LEGO® CHRISTMAS WREATH 2-IN-1
#40426 LIGHT KIT
INSTALLATION GUIDE

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE
INSTALLATION GUIDE 2
Light My Bricks
LEGO® CHRISTMAS WREATH 2-IN-1
#40426 LIGHT KIT INSTALLATION GUIDE
Hi There!
We’re here to help you get started on the LEGO®
Christmas Wreath 2-in-1 (40426) Light Kit.
This PDF details the instructions for the LED light kit only. If
you are wishing to purchase this product, please click here
to view the product page.
If you run into any issues, please refer to the troubleshoot-
ing section towards the end of this guide.
Have fun and enjoy!

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE
PACKAGE CONTENTS 3
PACKAGE CONTENTS: LEGO PIECES:
4 x White 30cm Bit Light
4 x Red 30cm Bit Light
4 x White 15cm Bit Light
1 x 6 Port Expansion Board
1 x 12 Port Expansion Board
6 x Adhesive Squares 5x5x2mm
• 4 x LEGO Round Plate 1x1 Trans-Red
• 4 x LEGO Round Plate 1x1 Trans-Orange
1 x Flicker Eects Board
2 x 5cm Connecting Cable
1 x Flat Battery Pack

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE
CONTENTS 4
Contents
Before You Begin 5
Option 1 Instructions 9
Option 2 Instructions 18
Final Product 30
Troubleshooting 31
Contact 36

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 5
Before You Begin
Laying cables in between
and underneath bricks
Cables can fit in between and underneath
LEGO® bricks, plates, and tiles providing
they are laid correctly between the
LEGO® studs. Do NOT forcefully join
LEGO® together around cables; instead
ensure they are laying comfortably in
between each stud.
CAUTION: Forcing LEGO® to connect over
a cable can result in damaging the cable
and light.
Connecting Cable
Connectors To Expansion
Boards
Take extra care when inserting connectors
to ports of Expansion Boards. Connectors
can be inserted only one way. With the
expansion board facing up, look for the
soldered “=” symbol on the left side of the
port. The connector side with the wires
exposed should be facing toward the
soldered “=” symbol as you insert into the
port. If a plug won’t fit easily into a port
connector, do not force it.
Incorrectly inserting the connector can
can result in bent pins inside the port or
possible overheating of the expansion
board when connected.

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 6
Before You Begin
Connecting Cable
Connectors To Strip Lights
Take extra care when inserting connectors
to ports on the Strip Lights. Connectors
can be inserted only one way. With the
Strip Light facing up, ensure the side of
the connector with the wires exposed is
facing down. If a plug won’t fit easily into
a port connector, don’t force it. Doing so
will damage the plug and the connector.
Connecting Micro Cable
Connectors To Micro
Expansion Board Ports
Take extra care when inserting the
micro connectors to micro ports of Micro
Expansion Boards. Connecting Micro Bit
Lights to Micro Expansion Boards is similar
to connecting lights and cables to Strip
Lights. With the expansion board facing
up, ensure the side of the connector with
the wires exposed is facing down. If a plug
won’t fit easily into a port connector, do
not force it. Use your fingernail to push the
plastic part of the connector to the micro
port.

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 7
Before You Begin
Installing Bit Lights Under
Lego® Bricks And Plates
When installing Bit Lights under LEGO®
pieces, ensure they are placed the correct
way up (Yellow LED component exposed).
You can either place them directly on top of
LEGO® studs or in between.

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 8
INSTRUCTIONS
This section is for the Hanging
Wreath. To light up the Candle
Wreath, click here.
To ensure a smooth installation of
your light kit, please read and follow
each step carefully. If you run into
any issues, please refer to the online
troubleshooting guide.

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 9
1
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Each letter
represents one
segment of the
wreath. These
will be referred
to throughout the
guide.
AB
C
D
E
H
G
F
I
J
K
L
M
N
O
P
K
J
White 30cm Bit Light

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 10
2 3
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Red 30cm Bit Light
Trans Red Round Plate 1x1
L
White 30cm Bit Light
L
L
M

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 11
4
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
White 15cm Bit Light
M
White 15cm Bit Light
N

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 12
5
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Red 30cm Bit Light
12-Port Expansion Board
N
N
M
O
6FLAT BATTERY PACK
Trans Red Round Plate 1x1
2x Adhesive Squares
+-

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 13
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
If you experience any issues with the lights not working and suspect an issue with a component, please try a dierent port on the expansion board to verify where the fault lies (with the light or
expansion board). To correct any issues with expansion board ports, please view the section addressing expansion board issues in our troubleshooting section.
White 30cm Bit Light
Red 30cm Bit Light
H
F
7

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 14
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
White 30cm Bit Light
Trans Red Round Plate 1x1
E
White 15cm Bit Light
F
D
E
8

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 15
9 10
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
White 15cm Bit Light
D
C
E
6-Port Expansion Board
BC

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 16
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Plug the other
end of the 5cm
Connecting Cable
to the 12 Port
Expansion Board
from step 5.
5cm Connecting Cable
2x Adhesive Squares
B
DESCRIPTION
Red 30cm Bit Light
Trans Red Round Plate 1x1
D
11

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 17
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
2x Adhesive Squares
P
O
If you experience any issues with the lights not working and suspect an issue with a component, please try a dierent port on the expansion board to verify where the fault lies (with the light or
expansion board). To correct any issues with expansion board ports, please view the section addressing expansion board issues in our troubleshooting section.

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 18
INSTRUCTIONS
This section is for the Candle Wreath.
To light up the Hanging Wreath, click
here.
To ensure a smooth installation of
your light kit, please read and follow
each step carefully. If you run into
any issues, please refer to the online
troubleshooting guide.

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 19
1
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
AB
C
D
E
H
G
F
I
J
K
L
M
N
O
P
I
Each letter
represents one
segment of the
wreath. These
will be referred
to throughout the
guide.
White 30cm Bit Light
Red 30cm Bit Light
Trans Red Round Plate 1x1
K
I
J

LEGO CHRISTMAS WREATH 2-IN-1 40426 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 20
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
K
LWhite 30cm Bit Light
M
2
