BEFOREYOU BEGIN
Thank you for selecting the MARCY UB3000 Deluxe Utility Bench. For your safety and
benefit, read this manual carefully before using the equipment. If you have any questions, or
find there are missing or damaged parts, please contact our Customer Solutions
Department.
1
Pure-Tec Limited
www.puretecfitness.com
Email: [email protected]

IMPORTANT SAFETY NOTICE
PRECAUTIONS
This exercise machine is built for optimum safety. However, certain precautions apply
whenever you operate a piece of exercise equipment. Be sure to read the entire manual
before you assemble or operate your machine. In particular, note the following safety
precautions:
1. Keep children and pets away from the machine at all times. DO NOT
leave children unattended in the same room with the machine.
2. Only one person at a time should use the machine.
3. If the user experiences dizziness, nausea, chest pain, or any other abnormal
symptoms, STOP the workout at once. CONSULT A PHYSICIAN IMMEDIATELY.
4. Position the machine on a clear, levelled surface. DO NOT use the machine
near water or outdoors.
5. Keep hands away from all moving parts.
6. Always wear appropriate workout clothing when exercising. DO NOT wear
robes or other clothing that could become caught in the machine. Running
or aerobic shoes are also required when using the machine.
7. Use the machine only for its intended use as described in this manual. DO
NOT use attachments not recommended by the manufacturer.
8. Do not place any sharp object around the machine.
9. Disabled person should not use the machine without a qualified person or
physician in attendance.
10. Before using the machine to exercise, always do stretching exercises to
properly warm up.
11. Never operate the machine if the machine is not functioning properly.
12. Maximum user weight: 136 kg.
13. Maximum dumbbell weight: 45 kg.
14. This equipment is designed and intended for home and consumer use only, not for
commercial use.
CARE AND MAINTENANCE
1. Inspect and tighten all parts before using the machine.
2. The machine can be cleaned using a damp cloth and mild non-abrasive detergent.
DO NOT use solvents.
3. Keep fingers away from all Pinch Points.
WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR
PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE
OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL
INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. FITNESS BIT
ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY
DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT.
SAVE THESE INSTRUCTIONS. 2

WARNING LABEL PLACEMENT
The warning labels shown here have been placed on the Rear Stabilizer. If the labels are missing or illegible,
please contact Customer Solutions by email: [e-mail] for replacements. Apply the labels in the
location shown.
3

HARDWARE PACK
NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.
4

IMPORTANT ASSEMBLYINFORMATION
 Tools required for assembling the equipment: Two Adjustable Wrenches and Allen
Wrenches.
 NOTE: It is strongly recommended that this equipment is assembled by two or more
people to avoid possible injury.
 Ensure Carriage Bolts are inserted through the SQUARE holes on components that need to be
assembled. Attach washer only to end of the Carriage Bolt.
 Use Allen Bolts or Hex Bolts inserted through the ROUND hole on components that need to be
assembled.
 Always wait until all bolts are assembled onto the equipment before tightening the bolts. Do
not fasten each bolt right after it is installed
Fasten Nuts and Bolts
Securely tighten all Nuts and Bolts after all
components have been assembled in current and
previous steps.
NOTE: Do not over tighten any component with
pivotal function.
Make sure all pivotal components are able to move
freely.
Do not tighten all Nuts and Bolts in this step.
5

STEP 1 (See Diagram 1)
A.) Push the two Front Stabilizer End Caps (#13) and two Rear Stabilizer End Caps (#12) onto
the Front Stabilizer (#1) and the Rear Stabilizer (#2) from both ends.
B.) Attach a U-shaped Sleeve (#17) onto the bracket on the Front Stabilizer (#1). Make sure the
opening on the Sleeve is facing toward front.
C.) Attach the Front Stabilizer to the Vertical Frame (#4). Secure it with two M8 x 3 1/8” Allen Bolts
(#25), four Ø 5/8” Washers (#28), and two M8 Aircraft Nuts (#32).
D.) Attach one U-shaped Sleeve (#17) to the bracket on the Rear Stabilizer (#2). Attach the
Lower Main Frame (#34) to the Rear Stabilizer (#2). Secure it with two M8 x 3 1/8” Allen Bolts
(#25), four Ø 5/8” Washers (#28), and two M8 Aircraft Nuts (#32).
E.) Attach the Main Frame (#3) to the Lower Main Frame (#34). Secure it with three M10 x 1” Allen
Bolts (#35), six Ø 3/4” Washers (#33) and three M10 Aircraft Nuts (#31).
F.) Attach the Main Frame (#3) to the Front Vertical Frame (#4). Secure the lower hole with one
M10 x 3 ¾” Allen Bolt (#22), two Ø ¾” Washers (#33), and one M10 Aircraft Nut (#31). Insert a
L-shaped Lock Pin (#21) through the upper hole to lock the Front Vertical Frame in position.
Remove the Pin when folding the bench for storage.
G.) Attach two L-shaped Brackets (#9) to the Main Frame (#3). Secure them with one M8 x 3 ½”
Allen Bolt (#26), two Ø 5/8” Washers (#28), and one M8 Aircraft Nut (#32).
6

STEP 2 (See Diagram 2)
A.) Attach the Incline Support (#6) in between the two Backrest Supports (#5).
B.) Attach the Pivot of the Backrest Supports (#5) to the Pivot on the Main Frame (#3).
Secure them with one M12 x 6 7/8” Hex Bolt (#27) and M12 Aircraft Nut (#30).
DIAGRAM 2
7

STEP 3 (See Diagram 3)
A.) Place the Seat (#10) onto the Main Frame (#3). Secure it to the two L-shaped Brackets (#9)
with two M8 x 5/8” Allen Bolts (#23) and Ø 5/8” Washers (#28). Secure the Seat to the Main
Frame with one M8 x 1 ¾” Allen Bolt (#24) and Ø 5/8” Washer (#28).
B.) Place the Backrest Board (#11) onto the Backrest Supports (#5). Secure it with four M8 x 1 ¾”
Allen Bolts (#24) and Ø 5/8” Washers (#28).
C.) Attach the Cross Tube (#7) to the Front Vertical Frame (#4). Use a Lock Knob (#16) to secure
the Tube at selected hole on the Frame.
D.) Insert the Foam Tube (#8) halfway through the hole on the Front Vertical Frame (#4). Push
four Vinyl Foam Rolls (#14) onto the Tubes.
E.) Lubricate the inside of the Foam Grips (#15) with water. Slide the Foam Grips onto the Foam
Tube (#8) from both sides.
DIAGRAM 3
8

9

Parts list
KEY NO. DESCRIPTION Q’ty
1
Front Stabilizer
1
2
Rear Stabilizer
1
3
Main Frame
1
4
Front Vertical Frame
1
5
Backrest Support
2
6
Incline Support
1
7
Cross Tube
1
8
Foam Tube
1
9
L-shaped Bracket
2
10
Seat
1
11
Backrest Board
1
12
Rear Stabilizer End Cap
2
13
Front Stabilizer End Cap
2
14
Vinyl Foam Roll
4
15
Foam Grip
2
16
Lock Knob
1
17
U-shaped Sleeve
2
18
Ø 1” End Cap
4
19
1” Square End Cap
2
20
Rubber Bumper
1
21
L-shaped Lock Pin
1
22
M10 x 3 ¾” Allen Bolt
1
23
M8 x ¾” Allen Bolt
2
24
M8 x 1 ¾” Allen Bolt
5
25
M8 x 3 1/8” Allen Bolt
4
26
M8 x 3 ½” Allen Bolt
1
27
M12 x 6 7/8” Hex Bolt
1
28
Ø 5/8” Washer
17
29
M6 x 5/8” Philips Screw
1
30
M12 Aircraft Nut
1
31
M10 Aircraft Nut
5
32
M8 Aircraft Nut
5
33
Ø ¾” Washer
10
34
Lower Main Frame
1
10
35 M10 x 1 ” Allen Bolt 4

LIMITED WARRANTY
Fitness Bit warrants this product to be free from defects in workmanship and
material, u nder normal us e and s ervice c onditions. P lease r efer
to www.fitnessdigital.com for warranty conditions. This warranty extends only to
the original purchaser and is validforhome use only. Fitness Bit ’s obligation
under this Warranty is limited to replacing damaged or faulty parts at Fitness Bit ’s
option.
All returns must be pre-authorised by Fitness Bit. This warranty does not extend
to any product or damage to a product caused by or attributable to freight
damage, abuse, misuse, improper or abnormal usage, purchasers own
repairs or for products used for commercial or rental purposes. No other
warranty beyond that specifically set forth above is authorised by Fitness Bit.
Fitness Bit is not responsible or liable for indirect, special or consequential
damages arising out of or in connection with the use or performance of the product
or other da mages w ith r espect t o any ec onomic l oss, l oss of pr operty, l oss of
revenues or pr ofits, l oss of enj oyments or us e, c osts of r emoval, i nstallation or
other consequential damages or whatsoever natures.
The warranty extended hereunder is in lieu of any and all other warranties and any
implied warranties of merchantability or fitness for a particular purpose is limited in
its scope and duration to the terms set forth herein.
Your statutory rights are not affected.
ORDERING REPLACEMENT PARTS
Replacement parts can be ordered by contacting our Customer Solutions
Department.
Pure-Tec Limited
www.puretecfitness.com
Email: [email protected]
When ordering replacement parts, please give the following information,
1. Model
2. Description of Parts
3. Part Number
4. Date of Purchase
11
