This document does not replace the instructions
for use. For complete information, see
the instructions for use and the additional
information for hospital staff.
Brief instructions for use
Brief instructions for use
for hospital staff
Enable and lock clinical functions
Switch device on and off
Press on/off key . When switching off, acknowledge the
alarm Warning: Device switched off.
Enable
In patient mode or with autolock activated:
hold down the IPAP and PEEP keys for 4 seconds until the
message Hospital menu locked! or Only available in hospital
menu! is no longer displayed.
Lock
Press the IPAP and PEEP keys until the message Hospital menu
locked! appears.
Alternatively:
activate patient mode via the menu.
VENTIlogic plus
VENTIlogic LS
Alarms
Risk of injury due to implausible alarm limits!
-> Always set alarm limits to suit the patient in the Alarms
menu item.
Alarm symbols
Physiological alarm activated.
Physiological alarm deactivated.
Alarm switched to mute.
Priorities if alarms are triggered simultaneously
High priority (red)
Medium priority (yellow)
Low priority (yellow)
Acknowledge alarms
Press the alarm acknowledgement key to suppress the
acoustic alarm for 120 sec.
Symbols in the display
Battery: displays the number of batteries and
battery capacity
SD card: measured values are written to the
memory card.
Filter change required
Servicing required
Blower off (standby mode)
Press the IPAP
and PEEP keys
simultaneously
Weinmann
Geräte für Medizin GmbH+Co.KG
Kronsaalsweg 40 D-22525 Hamburg, Germany
E: [email protected] www.weinmann.de
T: [phone] switchboard
F: [phone] switchboard
WM 67621 - 05/2014
On/
off key
On/off key
Replaceable battery
(optional)
SD card
Alarm
suppression

VENTIlogic plus
VENTIlogic LS
1. Ifnecessary:texhalationblockandsetDouble patient valve
in the device.
2. Push ventilation tube (1) onto the device outlet port.
3. Pushtheexhalationtubewithpatientvalve(4)ontothe
deviceinletontheexhalationblock.
4. Connect pressure measurement tube (2) to connection
with the blue marking.
5. Connect valve control tube (3) to connection .
6. Connect the end of the tube (Y-piece) to the patient/
ventilator interface.
1. If necessary: convert device for operation with leakage
system and set Leakage system in the device.
2. Push patient circuit onto the device outlet port until the click
adapter engages.
3. Connect the end of the tube to the patient/ventilator
interface.
Patient circuit
Risk of device overheating due to inadequate tube diameter!
-> Only use patient circuits with a diameter of Ø 15 mm or
more.
-> Notethattotalpermittedresistancemaybeexceededeven
in patient circuits with a diameter of 15 mm when these are
combinedwithbacterialters.
Risk of suffocation due to accumulation of CO2!
-> Onlyuseleakagesystemwithanexhalationsystem.
-> Always keep the patient valve open with valve ventilation.
Oxygen supply
Risk of re due to oxygen!
->Nosmokingornakedames.
-> Do not use electrically conductive tubes.
->Supplyoxygenonlyviatheoxygenconnection.
Connect oxygen supply
1. Switch on therapy device.
2. Connect O2coupling (1) to
the therapy device.
3. Connecttheoxygensourceto
the O2coupling.
4. Startoxygensupply.
Measure oxygen concentration
(valve ventilation only)
1. Assemble air guide adapter
(2),oxygensensor(1)and
T-adapter (3) and push onto
the device outlet port.
2. Connect the sensor cable to
oxygenmeasuringsocket(4).
3. Connect patient circuit.
4. Calibrateoxygensensorwith
ventilation in progress. Press
the O2key to do so
Stop oxygen supply
1. Shutoffoxygensupply.
2. Operatedevicewithoutoxygentoushouttheremaining
oxygen.
Connect single patient circuit, valve ventilation
Connect double patient circuit, valve ventilation
(VENTIlogic LS only)
Connect leakage system
1. If necessary: convert device for operation with valve
ventilation and set Single patient valve in the device.
2. Push ventilation tube (1) onto the device outlet port.
3. Connect pressure measurement tube (2) to connection
with the blue marking.
4. Connect valve control tube (3) to connection .
5. Connect the end of the tube with patient valve (4) to the
patient/ventilator interface.
