Linksys Linksys SPA9000 Service manual

Corporate Headquarters
Linksys
121 Theory Drive
Irvine, CA 92617
USA
http://www.linksys.com
Tel: [phone]
800 546-5797
Fax: [phone]
Linksys SPA9000 Administrator Guide
Document Version 3.01

Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other
countries. Other brands and product names are trademarks or registered trademarks of their respective holders.
Linksys SPA9000 Administrator Guide
Copyright ©2007 Cisco Systems, Inc. All rights reserved.

iii
Linksys SPA9000 Administrator Guide
Document Version 3.01
CONTENTS
Preface i-xi
Document Audience i-xi
How This Document is Organized i-xii
Document Conventions i-xii
Related Documentation i-xiii
Technical Support i-xiii
CHAPTER 1Using the Linksys Voice System 1-1
The Linksys Voice System 1-1
Overview 1-1
SPA400 SIP-PSTN Gateway and Voicemail 1-2
Auto-Attendant 1-3
SPA9000 System Features 1-3
Additional Features When Used with SPA900 Series IP Phones 1-5
Technology Background 1-6
Session Initiation Protocol 1-6
SPA9000 Media Proxy 1-7
Using the SPA9000 with a Firewall or Router 1-8
SPA400 SIP-PSTN Gateway 1-8
Network Address Translation (NAT) 1-9
NAT Overview 1-9
NAT Types 1-10
Simple Traversal of UDP Through NAT 1-10
SIP-NAT Interoperation 1-11
SPA9000 Architecture 1-11
Architectural Components 1-12
Multicast Addressing and Group Paging 1-13
Configuration Options 1-14
Interactive Voice Response 1-14
Setup Wizard 1-14
Administration Web Server 1-14
Local Client Configuration and Registration 1-15

Contents
iv
Linksys SPA9000 Administrator Guide Document Version 3.01
Remote Provisioning of the SPA9000 1-15
Where to Go From Here 1-16
CHAPTER 2Getting Started 2-1
Implementing LVS 2-1
Using the SPA9000 and SPA400 as a VoIP PBX System 2-2
Using the SPA9000 as a Media Proxy 2-3
Using the LVS as a Key System 2-3
SPA9000 Hardware 2-4
SPA9000 Back Panel 2-4
The Front Panel 2-5
SPA400 Hardware 2-6
Bandwidth Requirements 2-6
Caring for Your Hardware 2-7
Making the Physical Connections 2-8
Using the Interactive Voice Response Interface 2-8
Using the IVR Menu 2-9
IVR Options 2-10
Entering a Password through the IVR 2-12
Initial Setup and Configuration 2-12
Licensing 2-13
Using DHCP or Static IP Addressing 2-13
Using the Wizard for Initial Configuration 2-13
Using the Wizard to Upgrade Software 2-18
Setting the SPA9000 Administrator Account Password 2-22
Using the Administration Web Server 2-22
Connecting to the Administration Web Server 2-22
Administrator Account Privileges 2-24
Advanced Methods of Configuration 2-24
Web Interface URLs 2-24
Upgrade URL 2-25
Resync URL 2-25
Reboot URL 2-25
Provisioning 2-26
Provisioning Capabilities 2-26
Configuration Profile 2-26
Client Auto-Configuration 2-27
Manual Client Configuration 2-28
Client Registration 2-30

Contents
v
Linksys SPA9000 Administrator Guide
Document Version 3.01
Troubleshooting and Configuration FAQ 2-31
CHAPTER 3Configuring Voice Service and Voicemail 3-1
Using the Wizard to Configure ITSP Voice Services and Voicemail 3-1
Completing the Voicemail Configuration 3-6
Configuring the SPA400 for PSTN Connectivity or Voicemail 3-8
Understanding How the SPA400 Interacts with the SPA9000 3-8
Using the SPA9000 Setup Wizard to Configure the SPA400 3-8
Using the Administration Web Server to Configure the SPA400 3-11
Accessing the Administration Web Server 3-12
Configuring the SPA400 to Connect to the SPA9000 3-12
Configuring the SPA9000 to Register the SPA400 3-15
Configuring the SPA400 Voicemail Services 3-15
Configuring the SPA9000 Voicemail Settings 3-16
Configuring SPA400 Voicemail Accounts 3-17
Configuring a SPA IP Phone for Voice Mail Service 3-18
SPA400 Voicemail Options 3-20
Managing Voicemail 3-20
How Voicemail Works 3-21
Checking Voicemail from an External Number 3-22
Depositing Voicemail 3-22
Subscribing to Voicemail Notification 3-23
CHAPTER 4Configuring SPA9000 Features 4-1
Using the Wizard to Configure SPA9000 Voice Features 4-1
Configuring Client Stations 4-2
Configuring Client Extensions 4-4
Configuring Shared Extensions 4-5
Configuring a Call Hunt Group 4-6
Using the Wizard for Localization 4-7
Using Dial Plans 4-9
Configuring Dial Plans 4-9
Dial Plan Digit Sequences 4-9
Dial Plan Rules 4-10
Dial Plan Examples 4-11
Dial Plan Timers 4-12
Interdigit Long Timer 4-12
Interdigit Short Timer 4-12

Contents
vi
Linksys SPA9000 Administrator Guide Document Version 3.01
Dial Plans 4-13
Basic Call Management 4-13
Receiving External Phone Calls 4-13
Calling Between Client Stations 4-13
Client Stations Calling an External Number 4-14
External Users Calling the SPA9000 4-15
Supporting Multiple DID Numbers Per Line Interface 4-16
Managing Call Forwarding 4-17
How Call Forwarding Works 4-17
Using Call Hunt Groups 4-19
Overview 4-19
Configuring a Hunt Group Rule 4-19
Using the Contact List Parameter 4-20
Using the Administration Web Server to Configure Hunt Groups 4-20
Client Station Blind Transfers External Caller To DID/Hunt Group 4-21
Using Shared Line Appearance 4-22
Managing Call Pickup 4-25
Directed Call Pickup 4-25
Group Call Pickup 4-26
Call Park and Pickup 4-26
Multicast and Group Paging 4-27
Music On Hold 4-28
Overview 4-28
Changing the Internal Music Source 4-28
Restoring the Default Internal Music Source 4-29
Using a Streaming Audio Server 4-30
Using the IVR with an SAS Line 4-30
Example SAS with MOH 4-31
Configuring the Streaming Audio Server 4-32
Enhancements in Release 5.1 4-32
Bridge Mode 4-32
Call Forward Bridge Mode 4-33
Call Transfer Bridge Mode 4-33
REGISTER Enhancement 4-33
Renew DHCP On SIP Request Timeout 4-34
CHAPTER 5Configuring the LVS Auto-Attendant 5-1
Configuring Auto-Attendant 5-1
How the Auto-Attendant Works 5-1

Contents
vii
Linksys SPA9000 Administrator Guide
Document Version 3.01
Using the IVR to Record Auto-Attendant Prompts 5-2
Using the Wizard to Configure the Auto-Attendant 5-4
Using the Administration Web Server to Configure the Auto-Attendant 5-6
Downloading Prompts 5-8
Configuring Dial Plans for the Auto-Attendant 5-9
Alternative AA Configuration 5-10
Switching Between Alternative AAs Using the IVR 5-10
XML Scripting for the Auto-Attendant 5-13
Overview 5-13
XML Scripting Grammar 5-13
Node Type Dialog 5-14
Menu Type Dialog 5-14
Dialplan Statement 5-14
AA Instructions 5-15
Audio Instruction 5-15
Action Instruction 5-15
Noinput Instruction 5-15
Nomatch Instruction 5-16
Menu Matched Instruction—Recognition of Touch Tone (DMTP) Key Presses 5-16
AA XML Script Examples 5-17
Example 1—AA Default XML Script 5-17
Example 2 5-18
Example 3—AA Script with Two Treatments 5-19
Office Hour AA Treatment 5-19
Non-Office Hour AA Treatment 5-20
Auto-Attendant XML Instructions Set 5-22
CHAPTER 6SPA9000 Field Reference 6-1
Info Tab 6-2
Product Information 6-2
System Status 6-2
Line 1/2/3/4 Status 6-3
FXS 1/2 Status 6-3
Auto Attendant Prompt Status 6-4
Internal Music Status 6-5
System Tab 6-6
System Configuration 6-6
Miscellaneous Settings 6-6

Contents
viii
Linksys SPA9000 Administrator Guide Document Version 3.01
SIP Tab 6-7
SIP Parameters 6-7
SIP Timer Values (sec) 6-8
Response Status Code Handling 6-10
RTP Parameters 6-10
SDP Payload Types 6-11
NAT Support Parameters 6-13
PBX Parameters 6-14
Internal Music Source Parameters 6-17
Auto Attendant Parameters 6-18
PBX Phone Parameters 6-21
Regional Tab 6-23
Call Progress Tones 6-23
Distinctive Ring Patterns 6-24
Distinctive Call Waiting Tone Patterns 6-26
Distinctive Ring/CWT Pattern Names 6-26
Ring and Call Waiting Tone Spec 6-27
Control Timer Values (sec) 6-28
Vertical Service Activation Codes 6-29
Vertical Service Announcement Codes 6-33
Outbound Call Codec Selection Codes 6-33
Miscellaneous 6-35
FXS 1/2 Tab 6-38
Line Enable 6-38
Network Settings 6-38
SIP Settings 6-39
Subscriber Information 6-41
Dial Plan 6-41
Mailbox Status 6-41
Streaming Audio Server (SAS) 6-42
Call Feature Settings 6-43
Audio Configuration 6-43
FXS Port Polarity Configuration 6-46
Line 1/2/3/4 Tab 6-47
Line Enable 6-47
Network Settings 6-47
SIP Settings 6-48
Subscriber Information 6-50
Dial Plan 6-52

Contents
ix
Linksys SPA9000 Administrator Guide
Document Version 3.01
NAT Settings 6-53
Proxy and Registration 6-54
APPENDIX AAcronyms
APPENDIX BGlossary
I NDEX

Contents
x
Linksys SPA9000 Administrator Guide Document Version 3.01

xi
Linksys SPA9000 Administrator Guide
Document Version 3.01
Preface
The LVS 9000 solution includes a line of IP communication products including desktop IP phones, an
IP PBX, and PSTN gateway
This guide describes basic administration and use of the Linksys SPA9000 IP PBX and the SPA400
PSTN gateway. It contains the following sections:
• Document Audience, page xi
• How This Document is Organized, page xii
• Document Conventions, page xii
• Related Documentation, page xiii
• Technical Support, page xiii
Document Audience
This document is written for the following audience:
• Service providers offering services using LVS products
• VARs and resellers who need LVS configuration references
• System administrators or anyone who performs LVS installation and administration
Note This guide does not provide the configuration information required by specific service
providers. Please consult with the service provider for specific service parameters.

xii
Linksys SPA9000 Administrator Guide Document Version 3.01
Preface
How This Document is Organized
How This Document is Organized
This document is divided into the following chapters and appendices.
Document Conventions
The following are the typographic conventions used in this document.
Chapter Contents
Chapter 1, “Using the Linksys
Voice System.” This chapter introduces the SPA9000 IP PBX and the SPA400
PSTN gateway.
Chapter 2, “Getting Started.” This chapter describes how to establish connectivity between the
SPA9000, the SPA400, and other components.
Chapter 3, “Configuring Voice
Service and Voicemail.” This chapter describes how to configure voice services and SPA400
or ITSP-hosted voicemail.
Chapter 4, “Configuring
SPA9000 Features.” This chapter describes how to configure SPA9000 features.
Chapter 5,“ConfiguringtheLVS
Auto-Attendant.” This chapter describes how to configure or write XML scripts for
the Auto-Attendant
Chapter 6, “SPA9000 Field
Reference” This chapter lists the function and usage for each field or parameter
on the SPA9000 administration web server pages.
Appendix A “Acronyms.” This appendix provides the expansion of acronyms used in this
document.
Appendix B “Glossary.” This appendix defines the terms used in this document.
Typographic Element Meaning
Boldface Indicates an option on a menu or a literal value to be entered in a field.
<parameter> Angle brackets (<>) are used to identify parameters that appear on the
configuration pages of the SPA9000 administration web server. The index
at the end of this document contains an alphabetical listing of each
parameter, hyperlinked to the appropriate table in Chapter 6, “SPA9000
Field Reference”
Italic Indicates a variable that should be replaced with a literal value.
Monospaced Font Indicates code samples or system output.

xiii
Linksys SPA9000 Administrator Guide
Document Version 3.01
Preface Related Documentation
Related Documentation
The following documentation provides additional information about features and functionality of the
SPA9000:
• LVS CTI Integration Guide
• LVS Integration with ITSP Hosted Voicemail Guide
• AA & IVR Quick Guides
• SPA Provisioning Guide
• SPA9000 User Guide
The following documentation describes how to use other Linksys Voice System products:
• SPA900 Series IP Phones Administrator Guide
• LVS Linksys Voice over IP Products Guide
• SPA 2.0 Analog Telephone Adapter Administrator Guide
Technical Support
If you are an end user of LVS products and need technical support, contact the reseller or Internet
telephony service provider (ITSP) that supplied the equipment.
Technical support contact information for authorized Linksys Voice System partners is as follows:
• LVS Phone Support (requires an authorized partner PIN)
888 333-0244 Hours: 4am-6pm PST, 7 days a week
• E-mail support
[e-mail]

xiv
Linksys SPA9000 Administrator Guide Document Version 3.01
Preface
Technical Support

1-1
Linksys SPA9000 Administrator Guide
Document Version 3.01
CHAPTER
1
Using the Linksys Voice System
This chapter provides an introduction to the components and functionality of the Linksys Voice System
(LVS). It includes the following sections:
• The Linksys Voice System, page 1-1
• Technology Background, page 1-6
• SPA9000 Architecture, page 1-11
• Where to Go From Here, page 1-16
The Linksys Voice System
This section provides basic information about the LVS VoIP PBX system and includes the following
topics:
• Overview, page 1-1
• SPA400 SIP-PSTN Gateway and Voicemail, page 1-2
• Auto-Attendant, page 1-3
• SPA9000 System Features, page 1-3
• Additional Features When Used with SPA900 Series IP Phones, page 1-5
Overview
The Linksys Voice System (LVS) is an affordable, feature-rich, multi-line voice over IP (VoIP) telephone
system that provides sophisticated communication services to small business users. The LVS uses
standard TCP/IP protocols and can provide global connectivity through any Internet Telephony Service
Provider (ITSP) that supports Session Initiation Protocol (SIP). In addition, with the optional SPA400,
the LVS provides full interconnectivity with the Public Switched Telephone Network (PSTN).
The LVS solution, illustrated in Figure 1-1, provides a line of IP communication products that include
the following:
• SPA9000 IP PBX
• SPA400 SIP-PSTN gateway
• SPA900 Series IP phones (SPA921, 922, 941, 942, and 962)

1-2
Linksys SPA9000 Administrator Guide Document Version 3.01
Chapter 1 Using the Linksys Voice System
The Linksys Voice System
Figure 1-1 The Linksys Voice System (LVS) with the SPA9000 and SPA400
The LVS 9000 system uses the power of VoIP to provide enterprise-quality telephony features to small
office/home office (SOHO) and small businesses. The LVS is based on open standards, such as SIP,. This
allows interoperation with other standards-based products and simplifies configuration and use. The
SPA9000, with a base license, supports up to four IP phones and up to 16 phones with an upgraded
license.
With the optional SPA400, the SPA9000 can also manage calls to and from the PSTN. The SPA9000 also
includes an Analog Telephone Adapter (ATA), with two FXS ports for connecting analog telephones, fax
devices, or an external music source for the music on-hold service included with the SPA9000.
The SPA9000 supports four independent line interfaces with numbers assigned by one to four different
ITSPs, with each line supporting up to 16 extensions. If the service provider supplies a group of
sequential direct inward dial (DID) phone numbers (such as 408-777-1000 through 777-1015) the
SPA9000 can support all the assigned numbers on a single line interface.
For information about LVS architecture, refer to the “SPA9000 Architecture” section on page 1-11.
SPA400 SIP-PSTN Gateway and Voicemail
The SPA400 is optionally used with the SPA9000 to provide a SIP-PSTN gateway, providing voice
connectivity between the PSTN and local client stations connected to the SPA9000. It also provides a
local voicemail server.
Note The SPA400 provides four FXO ports and occupies one line interface on the SPA9000.
A total of four SPA400 devices can be configured per SPA9000, using up to 16 analog phone lines and,
with the SPA9000, automatically routing calls to and from your existing PSTN telephone service.
SPA400
SIP-PSTN
gateway
SPA901, 921, 922, 941, 942, 962
Internet
ITSP
Up to 4 FXO lines
Local voicemail
Fax/Analog
Phones
SPA9000
IP PBX
PSTN
ISP
FXS1 FXS2
Switch

1-3
Linksys SPA9000 Administrator Guide
Document Version 3.01
Chapter 1 Using the Linksys Voice System The Linksys Voice System
Designed to be implemented with the SPA9000, the SPA400 lets cost-conscious business users take
advantage of all the high-value features on the LVS, which are typically found on much more expensive
voice communications systems. The SPA400 includes an integrated voicemail application supporting up
to 32 voicemail accounts with customized greetings, providing LVS users the ability to receive and
playback voicemail messages. The SPA400 ships with a USB voicemail module, which stores voicemail
prompts and allows recording of up to four hours of high-quality voice messages.
For detailed information about using the SPA400 voice services and voicemail servers, refer to
Chapter 3, “Configuring Voice Service and Voicemail.”
Auto-Attendant
The Auto-Attendant is aninternal service within the SPA9000. It plays pre-recorded voice messages that
offer the caller a menu of choices, so the Auto-Attendant can appropriately direct the call. After the
caller has made a choice, the call is routed to the appropriate extension. When the Auto-Attendant is
enabled, it parses and operates on user input (key presses or DTMF tones) following the rules specified
in the Auto-Attendant script on the SPA9000.
For detailed information about using and configuring the Auto-Attendant, refer to Chapter 5,
“Configuring the LVS Auto-Attendant.”
SPA9000 System Features
This following summarizes the features provided by the SPA9000:
• SIP Application Server, Proxy, Registrar and Location Server (RFC3261)
• Multiple Service Provider Lines / SIP Account Support (4)
• Shared Line Appearance (SLA)
• Configurable AA Answer Delay
• Interactive Voice Response (IVR)
• Recordable IVR Prompts
• Automatic Call Distribution (ACD)
• Configurable Call Routing
– Least Cost Routing
– Multiple DID Numbers Per VoIP Line
– Call Routing to Multiple Extensions or Targeted User
– Call Hunting - Sequential, Round Robin, Random
• Phone Configuration and Management Server
– Discovery and Configuration of IP Phones
– Assignment of Extension
– Assignment of Dial plan
– Proxy Logging of SIP Messages
– Phone Firmware Upgrade Management
• Corporate Directory with Automatic Update

1-4
Linksys SPA9000 Administrator Guide Document Version 3.01
Chapter 1 Using the Linksys Voice System
The Linksys Voice System
• Configuration and Maintenance via Web Interface (Local or Remote
– Status Display of All Connections
• Remote Configuration via
– HTTPS with XML Formatted Files
– HTTP or TFTP with 256-Bit Encrypted Binary Files
• Call Park -User Definable Parking Space Number
• Call Unpark
• Call Transfer - Attended and Blind
• Call Forward
• Group Paging
• Intercom
• Directed Call Pick Up
• Group Call Pick Up
• Music / Information via Streaming Audio Server (SAS) for Calls:
– On Hold
– Parked in the Parking Lot
– Being Transferred
• Simultaneous Ringing (Find Me Service)
• Do Not Disturb
• Voice Mail Integration - Service Provider Based
– Voice Mail Notification via SUBSCRIBE / NOTIFY
– Forward Call Directly to Voice mail
• Integrated Media Proxy or Direct RTP Routing to ITSP
• Differentiated Services (DiffServ) / Type of Service (TOS) Support
• Two FXS (RJ-11) ports for Phones, Fax machines, Media Adapters
• Voice encoding with G.711 (64kbit/s) and other codecs (G.723, G.726, and G.729
• Fax Support using G.711 Pass-Through or T.38
• Echo Cancellation (G.165)
• Line Status - Active Line Indication, Name/Number
• Digits Dialed with Number Auto-Completion
• Call Hold
• Call Waiting
• Call Conferencing
• Automatic Redial
• Call Pick Up - Selective and Group
• Call Forwarding - Unconditional, No Answer, On Busy

1-5
Linksys SPA9000 Administrator Guide
Document Version 3.01
Chapter 1 Using the Linksys Voice System The Linksys Voice System
Additional Features When Used with SPA900 Series IP Phones
The following lists the additional features available when using the SPA9000 with SPA900 Series IP
phones:
• Line Status - Active Line Indication, Name/Number
• Digits Dialed with Number Auto-Completion
• Call Hold
• Call Waiting
• Call Transfer - Attended and Blind
• Call Conferencing
• Automatic Redial
• Call Pick Up - Selective and Group
• Call Swap
• Call Forwarding - Unconditional, No Answer, On Busy
• Hot Line and Warm Line Automatic Calling
• Call Log (60 entries each): Made, Answered, Missed Calls
• Personal Directory with Auto-dial (100 entries)
• Do Not Disturb
• URI (IP) Dialing Support (Vanity Numbers)
• On Hook Default Audio Configuration (Hands Free/Headset)
• Multiple Ring Tones with Selectable Default Ring Tone per Line
• Called Number with Directory Name Matching
• Calling Number with Name - Directory Matching or via Caller ID
• Subsequent Incoming Calls with Calling Name and Number
• Date and Time with Intelligent Daylight Savings Support
• Call Duration with Call Time Stamp Stored in Call Logs
• Name/Identity (Text) Display at Start Up
• Distinctive Ringing Based on Calling and Called Number
• User Downloadable Ring Tones and Ring Tone Generator (Free from www.linksys.com)
• Download on Demand Ring Tones - 10
• Speed Dial Support
• Configurable Dial/Numbering Plan Support - per Line
• DNS SRV and Multiple A Records for Proxy Lookup and Proxy Redundancy
• Syslog, Debug, Report Generation and Event Logging
• Secure Call Encrypted Voice Communication Support
• Built-in Web Server for Admin and Config with Multiple Security Levels
• Automated Provisioning, Multiple Schemes-Up to 256 Bit Encryption: (HTTP, HTTPS, TFTP)
• Require Admin Password to Reset Unit to factory Defaults Option

1-6
Linksys SPA9000 Administrator Guide Document Version 3.01
Chapter 1 Using the Linksys Voice System
Technology Background
Technology Background
This section provides background information about the technology and protocols used by the SPA9000
system. It includes the following topics:
• Session Initiation Protocol, page 1-6
• SPA9000 Media Proxy, page 1-7
• Using the SPA9000 with a Firewall or Router, page 1-8
• SPA400 SIP-PSTN Gateway, page 1-8
• Network Address Translation (NAT), page 1-9
Session Initiation Protocol
The LVS is implemented using open standards, such as Session Initiation Protocol (SIP), allowing
interoperation with all ITSPs supporting SIP. Figure 1-2 illustrates a SIP request for connection to
another subscriber in the network. In the SIP protocol, the requestor of the session is called the user agent
server (UAS), while the receiver of the request is called the user agent client (UAC).
Figure 1-2 SIP Requests and Responses
Note In this manual, the term client station is used to describe any SIP UA (including IP phones) that registers
with the SPA9000.
In a SIP VoIP network, when the SIP proxy receives a request from a client station (UAS) for a
connection and it does not know the location of the UAC, it forwards the message to another SIP proxy
in the network. Once the UAC is located and the response is routed back to the UAS, a direct peer-to-peer
session is established between the two UAs. The actual voice traffic is transmitted between UAs over
dynamically assigned ports using the Real-time Protocol (RTP).
SIP UA
SIP UA
SIP Proxy
SIP Proxy
RTP
1
2
3
4
SIP Proxy
