Makita DTM50 User manual

1
GB Cordless Multi Tool INSTRUCTION MANUAL
UA
Акумуляторний універсальний інструмент ІНСТРУКЦІЯ ЗЕКСПЛУАТАЦІЇ
PL
Bezprzewodowe Narzędzie Wielofunkcyjne INSTRUKCJA OBSŁUGI
RO Maşinămultifuncţionalăfărăfir MANUAL DE INSTRUCŢIUNI
DE Akku-Multifunktions-Werkzeug BEDIENUNGSANLEITUNG
HU Vezeték nélküli többfunkciós gép HASZNÁLATI KÉZIKÖNYV
SK Univerzálny akumulátorový nástroj NÁVOD NA OBSLUHU
CZ Víceúčelové akumulátorové nářadí NÁVOD K OBSLUZE
DTM40
DTM50

2
1
2
3
1 012765
1
2 012128
1
2
3 015659
1
4 012768
1
5 012770
1
6 012779
1
7 012771
1
3
2
8 012826
12
3
9 012767
1
2
3
4
10 012847
1
11 012766 12 012801

3
13 012769
14 012800

4
ENGLISH (Original instructions)
Explanation of general view
1-1. Button
1-2. Red indicator
1-3. Battery cartridge
2-1. Star marking
3-1. Indicator lamps
3-2. Check button
4-1. Slide switch
5-1. Dial
6-1. Front lamp
7-1. Indication lamp
8-1. Application tool installation bolt
8-2. Holes in the application tool
8-3. Protrusions of the tool flange
9-1. Application tool installation bolt
9-2. Hex wrench
9-3. Tighten
10-1. Application tool installation bolt
10-2. Holes in the application tool
10-3. Adapter (required for some
application tools)
10-4. Protrusions of the tool flange
11-1. Hex wrench
SPECIFICATIONS
Model DTM40 DTM50
Oscillation per minute 6,000 - 20,000 (min-1)
Oscillation angle, left/right 1.6 ﾟ(3.2 ﾟtotal)
Overall length 324 mm
Standard battery cartridge
BL1430 /
BL1440 /
BL1450
BL1415 * /
BL1415N *
BL1830 /
BL1840 / BL1840B /
BL1850 / BL1850B
BL1815 * / BL1815N * /
BL1820 * / BL1820B *
without dust extraction attachment 1.9 kg 1.7 kg 2.0 kg 1.8 kg
Net weight with dust extraction attachment 2.0 kg 1.8 kg 2.1 kg 1.9 kg
Rated voltage D.C. 14.4 V D.C. 18 V
* NOTE: For continuous operation, high capacity battery cartridge BL1430, BL1440, BL1450, BL1830, BL1840, BL1840B, BL1850 and
BL1850B are recommended.
• Due to our continuing program of research and development, the specifications herein are subject to change without notice.
• Specifications and battery cartridge may differ from country to country.
• Weight, with battery cartridge, according to EPTA-Procedure 01/2003
ENE080-1
Intended use
The tool is intended for sawing and cutting wood, plastic,
gypsum, non-ferrous metals, and fastening elements (e.
g. unhardened nails and staples). It is also intended for
working soft wall tiles, as well as dry sanding and
scraping of small surfaces. It is especially for working
close to edge and flush cutting.
ENG905-1
Noise
The typical A-weighted noise level determined according
to EN60745:
Work mode: Sanding
Sound pressure level (LpA) : 78 dB (A)
Uncertainty (K) : 3 dB (A)
The noise level under working may exceed 80 dB (A).
Work mode: Cutting with plunge cut saw blade
Model DTM40
Sound pressure level (LpA) : 82 dB (A)
Sound power level (LWA) : 93 dB (A)
Uncertainty (K) : 3 dB (A)
Model DTM50
Sound pressure level (LpA) : 84 dB (A)
Sound power level (LWA) : 95 dB (A)
Uncertainty (K) : 3 dB (A)
Work mode: Cutting with segmental saw blade
Sound pressure level (LpA) : 81 dB (A)
Sound power level (LWA) : 92 dB (A)
Uncertainty (K) : 3 dB (A)
Work mode: Scraping
Model DTM40
Sound pressure level (LpA) : 81 dB (A)
Sound power level (LWA) : 92 dB (A)
Uncertainty (K) : 3 dB (A)
Model DTM50
Sound pressure level (LpA) : 83 dB (A)
Sound power level (LWA) : 94 dB (A)
Uncertainty (K) : 3 dB (A)
Wear ear protection

5
ENG900-1
Vibration
The vibration total value (tri-axial vector sum)
determined according to EN60745:
Work mode: Sanding
Vibration emission (ah) : 2.5 m/s2or less
Uncertainty (K) : 1.5 m/s2
Work mode: Cutting with plunge cut saw blade
Model DTM40
Vibration emission (ah) : 9.5 m/s2
Uncertainty (K) : 1.5 m/s2
Model DTM50
Vibration emission (ah) : 10.0 m/s2
Uncertainty (K) : 1.5 m/s2
Work mode: Cutting with segmental saw blade
Model DTM40
Vibration emission (ah) : 5.0 m/s2
Uncertainty (K) : 1.5 m/s2
Model DTM50
Vibration emission (ah) : 5.5 m/s2
Uncertainty (K) : 1.5 m/s2
Work mode: Scraping
Model DTM40
Vibration emission (ah) : 7.5 m/s2
Uncertainty (K) : 1.5 m/s2
Model DTM50
Vibration emission (ah) : 9.5 m/s2
Uncertainty (K) : 1.5 m/s2
ENG901-1
• The declared vibration emission value has been
measured in accordance with the standard test method
and may be used for comparing one tool with another.
• The declared vibration emission value may also be
used in a preliminary assessment of exposure.
WARNING:
• The vibration emission during actual use of the power
tool can differ from the declared emission value
depending on the ways in which the tool is used.
• Be sure to identify safety measures to protect the
operator that are based on an estimation of
exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as
the times when the tool is switched off and when it
is running idle in addition to the trigger time).
ENH101-18
For European countries only
EC Declaration of Conformity
Makita declares that the following Machine(s):
Designation of Machine:
Cordless Multi Tool
Model No./ Type: DTM40, DTM50
Conforms to the following European Directives:
2006/42/EC
They are manufactured in accordance with the following
standard or standardized documents:
EN60745
The technical file in accordance with 2006/42/EC is
available from:
Makita, Jan-Baptist Vinkstraat 2, 3070, Belgium
31.12.2013
000331
Yasushi Fukaya
Director
Makita, Jan-Baptist Vinkstraat 2, 3070, Belgium
GEA010-1
General Power Tool Safety
Warnings
WARNING Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for
future reference.
GEB094-2
CORDLESS MULTI TOOL
SAFETY WARNINGS
1. This power tool is intended to function for
sawing, cutting, grinding and sanding. Read
all safety warnings, instructions, illustrations
and specifications provided with this power
tool. Failure to follow all instructions listed below
may result in electric shock, fire and/or serious
injury.
2. Hold power tool by insulated gripping
surfaces, when performing an operation
where the cutting accessory may contact
hidden wiring. Cutting accessory contacting a
"live" wire may make exposed metal parts of the
power tool "live" and could give the operator an
electric shock.

6
3. Use clamps or another practical way to secure
and support the workpiece to a stable platform.
Holding the work by hand or against your body
leaves it unstable and may lead to loss of control.
4. Always use safety glasses or goggles.
Ordinary eye or sun glasses are NOT safety
glasses.
5. Avoid cutting nails. Inspect workpiece for any
nails and remove them before operation.
6. Hold the tool firmly.
7. Make sure the application tool is not
contacting the workpiece before the switch is
turned on.
8. Keep hands away from moving parts.
9. Do not leave the tool running. Operate the tool
only when hand-held.
10. Always switch off and wait for the blade to
come to a complete stop before removing the
blade from the workpiece.
11.
Do not touch the application tool or the
workpiece immediately after operation; they may
be extremely hot and could burn your skin.
12. Do not operate the tool at no-load unnecessarily.
13. Always use the correct dust mask/respirator
for the material and application you are
working with.
14. Some material contains chemicals which may
be toxic. Take caution to prevent dust
inhalation and skin contact. Follow material
supplier safety data.
15. This tool has not been waterproofed, so do not
use water on the workpiece surface.
16. Ventilate your work area adequately when you
perform sanding operations.
17. Use of this tool to sand some products, paints
and wood could expose user to dust
containing hazardous substances. Use
appropriate respiratory protection.
18. Be sure that there are no cracks or breakage
on the pad before use. Cracks or breakage
may cause a personal injury.
19. Do not use accessories which are not
specifically designed and recommended by
the tool manufacturer. Just because the
accessory can be attached to your power tool, it
does not assure safe operation.
20. Wear personal protective equipment.
Depending on application, use face shield,
safety goggles or safety glasses. As
appropriate, wear hearing protectors, gloves
and workshop apron capable of stopping
small abrasive or workpiece fragments. The
eye protection must be capable of stopping flying
debris generated by various operations . The dust
mask or respirator must be capable of filtrating
particles generated by your operation. Prolonged
exposure to high intensity noise may cause
hearing loss.
21. Keep bystanders a safe distance away from
work area. Anyone entering the work area
must wear personal protective equipment.
Fragments of workpiece or of a broken accessory
may fly away and cause injury beyond immediate
area of operation.
22. Never lay the power tool down until the
accessory has come to a complete stop. The
spinning accessory may grab the surface and pull
the power tool out of your control.
23. Do not run the power tool while carrying it at
your side. Accidental contact with the accessory
could snag your clothing, pulling the accessory
into your body.
24. Do not operate the power tool near flammable
materials. Sparks could ignite these materials.
25. Do not use accessories that require liquid
coolants. Using water or other liquid coolants
may result in electrocution or shock.
26. Always be sure that the tool is switched off
and unplugged or that the battery cartridge is
removed before carrying out any work on the
tool.
27. Always be sure you have a firm footing. Be
sure no one is below when using the tool in
high locations.
SAVE THESE INSTRUCTIONS.
WARNING:
DO NOT let comfort or familiarity with product
(gained from repeated use) replace strict adherence
to safety rules for the subject product. MISUSE or
failure to follow the safety rules stated in this
instruction manual may cause serious personal
injury.
ENC007-9
IMPORTANT SAFETY
INSTRUCTIONS
FOR BATTERY CARTRIDGE
1. Before using battery cartridge, read all
instructions and cautionary markings on (1)
battery charger, (2) battery, and (3) product
using battery.
2. Do not disassemble battery cartridge.
3. If operating time has become excessively
shorter, stop operating immediately. It may
result in a risk of overheating, possible burns
and even an explosion.
4. If electrolyte gets into your eyes, rinse them
out with clear water and seek medical
attention right away. It may result in loss of
your eyesight.

7
5. Do not short the battery cartridge:
(1) Do not touch the terminals with any
conductive material.
(2) Avoid storing battery cartridge in a
container with other metal objects such as
nails, coins, etc.
(3) Do not expose battery cartridge to water
or rain.
A battery short can cause a large current flow,
overheating, possible burns and even a
breakdown.
6. Do not store the tool and battery cartridge in
locations where the temperature may reach or
exceed 50 ﾟC (122 ﾟF).
7. Do not incinerate the battery cartridge even if
it is severely damaged or is completely worn
out. The battery cartridge can explode in a fire.
8. Be careful not to drop or strike battery.
9. Do not use a damaged battery.
10. Follow your local regulations relating to
disposal of battery.
SAVE THESE INSTRUCTIONS.
Tips for maintaining maximum battery life
1. Charge the battery cartridge before
completely discharged.
Always stop tool operation and charge the
battery cartridge when you notice less tool
power.
2. Never recharge a fully charged battery
cartridge.
Overcharging shortens the battery service life.
3. Charge the battery cartridge with room
temperature at 10 ﾟC - 40 ﾟC (50 ﾟF - 104 ﾟF).
Let a hot battery cartridge cool down before
charging it.
4. Charge the battery cartridge if you do not use
it for a long period (more than six months).
FUNCTIONAL DESCRIPTION
WARNING:
• Always be sure that the tool is switched off and
battery cartridge is removed before adjusting or
checking function on the tool.
Failure to switch off
and remove the battery cartridge may result in
serious personal injury from accidental start-up.
Installing or removing battery cartridge
Fig.1
CAUTION:
• Always switch off the tool before installing or
removing of the battery cartridge.
• Hold the tool and the battery cartridge firmly when
installing or removing battery cartridge.
Failure to
hold the tool and the battery cartridge firmly may cause
them to slip off your hands and result in damage to the
tool and battery cartridge and a personal injury.
To remove the battery cartridge, slide it from the tool
while sliding the button on the front of the cartridge.
To install the battery cartridge, align the tongue on the
battery cartridge with the groove in the housing and slip
it into place. Insert it all the way until it locks in place with
a little click. If you can see the red indicator on the upper
side of the button, it is not locked completely.
CAUTION:
• Always install the battery cartridge fully until the
red indicator cannot be seen. If not, it may
accidentally fall out of the tool, causing injury to
you or someone around you.
• Do not install the battery cartridge forcibly. If the
cartridge does not slide in easily, it is not being
inserted correctly.
Battery protection system
(Lithium-ion battery with star marking)
Fig.2
Lithium-ion batteries with a star marking are equipped
with a protection system. This system automatically cuts
off power to the tool to extend battery life.
The tool will automatically stop during operation if the
tool and/or battery are placed under one of the following
conditions:
• Overloaded:
The tool is operated in a manner that causes
it to draw an abnormally high current.
In this situation, slide the slide switch on the
tool toward the "O (OFF)" position and stop the
application that caused the tool to become
overloaded. Then slide the slide switch toward
the "I (ON)" position again to restart.
If the tool does not start, the battery is
overheated. In this situation, let the battery
cool before sliding the slide switch toward the
"I (ON)" position again.

8
• Low battery voltage:
The remaining battery capacity is too low and
the tool will not operate. In this situation,
remove and recharge the battery.
Indicating the remaining battery capacity
(Only for battery cartridges with "B" at the end of the
model number.)
Fig.3
Press the check button on the battery cartridge to
indicate the remaining battery capacity. The indicator
lamps light up for few seconds.
Off BlinkingLighted
Indicator lamps
Charge the
battery.
0% to 25%
25% to 50%
50% to 75%
75% to 100%
Remaining
capacity
The battery
may have
malfunctioned.
015658
NOTE:
• Depending on the conditions of use and the
ambient temperature, the indication may differ
slightly from the actual capacity.
Switch action
Fig.4
CAUTION:
• Before installing the battery cartridge into the tool,
always check to see that the tool is switched off.
To start the tool, slide the slide switch toward the "I (ON)"
position.
To stop the tool, slide the slide switch toward the "O
(OFF)" position.
Adjusting the orbital stroke rate
Fig.5
The orbital stroke rate is adjustable. To change the
orbital stroke rate, turn the dial between 1 and 6. The
higher the number is, the higher the orbital stroke rate is.
Preset the dial to the number suitable for your
workpiece.
NOTE:
• The dial cannot be turned directly from 1 to 6 or
from 6 to 1. Forcing the dial may damage the tool.
When changing the dial direction, always turn the
dial moving it through each intermediate number.
Lighting up the front lamp
WARNING:
• Never look into the light directly. Direct light causes
damage to your eyes.
Fig.6
Slide the slide switch toward the "I (ON)" position to light
up the front lamp. The lamp keeps on lighting while the
switch is the "I (ON)" position. The light automatically
goes out after pressing the rear of the slide switch, and
then sliding the slide switch toward the "O (OFF)"
position.
Overload protection
When the tool is overloaded and the tool temperature
reaches a certain level, the front lamp blinks and the tool
automatically stops. Remove a cause of overload to
restart.
Indication lamp
Fig.7
• When the remaining battery capacity gets low, the
indication lamp blinks.
• When the remaining battery capacity gets much
lower, the tool stops during operation and the
indication lamp lights up about 10 seconds.
At this time, remove the battery cartridge from the tool
and charge it.
ASSEMBLY
CAUTION:
• Always be sure that the tool is switched off and the
battery cartridge is removed before carrying out
any work on the tool.
Installing or removing application tool
(optional accessory)
WARNING:
• Do not install application tool upside down.
Installing application tool upside down may
damage the tool and cause serious personal injury.
• Install attachment tool in the correct direction
according to your work. Application tool can be
installed at an angle of every 30 degree.
Fig.8
Fig.9
Put an application tool (optional accessory) on the tool
flange so that the protrusions of the tool flange fit in the
holes in the application tool and secure the application
tool by tightening the bolt firmly with the hex wrench.
When using sanding application tool, mount the
application tool on the sanding pad so that it matches
the sanding pad direction.

9
The sanding pad has a hook and loop type fitting system
which allows easy and rapid fitting of a sanding paper.
As sanding papers have holes for dust extraction, mount
a sanding paper so that the holes in a sanding paper
match those in the sanding pad.
To remove a sanding paper, raise its end and peel it off.
Loosen and remove the application tool installation bolt
using a hex wrench and then take off the application
tool.
Fig.10
When using application tools with a different type of
installation section, use a correct adapter (optional
accessory).
Hex wrench storage
Fig.11
When not in use, store the hex wrench as shown in the
figure to keep it from being lost.
OPERATION
WARNING:
• Before starting the tool and during operation, keep
your hand and face away from the application tool.
CAUTION:
• Do not apply excessive load to the tool which may
cause a motor lock and stop the tool.
Cutting, sawing and scraping
CAUTION:
• Do not move on the tool forcibly in the direction (eg.
towards either side) of tool application with no
cutting edge. It may damage the tool.
Fig.12
Put the application tool on the workpiece.
And then move the tool forward so that the application
tool movement does not slow down.
NOTE:
• Forcing or excessive pressure on the tool may
reduce efficiency.
• Before cutting operation, it is recommended to
preset the orbital stroke rate 4 - 6.
Sanding
CAUTION:
• Do not reuse a sanding paper used for sanding
metal to sand wood.
• Do not use a worn sanding paper or sanding paper
without grit.
Fig.13
Apply a sanding paper on the workpiece.
NOTE:
• Using a test material sample to try is
recommendable to determine a correct orbital
stroke rate suitable for your work.
• Use a sanding paper with the same grit until
sanding the whole workpiece is completed.
Replacing a sanding paper with different grit
sanding paper may not get a fine finish.
Dust extraction attachment (optional accessory)
1
2
3
4
5
6
7
9
8
012778
• Install dust nozzles and dust attachment.
• Install the nozzle band on the tool so that its
protrusions fit in the holes in the tool to secure it.
• Put the felt ring and the sanding pad on the dust
attachment and then secure them with the
application tool installation bolt.
Fig.14
When you wish to perform cleaner operation, connect a
vacuum cleaner to your tool. Connect a hose of vacuum
cleaner to the dust extraction attachment (optional
accessory).
1. Nozzle band
2. Dust nozzle
3. Dust nozzle
4. Dust attachment
5. Felt ring
6. Pad
7. Application tool installation bolt
8. Holes in the tool
9. Protrusions on the nozzle band

10
MAINTENANCE
CAUTION:
• Always be sure that the tool is switched off and the
battery cartridge is removed before attempting to
perform inspection or maintenance.
• Never use gasoline, benzine, thinner, alcohol or
the like. Discoloration, deformation or cracks may
result.
To maintain product SAFETY and RELIABILITY, repairs,
carbon brush inspection and replacement, any other
maintenance or adjustment should be performed by
Makita Authorized Service Centers, always using Makita
replacement parts.
OPTIONAL ACCESSORIES
CAUTION:
• These accessories or attachments are
recommended for use with your Makita tool
specified in this manual. The use of any other
accessories or attachments might present a risk of
injury to persons. Only use accessory or
attachment for its stated purpose.
If you need any assistance for more details regarding
these accessories, ask your local Makita Service Center.
• Segment saw blade
• Round saw blade
• Plunge cut saw blade
• Scraper (rigid)
• Scraper (flexible)
• Serrated seg blade
• General joint cutter
• HM remover
• HM seg saw blade
• HM sanding plate
• Diamond seg sawblade
• Sanding pad
• Adapter
• Abrasive paper delta (red / white / black)
• Fleece delta (medium / coarse / without grit)
• Polishing felt delta
• Hex wrench
• Dust extraction attachment
• Makita genuine battery and charger
NOTE:
• Some items in the list may be included in the tool
package as standard accessories. They may differ
from country to country.
