INSTRUCTION MANUAL
Cordless Shear Wrench
DWT310
ENGLISH: Original instructions
Read before use.

2ENGLISH
SPECIFICATIONS
Model: DWT310
Bolt size M16, M20, M22
Maximum torque 804 N•m
No load speed (RPM) 14 min-1
Overall length 296 mm
Rated voltage D.C. 36 V
Net weight 6.5 - 7.1 kg
• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange
without notice.
• Specicationsandbatterycartridgemaydifferfromcountrytocountry.
• Theweightmaydifferdependingontheattachment(s),includingthebatterycartridge.Thelightestandheavi-
est combination, according to EPTA-Procedure 01/2014, are shown in the table.
Applicable battery cartridge and charger
Batterycartridge BL1815N / BL1820 / BL1820B / BL1830 / BL1830B / BL1840 /
BL1840B / BL1850 / BL1850B / BL1860B
Charger DC18RC / DC18RD / DC18RE / DC18SD / DC18SE / DC18SF
• Someofthebatterycartridgesandchargerslistedabovemaynotbeavailabledependingonyourregionof
residence.
WARNING: Only use the battery cartridges and chargers listed above.Useofanyotherbatterycartridges
andchargersmaycauseinjuryand/orre.
Symbols
Thefollowingshowthesymbolsusedfortheequipment.
Besurethatyouunderstandtheirmeaningbeforeuse.
Read instruction manual.
Ni-MH
Li-ion
OnlyforEUcountries
Donotdisposeofelectricequipmentorbattery
pack together with household waste material!
In observance of the European Directives,
on Waste Electric and Electronic Equipment
and Batteries and Accumulators and Waste
Batteries and Accumulators and their imple-
mentation in accordance with national laws,
electricequipmentandbatteriesandbattery
pack(s) that have reached the end of their life
mustbecollectedseparatelyandreturnedtoan
environmentallycompatiblerecyclingfacility.
Intended use
Thetoolisintendedforfastening"tor-sheartype"high
tensile bolts.
SAFETY WARNINGS
General power tool safety warnings
WARNING: Read all safety warnings, instruc-
tions, illustrations and specications provided with this
power tool. Failure to follow all instructions listed below
mayresultinelectricshock,reand/orseriousinjury.
Save all warnings and instruc-
tions for future reference.
Theterm"powertool"inthewarningsreferstoyour
mains-operated(corded)powertoolorbattery-operated
(cordless) power tool.
Work area safety
1. Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
2. Do not operate power tools in explosive atmo-
spheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks
whichmayignitethedustorfumes.
3. Keep children and bystanders away while
operating a power tool. Distractions can cause
youtolosecontrol.
Electrical Safety
1. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodiedplugsandmatchingoutletswill
reduce risk of electric shock.
2. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of elec-
tricshockifyourbodyisearthedorgrounded.
3. Do not expose power tools to rain or wet con-
ditions. Water entering a power tool will increase
the risk of electric shock.
4. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords
increase the risk of electric shock.

3ENGLISH
5. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
6. If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
7. Power tools can produce electromagnetic
elds (EMF) that are not harmful to the user.
However, users of pacemakers and other similar
medical devices should contact the maker of their
device and/or doctor for advice before operating
this power tool.
Personal Safety
1. Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired or
under the inuence of drugs, alcohol or med-
ication. A moment of inattention while operating
powertoolsmayresultinseriouspersonalinjury.
2. Use personal protective equipment. Always
wear eye protection. Protective equipment such
asadustmask,non-skidsafetyshoes,hardhator
hearing protection used for appropriate conditions
willreducepersonalinjuries.
3. Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool.Carryingpowertoolswith
yourngerontheswitchorenergisingpowertools
that have the switch on invites accidents.
4. Remove any adjusting key or wrench before
turning the power tool on.Awrenchorakeyleft
attachedtoarotatingpartofthepowertoolmay
resultinpersonalinjury.
5. Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
6. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away
from moving parts.Looseclothes,jewelleryor
long hair can be caught in moving parts.
7. If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
8. Do not let familiarity gained from frequent use
of tools allow you to become complacent and
ignore tool safety principles. A careless action
cancausesevereinjurywithinafractionofa
second.
9. Always wear protective goggles to protect
your eyes from injury when using power tools.
The goggles must comply with ANSI Z87.1 in
the USA, EN 166 in Europe, or AS/NZS 1336
in Australia/New Zealand. In Australia/New
Zealand, it is legally required to wear a face
shield to protect your face, too.
It is an employer's responsibility to enforce
the use of appropriate safety protective equip-
ments by the tool operators and by other per-
sons in the immediate working area.
Power tool use and care
1. Do not force the power tool. Use the correct
power tool for your application. The correct
powertoolwilldothejobbetterandsaferatthe
rate for which it was designed.
2.
Do not use the power tool if the switch does not turn
it on and off.Anypowertoolthatcannotbecontrolled
with the switch is dangerous and must be repaired.
3. Disconnect the plug from the power source
and/or remove the battery pack, if detachable,
from the power tool before making any adjust-
ments, changing accessories, or storing power
tools.Suchpreventivesafetymeasuresreduce
theriskofstartingthepowertoolaccidentally.
4.
Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool
or these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
5. Maintain power tools and accessories. Check for
misalignment or binding of moving parts, break-
age of parts and any other condition that may
affect the power tool’s operation. If damaged, have
the power tool repaired before use.Manyaccidents
arecausedbypoorlymaintainedpowertools.
6. Keep cutting tools sharp and clean.Properly
maintained cutting tools with sharp cutting edges
arelesslikelytobindandareeasiertocontrol.
7. Use the power tool, accessories and tool bits
etc. in accordance with these instructions, tak-
ing into account the working conditions and
the work to be performed. Use of the power tool
for operations different from those intended could
result in a hazardous situation.
8.
Keep handles and grasping surfaces dry, clean
and free from oil and grease.Slipperyhandlesand
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
9. When using the tool, do not wear cloth work
gloves which may be entangled. The entangle-
mentofclothworkglovesinthemovingpartsmay
resultinpersonalinjury.
Battery tool use and care
1. Recharge only with the charger specied by
the manufacturer. A charger that is suitable for
onetypeofbatterypackmaycreateariskofre
whenusedwithanotherbatterypack.

4ENGLISH
2. Use power tools only with specically desig-
nated battery packs.Useofanyotherbattery
packsmaycreateariskofinjuryandre.
3.
When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys, nails,
screws or other small metal objects, that can make a
connection from one terminal to another. Shorting the
batteryterminalstogethermaycauseburnsorare.
4. Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact acci-
dentally occurs, ush with water. If liquid contacts
eyes, additionally seek medical help.Liquidejected
fromthebatterymaycauseirritationorburns.
5. Do not use a battery pack or tool that is damaged or
modied.Damagedormodiedbatteriesmayexhibitunpre-
dictablebehaviourresultinginre,explosionorriskofinjury.
6. Do not expose a battery pack or tool to re or
excessive temperature.Exposuretoreortem-
peratureabove130°Cmaycauseexplosion.
7.
Follow all charging instructions and do not charge
the battery pack or tool outside the temperature
range specied in the instructions. Charging improp-
erlyorattemperaturesoutsidethespeciedrangemay
damagethebatteryandincreasetheriskofre.
Service
1.
Have your power tool serviced by a qualied repair
person using only identical replacement parts. This will
ensurethatthesafetyofthepowertoolismaintained.
2. Never service damaged battery packs. Service
ofbatterypacksshouldonlybeperformedbythe
manufacturer or authorized service providers.
3. Follow instruction for lubricating and chang-
ing accessories.
Cordless Shear Wrench Safety Warnings
1. Hold the power tool by insulated gripping
surfaces, when performing an operation
where the fastener may contact hidden wiring.
Fastenerscontactinga"live"wiremaymake
exposed metal parts of the power tool "live" and
could give the operator an electric shock.
2.
Before using power tool, make sure that the outer
sleeve smoothly turns by hand. When it does
not smoothly turn, never use it and ask Makita
Authorized Service Center for check and repair.
3. When sheared bolt tip falls without pulling the
eject lever, never use the tool and ask Makita
Authorized Service Center for check and repair.
4. Always be sure you maintain good balance
and rm footing. Be sure no one is below when
using the tool in high or elevated locations.
5. Hold the tool rmly.
6.
Use care and common sense when disposing
of sheared bolt tips. Dropping tips from high loca-
tionsorscatteredtipsmaycausesevereinjury.
7. Do not attach the tool to your cloth or safety
harness at high locations.
WARNING: DO NOT let comfort or familiarity with
product (gained from repeated use) replace strict adher-
ence to safety rules for the subject product. MISUSE or
failure to follow the safety rules stated in this instruc-
tion manual may cause serious personal injury.
Important safety instructions for
battery cartridge
1. Before using battery cartridge, read all instruc-
tions and cautionary markings on (1) battery
charger, (2) battery, and (3) product using
battery.
2. Do not disassemble battery cartridge.
3. If operating time has become excessively
shorter, stop operating immediately. It may
result in a risk of overheating, possible burns
and even an explosion.
4. If electrolyte gets into your eyes, rinse them
out with clear water and seek medical atten-
tion right away. It may result in loss of your
eyesight.
5. Do not short the battery cartridge:
(1) Do not touch the terminals with any con-
ductive material.
(2) Avoid storing battery cartridge in a con-
tainer with other metal objects such as
nails, coins, etc.
(3) Do not expose battery cartridge to water
or rain.
A battery short can cause a large current
ow, overheating, possible burns and even a
breakdown.
6. Do not store the tool and battery cartridge in
locations where the temperature may reach or
exceed 50 °C (122 °F).
7. Do not incinerate the battery cartridge even if
it is severely damaged or is completely worn
out. The battery cartridge can explode in a re.
8. Be careful not to drop or strike battery.
9. Do not use a damaged battery.
10. The contained lithium-ion batteries are subject
to the Dangerous Goods Legislation require-
ments.
Forcommercialtransportse.g.bythirdparties,
forwarding agents, special requirement on pack-
aging and labeling must be observed.
For preparation of the item being shipped, consult-
ing an expert for hazardous material is required.
Pleasealsoobservepossiblymoredetailed
national regulations.
Tape or mask off open contacts and pack up the
batteryinsuchamannerthatitcannotmove
around in the packaging.
11. Follow your local regulations relating to dis-
posal of battery.
12. Use the batteries only with the products
specied by Makita. Installing the batteries to
non-compliantproductsmayresultinare,exces-
siveheat,explosion,orleakofelectrolyte.
SAVE THESE INSTRUCTIONS.
CAUTION: Only use genuine Makita batteries.
Use of non-genuine Makita batteries, or batteries that
havebeenaltered,mayresultinthebatterybursting
causingres,personalinjuryanddamage.Itwill
alsovoidtheMakitawarrantyfortheMakitatooland
charger.

5ENGLISH
Tips for maintaining maximum
battery life
1. Charge the battery cartridge before completely dis-
charged. Always stop tool operation and charge the
battery cartridge when you notice less tool power.
2. Never recharge a fully charged battery cartridge.
Overcharging shortens the battery service life.
3. Charge the battery cartridge with room tempera-
ture at 10 °C - 40 °C (50 °F - 104 °F). Let a hot
battery cartridge cool down before charging it.
4. Charge the battery cartridge if you do not use
it for a long period (more than six months).
FUNCTIONAL DESCRIPTION
CAUTION: Always be sure that the tool is
switched off and the battery cartridge is removed
before adjusting or checking function on the tool.
Installing or removing battery cartridge
CAUTION: Always switch off the tool before
installing or removing of the battery cartridge.
CAUTION: Hold the tool and the battery cartridge
rmly when installing or removing battery cartridge.
Failuretoholdthetoolandthebatterycartridgermlymay
causethemtoslipoffyourhandsandresultindamageto
thetoolandbatterycartridgeandapersonalinjury.
1
2
3
►1. Red indicator 2. Button 3.Batterycartridge
Toremovethebatterycartridge,slideitfromthetool
while sliding the button on the front of the cartridge.
Toinstallthebatterycartridge,alignthetongueonthe
batterycartridgewiththegrooveinthehousingandslip
itintoplace.Insertitallthewayuntilitlocksinplace
withalittleclick.Ifyoucanseetheredindicatoronthe
uppersideofthebutton,itisnotlockedcompletely.
CAUTION: Always install the battery cartridge
fully until the red indicator cannot be seen. If not,
itmayaccidentallyfalloutofthetool,causinginjuryto
youorsomeonearoundyou.
CAUTION: Do not install the battery cartridge
forcibly.Ifthecartridgedoesnotslideineasily,itis
notbeinginsertedcorrectly.
Indicating the remaining battery
capacity
Only for battery cartridges with the indicator
1
2
►1. Indicator lamps 2. Check button
Pressthecheckbuttononthebatterycartridgetoindi-
catetheremainingbatterycapacity.Theindicatorlamps
light up for a few seconds.
Indicator lamps Remaining
capacity
Lighted Off Blinking
75% to 100%
50% to 75%
25% to 50%
0% to 25%
Charge the
battery.
Thebattery
mayhave
malfunctioned.
NOTE: Depending on the conditions of use and the
ambienttemperature,theindicationmaydifferslightly
fromtheactualcapacity.
Tool / battery protection system
Thetoolisequippedwithatool/batteryprotectionsys-
tem.Thissystemautomaticallycutsoffpowertothe
motortoextendtoolandbatterylife.Thetoolwillauto-
maticallystopduringoperationifthetoolorbatteryis
placed under one of the following conditions:
Overload protection
Whenthetoolorbatteryisoperatedinamannerthat
causesittodrawanabnormallyhighcurrent,thetool
automaticallystopswithoutanyindication.Inthissit-
uation, turn the tool off and stop the application that
caused the tool to become overloaded. Then turn the
tool on to restart.

6ENGLISH
Overheat protection
Whenthetoolorbatteryisoverheated,thetoolstops
automatically.Inthiscase,letthetoolandbatterycool
before turning the tool on again.
Overdischarge protection
Whenthebatterycapacityisnotenough,thetoolstops
automatically.Inthiscase,removethebatteryfromthe
toolandchargethebattery.
Switch action
WARNING: Before installing the battery car-
tridge into the tool, always check to see that the
switch trigger actuates properly and returns to
the "OFF" position when released.
Topreventtheswitchtriggerfromaccidentallypulled,
the trigger-lock button is provided.
To start the tool, depress the trigger-lock button from A side
and pull the switch trigger. Release the switch trigger to
stop. After use, press in the trigger-lock button from B side.
AB
1
2
►1. Trigger-lock button 2. Switch trigger
NOTE:Thetoolautomaticallystopsifyoukeeppull-
ing the switch trigger for about 6 minutes.
Whenyoupulltheejectlever,thebolttipisejectedfrom
the tool.
1
►1.Ejectlever
Battery power lamp
Whentheremainingbatterycapacitybecomeslow,thebattery
powerlampblinks.Chargethebatteryorreplacethebatterywith
fullychargedone.Whentheremainingbatterycapacitybecomes
muchlower,thetoolstopsandthebatterypowerlamplightsup.
1
►1.Batterypowerlamp
Hook
CAUTION: Be sure to attach the shoulder belt
included in the tool as the standard accessory. Use the
shoulder belt for carrying the tool, and never use the
hook for other purposes such as the fall prevention
at high location. If the hook is used for other purposes,
excessiveloadmaybreakthemandcauseseriousinjuryto
the operator and person around/underneath the operator.
CAUTION: When you attach the shoulder belt to
the hook, be sure to attach it securely. If it is attached
incompletely,thetoolmaycomeoffandcauseaninjury.
CAUTION: When carrying the tool using the
shoulder belt, be careful not to entangle the shoulder
belt with your body or objects and not to hit objects
with the tool.Failuretodosomaycauseanaccident.
CAUTION: Remove the shoulder belt from the
hook before operating the tool.Failuretodosomay
loseyourbalanceatoperationandcauseanaccident.
1 2
►1. Hook 2. Shoulder belt
Attach the shoulder belt included in the tool as the stan-
dardaccessorytothehookforcarryingthetool.Remove
the shoulder belt from the hook before operating the tool.

7ENGLISH
ASSEMBLY
CAUTION: Always be sure that the tool is
switched off and the battery cartridge is removed
before carrying out any work on the tool.
Removing the outer and inner
sleeves
CAUTION: Be careful not to allow foreign mat-
ter to enter the insides of the tool when removing
or installing the outer and inner sleeves.
1. Loosen the two screws while holding the outer
sleeve. The outer and inner sleeves will be pushed up
bythespringsbuiltintothetool.
1
2
►1. Outer sleeve 2. Screw
2. Press the pin down to remove the inner sleeve
from the outer sleeve.
1
2
3
►1. Inner sleeve 2. Pin 3. Outer sleeve
NOTICE: Be careful not to drop the inner sleeve
when removing it.
NOTICE: Do not remove the tip rod, tip rod
spring, and inner sleeve spring from the tool.
1
2
3
►1. Tip rod 2. Tip rod spring 3. Inner sleeve spring
Installing the outer and inner
sleeves
Place the inner sleeve with the pin facing upward.
Attachtheoutersleevetotheinnersleevesecurely
while pressing the pin of the inner sleeve.
1
2
3
►1. Outer sleeve 2. Pin 3. Inner sleeve
Insert the outer and inner sleeves into the tool while
rotating the inner sleeve clockwise and counterclock-
wise until the outer sleeve touches the tool. Tighten the
twoscrewsrmly.

8ENGLISH
1
2
►1. Outer sleeve 2. Screw
NOTICE: Make sure that there is no gap between
the outer sleeve and the tool.
OPERATION
CAUTION: Always insert the battery cartridge
all the way until it locks in place.Ifyoucanseethe
red indicator on the upper side of the button, it is not
lockedcompletely.Insertitfullyuntiltheredindicator
cannotbeseen.Ifnot,itmayaccidentallyfalloutof
thetool,causinginjurytoyouorsomeonearoundyou.
CAUTION: Keep the bolt tips off of the
ground, oor, walkways, etc. to prevent injury
from tripping or falling.
1. Tightenboltspreliminarilybyusingahandwrench.
2.
Holdthetoolrmlyandplacetheinnersleeveoverthe
boltsothattheinnersleevecompletelycoversthebolttip.
1
2
►1. Inner sleeve 2. Bolt tip
NOTICE: Be careful when tting the sleeve onto
the bolt tip. Striking the tip can damage it so that it
willnolongertinsidethesleeveproperly.
3. Pushthetoollightlyuntiltheoutersleevecompletelyhold
the nut. If the outer sleeve fails to hold the nut, rotate the tool
clockwiseorcounterclockwisewhilepushingthetoollightly.
4. Press the trigger-lock button, and then pull the
switch trigger. The outer sleeve rotates to tighten the nut.
1
2
►1. Outer sleeve 2. Nut
NOTICE: Do not force the tool down excessively. Apply
the downward force to the degree needed to stabilize the tool.
5. Whenthespeciedtorqueisattained,thebolt
tip will be sheared at its notched portion. The bolt tip
remains inside the inner sleeve.
1
2
►1. Notched portion 2. Bolt tip
6. Release the switch trigger and withdraw the tool in
a straight line.
1
►1. Outer sleeve

9ENGLISH
7. Pulltheejectlevertoejectthebolttipfromthe
tool. Catch the sheared bolt tips to prevent them from
falling.
1
►1. Bolt tip
NOTICE: Washer and nut have head and tail.
Head has identication mark for nut and chamfer
for washer. When placing them, be careful not to
place in reverse.
1
23
4
5
►1.Identicationmark2. Nut 3. Bolt 4. Chamfered
5. Washer
NOTICE: Replace nut, bolt and washer all
together at one time when these rotate together,
nut rotates excessively or a bolt protrude from
nut surface too much or less.
NOTICE: Do not reuse used nut, bolt and washer.
The range for the remaining length of bolts after cutting
offthebolttipsaredeterminedbyboltsize.Refertothe
table below and choose shear bolts according to the
thickness of workpiece to be fastened.
Bolt size Maximum remain-
ing length
Minimum remain-
ing length
M16 20 mm 4.5 mm
M20 15 mm 5.5 mm
M22 14 mm 7 mm
1
►1. Remaining length
NOTICE: Use bolts with the remaining length
within the range shown in the table above as bolts
with different size have different maximum and
minimum remaining length.
NOTICE: Be careful not to use bolts beyond
the specied range which may cause the tool
malfunction.
MAINTENANCE
CAUTION: Always be sure that the tool is
switched off and the battery cartridge is removed
before attempting to perform inspection or
maintenance.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
To maintain product SAFETY and RELIABILITY,
repairs,anyothermaintenanceoradjustmentshould
beperformedbyMakitaAuthorizedorFactoryService
Centers,alwaysusingMakitareplacementparts.
Battery guard
WARNING: Do not remove the battery
guard. Do not use the tool with the battery guard
removed or damaged.Directimpacttothebattery
cartridgemaycausebatterymalfunctionandresult
ininjuryand/orre.Ifthebatteryguardisdeformed
ordamaged,contactyourauthorizedservicecenter
for repairs.
CAUTION: Do not attach a strap to the battery
guard for hanging the tool.
CAUTION: Do not attach the shoulder belt to
the battery guard.

10 ENGLISH
21
►1.Batteryguard2.Batteryguardholder
OPTIONAL
ACCESSORIES
CAUTION: These accessories or attachments
are recommended for use with your Makita tool
specied in this manual.Theuseofanyother
accessories or attachments might present a risk of
injurytopersons.Onlyuseaccessoryorattachment
for its stated purpose.
Ifyouneedanyassistanceformoredetailsregard-
ingtheseaccessories,askyourlocalMakitaService
Center.
Bolt size Sleeve Length
M16 Outer sleeve 35 mm
Inner sleeve 36 mm
M20 Outer sleeve 37 mm
Inner sleeve 38 mm
M22 Outer sleeve 39 mm
Inner sleeve 39 mm
M22 Outer sleeve 85 mm
Inner sleeve 85 mm
5/8" Outer sleeve 35 mm
Inner sleeve 36 mm
3/4" Outer sleeve 37 mm
Inner sleeve 38 mm
3/4" Outer sleeve 83 mm
Inner sleeve 84 mm
• Makitagenuinebatteryandcharger
NOTE:Someitemsinthelistmaybeincludedinthe
toolpackageasstandardaccessories.Theymay
differfromcountrytocountry.

11

Makita Corporation
www.makita.com
885624-1
EN
20180228
