LUCCI Air ARIA GX53 CTC DC Installation guide

v1.0-AU (07/2022)
LUCCI
ARIA GX53 CTC DC
CEILING FAN
⚫INSTALLATION
⚫OPERATION
⚫MAINTENANCE
⚫WARRANTY INFORMATION
CAUTION
READ INSTRUCTIONS CAREFULLY FOR SAFE
INSTALLATION AND FAN OPERATION.

ARIA GX53 CTC DC Installation Instructions
1 | P a g e
THANK YOU FOR PURCHASING
Thank you for purchasing the latest in energy saving ceiling fans. This fan runs on DC (direct current) power
which gives it the benefit of being super energy efficient whilst still maintaining high volume air-movement and
silent operation.
Energy saving - The DC motor is the latest technology in fan design. Its highly efficient motor saves up to
65% more energy than ceiling fans with traditional AC motors.
Silent operation – This DC fan motor is programmed with a stabilised current which efficiently reduces motor
noise.
Low operating temperature – The DC power is managed effectively which brings down the motor operating
temperature to less than 50℃. This results in a much cooler motor than a standard AC fan and increases the
longevity of the motor.
6 speed remote control - Regular AC ceiling fans usually come with only 3 speeds, this DC fan comes
complete with a 6 speed remote, which gives a greater choice of comfort levels.
SAFETY PRECAUTIONS
1. The appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning the use of the appliance by a person responsible for their safety.
2. Children should be supervised to ensure that they do not play with the appliance.
3. An all-pole disconnection switch must be incorporated into the fixed wiring, in accordance with local wiring
rules.
WARNING:
FOR SAFE USE OF THIS FAN AN ALL-POLE DISCONNECTION
MUST BE INCORPORATED INTO THE FIXED WIRING IN
ACCORDANCE WITH THE WIRING RULES.
As outline in clause 7.12.2 of AS/NZS 60335-1 for meeting the minimum
electrical safety of this standard.
Please note warranty will be void if installation is without a means for an
all-pole disconnection incorporated in the fixed wiring in accordance with
the wiring rules.

ARIA GX53 CTC DC Installation Instructions
2 | P a g e
Example: If a fan is connected to a circuit that can be isolated via an all-
pole safety switch at the switchboard, then this is considered to be an
all-pole disconnection to the ceiling fan electrical circuit, meeting the
requirements of clause 7.12.2 of AS/NZS 60335.1.
A single-pole switch on the active of the receiver input of remote
control must also be included in the wiring, and located the same
room as the ceiling fan.
4. Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities.
Contact your local government for information regarding the collection systems available. If electrical
appliances are disposed of in landfills or dumps, hazardous substances can leak into the ground water
and get into the food chain, damaging your health and well-being.
5. The structure to which the fan is to be mounted must be capable of supporting a weight of 17kg.
6. The fan should be mounted so that the blades are at least 2.1 m above the floor.
7. This fan is suitable for indoor, alfresco and coastal areas where the fan is fully undercover with a minimum
of 1 wall. This fan is not waterproof. When installed in an alfresco or coastal area, the ceiling fan must be
positioned in a location protected from water, wind and dust. Exposure to these elements will void the
warranty. Mounting the fan in a situation where it is subject to water or moisture is dangerous and may
increase the risk of damage, injury or electrical shock and will void the warranty.
8. Must be assembled and installed by a licensed electrician.
9. WARNING: If unusual wobbling or oscillating movement is observed, immediately stop using the ceiling
fan and contact the manufacturer, its service agent or suitably qualified persons.
10. The replacement of parts of the safety suspension system device shall be performed by the manufacturer,
its service agent or suitably qualified persons.
11. The fixing means for attachment to the ceiling such as hooks or other devices shall be fixed with a
sufficient strength to withstand 4 times the weight of the ceiling fan; that the mounting of the suspension
system shall be performed by the manufacturer, its service agent or suitably qualified persons.

ARIA GX53 CTC DC Installation Instructions
3 | P a g e
PARTS LIST
•Unpack your ceiling fan carefully. Remove all parts and hardware.
•Lay out all the components on a smooth non-scratch surface and make sure there are no components
missing before assembling. If parts are missing, return the complete product to the place of purchase for
inspection or replacement.
•Check whether the ceiling fan has been damaged during transport. Do not operate/install any product
which appears damaged in any way. Return the complete product to the place of purchase for inspection,
repair or replacement.
•Examine all parts, you should have the following:
1
Mounting bracket x1 set
6
Motor housing x 1 set
2
Fan assembly x1 set
7
Mounting bracket screws x4
3
Blades x 4 pcs
8
Spare screw for fan blade x 1
4
Light kit plate x1 pcs
9
Remote receiver and Remote controller, screw,
battery, holder x 1 set
5
GX53 lamp x 1 set
Fig. 1

ARIA GX53 CTC DC Installation Instructions
4 | P a g e
INSTALLING THE FAN
TOOLS REQUIRED:
- Phillips / flat head screwdriver
- Pair of pliers
- Adjustable spanner
- Step ladder
- Wire cutter
- Wiring, supply cable as required by local provincial and national wiring codes and regulations
INSTALLING THE MOUNTING BRACKET
•The ceiling fan must be installed in a location so that the blades are spaced 300mm from the tip of the
blade to the nearest objects or walls.
•Install the hanging bracket to the ceiling joist or structure that is capable of carrying a load of at least 17kg,
with 4 long screws provided. Ensure at least 30mm of the screw is threaded into the support. (Fig. 2)
NOTE: The bracket screws provided are for use with wooden structures only. For structures other
than wood, the appropriate screw type MUST be used. Ensure the screws used are suitable for the
mounting surface and the surrounding environment.
ANGLED CEILING INSTALLATION
The hanging system of this fan is ONLY suitable for flat ceiling installation.
DO NOT install the fan on an angled ceiling.
Fig. 2
17 KG

ARIA GX53 CTC DC Installation Instructions
5 | P a g e
HANGING THE FAN TO MOTOR ASSEMBLY
•Install the motor housing (1) onto the motor assembly. (Fig.3)
•Lift the fan assembly up to the mounting bracket. Hang the fan assembly onto the J-hook (2) of the
mounting bracket. (Fig.4)
⚫Complete the electrical wiring according to the ‘ELECTRICAL WIRING DIAGRAM’ section below.
⚫ELECTRICAL WIRING DIAGRAM THE FAN
PREPARE AND COMPLETE THE ELECTRICAL WIRING --- WIRING DIAGRAM (FIG. 5)
WARNING: FOR YOUR SAFETY ALL ELECTRICAL CONNECTIONS MUST BE UNDERTAKEN BY A
LICENSED ELECTRICIAN.
NOTE: AN ADDITIONAL ALL POLE DISCONNECTION SWITCH MUST BE INCLUDED IN THE FIXED
WIRING.
NOTE: IF THERE ARE TWO OR MORE DC CEILING FANS INSTALLED IN THE ONE LOCATION, AN
ISOLATION SWITCH IS REQUIRED FOR EACH CEILING FAN. THIS IS REQUIRED WHEN
PROGRAMMING THE REMOTE AND RECEIVER TO PAIR TOGETHER.
Ensure the motor earth wire is connected to the single earthing terminal block “1” in the diagram below.
(Fig. 5)
Fig. 3
Fig. 4

ARIA GX53 CTC DC Installation Instructions
6 | P a g e
From mains supply to mounting bracket terminal block: (Fig. 5)
1. Connect the live supply wire to the “L” terminal of the terminal block on the mounting bracket.
2. Connect the neutral supply wire to “N” terminal of the terminal block on the mounting bracket.
3. Connect earth wire to the earth terminal of the terminal block on the mounting bracket.
From mounting bracket to receiver and motor: (Fig. 5)
4. Click together the supply wires from the mounting bracket to the input of the DC motor receiver.
5. Click together the output wires of DC motor receiver to the input wires of the fan motor and the light kit via
the quick connector plugs.
6. Connect the earth wires from the fan motor to the single earthing terminal block “1” in the diagram.
Fig. 5

ARIA GX53 CTC DC Installation Instructions
7 | P a g e
INSTALL THE FAN ASSEMBLY TO THE MOUNTING BRACKET
•After completing the electrical connection at the mounting bracket terminal block, connect the ceiling fan
wiring via the quick connector plugs.
NOTE: Ensure the earth wiring is secure and correct, by performing an earthing continuity test from
the fan’s accessible metal body back to the earth terminal at the terminal block on the mounting
bracket.
Install the fan assembly to the mounting bracket (Fig.6)
•There are 4 screws pre-installed on the mounting bracket:
- Loosen two canopy screws with star washer (2) by half thread from the mounting bracket. (For L-shape
slot on canopy to be mounted).
- Loosen two canopy screws (1) and remove from the mounting bracket.
•Lift the hanging canopy of the fan assembly up to the mounting bracket and let the L-shape slot on the
hanging canopy go through the two canopy screws with star washer (2).
•Turn the hanging canopy until it locks in place at the end section of the L-shape slot, ensure the star
washer are between the hanging canopy (3) and screw head. Secure it by tightening the two canopy
screws with star washer (2).
•Secure and tighten the canopy screws (1) to the mounting bracket. The hanging canopy (3) shall have 4
screws (1) & (2) in total. Avoid damaging the electrical wiring prepared previously when hanging the
canopy.
•Align the arrow mark (4) on the hook surface of the motor housing (5) up to the screws (2) of hanging
canopy (3).
•Finally attach the motor housing (5) to the mounting bracket, secure it by pushing the hooks of the
motor housing into the slot holes of the hanging canopy and turn it anti clockwise.
Fig. 6

ARIA GX53 CTC DC Installation Instructions
8 | P a g e
Fig. 6
INSTALLING THE FAN BLADE AND LIGHT KIT
BLADE ATTACHMENT (Fig.7)
1. Before installing the blades, remove the blade screws and flat washers from the bottom of fan motor.
2. Align the 2 holes on the blade with the 2 holes on the rotating member of fan motor assembly and using
the 2 blade screws and flat washers in step 1, to secure the blade to the fan motor assembly.
Ensure all screws are tightened evenly to reduce the chance of warping or unbalancing. Take care not
to over tighten the screws, as this can damage the blades.
3. Once completed, repeat the process on the remaining blades.
INSTALLATION OF LIGHT KIT (Fig. 8)
NOTE: The light kit must be installed by a licensed electrician.
1. Loosen the screw (1) from the fan bracket. (Fig. 8)
2. Align the two slot screws with the keyhole slots (2) of the light kit plate. (Fig. 8)
3. Turn the light kit plate counterclockwise until the slot screws are firmly at the end of the slots (2).
4. Secure screw (1) to the lamp shade bracket. Tighten all three screws. Do not over-tighten.
Fig. 7
Fig. 8

ARIA GX53 CTC DC Installation Instructions
9 | P a g e
INSTALLATION OF LAMP (Fig. 9)
• Install the lamp on the fan assembly then secure it by turning clockwise. (Fig. 9)
INSTALLATION OF THE REMOTE CONTROL HOLDER (Fig. 10)
1. Locate a suitable wall to fix the remote control holder with the 2 screws. (Fig.10a).
2. Slide the remote into the holder to rest the remote. (Fig. 10b)
Fig. 10a
Fig. 10b
Fig. 9
