PRODUCT DATA
WIP300
Wireless-G IP Phone
Model No.
Mobile WiFi Phone for VoIP
Service
Make Low-Cost High Quality
VoIP Calls On Your Wireless-G
Network.
Superior Range and
Performance with 802.11g
Easy, Secure Setup on WiFi
Network (with SES)
Intuitive User Interface

• Support SIP v2 Standards
• Compliance with IEEE 802.11b/g Wireless Standard
• High Resolution Color LCD screen
• 50 hours standby time, 3 hours talk time on average**
• Backlit Keypad
• Intuitive User Display
•RFandBatteryLevelIndication
• WiFi Site Survey Tool
• Connection Status Button
• USB Charger Interface
**Batteries are rechargeable and have a limited number of charge cycles. The batteries may
eventually need to be replaced. Battery life will vary from the stated average by usage,
configuration and environment.
•Handset
•USBPowerAdapter
• Li-ion Battery
• Quick Install Guide
• UserGuideonCD-ROM
• Internet Connection (cable/DSL/other)
• Wireless Router / Access Point with DHCP server
• Activated VoIP Service
PRODUCT DATA
Features
WIP300
Model No.
Package Contents
Minimum
Requirements

Specifications
Model
Standards
Band
Transmit Power
Radio Range
External interface
Display
Memory
WiFi Account Support
Network Protocols
Security
Voice Protocols
Voice Codec's
DTMF Transmission
Voice Quality
Telephony and
Supplementary
Services
Management features
Dimensions
Unit Weight
Power
Certification
Operating Temp.
Storage Temp.
Operating Humidity
Storage Humidity
WIP300
802.11b, 802.11g
2.4GHz
12.5 dBm for 802.11g / 16.6 dBm for 802.11b
Outdoors up to 200m, Indoors up to 75m via Embedded Antenna
One USB 1.1 port, 2.5mm standard 4 segment Ear Phone Jack
1.8 inch TFT, LCD (128 x 160 pixels) with 65K colors
16MB Flash, 12MB SRAM
Multiple Access point Registration Support
TCP/UDP/IP, IPV4, DNS, SDP, ARP, ICMP, DHCP Client, Static IP, PPPoE
WEP, WPA,WPA2,TKIP
SIP v2 Session Initiation Protocol (RFC3261)
SIP Session Keep Alive
Multiple SIP Account Support
G.711( A-law and µ-law), G.729 A/B
In-band, Out-band (RFC2833)
G.168 Echo Cancellation
Jitter Buffer Control
CNG - Comfortable Noise Generation
Speaker and Microphone Volume Control
Silence Suppression
VAD - Voice Activity Detection
Call Hold and Resume
Caller ID Presentation
Dial by Phone Number
Call Forward
DTMF Tone Detection and Generation
Call Transfer
Call Waiting and Retrieve
Mute
Speed Dial
Last Number Redial
Volume Control
Vibrator (Silent mode)
Password Security
Phone Book (200 Records)
Call History (20 Records)
POP3/SMTP Email Access (optional)
Ring tones: True Tones,
Selectable Wallpaper Background
Language - English
AES Encryption
Embedded Web configuration interface (with password protection)
Firmware upgrade through HTTP over WiFi
Configuration file backup and restore
45 x 118 x 19.7x mm (1.77 x 4.65 x 0.78 in)
0.1 kg (3.53 oz)
900mAh Li-ion Battery, AC Adapter
FCC, CE
0ºC to 40ºC (32ºF to 104 ºF)
-20ºC to 65ºC (-4ºF to 149 ºF)
10% to 85% relative humidity, non-condensing
10% to 95% non-condensing
WIP300
Model No.
PRODUCT DATA
Environmental

The Linksys WIP300 Wireless-G IP Phone enables high-quality voice over IP (VoIP)
service through a Wireless-G network and high-speed Internet connection. Connect at
home or your office, and make low-cost phone calls through your Internet Telephony
Service Provider.
The WIP300 Wireless-G IP Phone operates in the 2.4GHz band, supports 802.11g and
the latest VoIP SIP protocols. The large, full-color high resolution display features an
intuitive user interface enabling users to easily and quickly configure the handset using
Secure Easy Setup (SES).
SES is a fast, secure way of connecting the WIP300 Wireless-G IP Phone to a Linksys
Wireless-G broadband router. Just press the associated SES button on both devices
and your connection will automatically be configured and secured with a custom SSID
using powerful WPA (Wi-Fi Protected Access) encryption. That’s it! Within seconds you
have successfully set up a secure connection.
Get the value of low-cost VoIP service with the convenience of Wireless-G connectivity
with the Wireless-G IP Phone from Linksys.
