LifeSize Icon User manual

Lifesize®Icon™ Guide
May 2014
Lifesize Icon 600
Lifesize Icon 800

Lifesize Icon Guide 2
Lifesize Icon Video Systems
Congratulations on joining Lifesize for the ultimate video conferencing experience!
Learn More About Your System
Extend the Capabilities
When these Lifesize products are integrated with your Icon system you can do the following:
Read more about Integrations.
To access the full set of features available with your Icon video system, your environment must include
UVC Platform with the UVC suite of applications. Refer to the documentation that accompanies these
products for detailed configuration information.
Related information is available from lifesize.com/support.
After installing your system, complete additional setup
tasks, such as changing default passwords and configuring
firewalls.
Deploying Your Icon Video System
Then, start placing calls. You can also manage your calls,
share data, and create recordings. Using Your Icon
Advanced preferences are available for additional
configuration. Preferences
Perform regular maintenance, such as software upgrades,
restoring default settings, and troubleshooting. Maintaining and Troubleshooting
You can optionally use shell commands to control your
system with the Icon API. Icon Video System API
Lifesize Cloud A cloud-based video service that supports desktop and mobile video
collaboration with your Icon.
UVC ClearSea Supports desktop and mobile video collaboration with your Icon.
UVC Multipoint A flexible capacity MCU allowing you to access calls hosted by the
bridge directly from your Icon.
UVC Video Center Provides video recording and publishing directly from your Icon.
UVC Manager Enables IP management of devices. Calls scheduled on UVC Manager
appear in your Icon schedule.
UVC Transit Provides a firewall and NAT traversal solution that enables video calls
within and across enterprises and organizations.
UVC Access A standalone H.323 gatekeeper that provides address translation,
network access control, bandwidth management, and routing
management for H.323 calls to gateways, video systems, and MCUs.
Lifesize Bridge Enables multiway video conferences. You can access calls hosted by
the bridge directly from your Icon.

Lifesize Icon Guide 3
Section 1: Deploying Your Icon Video System
Configuration Overview
When you first install your system, a wizard directs you to configure the language, network settings, and
time zone. You can also choose to connect your Icon to the Lifesize Cloud service at this time.
After installation, configure your video system:
1. Open a web browser.
2. Navigate to the system IP address. This appears in on the main screen.
Lifesize Cloud users: select >to view the IP address.
3. To learn about your system’s configuration preferences, click Help.
After installation you can configure the following:
Configuration Description Read More
Lifesize Cloud If you did not connect your Icon to Lifesize Cloud during initial
configuration, reset your system to associate it with your Lifesize Cloud
account.
Connecting to
Lifesize Cloud
Integrations Integrate your video system with Lifesize Cloud, the Lifesize UVC suite of
applications, and Lifesize Bridge. Integrations
Administrator
passwords BROWSER: Manage administrator passwords in Preferences > Passwords. System Access and Passwords
Date and time BROWSER: Set the system date and time and time zone in Preferences >
Date and Time.Help
Language BROWSER: Select the language for the system’s interface in Preferences
> Appearance.
REMOTE CONTROL: Select >.
NOTE: To change the language of your system’s web interface, select
Language in the sign-in screen of the web interface.
Help
System name BROWSER: Define the system name in Preferences > System.
Lifesize Cloud users: Your system name is defined through Lifesize Cloud
when you connect the Icon to the service.
Help
Safe area REMOTE CONTROL: If the day, date, and time are not fully visible in the
upper right corner of your display, select >to adjust the safe area. Help
Dual displays BROWSER: If your video system is connected to two displays, select your
display configuration in Preferences > Appearance > Physical Display
Arrangement.
Dual Displays
Help
H.323 BROWSER: If you are using H.323 gatekeepers and want to place calls
using a name or extension with the H.323 protocol, configure your Lifesize
system to use H.323 in Preferences > H.323.
Help

Lifesize Icon Guide 4
System Access and Passwords
SIP BROWSER: If you are using SIP servers, configure your Lifesize system to
use SIP in Preferences > SIP Registrar 1 and Preferences > SIP
Registrar 2.
Help
Calls, audio, and
video BROWSER: Configure call, audio, and video preferences:
•Preferences > Calls
•Preferences > Audio
•Preferences > Video
Help
Firewall Configure your video system for firewall traversal. Configuring Your
Firewall
Automatic
provisioning Enable your video system to discover a provisioning server and to configure itself with settings that are specified on the server. ProvisioningYour Icon through
UVC ClearSea
DHCP By default, DHCP is enabled on Lifesize systems. If you disable DHCP,
you must specify the system’s IP address, subnet mask, and default
gateway.
BROWSER: Preferences > Network
REMOTE CONTROL: Select >and enter the passcode (by default,
1234) to access .
Lifesize Icon
Installation Guide
Remote control Select >and enter the passcode (by default, 1234) to access a limited set of
administrator functions from the video system’s display:
Enable or disable DHCP. When DHCP is disabled, you can set the IP address, netmask,
default gateway, and address of the static DNS server.
Reset network settings.
Reset all settings.
Revert to the alternate software version and reset all settings to their default values.
Browser Open a web browser and enter the IP address of the Lifesize system. Sign in with administrator
credentials. The default username and password are admin.
The IP address of the system appears in on the main screen.
Lifesize Cloud users: select > to view the IP address.
By default, remote management of a Lifesize video system over HTTP is enabled at
Preferences > Security > Enable Remote Management Over HTTP.
CAUTION: Disabling HTTP signs you out and prevents you from signing back in to the system.
SSH Sign in with administrator credentials in an SSH session and enter commands to manage your
Lifesize system remotely. The default username and password are admin. Read more at Icon
Video System API.
By default, remote management over SSH is enabled at Preferences > Security > Enable
SSH Access.
CAUTION: Disabling SSH prevents you from managing the system remotely over SSH.
UVC Manager With UVC Manager, administrators can manage your Lifesize video system and other video
systems across the enterprise.
Configuration Description Read More

Lifesize Icon Guide 5
Sign in to your video system from a web browser and navigate to Preferences > Passwords to manage
passwords:
Passwords can be up to 16 characters in length and contain any combination of the numbers 0-9, the
letters a-z and A-Z, and the symbols * (star) and # (pound). The passcode must be one to 32 characters in
length and contain any combination of the numerals 0-9.
You cannot change the username.
Integrations
You can integrate your Icon with Lifesize Cloud, the UVC suite of applications, and Lifesize Bridge.
Available options depend on the applications configured in your environment:
User Access Username Default Password
Administrator Browser, SSH admin admin
Remote control through the video system’s display none 1234
Support Browser, SSH support support
Option Appears when integrated with... Configuration
Schedule UVC Manager Manage your video system in UVC Manager.
Directory Lifesize Cloud Connecting to Lifesize Cloud
UVC ClearSea Provisioning Your Icon through UVC ClearSea
Integrating Icon with UVC ClearSea
UVC Manager Manage your video system in UVC Manager.
A directory server Configure the integration in Preferences > Directory.
Meetings Lifesize Cloud Connecting to Lifesize Cloud
UVC ClearSea
(Your system registers to UVC
ClearSea over H.323.)
Enabling Icon Support for Lifesize MCU Conferences
UVC Manager Manage your video system in UVC Manager.
UVC Multipoint or Lifesize Bridge Configure the integration in Preferences > MCUs >
Enable MCU Integration.
Record UVC Video Center Configure your system to record to UVC Video Center
in Preferences > Record and Stream.
Call escalation Lifesize Cloud Connecting to Lifesize Cloud
UVC ClearSea Provisioning Your Icon through UVC ClearSea
Integrating Icon with UVC ClearSea
Global
search UVC ClearSea Provisioning Your Icon through UVC ClearSea
Integrating Icon with UVC ClearSea
Navigation and Search

Lifesize Icon Guide 6
Connecting to Lifesize Cloud
Once you have a Lifesize Cloud account, you can connect your Icon to the Cloud service. Associate your
Icon with your Cloud account or activate an Icon that serves as a conference room system.
After you are connected, you can take advantage of these features:
•You can download the Cloud app on all of your devices: laptop, tablet, and smartphone. Incoming calls
ring all devices.
•Lifesize Cloud applies configuration settings to the Icon directly.
•All contacts in your company’s Cloud group are available from your Icon directory. Their online status
appears as well.
•Virtual meeting rooms configured by your Cloud account manager are available in Meetings . All
Cloud users can add meetings from their Cloud app.
•Icon can add video participants and accept multiple incoming callers to the active call.
•Software updates are automatically applied to your Icon instead of requiring you to perform a manual
update from a separate file. The system prompts you to apply the update, allowing you to delay the
operation if you are in a call or otherwise using the system.
NOTE Learn more about Lifesize Cloud at lifesize.com.
Activating Icon on Lifesize Cloud
Connect to the Lifesize Cloud service during initial configuration. To initiate this process after installation,
reset your system to its default settings. Read more at Resetting the System.
NOTE You must have a Lifesize Cloud user account to connect your Icon to the
service.
1. When the initial configuration wizard asks you to join the Cloud service, select Yes.
2. Open a browser and navigate to the URL shown on your Icon.
NOTE You cannot activate your Icon from the system’s web interface.
3. Sign in by entering your Cloud email address and password.

Lifesize Icon Guide 7
4. Enter the activation code shown on your Icon.
Scanning the QR code opens the Lifesize Cloud sign-in page in a browser, where your activation code
already appears.
5. You can associate an Icon to an individual user or a conference room.
6. From the Icon main screen, navigate to > to view the status of the system. When your Icon is
successfully activated, Ready shows for Communications > Lifesize Cloud Service.
Removing an Icon from a Cloud User Account
1. Reset your system to its default settings.
2. When the initial configuration wizard asks you to join the Cloud service, select No.
3. Cloud account manager: Sign in to the Cloud web console and remove the Icon from the Cloud user
account. Learn more in the online help available from the console.
Individual user Me – allows Cloud end users to associate the device to themselves.
User – allows Cloud account managers to associate the device to any user in
their Cloud group.
Conference room Use this option if the device resides in a conference room and is intended for
multiple users.
Creates a separate Cloud account for the Icon. Enter a name for the system that
will appear in the Cloud directory. Optionally, enter an email address for calling
the system.

Lifesize Icon Guide 8
Configuring Your Firewall
This section explains how to configure your Lifesize video systems for firewall traversal, assuming you are
not using firewall traversal products such as UVC Transit or UVC ClearSea.
•If you are using UVC Transit, refer to the Lifesize UVC Transit Deployment Guide. If you are using
UVC ClearSea, refer to the Lifesize UVC ClearSea Deployment Guide.
•If your Icon is connected to Lifesize Cloud, refer to the online help available from the Cloud web
console.
Placement Behind a Firewall
Lifesize recommends that you place your system behind a firewall. Use one of the following options:
Firewall Settings for Ports
At a minimum, block external or inbound access to the following ports:
•22 (SSH)
•80 (HTTP)
•443 (HTTPS)
•554 (RTSP)
•10008 (REST API service if UVC Manager manages your system)
Lifesize recommends that these ports remain open for internal administrator access. Ensure that you
change the default administrator password to be secure.
NOTE Change the administrator password in the web interface in Preferences >
Passwords. You can disable SSH and web access on the system in
Preferences > Security.
DMZ with public IP address Placing your video systems in the DMZ allows you to assign public IP addresses.
This configuration makes it easier for your system to connect with public video
systems on the Internet.
Private LAN with NAT Placing your video systems in the private LAN with Network Address Translation
(NAT) obscures their private IP addresses, but makes calls with systems outside of
your network more complicated.

Lifesize Icon Guide 9
Call Setup and Media Ports
To place calls to other systems through the firewall, you must configure your firewall to allow incoming and
outgoing traffic to the system through the following:
Restricting Reserved Ports
To place calls to other devices through a firewall, you must configure your firewall to allow incoming and
outgoing traffic to the Lifesize system through the reserved ports. Users placing calls through a firewall to
systems with public IP addresses may experience one-way audio or video if the firewall is not properly
configured to allow two-way audio and video traffic.
By default, Lifesize systems communicate through TCP and UDP ports in the range 60000 - 64999 for
video, voice, presentations, and camera control. Lifesize systems use a subset of these ports during a call.
NOTE The minimum number of required ports is 100.
To minimize the number of UDP and TCP ports that are available for communication, restrict the range by
changing values in the browser in Preferences > Network > Reserved Ports. Lifesize recommends that
the range you choose, if other than a subset of the default range, begins with a port number greater than
49151. The range must start with an even number and end with an odd number to include an even number
of total ports. For a range that starts at 62000, set the lower end to 62000 and the upper end to 62099 to
allocate a range of 100 ports, the minimum.
NOTE Changing the values in Reserved Ports causes the system to restart.
UDP port 1719
TCP port 1720 Gatekeeper registration. H.323 call negotiation.
UDP port 5060 SIP call negotiation.
TCP port 5060 SIP call negotiation if TCP signaling is enabled for SIP calls.
TCP port 5061 TLS signaling in SIP calls if TLS signaling is enabled.
NOTE: TLS is the only transport that is supported for encrypted calls.
Required TCP and
UDP ports Range specified in Preferences > Network > Reserved Ports.

Lifesize Icon Guide 10
Using Lifesize Systems in a Private LAN with NAT
If you choose to place your video systems in a private LAN, you must use NAT to communicate with
outside systems. This may include enabling static NAT on your Lifesize system.
On your firewall, whether standalone or built in to your router, you must complete one of the following
tasks:
•Use 1:1 NAT and open the Call Setup and Media Ports over that connection bidirectionally with an
access list.
•Forward the Call Setup and Media Ports to your Lifesize system.
Refer to Restricting Reserved Ports and your firewall vendor's documentation for more information.
Enabling Static NAT
NAT enables communication between devices on your LAN that have private IP addresses and devices
that are accessed through a public IP network. Static NAT ensures that the same public IP address always
maps to a system’s private IP address so that data from the public network intended for the private system
can be routed to the system reliably.
If you are using static NAT to associate a public IP address with the private IP address of your Lifesize
system, you must configure your Lifesize system to work with your static NAT server. From a browser,
navigate to Preferences > Network and select Static NAT. Enter the public IP address, hostname, or fully
qualified domain name of your system in NAT Public IP Address.
NOTE You cannot upgrade the system from a web browser outside a firewall when
static NAT is enabled. Instead, perform the upgrade from within the firewall.
Testing your NAT Environment
If your firewall does not employ a feature set that performs H.323 or SIP NAT, you must enable NAT on
your private Lifesize system.
1. Place a call from a system on the Internet to your system in the private LAN. If your private system
connects within the first 2 seconds after answering, your NAT configuration is working properly. If the
call does not connect after answering and disconnects after 30 to 50 seconds, the reserved port
settings on your codec do not match the settings on your firewall. Ensure that the system and firewall
settings for UDP/TCP ports match.
2. If you still cannot place a successful call, you may have to disable the stateful packet inspection
feature on the firewall. Some firewall vendors may call this feature dynamic packet filtering. Refer to
your firewall vendor's documentation for more information.

Lifesize Icon Guide 11
Provisioning Your Icon through UVC ClearSea
UVC ClearSea allows Icon to discover a provisioning server and to configure itself with settings that are
specified on the server. When auto provisioning is enabled, UVC ClearSea functions as the provisioning
server. Whenever your device discovers this server, it retrieves the hosted configuration settings and
applies them locally.
NOTE Automatic provisioning requires Icon to discover the provisioning server. Read
more at Discovering the Provisioning Server.
You can use one of the following options to provision Icon through UVC ClearSea:
Select >to view the auto provisioning status in the Communications section of the table. If your
system was provisioned successfully, the IP address of the provisioning server appears.
If no explicit ports are available, Icon attempts to communicate through the following default ports:
•HTTP requests are sent to port 80. Failed requests revert to port 8180.
•HTTPS requests are sent to port 443. Failed requests revert to port 8181.
Enabling Icon Support for Lifesize MCU Conferences
This configuration allows Icon to dial in to bridge conferences through UVC ClearSea. The managed MCU
populates Meetings on Icon.
Complete the following prerequisite steps on UVC ClearSea:
1. Add an MCU in Manage > MCUs. Select Enable MCU Integration.
2. Create a user account for your Icon in Manage > Users.
a. Users registering with SIP or H.323 devices must use local credentials.
b. Enter the device’s IP address in UVC Auto Provisioning.
3. Add a call routing rule in Manage > Call Routing that forwards the dial string to the MCU address. The
forwarding destination uses the format:
<dialstring>@<mcuIPAddress>
OPTION 1: Register your Icon to
UVC ClearSea over H.323 or
SIP.
Lifesize MCU conferences appear in
Meetings on your Icon. Enabling Icon Support for Lifesize MCU Conferences
OPTION 2: Integrate Icon with
UVC ClearSea (using SIP only) Icon applies configuration settings from UVC ClearSea to enable multiway calling. Integrating Icon with UVC ClearSea

Lifesize Icon Guide 12
When Icon discovers the provisioning server, Icon retrieves the following configuration settings from UVC
ClearSea and applies them locally:
Registering Icon to UVC ClearSea through the SIP Registrar
Lifesize recommends that you register Icon over H.323 or SIP, not both. If you register the device over SIP,
keep H.323 enabled.
1. Navigate to Preferences > SIP Registrar.
2. Enter the user ID of the Icon account you created in UVC ClearSea in SIP Username.
3. Enter the user ID and password of the Icon account you created in UVC ClearSea in Authorization
Username and Authorization Password.
4. Enter the IP address or domain name for UVC ClearSea in Registrar Hostname and Proxy
Hostname (if you use a SIP proxy).
Integrating Icon with UVC ClearSea
Integrating your Icon with UVC ClearSea provides the following features:
•Icon registers to UVC ClearSea over SIP and uses configuration settings for the Icon user directly from
UVC ClearSea Server.
•Icon can add video participants and accept multiple incoming callers to the ongoing call.
•UVC ClearSea contacts are available in Icon. A contact's online status appears in the directory in Icon.
Icon Preferences Description
Directory Registers to the directory server in UVC ClearSea.
Uses the credentials from UVC Address Book in the Icon account you created in
UVC ClearSea (in Manage > Users).
H.323 Enables H.323 and registers to the gatekeeper in UVC ClearSea using the
following settings:
•Sets Name and Extension to the user ID and extension for the Icon account
you created in UVC ClearSea.
•Sets Gatekeeper Mode to Manual.
•Sets Gatekeeper Address to the IP address or domain name for UVC
ClearSea Server.
•Sets Gatekeeper Username and Gatekeeper Password to the user ID and
password of the Icon account you created in UVC ClearSea.
SIP Enables SIP.
MCUs Uses a Lifesize MCU integrated with UVC ClearSea.
Uses the IP address for the UVC ClearSea Server and the user ID and password
of the Icon user account you created in UVC ClearSea.

Lifesize Icon Guide 13
Complete the following prerequisite steps on UVC ClearSea:
1. Add an MCU in Manage > MCUs.
2. Create a user account for your Icon in Manage > Users.
a. For automatic provisioning, users must use local credentials.
b. Enter the device’s IP address in UVC Auto Provisioning.
c. Select Enable ClearSea Integration.
3. Add a call routing rule in Manage > Call Routing that forwards the dial string to the MCU address. The
forwarding destination uses the format:
<dialstring>@<mcuIPAddress>
When Icon discovers the provisioning server, Icon retrieves the following configuration settings from UVC
ClearSea and applies them locally:
Because Icon is integrated with UVC ClearSea and relies on the server’s configuration, you are restricted
from editing MCU, H.323, and SIP preferences. Additionally, directory preferences are not set on Icon, and
Meetings does not appear.
Discovering the Provisioning Server
A device attempts to discover the provisioning server through the following methods:
Icon Preference Description
UVC ClearSea Username
UVC ClearSea Password
Uses the user ID and password of the Icon account that was created in UVC
ClearSea.
NOTE: If the Icon account does not use local credentials, enter the LDAP
password.
UVC ClearSea IP Address Uses the IP address of the UVC ClearSea Server.
DHCP option 157 Retrieves the IP address of the server. Read more in the Lifesize
UVC ClearSea Deployment
Guide.
DNS, based on local
search domains
(Icon only)
Devices use a preconfigured DNS name that
represents the provisioning server.
Update the settings
manually (Icon only) This option overwrites any IP address for the provisioning server that might have been obtained
through the DHCP or DNS options. Use this method
when you have little or no control over the DHCP and
DNS servers.
Sign in to your Icon from a
browserandselect Maintenance
> Auto Provisioning.

Lifesize Icon Guide 14
Section 2: Using Your Icon
When your Lifesize video system is idle, the screen shows video from your camera. When the Lifesize
video system is asleep, the screen is black. An incoming call, showing a presentation, or pressing any
button on the remote control activates the system. Point the remote control at the IR receiver (located on
both the camera and the codec), not the screen, and tap a button to activate the system.
Additional options include:
Placing, answering,
and ending a call Select Call and navigate to one of the available calling options:
Favorites
Recents
Directory
Meetings
Keypad (phone) or Dialer (video system)
Schedule
Select Answer to answer a call and to end a call.
Placing a Call
Managing Your Video
System In a Call
Initiating a
presentation Select Presentation .
If you connect a laptop to a video input on the system during a
call, a presentation starts automatically.
Initiating a Presentation
Controlling a near
or far end camera To adjust the near end camera when the system is idle, select View .
During a call, select to adjust the near end camera. Select
to adjust the far end camera.
Camera Control
Creating a
recording With UVC Video Center configured, select . Recording with LifeSize UVC Video Center
My Info Shows the system name and numbers that callers use to dial into the video system.
Do Not Disturb Select to reject incoming calls. When enabled, appears.
Volume Opens a volume navigation bar.
REMOTE CONTROL: Select a volume level from 0 to 100. The level represents the volume as
a percentage. Use the remote control to adjust the level. Tap or to adjust the level in
1% increments. Press or to rapidly and continuously adjust the volume.
Sleep Select to put the video system (including camera and display) to sleep.
Read more at Sleep.
System Select to show system status and information.
Read more at System Options.
5

Lifesize Icon Guide 15
Sleep
Select to put the system, camera, and display to sleep. The video system automatically sleeps under
the following conditions:
•Ten minutes elapse without user interaction.
•A voice call connects.
Tap on the phone or any key on the remote control to wake the system. When the system wakes, one
of the following options is highlighted, depending on the state of the video system:
– A system issue is present. Select for more information about the issue.
– The do not disturb feature is enabled.
– A call scheduled on UVC Manager is available on your video system.
– No other conditions are present.
Navigation and Search
Your Icon shows call entries and other system information in lists.
Navigate information with the remote control as follows.
When you select Russian for the language of the video system’s display, the search uses the Cyrillic
alphabet. Select using your phone and abc using the remote control to show the Latin alphabet.
If your Icon is integrated with UVC ClearSea, select to search all UVC ClearSea entries, not just the
entries in your group. Add a global entry to your Favorites for quick access. As you enter your search
string, the results are filtered to match any word in an entry’s name that starts with the filter string. Entries
from the global directory are denoted with .
Navigate to the top
or bottom of a list Tap to quickly navigate to the top or bottom of the list.
A bar to the right of the list shows your current position and the total number of entries in
the list.
Search call entries Tap to open a search box to locate call entries.
As you select values, the list is filtered to match any word in an entry’s name that starts
with the filter string. Search box options include:
•Tap to delete a value in the search box.
•Select the # symbol to represent any numeral.
•Select the symbol to insert a space between search entries, allowing you to use
multiple words in your filter.

Lifesize Icon Guide 16
Placing a Call
Place a call using one of the following methods.
A video icon represents a video call in progress. A voice icon represents a voice call. Select to
end the call.
Available calling options also depend on the applications configured in your environment. Read more at
Integrations.
Schedule Select to show upcoming calls that UVC Manager has scheduled for your video system.
Details about the call can include the start time, title, description, and participants. Calls that
require a passcode show a lock icon . The schedule also shows time periods during which no
calls are scheduled.
A call begins at its scheduled start time and connects the participants either automatically or
after one or more of them accepts an invitation to join the call.
Favorites Select >to show your Favorites. Select an entry in the list to dial the number.
REMOTE CONTROL: Additional options include Advanced Dialing and Remove or Remove All
(to manage the entries in Favorites).
Recents Select >to show recently dialed , received , or missed calls. Select an entry to
dial the number.
REMOTE CONTROL: Additional options include Advanced Dialing, Add to Favorites, and
Remove or Remove All (to manage the entries in Recents).
Recents is limited to 50 entries.
Directory Select >to show entries. Select an entry to dial the number.
REMOTE CONTROL: Additional options include Advanced Dialing and Add to Favorites.
Meetings Select >to show available calls. Select an entry to dial the number. Read more at Joining
a Meeting.
Keypad PHONE: Select >to enter calling information manually. As you enter each character, the
corresponding touch tone is audible for the values 0-9, #, and *.
Select abc to open a keyboard to enter alphabetic characters. Select the shift character to
enter an uppercase letter. Select the shift character twice for caps lock.
Dialer REMOTE CONTROL: Select >to enter calling information manually. Navigate to advanced
options to enter alphabetic characters or select a call bandwidth or protocol. The list of available
bandwidth values adjusts to the maximum bandwidth preference set by your administrator.
Similarly, only enabled call protocols appear.
5 5

Lifesize Icon Guide 17
Joining a Meeting
Select >to show available meetings. Details about the meeting can include the start time, meeting
name, and description. Calls that require a passcode show a lock icon .
The status for a meeting can be one of the following entries:
Select an entry from the list to join the meeting. If the meeting has not yet started, a counter shows the time
remaining until the meeting is live. You can join the meeting ten minutes before the start time; the bridge
connects you automatically when the meeting is live.
Including Multiple Callers in a Call
In multiway calls, video composited from the external MCU appears on each caller’s display. Requirements
for multiway calling include:
To add a participant to an ongoing call, select Add. Use this method also to transfer a caller: after you
add the participant, you can leave the call without ending it. To remove an individual caller, select and
the participant you want to remove.
For incoming calls, the following options are available:
•Click End + Answer to end the current call and answer the incoming call.
•Click Answer to add the caller to the current call.
•Click Ignore to ignore the caller.
If your Icon has an associated Lifesize ClearSea Client that is active and registered to UVC ClearSea, you
can select on the client for the client to join the call. This action disconnects the call on your Icon.
Live The meeting has started.
Live in <minutes> The meeting starts within 10 minutes.
Ready The meeting is open to participants, but has no participants yet.
Active Participants have already joined the meeting.
If an active meeting is full, the bridge does not accept new participants.
Unavailable No resources are available.
Full No ports are free because the conference is full.
Your Icon is integrated with UVC ClearSea and a supported
Lifesize MCU. Integrating Icon with UVC ClearSea
Your Icon is connected to Lifesize Cloud. Connecting to Lifesize Cloud

Lifesize Icon Guide 18
Managing Your Video System In a Call
By default, you must manually answer or ignore incoming calls. Administrators can set Auto Answer and
Auto Answer Mute in Preferences > Calls.
Initiating a Presentation
Select Presentation to start a presentation before or during a call. If you connect a laptop to a video
input on the system, a presentation starts automatically, and appears. To stop the presentation, select
. Stopping a presentation ends any active recording.
Icon 800 only: The DVI input that functions as presentation input is represented by a numeral in the
Presentation option. Example: . To change the presentation input, select . You cannot use the
primary camera input as presentation input.
Hide onscreen text Select Hide.
Mute audio Press to mute audio to the far end. When enabled, appears. If audio at the far
end is muted, appears.
Mute video Select >to mute video to the far end. When enabled, appears.
Show picture in picture Select >to show picture in picture video during a call. When enabled,
appears.
Change the call and
presentation layout Select or and navigate to the desired layout. is not available if the call has only one available layout. Read more at Managing Calls Hosted by a Lifesize
MCU and Initiating a Presentation.
Lifesize Cloud users: you can change the layout only when a presentation is active.
Move the cameras During a call, select to adjust the near end camera. Select to adjust the far
end camera.
Read more at Camera Control.
Swap camera input If two cameras are connected, select or to swap the primary camera input.
Selecting adjusts the current camera:
•Icon 600: By default, the HD camera is the primary input, camera 1, and the DVI
camera is camera 2. Presentations are not available with two connected
cameras.
•Icon 800: By default, DVI 1 is the primary input.
Change camera input
(Icon 800 only) If three or more cameras are connected, select to change the primary camera
input.
Use the keypad Select to show a keypad to enter tones.
Show caller information Select >to show details about the caller, including the system name and
number, and call statistics, including the call type and protocol, connection time, and
direction of the call.
Show recording
information Select (or >with the remote control) while recording with UVC Video Center to show video and audio statistics of the recording stream.
End the call Select .
2

Lifesize Icon Guide 19
If your video system is already receiving a presentation, you cannot connect a laptop and start your own
presentation without first stopping the current presentation to all callers. Further, you cannot take control of
a remote presentation.
Select from the following layout options during a call:
– Presentation input and video from the far end appear side by side.
– Presentation input and video from multiple callers appear. This layout is available with integrated
bridge calls from Meetings . For bridges that are not integrated, select <or >to choose a layout.
– Presentation input appears.
– Video from the far end appears.
If the video call does not support presentations simultaneously with video, the video system automatically
swaps the primary and presentation inputs to send the presentation. The near end shows both the camera
and presentation input, and the far end shows only the presentation.
Camera Control
Your Icon allows you to adjust a camera during and before a call. To prevent far end users from adjusting
the near end camera, your administrator can disable Far Control of Near Camera (enabled by default) in
Preferences > Video. To prevent far end users from using and configuring camera presets for the near
end camera, disable Far Control of Near Camera or Far Set of Camera Presets.
Pan, Tilt, Zoom, and Presets
1. From the phone, select the camera that you want to control:
>– Adjust the near end camera when the system is not in a call.
– Adjust the near end camera during a call. The near end video appears in the PIP window.
– Adjust the far end camera.
2. Adjust pan and tilt using the group of four arrows.
3. Adjust the zoom using the group of two arrows.
4. A camera preset is a predefined camera position that is associated with a numeral. Camera presets
enable you to quickly change the position of a camera during a call.
-To define a camera preset for the current camera position, press and hold a numeral until Preset
saved appears.
-To move the camera to a preset location, tap the numeral.
5. To end your camera control session, select End.

Lifesize Icon Guide 20
Recording with LifeSize UVC Video Center
With UVC Video Center configured in your environment, you can initiate a recording at any time.
To show video and audio statistics of the recording stream during recording, select using the phone or
>using the remote control.
Recording During a Call
Select to start recording during a call. If prompted, enter a valid recording key. If successful, the
recording begins and the recording icon appears.
By default, all callers are recorded. To record only the near or far video, change the default recording
layout in Preferences > Record and Stream.
To stop a recording, end the call or presentation, or select .
Recording Outside a Call
1. Select .
2. Select from one of the available recording options to start the recording session:
– Record input from the camera.
– Record input from the presentation.
– Record two streams: input from the presentation and camera.
– Record input from two cameras. Select or to select the camera that provides the primary
input. This option is available only with two connected cameras.
3. Select to start recording. If prompted, enter a valid recording key. If successful, the recording
begins and the recording icon appears.
4. Optional: If you are recording input from the camera or from a presentation, select to toggle the
input: presentation or camera. If you are recording two streams, select to toggle between recording
two streams (presentation and camera) and a single stream (camera).
5. To stop recording, select .
NOTE If you placed a call or started a presentation after the recording started, you
can stop the recording and the session by ending the call or presentation.
6. To end the recording session, select the appropriate option: , , , or , depending on your
selection in step 2.
