Lincoln QLS 301 User manual

Page 1 of 44
User Manual
InstallationandOperationInstructions
2.1B-38006-C02
Form 403013
Subject to modificaitons
Form 403013
Lubrication System QLS 301
4197a99
6093b03
U.S. Patent-No. 6,244,387, German Registration Design No. 29923765.6
810-55230-1

Page 2 of 44
User Manual
Installation and Operation Instructions
2.1B-38006-C02 Form 403013
Subject to modificaitons
All rights reserved.
Any duplication of this Owner Manual, in its entirety or in part,
by whatever means is prohibited without the prior consent in
writing of Lincoln GmbH & CO. KG.
Subject to modifications without prior notification.
© 2002 by
LINCOLN GmbH & Co. KG
Postfach 12 63
D-69183 Walldorf
Phone: [phone]
Fax: [phone]

Page 3 of 44
User Manual
Installation and Operation Instructions
2.1B-38006-C02
Form 403013
Subject to modificaitons
List of Content
Page Page
Safety Instructions ........................................................ 5
Installation Instructions................................................ 7
Pump ................................................................................ 7
SSV Divider Block............................................................ 7
Crossporting of the SSV Divider Blocks ....................... 7
Check valve ................................................................. 7
Direct (internal) feedback feature .................................. 8
Lubrication Points ............................................................ 9
Installing Zerk-Locks onto grease fittings .................... 9
Connection to Feed Lines ............................................ 10
Filling of reservoir .................................................... 10
QLS 301 Selection Guide ............................................. 11
Electrical Connecting Diagrams.................................. 12
Description of QLS 301 ............................................... 20
Operation of QLS 301 .................................................. 22
Pressure Relief Valve .................................................... 22
Pump Display Window .................................................. 22
Monitoring time / malfunction ................................. 23
Models with Low Level Control .............................. 24
Malfuntion / low level indication ............................. 24
Acknowledging receipt of a malfunction ............... 25
Acknowledging receipt of the low level indication 25
Monitoring relay .............................................................. 25
Setting and Operation of QLS 301 ............................ 26
Display Mode .................................................................. 26
Operating Mode .............................................................. 27
Programming Mode ....................................................... 28
Maintenance, Repair and Tests ................................. 30
Maintenance ................................................................... 30
Filling of reservoir .................................................... 30
Repair .............................................................................. 31
Functional Test ............................................................... 31
Troubleshooting ........................................................... 32
Technical Data .............................................................. 36
Dimensions .................................................................... 37
Service Parts for the QLS 301 ................................... 38
Option for metric fittings ................................................ 42
Declaration of Conformity ............................................. 44

Page 4 of 44
User Manual
Installation and Operation Instructions
2.1B-38006-C02 Form 403013
Subject to modificaitons
Introduction
Explanation of Symbols Used
The following description standards are used in this manual:
Safety Instructions
Structure of safety instructions:
Pictogram
Signal word
Danger text
- Danger note
- How to avoid danger
The following pictograms are used in this manual and are
combined with the corresponding signal words:
1013A94 4273a00 6001a02
- ATTENTION
- CAUTION
- WARNING
- ATTENTION
- CAUTION
- WARNING
- NOTE
- IMPORTANT
The signal words give the seriousness of danger if the follow-
ing text will be not observed:
ATTENTION refers to faults or damages on
machines.
CAUTION refers to bad damages and possi-
ble injuries.
WARNING refers to possible dangerous inju-
ries.
NOTE refers to improvements in handling
of systems.
IMPORTANT refers to considerable disadvan-
tages in handling of systems.
Example:
1013A94
ATTENTION!
When making use of other than the origi-
nal spare parts, serious damage may
affect your device.
Therefore, for the operation of your device
always use original spare parts made by
Lincoln GmbH & Co. KG.
Furthermore, you will find the following text symbols in this
manual:
Listing
- Subpoint
Procedural instruction
User's Responsibility
To ensure the safe operation of the unit, the user is responsi-
ble for the following:
1. The pump / system shall be operated only for the in-
tended use (see chapter "Safety Instructions", on page 5)
and its design shall neither be modified nor transformed.
2. The pump / system shall be operated only if it is in a
proper functioning condition and if it is operated in accor-
dance with the maintenance requirements.
3. The operatin
g
personnel must be familiar with this Owner
Manual and the safety instructions mentioned within and
observe these carefully.
The correct installation and connection of tubes and hoses, if
not specified by Lincoln GmbH & Co. KG, is the user's re-
sponsibility. Lincoln GmbH & Co. KG will gladly assist you
with any questions pertaining to the installation.
Environmental Protection
Waste (e.g. used oil, detergents, lubricants) must be dis-
posed of in accordance with relevant environmental regula-
tions.
Service
The personnel responsible for the handling of the pump /
system must be suitably qualified. If required, Lincoln GmbH
& Co. KG offers you full service in the form of advice, on-site
installation assistance, training, etc. We will be pleased to
inform you about our possibilities to support you purposefully.
In the event of inquiries pertaining to maintenance, repairs
and spare parts, we require model specific data to enable us
to clearly identify the components of your pump / system.
Therefore, always indicate the part, model and series number
of your pump / system.

Page 5 of 44
User Manual
Installation and Operation Instructions
2.1B-38006-C02
Form 403013
Subject to modificaitons
Safety Instructions
Appropriate Use
The lubrication system QLS 301 has been designed for initial
and retrofit installation. It has been designed for:
1. the automatic lubrication of machines and systems
2. the automatic lubrication of commercial vehicles and
construction machines
3. the automatic lubrication of hydraulically driven units and
devices.
The lubrication system QLS 301 is able to deliver greases up
to NLGI - class 2 or fluid greases of NLGI - class 000 or 00.
Use the QLS 301 exclusively to supply lubricants.
The QLS 301 is adequate for intermittent operation only.
The QLS 301 is adequate for feeding max. 18 lube points
per lube cycle.
Do not use QLS 301 with SSV divider block in bottom
mounting position for mobile applications. Do not install
the system with machines exposed to shock.
Misuse
Any use of the QLS 301 that is not expressly mentioned in
this Owner Manual will be regarded as misuse.
If the QLS 301 is used or operated in a different manner other
than specified, any claim for warranty or liability will be null
and void.
6001a02
NOTE
If personal injury or material damage
occurs as a result of inappropriate opera-
tion, e.g. if the safety instructions are
ignored or resulting from an incorrect
installation of the QLS 301, no claims or
legal actions may be taken against
LINCOLN GmbH & Co. KG.
General Safety Instructions
Lubrication systems QLS 301
- are designed state-of-the-art.
- can be assembled for safe operation.
- must be regularly refilled with clean lubricant.
Incorrect use may result in bearing damage caused by
poor or over-lubrication.
Do not over-pressurize reservoir when filling the pump.
Refill QLS 301 pump with clean lubricant.
Each outlet needed must be equipped with an appropriate
check valve.
6001a02
IMPORTANT
Do not paint the pump. Before painting a
machine or commercial vehicle, remove
or cover the pump completely.
Unauthorized modifications or changes to an installed
system are not recommended and will void warranty. Any
modifications must be subject to prior consultation with
the manufacturer of the QLS 301.
Regulations for Prevention of Accidents
To prevent accidents, observe all city, state and federal
safety regulation of the country in which the product will be
used.
Operation, Repair and Maintenance
1013A94
ATTENTION!
Malfunction because of dirt!
When executing any maintenance or
repair works on the QLS 301, ensure
absolute cleanliness.
4273a00
CAUTION!
115-230 V!
For pumps with 120 VAC and 230 VAC,
switch off the power supply before be-
ginning maintenance or repair work.
Repair
Repairs should only be performed by authorized personnel
who are familiar with the instructions.

Page 6 of 44
User Manual
Installation and Operation Instructions
2.1B-38006-C02 Form 403013
Subject to modificaitons
Safety Instructions, continuation
Operation, Repair and Maintenance,
continuation
Operation/Maintenance
Lubrication systems QLS 301
must operate with mounted pressure relief valve, only.
must operate only with mounted or connected SSV divider
blocks.
must be regularly filled with clean and air-free lubricant.
operates automatically. However, a regular check (ap-
proximately every 2 weeks) should be made to ensure
that lubricant is being dispensed from all lubricant points.
Disposal
Used or contaminated lubricants must be disposed of in ac-
cordance with local environmental regulations, see technical
data sheets of lubricants.
Exclusion of Liability
The manufacturer of the centralized lubrication system will
not accept any liability for:
damage caused by insufficient lubricant and irregular
refilling of pump.
damage due to the use of greases which are not or are
only conditionally pumpable in centralized lubrication sys-
tems.
damage caused by the use of contaminated lubricants.
damage caused by inadequate disposal of used or con-
taminated lubricants.
damage caused by unauthorized modification of system
components.
damage caused by the use of unapproved parts (voids the
pump warranty).
Installation
6001a02
IMPORTANT
Do not remove, modify or alter any
safety equipment already installed on
the machine.
Installation, continuation
If necessary, these devices may be removed temporarily
during the installation of the pump.
The devices must be properly put back in place after the
installation of the pump.
Use only original spare parts or spare parts authorized by
LINCOLN.
Pump QLS 301 must be kept away from sources of heat
(see Operating Temperature Specification).
Provide access to fill, clean and visually monitor the pump
operation.
6001a02
IMPORTANT
Follow installation instructions of the
OEM regarding minimum distances
between the drilled holes and welding
procedures.
4273a00
CAUTION!
115-230 V!
The QLS 301 may only be installed by
qualified personnel. The connection
(N/L/PE) of the supply voltage must be
made according to VDE 0100 and VDE
0160.
Install a protective and lock out device
for isolating and disconnecting the QLS
301. Before beginning the installation
work, disconnect the electrical supply.
4273a00
WARNING!
115-230 V!
Failure to observe the safety
instructions, e. g. touching electrically
charged parts when the system is
opened, or improper handling of the
QLS 301 may cause serious injury or
death.
If the values specified in the Technical
Data are exceeded, the device may
overheat. It may damage the QLS 301
and thus impair the electric safety.

Page 7 of 44
User Manual
Installation and Operation Instructions
2.1B-38006-C02
Form 403013
Subject to modificaitons
Installation Instructions
Pump
SSV Divider Block
1014b00
Fig. 1 Single double and triple lubricant output, on rear side
mounted divider blocks
0x-3x Outlet quantity (single, double, etc.)
1-6 Outlet numbers
A Clamping ring (brass)
B Grease supply
C Enclosed grease
R Return to reservoir
4163a98
Fig. 2 Closure plug, also provided in the accessory kits
4180a02
Fig. 3 Check valve, push-in type
A Clamping ring (brass)
Use drilling template to mark and drill mounting holes of the
QLS 301. Drilling template and mounting bolts are included in
the package.
Crossporting of the SSV divider blocks
Single Output
A single output is the lubricant quantity fed to the lube point
by a piston per stroke and outlet port. It amounts to ap-
proximately 0.2 cm³, see outlet 6, fig. 1.
Double or Multiple Outputs
Outputs can be increased by simply plugging the unused
outlet ports with closure plugs (fig. 2, provided in the ac-
cessory kit).
Lubricant from a plugged outlet is redirected to the next
outlet on the same side of the SSV divider block in de-
scending numerical order (see fig.1).
Example, see fig. 1:
By closing
- of outlet 4, outlet 2 receives the double quantity.
- of outlets 5 and 3, outlet 1 receives the triple amount of
lubricant. The connecting conduit from outlet line 1 to
outlet line 2 and to the return line (R) is closed by
clamping rings (A) of the check valve.
Unused lubricant can be internally fed back to the reser-
voir, see paragraph ‘’direct internal feed back feature”.
6001a02
NOTE
Do not plug outlets number 1 and 2
(horizontally positioned outlets) on
bottom-mounted lubricant divider blocks
SSV 8, 12 and 18.
Do not plug outlets number 1 or 2 on
externally mounted divider blocks.
Install a closure plug in each outlet port hole which is not
required, see fig. 1 or 4.
Check valve
For feedlines (diameter 6x1.5 mm, 1/4” I.D., provided in
the accessory kits) use check valves with standard collar
and knurled flange.

Page 8 of 44
User Manual
Installation and Operation Instructions
2.1B-38006-C02 Form 403013
Subject to modificaitons
Installation Instructions, continuation
4188b99
Fig. 4 Internal feedback of supplied lubricant, only on rear-side
mounted SSV divider blocks
0x-2x Outlet quantity (single, double, etc.)
1-6 Outlet numbers
A Clamping ring (brass)
B Grease supply
C Enclosed grease
R Return line bore hole
6001a02
NOTE
Maximum internal combination of
outlets:
SSV 6 = 3
SSV 12 = 6
SSV 18 = 9
Further combinations are possible
outside the divider valve by means of a
tee-piece only.
Direct (internal) feedback feature
All pumps with back- mounted SSV divider block have
the capability to feed back unused lubricant internally from
closed outlets directly to the reservoir (see R fig. 4, 5).
This procedure will start automatically, if outlet port 2 is
plugged with a closure plug. All pumps have capability to
feed back the lubricant directly to the reservoir from even
and odd outlets via the channel from outlet 1 to outlet 2 .
Start from the smallest outlet number when closing the
outlets, for instance 2, 4, 6 on even side or 1, 3, 5 on odd
side plus outlet 2. In fig. 4 the quantities of outlets 1, 2 and
4 (3xR) are fed back to the reservoir.
The remaining outlets are to be used for the connection to
the lube point or for increasing the lubricant quantity (dou-
ble or triple), see fig.1.
1013A94
CAUTION!
To change the outlet 2 for bearing lubri-
cation, replace closure plug with check
valve (Fig. 3), then never close outlet
1, see fig. 1.
6001a02
NOTE
To feed back unneeded lubricant quanti-
ties from bottom- mounted divider
blocks to the reservoir, connect un-
needed outlet via the feedline to plug 5
(fig. 17) for external return line.

Page 9 of 44
User Manual
Installation and Operation Instructions
2.1B-38006-C02
Form 403013
Subject to modificaitons
Installation Instructions, continuation
Lubrication Points
Installing Quicklinc fittings into lube points
Remove hydraulic lube fittings from lube points and install
appropriate Quicklinc fittings into the bore holes of the lube
points.
Installing Zerk-Locks onto Grease Fittings
4200a99 4201a99
Fig. 5 Place the Zerk-Lock
body over the grease
fitting
Fig. 6 Installation of Zerk-
Locks with staking tool
4202a99
Fig. 7 Screwing Quicklinc fitting into the Zerk-Lock body
The Zerk-Lock fitting consists of the Zerk-Lock body, insert
and a Quicklinc fitting.
Place the Zerk-Lock body over the grease fitting and
place the staking tool firmly against the Zerk-Lock insert.
(Staking tool is included in the accessory kits).
Strike the tool sharply with a hammer until the Zerk-Lock
insert partially crimps onto the grease fitting.
Screw the Quicklinc fitting into the Zerk-Lock body and
tighten until parts resist further tightening (about 1-1/2
turns).
6001a02
NOTE
Quicklinc hex. is 12 mm. Zerk-Lock body
hex is 1/2 ’’.
Move the Zerk-Lock and tube fitting from side to side on
the grease fitting to insure the Zerk-Lock is firmly seated.

Page 10 of 44
User Manual
Installation and Operation Instructions
2.1B-38006-C02 Form 403013
Subject to modificaitons
Installation Instructions, continuation
Connection of Feed Lines
4203a99
Fig. 8 Feedline installed in the Quicklinc fitting
4157a98
Fig. 9 Feedline insert into the fitting up to the next white mark
Measure, cut and route the feedlines included in the kit.
6001a02
NOTE
Avoid sharp bends of the plastic tubing
and the moving parts of the machine that
could damage the lubrication lines. Mini-
mum bending radius is 50 mm (2 in).
Secure the lubrication lines to the machine using nylon
ties, clamps or straps provided in the accessory kit.
If the feedlines are not primed, prime all lubrication feedli-
nes before connecting them to the lube point (by trigger-
ing additional lubrications).
Connect the feedlines directly to the check valves of the
divider block and to the Quicklinc fittings of the lube point.
6001a02
NOTE
Push the ends of the feedlines firmly into
the Quicklinc fittings until they are fully
seated in the body of the fitting. The
primed feedlines are marked with white
lines (fig. 9, 10) to facilitate installation.
Cut the pressure plastic tube off at one of the white lines
before it is mounted.
Then insert the plastic pressure tube into the fitting up to
the next white mark.
This will ensure a correct installation of the pressure plas-
tic tube in the threaded tube fitting.
Filling of reservoir
4204a99
Fig. 10 Vent hole on reservoir
Fill the reservoir with suitable clean lubricant.
1013A94
WARNING!
Risk of bursting if the reservoir is
overfilled. When filling the reservoir by
means of pumps with a large delivery
volume do not exceed the max. filling
mark.
CAUTION!
Avoid inclusions of air in the lubricant
below the follower plate. When filling the
reservoir, the follower plate sealing lip –
overlaps the vent hole (see fig. 10) to
ensure that all air pockets can be vented.

Page 11 of 44
User Manual
Installation and Operation Instructions
2.1B-38006-C02
Form 403013
Subject to modificaitons
QLS 301 Selection Guide
Pump models P30100810111
Examples of part numbers P30162410151
P301 6 2 4 1 0 1 5 1
Pump
for grease..................................................
.
P301
SSV Divider Block
External, SSV 6, SSV 8**.................................
.
External, SSV 12, SSV 18**.............................
.
SSV 6 (back) ...................................................
.
SSV 8 (bottom)................................................
.
SSV 12............................................................
.
SSV 18............................................................
.
0
1
3
4
6
9
SSV Divider Block Position
None ...............................................................
.
Back................................................................
.
Bottom1...........................................................
.
0
1
2
Operating Voltage
12 VDC* ..........................................................
.
24 VDC* ..........................................................
.
120 VAC* ........................................................
.
230 VAC* ........................................................
.
2
4
6
8
Reservoir / Low-level control
1 L reservoir with low level control....................
.
1
Dry contacts
None ...............................................................
.
Yes..................................................................
.
0
1
Type of Plug Connector
Square-type, acc. to DIN 43650 type of con-
struction A .......................................................
.
1
Electrical Connectors
Without socket, without cable...........................
.
With socket, without cable* ..............................
.
With socket, with cable, 10 m...........................
.
With socket, with ADR cable, 10 m ..................
.
0
1
5
6
Control p. c. b.
None ...............................................................
.
Monitored, 1 cycle, SSV 12, SSV 18
Monitored, 1, 2, 3 cycles, SSV 6, SSV 8
Alarm contact (option) normally open contact
Alarm contact (option) normally closed contact
0
1
2
Example of an explained model number:
Pump model P30131810111-Grease pump, SSV 6 block mounted on the back, 230 VAC, with low level and without dry con-
tact.
* Note: Standard 120 and 230 VAC pump models for industry are supplied without electrical cable. Standard 12 and 24 VDC pump
models for mobile applications can be supplied with 10 meter (30’) electrical cable.
** Note: For external divider block application only use the specific divider blocks SSV ... KNQLS.
Regarding pump models without divider block, it is not possible to close cycles without changes on the p. c. b.
*** Note: Do not use QLS 301 with SSV block in bottom-mounting position for mobile applications. Do not install the pump in areas
exposed to shock.
Accessory kits, see chapter ”Technical Data”

Page 12 of 44
User Manual
Installation and Operation Instructions
2.1B-38006-C02 Form 403013
Subject to modificaitons
Electrical Connecting Diagrams
Electrical connection
4273a00
CAUTION!
115-230 V!
Before starting, make sure that the
electrical supply is off. The device may
not be connected or disconnected when
the power is on. The protective
conductor must always be connected.
Take care that this line section is
undamaged and conforms to standards
and the contacts are safe.
Connect the electrical wires according to the following
electrical connecting diagrams.
6001a02
NOTE
The protection IP6K9K (NEMA 4) is
guaranteed when the socket (x1, x2) is
tightened on housing cover with flat
packing.
Direct current (DC)
with integrated p.c.b. and attached divider block, alarm contact as normally open contactt:
4253a00
Fig. 11 Electrical Connecting Diagram, DC

Page 13 of 44
User Manual
Installation and Operation Instructions
2.1B-38006-C02
Form 403013
Subject to modificaitons
Electrical Connecting Diagrams, continuation
Direct current (DC)
with integrated p.c.b. and external divider block, alarm contact as normally open contact:
4258a00
Fig. 12 Electrical Connecting Diagram, DC

Page 14 of 44
User Manual
Installation and Operation Instructions
2.1B-38006-C02 Form 403013
Subject to modificaitons
Electrical Connecting Diagrams, continuation
Direct current (DC)
with integrated p.c.b. and attached divider block, alarm contact as normally closed contact:
4253a02
Fig. 13 Electrical Connecting Diagram, DC

Page 15 of 44
User Manual
Installation and Operation Instructions
2.1B-38006-C02
Form 403013
Subject to modificaitons
Electrical Connecting Diagrams, continuation
Direct current (DC)
with integrated p.c.b. and external divider block, alarm contact as normally closed contact:
4258a02
Fig. 14 Electrical Connecting Diagram, DC

Page 16 of 44
User Manual
Installation and Operation Instructions
2.1B-38006-C02 Form 403013
Subject to modificaitons
Electrical Connecting Diagrams, continuation
Alternate current (AC)
with integrated p.c.b. and attached divider block, alarm contact as normally open contact:
4254a00
Fig. 15 Electrical connecting diagram, AC

Page 17 of 44
User Manual
Installation and Operation Instructions
2.1B-38006-C02
Form 403013
Subject to modificaitons
Electrical Connecting Diagrams, continuation
Alternate current (AC)
with integrated p.c.b. and external divider block, alarm contact as normally open contact:
4260a00
Fig. 16 Electrical connecting diagram, AC

Page 18 of 44
User Manual
Installation and Operation Instructions
2.1B-38006-C02 Form 403013
Subject to modificaitons
Electrical Connecting Diagrams, continuation
Alternate current (AC)
with integrated p.c.b. and attached divider block, alarm contact as normally closed contact:
4254a02
Fig. 17 Electrical connecting diagram, AC

Page 19 of 44
User Manual
Installation and Operation Instructions
2.1B-38006-C02
Form 403013
Subject to modificaitons
Electrical Connecting Diagrams, continuation
Alternate current (AC)
with integrated p.c.b. and external divider block, alarm contact as normally closed contact:
4260a02
Fig. 18 Electrical connecting diagram, AC

Page 20 of 44
User Manual
Installation and Operation Instructions
2.1B-38006-C02 Form 403013
Subject to modificaitons
Description of QLS 301
4198a99
Fig. 19 QLS 301 with back position of the SSV divider block
1 Proximity switch
2 Control pin
3 SSV divider block
4 Nipple for external manual lubrication (1/8’’)
4199b02
Fig. 20 QLS 301 with bottom position of the SSV divider block
The QLS 301 is a complete compact lubrication system
for a maximum of 18 lubrication points per cycle.
The pump has three basic configurations:
- SSV divider block mounted on the back (see Fig. 19)
- SSV divider block mounted on the bottom (see Fig. 20)
- Pump without the SSV divider block attached respec-
tively with external divider block KNQLS (see fig. 21)
The pump with the SSV divider block mounted on the
bottom has the capability of using steel tubing as lubrica-
tion lines if necessary.
Standard lubrication lines are high-pressure plastic hoses
included in the pump installation kit for pumps with the
SSV divider block attached.
6001a02
NOTE
The function of the pump is independent
of the SSV divider block's mounting posi-
tion.
A signal from the pump timer starts the electric motor and
the pumping element starts pumping the lubricant to the
SSV divider block.
When all lubrication points have received lubricant, an
internal proximity switch 1 Fig. 19 (initiator) turns the mo-
tor off, completing one lubrication cycle.
If the pump does not complete the cycle within 15 minutes
of operation, the alarm message ”Er” will be displayed as
a flashing light in the keypad window, see fig. 26.
1 Connecting block
2 Manifold
3 SSV divider block
4 Nipple for external manual lubrication (1/8’’)
5 Plug (1/8’’) for
P external pressure line
R external return line
