Parts Breakdown HM1140C
Page 1 of 3 2/8/2008

Parts Breakdown HM1140C
Fig # Part ID Part Name Quantity
1 286252-9 TOOL HOLDER CAP, HM1140C 1
2 416790-9 TOOL HOLDER COVER, HM1140C 1
3 213430-8 O RING 28, HM1140C 1
4 256156-9 PIN 6, HK1800 1
5 323833-9 ROLLER GUIDE, HM1140C 1
6 233208-3 COMPRESSION SPRING 47, HM1140C 1
7 331489-4 STEEL BALL GUIDE, HM1100C 1
8 416087-6 CHANGE RING, HM1100C 1
8 416087-6 CHANGE RING, HM1100C 1
9 216011-7 STEEL BALL 5.6, 6222DWE 4
10 323835-5 TOOL HOLDER SUPPORT, HM1140C 1
11 922351-0 H.S.H. BOLT M6X30, HM1100C 4
12 213554-0 O RING, HR2511 1
13 231972-0 RING SPRING 52, HM1100C 1
14 265439-6 HEX BOLT M8X150, HM1100C 1
15 416009-6 SIDE HANDLE, HM1100C 1
15 417003-1 SIDE HANDLE, HM1202C 1
16 252640-2 WING NUT M8, HM1100C 1
17 417002-3 SIDE HANDLE CAM, HM1202C 1
17 416396-3 HANDLE BASE 60,HM1100C 1
18 344559-0 HANDLE SPRING 60,HM1100C-T1 1
18 152620-7 SIDE HANDLE BASE CPL.,HM1100C 1
19 416396-3 HANDLE BASE 60,HM1100C 1
19 417002-3 SIDE HANDLE CAM, HM1202C 1
20 416086-8 SIDE HANDLE SUPPORT, HM1100C 1
21 213479-8 O RING 33, HM1100C 1
22 323860-6 ROLLER 12, HM1140C 1
23 323834-7 TOOL HOLDER, HM1140C 1
24 213269-9 X RING 19, HM1100C 1
25 213311-6 O RING 19, HM1100C 1
26 323845-2 IMPACT BOLT, HM1100C 1
27 962154-0 RETAINING RING R-36, HM1100C 1
28 421570-0 RING 36, HM1100C 1
29 331487-8 IMPACT BOLT GUIDE, HM1100C 1
30 213391-2 O RING 25, HM1100C 1
31 331526-4 SLEEVE GUIDE, HM1140C 1
32 213370-0 O RING 22, AF502 1
33 213554-0 O RING, HR2511 1
34 125071-7 CYLINDER LINER ASS'Y, HM1100C-T1 1
34 322757-6 CYLINDER LINER 34, HM1140C 1
35 323861-4 STRIKER, HM1140C 1
36 213429-3 O RING 27, HM1100C 1
37 213614-8 O RING 50, HM1100C 1
38 316672-4 BARREL, HM1100C 1
39 922351-0 H.S.H. BOLT M6X30, HM1100C 4
40 213606-7 O RING 48, HR2511 1
41 213429-3 O RING 27, HM1100C 1
42 415773-6 PISTON, HM1100C 1
43 256165-8 PIN 8, HM0810B 1
43 257676-6 SLEEVE 6, HM1100C-T1 1
44 213415-4 O RING 28, 5005BA 1
45 415689-5 ROD, HM1100C 1
46 211129-9 BALL BEARING 6201DDW, N9501B 1
46 211143-5 BALL BEARING 6201DDW, HM1100C 1
47 213160-1 OIL SEAL 14, HR3851 1
48 516286-1 ARMATURE ASS'Y 115V, HM1100C 1
49 681650-6 INSULATION WASHER, HR4000C 1
50 211033-2 B. BEARING 608LB, 5091D 1
51 415693-4 BAFFLE PLATE, HM1100C 1
52 265345-5 HEX. BOLT M5X60, HM0810B 2
Page 2 of 3 2/8/2008

Parts Breakdown HM1140C
53 941102-2 F. WASHER 5, HM1100C 2
54 634281-0 FIELD 115V, HM1100C 1
55 632678-7 SUPPORT COMPLETE, HM1100C 1
56 851366-9 NAME PLATE, HM1140C 1
57 922364-1 H.S.H. BOLT M6X40, HM1100C 4
58 152662-1 MOTOR HOUSING COMPLETE,HM1100C 1
58 159919-1 MOTOR HOUSING COMPLETE, HM1100C 1
59 643750-0 BRUSH HOLDER CAP, HM1100C 2
60 191961-6 A.C. CARBON BRUSH, HM1100C 1
61 415700-3 REAR COVER, HM1100C 1
62 266021-4 TAPPING SCREW PT5X20, HM1100C 2
63 415695-0 FIX ROD, HM1100C 1
64 687052-4 STRAIN RELIEF, HM1500B 1
65 265995-6 TAPPING SCREW 4X18, 4323K 2
66 682560-0 CORD GUARD 10, HM1202C 1
67 664276-9 CORD (2X16X16 SJ), HR5000 1
68 415690-0 CRANK CAP, HM1100C 1
69 159975-1 HOUSING COVER COMPLETE, HM1140C 1
70 819064-1 MAKITA MARK, HM1100C 1
71 216116-3 INNER SLEEVE 812, HM1100C 1
72 153249-2 CRANK SHAFT COMPLETE, HM1100C 1
73 212259-9 NEEDLE BEARING 2116, HM1100C 1
74 962105-3 RETAINING RING R-26, HM1100C 1
75 210054-1 BALL BEARING 6000LLU, HM1100C 1
76 213707-1 O RING 65, HM1100C 1
77 317143-4 CRANK HOUSING, HM1140C 1
77 317143-4 CRANK HOUSING, HM1140C 1
78 415699-2 SWITCH BOX, HM1100C 1
79 263002-9 RUBBER PIN 4, HR2400 2
80 651481-7 SWITCH STE215K, HM1100C 1
81 213107-5 O RING 12, JR3000V 1
82 631203-1 CONTROLLER 100/115V, HM1100C 1
83 415691-8 SWITCH LEVER, HM1100C 1
84 415696-8 CONTROLLER COVER, HM1100C-T1 1
84 417447-5 CONTROLLER COVER, HM1100C 1
85 415692-6 STOPPER, HM1100C 1
86 421507-7 HANDLE, HM1100C 1
87 266135-9 H.S.H. BOLT M6X90,HM1100C 2
88 922371-4 H.S.H. BOLT M6X50, HM1211 2
89 331486-0 SLEEVE 39, HM1140C 1
90 233190-6 COMPRESSION SPRING 39, HM1100C 1
91 267156-4 FLAT WASHER 39, HM1100C 1
92 231971-2 RING SPRING 36, HM1100C 1
1,001 150676-4 PLASTIC CARRYING CASE, HM1100C 1
1,002 181573-3 BIT GREASE, HR2400 1
1,002 181573-3 BIT GREASE, HR2400 1
2,001 134793-8 SIDE HANDLE ASS'Y, HM1100C 1
2,001 134909-5 SIDE HANDLE ASSEMBLY,HM1100C 1
5,001 810245-0 N/A 1
Page 3 of 3 2/8/2008
