 15 meter
(49.2 foot) cables
-LifeSize Camera
• Standard 7.5 meter (24.6 foot) cable, optional 15 meter (49.2 foot) cable
• LifeSize Express 200 Codec
• LifeSize Remote Control (including three AAA batteries)
• Quick reference card
• Documentation CD
Installing LifeSize Express 200
Before you install a LifeSize video communications system, read the document LifeSize
Safety and Regulatory Notices for important safety information. The document is available
on the documentation CD-ROM and from the Support page of www.lifesize.com.
Warning: Exercise care when connecting cables to the codec to avoid damaging
cables or the connectors on the codec. Face the back of the codec or ensure that all
connectors are visible when connecting a cable to the codec.
To install the components of your LifeSize system, remove all components from the product
packaging, including cables, and place them in the desired positions in your conference
room.

LifeSize Express 200 Installation Guide 13
Warning: Do not place anything on top of or adjacent to the codec that can obstruct
air flow around the unit or generate heat. Doing so can cause the system to overheat
and reboot. Prolonged overheating can result in damage to the codec. Ensure the room
that houses the codec is properly ventilated and temperature controlled.
Refer to the LifeSize quick reference card included with your system for a visual depiction of
the proper setup. The numbers that appear on the quick reference card correspond to the
following steps:
1. Open the battery compartment on the back side of the remote control.
a. Before inserting the batteries, stretch each of the two straps across the outer battery
slot closest to it.
b. Insert the two outer batteries, negative end (-) first against the spring, then press the
positive (+) end into place, trapping the cloth straps beneath the batteries.
c. Lay the longer cloth strap over both batteries and insert the center battery’s negative
end against the spring first to trap the longer cloth strap beneath it. Then press the
positive end of the battery into place.
d. Lay the ends of the cloth straps over the center battery and install the cover.
2. To connect to a LifeSize Camera (2a) or LifeSize Focus (2b), insert the camera cable
into the port on the rear side of the camera and plug the opposite end into the port
marked with the camera symbol on the back of the codec.
3. Insert a video display cable into the port on the rear of your display and the opposite end
into the port marked with the display 1 symbol on the back of the codec (3a).Insert
the display power cord into a power outlet on the wall.
Note: If you plan to use external speakers that are not built into the display, connect
the speakers to the port marked with the line out symbol on the back of the codec.
To connect a second display, insert a video display cable into the port on the rear of your
display and the opposite end into the port marked with the display 2 symbol on the
back of the codec (3b). Insert the display power cord into a power outlet on the wall. By
default, the second display is blank. After you complete the initial configuration, refer to
“Configuring a Second Display” on page 16 to complete this process.
4. Insert the network cable into the network port marked with the LAN symbol on the
back of the codec. Insert the opposite end of the network cable into a network port on
the wall.

14 LifeSize Express 200 Installation Guide
5. If you are using LifeSize Focus for both video and audio, you can skip step 5. Otherwise,
do one of the following:
a. If you are using a single LifeSize MicPod for audio, insert the end of the cable from
the LifeSize MicPod into the microphone port marked with the microphone symbol
on the back of the codec. If the LifeSize MicPod is installed in an area where the
cord could be pulled or tripped upon, refer to “Attaching the LifeSize MicPod Strain
Relief Clip” on page 19.
Warning: Tripping on the LifeSize MicPod cord can cause personal injury as well
as permanent damage to the LifeSize MicPod cord connector and the connector in
the codec. LifeSize recommends that you use the cable strain relief clip included in
the LifeSize MicPod product box as described in “Attaching the LifeSize MicPod
Strain Relief Clip” on page 19.
If you are using dual LifeSize MicPods for audio, refer to “Configuring Dual
LifeSize MicPods” on page 18 for a description of supported configuration options.
b. If you are using the LifeSize Phone for audio, insert the phone cable into the port
marked with the LAN symbol on the underside of the phone.
Note: The exterior port marked with the symbol on the LifeSize Phone is
reserved for future use.
Insert the opposite end of the phone cable into the port marked with the
LifeSize Phone symbol on the back of the codec. Ensure the cables are
secured into the guides to avoid damage to them.
Note: When the LifeSize Phone is connected to a LifeSize video communications
system, you are unable to configure it as a standalone speakerphone. Configure
your system using the LifeSize video communications system interface.

LifeSize Express 200 Installation Guide 15
6. Insert the cord from the power adapter into the power outlet marked on
the back of the codec. Insert one end of the power cord into the power adapter and the
opposite end into a power outlet.
The LifeSize system starts, illuminating a blue LED on the front of the codec. See
“Status Icons” on page 23 for more information about the state of the system as it boots
or as conditions change.
The camera initializes the first time it is connected to a codec; this process takes
approximately 90 seconds.
Warning: Do not disturb or disconnect the devices during this time as you may
damage the system.
7. An Initial Configuration screen appears and prompts you to configure the system.
Refer to “Initial Configuration” on page 5 and the information you collected there
previously to guide you through your configuration choices. Use the arrow keys on the
remote control to navigate the preferences that appear in the initial configuration
screens. Icons and their descriptions that appear at the bottom of each screen
correspond to keys on the remote control and indicate what operations are available for
the screen or a selected object.
If the initial configuration screen does not appear and the display is blank, refer to
“Troubleshooting Installation Issues” on page 20.
The bottom of the screen contains the system status bar and the navigation bar. The
system status bar indicates system and network status. When the system is booting,
status also appears at the top of the REDIAL list to indicate the current state of the
system. See “Status Icons” on page 23 for an explanation of status icons you may
encounter.
Locking the LifeSize Codec
You can lock the LifeSize codec with a secure loop to prevent physical removal of the
device. For assistance, contact your LifeSize Partner or LifeSize Technical Services.

16 LifeSize Express 200 Installation Guide
Configuring a Second Display
If you installed a second display, you must configure it. From the main screen of the user
interface, press on the LifeSize remote control to access the System Menu. Navigate to
Administrator Preferences : Appearance : Layout and choose Display 2 Layout, which,
by default is set to None. Choose Presentations + DVI-I Input to configure the second dis-
play. When configured, display 2 shows either DVI-I input or presentations (near and far
end) when a presentation is sent or received.
The following conditions apply when using two displays with LifeSize Express 200:
• The presentation icon that appears on screen during a call to indicate that a near or far
end presentation is in progress appears in display 1. For a presentation sent from a far
end participant, the receiving presentation icon appears in the upper left corner of
display 1; for a presentation sent from the near end, the sending presentation icon
appears in the lower right corner of display 1.
• Only presentation video or DVI-I input is supported for display 2. Background image and
color preferences that appear in User Preferences : Backgrounds and Administrator
Preferences : Appearance : Backgrounds are available for display 1 only. The user
interface appears only in display 1.

LifeSize Express 200 Installation Guide 17
Optional Peripherals
You can connect the following optional peripherals to enhance your LifeSize system:
Peripheral Usage
DVI-I In DVI-I port for connecting laptops for presentations or to share PC data. For
devices and PCs with VGA output, LifeSize includes a DVI-A to VGA
cable. An HDMI source can be used with an adapter. For more information
about supported resolutions and audio support, refer to the LifeSize Video
Communications Systems Administrator Guide.
Networker For use with LifeSize Networker.
Note: This port is also marked with the LifeSize Phone symbol and
can be used with either LifeSize Phone or LifeSize Networker.
Microphone in For use with a single or dual LifeSize MicPod configuration.
In a single LifeSize MicPod configuration, you can add a LifeSize MicPod
extension cable (15 meters, 49.2 feet) to the LifeSize MicPod.
In a dual LifeSize MicPod configuration, you use a combination of two
LifeSize MicPods, one splitter cable, and extension cables in large rooms
to create wider coverage of audio input. Refer to “Configuring Dual
LifeSize MicPods” on page 18.
Audio In (Line In) For use with an external line level audio input, in addition to the
LifeSize Phone or LifeSize MicPod.
Audio Out (Line Out) For use with external line level output speakers that are not built into
display 1 or with a headset (left plus right).
Warning: Excessive sound pressure from earphones and
headphones can cause hearing loss.

18 LifeSize Express 200 Installation Guide
Configuring Dual LifeSize MicPods
If you are using dual LifeSize MicPods, you can use the splitter cable to connect a
combination of extension cables and two LifeSize MicPods to the single LifeSize MicPod
port on your LifeSize codec for maximum omnidirectional audio coverage in large
conference rooms.
Dual LifeSize MicPod configurations are limited to two LifeSize MicPods and one splitter
cable. (You cannot use multiple splitters to connect to more than two LifeSize MicPods.)
However, you can use variations on three configurations of extension cables:
• If you connect the male end of the splitter directly to the codec, you can use none, or
one extension cable to connect a LifeSize MicPod to each of the female ends of the
splitter.
• If you use one extension cable to connect the codec to the splitter, you can use none, or
one extension cable to connect a LifeSize MicPod to each of the female ends of the
splitter.
• If you use two extension cables to connect the codec to the splitter, you must connect
both LifeSize MicPods directly to the female ends of the splitter.
If the LifeSize MicPods are installed in an area where the cord could be pulled or tripped
upon, refer to “Attaching the LifeSize MicPod Strain Relief Clip” on page 19.
Warning: Tripping on the cord can cause personal injury as well as permanent
damage to the LifeSize MicPod cord connector and the connector in the codec. LifeSize
recommends that you use the cable strain relief clip included in the LifeSize MicPod
product box as described in “Attaching the LifeSize MicPod Strain Relief Clip” on
page 19.
A LifeSize codec detects any splitter or cable attached to the microphone input of the codec
as a LifeSize MicPod. If a LifeSize MicPod is not attached to the extension or splitter cable
and the microphone input is selected as the active microphone, no audio is available. The
No Active Microphone indicator does not appear in the status bar and the Active
Microphone field in the System Information page reports Microphone In as the active
microphone.

LifeSize Express 200 Installation Guide 19
Attaching the LifeSize MicPod Strain Relief Clip
If the LifeSize MicPod is installed in an area where the cord could be pulled or tripped upon,
LifeSize recommends using the strain relief clip included with your LifeSize MicPod to
reduce the chance of disconnecting or damaging the plug or the LifeSize video
communications system codec.
Before attaching the strain relief clip to the codec, ensure that the codec surface is clean
(free of dirt, dust, oil, and other residues) and dry. The adhesive tape on the strain relief clip
is intended for a single use. Attach the strain relief clip to the codec and route the
LifeSize MicPod cable through the strain relief clip as shown in the following diagram.
To obtain a replacement strain relief clip, contact your LifeSize Partner.

20 LifeSize Express 200 Installation Guide
Verifying Your Installation
The LifeSize Video Communications Systems Administrator Guide explains how to place a
test call to verify your installation. It also explains additional adjustments you may need to
make to your LifeSize configuration and your network if you use:
• Network Address Translation (NAT)
• a firewall
• H.323 gatekeepers
• Session Initiation Protocol (SIP)
• other network security protocols
Troubleshooting Installation Issues
Installation issues that you may encounter with your LifeSize system typically involve issues
with display output, improperly connected cables, or network bandwidth or connectivity. For
information about troubleshooting other issues that users may encounter with LifeSize
systems refer to the LifeSize Video Communications Systems User Guide.
Improperly connected or loose cables are common causes of problems with hardware units.
When investigating a system problem, first inspect all the external controls and cable
connections. Ensure that connections are correct and secure, and that nothing is obstructing
the cables.
Configuring Display Output from LifeSize Phone
If you are using LifeSize Phone and your display shows the initial configuration screen but
the image is distorted and unusable or the display is blank, you can configure the display
from the LifeSize Phone user interface. Follow these steps:
1. Ensure that no calls are in progress.
2. Log in to the Admin Menu on your LifeSize Phone.
a. Press sequentially when the phone is idle.
b. Enter the administrator password (1 2 3 4 by default) and press .
3. Press 1on the keypad to select Preferences.
4. Press 1on the keypad to select Display 1.
5. Press the key to select Auto.
