Mec MMAE16 Guide

Part # 95811
April 2022
Service & Parts Manual
Serial Number Range
17400000 - Up
MMAE16
ART_5805A

Page i MMAE16 - Service & Parts Manual
April 2022
Revision History
Date Reason for Update
April 2022 New Release
1401 S. Madera Avenue, Kerman, CA93630 USA
Toll Free: 1-877-632-5438
Phone: [phone]
Fax: [phone]
[email protected]
www.MECawp.com
MEC Aerial Work Platforms

Page ii MMAE16 - Service & Parts Manual
April 2022
Table of Contents
Chapter 1 - Service . . . . . . . . . . . . . 1
Service Introduction.................1
Section 1 - MEC Operator Policy .............2
MEC Operator Policy . . . . . . . . . . . . . . . . . . . 2
Section 2 - Safety Symbols & General Safety Tips . . . . . . . . 3
Safety Symbols & General Safety Tips . . . . . . . . . . . . . . 3
Section 3 - Specifications . . . . . . . . . . . . . . . 4
Specifications.....................4
Section 4 - Torque Specifications . . . . . . . . . . . . . 5
Bolt Torque Specification - American Standard . . . . . . . . . . . . 5
Bolt Torque Specification - Metric Standard . . . . . . . . . . . . . 6
Section 5 - Maintenance Safety. . . . . . . . . . . . . . 7
Maintenance Safety . . . . . . . . . . . . . . . . . . . 7
Section 6 - Electrical System and Total System . . . . . . . . . 8
Electrical System and Total System . . . . . . . . . . . . . . . 8
Section 7 - Machine Components . . . . . . . . . . . . . 9
Machine Components . . . . . . . . . . . . . . . . . . . 9
Section 8 - Emergency Systems and Procedures. . . . . . . . . 10
Emergency Systems and Procedures . . . . . . . . . . . . . . . 10
Section 9 - Transport and Lifting Instructions. . . . . . . . . . 11
Transport and Lifting Instructions . . . . . . . . . . . . . . . . 11
Section 10 - Maintenance . . . . . . . . . . . . . . . 13
Pre-start Inspection Report . . . . . . . . . . . . . . . . . 13
Maintenance Inspection Report . . . . . . . . . . . . . . . . 14
Daily Maintenance. . . . . . . . . . . . . . . . . . . . 15
Quarterly Maintenance . . . . . . . . . . . . . . . . . . 17
Semi-annual Maintenance. . . . . . . . . . . . . . . . . . 27
Yearly Maintenance . . . . . . . . . . . . . . . . . . . 28
Section 11 - Control System . . . . . . . . . . . . . . 29
Control Component Locations. . . . . . . . . . . . . . . . . 29
FaultCodes.....................30
Parameter Adjustment. . . . . . . . . . . . . . . . . . . 32
Section 12 - Schematics . . . . . . . . . . . . . . . 35
Electrical Schematic . . . . . . . . . . . . . . . . . . . 35

Page iii MMAE16 - Service & Parts Manual
April 2022
Chapter 2 - Parts . . . . . . . . . . . . . . 37
Parts Introduction .................37
Section 13 - Chassis.................38
Steer Linkage and Wheels Assembly Installation . . . . . . . . . . . . 38
Steer Linkage and Wheels Assembly . . . . . . . . . . . . . . . 40
Drive Wheel Assembly. . . . . . . . . . . . . . . . . . . 42
Pothole Protection Assembly . . . . . . . . . . . . . . . . . 44
Electric Control Assembly . . . . . . . . . . . . . . . . . . 46
Motor Controller Assembly . . . . . . . . . . . . . . . . . 48
Ground Control Assembly . . . . . . . . . . . . . . . . . . 50
Chassis Accessory Installation . . . . . . . . . . . . . . . . 52
Section 14 - Mast . . . . . . . . . . . . . . . . . 54
Mast and Chassis Installation . . . . . . . . . . . . . . . . . 54
MastAssembly ....................56
Mast 1 Assembly . . . . . . . . . . . . . . . . . . . . 58
Mast 2 Assembly . . . . . . . . . . . . . . . . . . . . 60
Mast 3 Assembly . . . . . . . . . . . . . . . . . . . . 62
Mast 4 Assembly . . . . . . . . . . . . . . . . . . . . 64
Mast 5 Assembly . . . . . . . . . . . . . . . . . . . . 66
(1-3) Mast Lifting Chain Installation . . . . . . . . . . . . . . . 68
(2-4) Mast Lifting Chain Installation . . . . . . . . . . . . . . . 70
(3-5) Mast Lifting Chain Installation . . . . . . . . . . . . . . . 72
Electric Cylinder Installation . . . . . . . . . . . . . . . . . 74
Section 15 - Platform . . . . . . . . . . . . . . . . 76
Platform and Mast Installation . . . . . . . . . . . . . . . . . 76
Main Platform Assembly . . . . . . . . . . . . . . . . . . 78
Platform Extension Assembly . . . . . . . . . . . . . . . . . 80
Platform Locking Device Assembly . . . . . . . . . . . . . . . 82
Platform Control Box Assembly . . . . . . . . . . . . . . . . 84
Section 16 - Electrical System . . . . . . . . . . . . . . 86
Electrical Harness . . . . . . . . . . . . . . . . . . . . 86
Section 17 - Decal . . . . . . . . . . . . . . . . . 88
Decals.......................88

Page 1 MMAE16 - Service & Parts Manual
April 2022
Service Introduction
This Service section is designed to provide you, the customer, with the instructions needed to
properly maintain the MEC self-propelled aerial work platform. When used in conjunction with the
illustrated Parts section in this manual and the Operator’s Manual (provided separately), this manual
will assist you in making necessary adjustments and repairs, and identifying and ordering the correct
replacement parts.
All parts represented here are manufactured and supplied in accordance with MEC quality
standards. We recommend that you use genuine MEC parts to ensure proper operation and reliable
performance.
To obtain maximum benefits from your MEC Aerial Work Platforms, always follow the proper
operating and maintenance procedures. Only trained authorized personnel should be allowed to
operate or service this machine. Service personnel should read and study the Operator’s, and the
Service and Parts Manuals in order to gain a thorough understanding of the unit prior to making any
repairs.
Chapter 1 - Service

Page 2 MMAE16 - Service & Parts Manual
April 2022
MEC Operator Policy
Note: The best method to protect yourself and others from injury or death is to use common sense.
If you are unsure of any operation, don’t start until you are satisfied that it is safe to proceed
and have discussed the situation with your supervisor.
Service personnel and machine operators must understand and comply with all warnings and
instructional decals on the body of the machine, at the ground controls, and platform control console.
MODIFICATIONS OF THIS MACHINE FROM THE ORIGINAL DESIGN AND
SPECIFICATIONS WITHOUT WRITTEN PERMISSION FROM MEC ARE
STRICTLY FORBIDDEN. A MODIFICATION MAY COMPROMISE THE
SAFETY OF THE MACHINE, SUBJECTING OPERATOR(S) TO SERIOUS
INJURY OR DEATH.
MEC’s policies and procedures demonstrate our commitment to Quality and our relentless ongoing
efforts towards Continuous Improvement, due to which product specifications are subject to change
without notice.
Any procedures not found within this manual must be evaluated by the individual to assure oneself
that they are “proper and safe.”
Your MEC Aerial Work Platform has been designed, built, and tested to provide many years of safe,
dependable service. Only trained, authorized personnel should be allowed to operate or service the
machine.
MEC, as manufacturer, has no direct control over machine application and operation. Proper safety
practices are the responsibility of the user and all operating personnel.
If there is a question on application and/or operation, contact MEC Aerial Work Platforms:
1401 S. Madera Avenue, Kerman, CA93630 USA
Toll Free: 1-877-632-5438
Phone: [phone]
Fax: [phone]
[email protected]
www.MECawp.com
MEC Aerial Work Platforms
MEC Operator Policy
Section 1 - MEC Operator Policy

Page 3 MMAE16 - Service & Parts Manual
April 2022
Safety Symbols & General Safety Tips
MEC manuals and decals use symbols, colors and signal words to help you recognize important
safety, operation and maintenance information.
RED and the word DANGER – Indicates an imminently hazardous
situation which, if not avoided, will result in death or serious injury.
ORANGE and the word WARNING – Indicates a potentially hazardous
situation which, if not avoided, could result in death or serious injury.
YELLOW with alert symbol and the word CAUTION – Indicates a
potentially hazardous situation which, if not avoided, may result in minor
or moderate injury.
YELLOW without alert symbol and the word CAUTION – Indicates a
potentially hazardous situation which, if not avoided, may result in
property damage.
GREEN and the word NOTICE – Indicates operation or maintenance
information.
Regular inspection and constant maintenance is the key to efficient economical operation of your
aerial work platform. It will help to assure that your equipment will perform satisfactorily with a
minimum of service and repair.
The actual operating environment of the machine governs the inspection schedule. Correct lubrication
is an essential part of the preventative maintenance to minimize wear on working parts and ensure
against premature failure. By maintaining correct lubrication, the possibility of mechanical failure and
resulting downtime is reduced to a minimum.
Use only recommended lubricants. Improper lubricants or incompatible lubricants may be as
harmful as no lubrication.
Watch for makeshift “fixes” which can jeopardize safety as well as lead to more costly repair.
•
•
Safety Symbols & General Safety Tips
Section 2 - Safety Symbols & General Safety Tips

Page 4 MMAE16 - Service & Parts Manual
April 2022
Specifications
Height, Working Maximum* Indoor 22 ft 6.7 m
Outdoor 18 ft 5.5 m
Height, Platform Maximum Indoor 16 ft 4.9 m
Outdoor 12 ft 3.7 m
Height Stowed Maximum 78.3 in 2 m
Guard Rails 43.3 in 1.1 m
Maximum Personnel Indoor 1
Outdoor 1
Manual Force Indoor 45 lbs 200 N
Outdoor 45 lbs 200 N
Width 30 in 0.76 m
Length, Stowed 57 in 1.45 m
Platform Dimensions (Length × Width) 40 × 30 in 1.02 × 0.76 m
Platform Extension Length 20 in 0.5 m
Maximum Load Capacity 500 lbs 227 kg
Platform Extension Load Capacity 250 lbs 113 kg
Maximum Wind Speed 28 mph 12.5 m/s
Wheelbase 47.6 in 1.21 m
Turning Radius Outside 70.8 in 1.8 m
Inside 23.6 in 0.6 m
Ground Clearance 2.5 in 6.4 cm
Ground Clearance (Pothole Guards Deployed) 0.55 in 1.4 cm
Weight** (See Serial Label) 2,170 lbs 985 kg
Maximum Wheel Load 800 lbs 363 kg
Controls Proportional
AC Outlet In Platform Standard
Power Source 2×12V 115Ah AGM
System Voltage 24 V
Tire Size 9×3.1 in 230×80 mm
Airborne Noise Emissions <70 dB (A-weighted) Maximum sound level at normal operating workstations
Vibration value does not exceed 2.5m/s2
Maximum Slope Rating, Stowed Position*** 25%
Maximum Side Slope Rating, Stowed Position*** 10%
Warning Slope X-1.5°, Y-3°
Drive Speeds
Stowed, Maximum 2.5 mph 4.0 km/h
Platform Raised, Maximum 0.5 mph 0.8 km/h
Floor Loading Information
Tire Load, Maximum 800 lbs 363 kg
Tire Contact Pressure Loaded 148 psi 10.4kg/cm2(1,020 kPa)
Unloaded 120 psi 8.5kg/cm2(834 kPa)
Occupied Floor Pressure **** 225 psf 0.11kg/m2(10.8 kPa)
Meets requirements of ANSI A92.20-2020 and CSA B354.6-2019.
*Working Height adds 6 feet (2 m) to platform height.
**Weight may increase with certain options.
***Slope rating is subject to ground conditions and adequate traction.
****Occupied floor pressure with deck extended is 168 psf - 0.08kg/m2(8 kPa).
Section 3 - Specifications Specifications

Page 5 MMAE16 - Service & Parts Manual
April 2022
Bolt Torque Specification - American Standard
Fasteners
Use the following values to apply torque unless a specific torque value is called out for the part being
used.
American Standard Cap Screws
SAE Grade 5 8
Cap Screw
Size (inches)
ART_5816A
ART_5816B
Torque Torque
Ft. Lbs Nm Ft. Lbs Nm
Min Max Min Max Min Max Min Max
1/4 - 20 6.25 7.25 8.5 10 8.25 9.5 11 13
1/4 - 28 8 9 11 12 10.5 12 14 16
5/16 - 18 14 15 19 20 18.5 20 25 27
5/16 - 24 17.5 19 12 26 23 25 31 34
3/8 - 16 26 28 35 38 35 37 47.5 50
3/8 - 24 31 34 42 46 41 45 55.5 61
7/16- 14 41 45 55.5 61 55 60 74.5 81
7/16 - 20 51 55 69 74.5 68 75 92 102
1/2 - 13 65 72 88 97.5 86 96 116 130
1/2 - 20 76 84 103 114 102 112 138 152
9/16 - 12 95 105 129 142 127 140 172 190
9/16 - 18 111 123 150 167 148 164 200 222
5/8 - 11 126 139 171 188 168 185 228 251
5/8 - 18 152 168 206 228 203 224 275 304
3/4 - 10 238 262 322 255 318 350 431 474
3/4 - 16 274 302 371 409 365 402 495 544
7/8 - 9 350 386 474 523 466 515 631 698
7/8 - 14 407 448 551 607 543 597 736 809
1- 8 537 592 728 802 716 790 970 1070
1 - 14 670 740 908 1003 894 987 1211 1137
Torque values apply to fasteners as received from the supplier, dry or when lubricated with
normal engine oil.
If special graphite grease, molydisulphide grease, or other extreme pressure lubricants are
used, these torque values do not apply.
Section 4 - Torque Specifications
Bolt Torque Specification - American Standard

Page 6 MMAE16 - Service & Parts Manual
April 2022Section 4 - Torque Specifications
Bolt Torque Specification - Metric Standard
Fasteners
Use the following values to apply torque unless a specific torque value is called out for the part being
used
Metric Cap Screws
Metric Grade 8.8 10.9
Cap Screw Size
(Millimeters)
8.8
ART_5816C
10.9
ART_5816D
Torque Torque
Ft. Lbs Nm Ft. Lbs Nm
Min Max Min Max Min Max Min Max
M6 × 1.00 6 8 8 11 9 11 12 15
M8 × 1.25 16 20 21.5 27 23 27 31 36.5
M10 × 1.50 29 35 39 47 42 52 57 70
M12 × 1.75 52 62 70 84 75 91 102 123
M14 × 2.00 85 103 115 139 120 146 163 198
M16 × 2.50 130 158 176 214 176 216 238 293
M18 × 2.50 172 210 233 284 240 294 325 398
M20 × 2.50 247 301 335 408 343 426 465 577
M22 × 2.50 332 404 450 547 472 576 639 780
M24 × 3.00 423 517 573 700 599 732 812 992
M27 × 3.00 637 779 863 1055 898 1098 1217 1488
M30 × 3.00 872 1066 1181 1444 1224 1496 1658 2027
Torque values apply to fasteners as received from the supplier, dry or when lubricated with
normal engine oil.
If special graphite grease, molydisulphide grease, or other extreme pressure lubricants are
used, these torque values do not apply.

Page 7 MMAE16 - Service & Parts Manual
April 2022
Maintenance Safety
Make sure that a chock is used during when working under an elevated
platform.
NEVER perform work on the machine with the platform elevated without first using a 2”×4” to support
the mast section as is shown below. Alternatively the platform can be supported with either a forklift or
a crane.
ART_5817
Section 5 - Maintenance Safety Maintenance Safety

Page 8 MMAE16 - Service & Parts Manual
April 2022
Electrical System and Total System
Electrical System
Prevent damage to battery and/or electrical system;
Always disconnect the negative battery cable first.
Always connect the positive battery cable last.
•
•
When the negative cable is installed, a spark will occur if contact is made between the positive side
of the battery and a metal surface on the machine. This can cause damage to the electrical system,
battery explosion, and personal injury.
Total System
FAILURE TO PERFORM PREVENTIVE MAINTENANCE AT
RECOMMENDED INTERVALS MAY RESULT IN THE UNIT BEING
OPERATED WITH A DEFECT THAT COULD RESULT IN INJURY OR
DEATH OF THE OPERATOR.
IMMEDIATELY REPORT TO YOUR SUPERVISOR ANY DEFECT OR
MALFUNCTION. ANY DEFECT SHALL BE REPAIRED PRIOR TO
CONTINUED USE OF THE AERIAL WORK PLATFORM.
INSPECTION AND MAINTENANCE SHOULD BE PERFORMED BY
QUALIFIED PERSONNEL FAMILIAR WITH THE EQUIPMENT.
Electrical System and Total System
Section 6 - Electrical System and Total System

Page 9 MMAE16 - Service & Parts Manual
April 2022
Machine Components
Platform
Entry Gate Platform
Controller
Platform
Extension
Pothole
Protection
Device Emergency
Lowering
Button
Emergency
Down
Battery
Main
Power
Switch
Ground
Control
Panel
Comms
Cable
Power To
Platform
Cable
Chassis
Mast
Assembly
Main
Platform
Front
Wheel
Rear
Wheel
Forklift
Pockets
Lanyard
Anchorage
Motor
Controllers
Batteries
Lifting
Points
Lifting
Points
Platform
Guard Rails
Platform
Extension
Release
Pedal
Batteries
Charger
Chassis Covers Removed
To Show Interior For Clarify Art_5805C
Machine Components
Section 7 - Machine Components

Page 10 MMAE16 - Service & Parts Manual
April 2022
Emergency Systems and Procedures
IF THE CONTROL SYSTEM FAILS WHILE THE PLATFORM IS ELEVATED,
HAVE AN EXPERIENCED OPERATOR USE THE EMERGENCY LOWERING
PROCEDURE TO SAFELY LOWER THE PLATFORM.
DO NOT ATTEMPT TO CLIMB DOWN ELEVATING ASSEMBLY.
Emergency Stop
The machine is equipped with an EMERGENCY STOP switch at the base
controls and the platform control box.
Press the EMERGENCY STOP switch at any time to stop all machine
functions.
Pull switch to reset.
Either switch will stop all machine functions.
Both switches must be reset or machine will not operate.
•
•
•
•
ART_3353
Emergency Lowering
Push the emergency lowering button located on the ground controls side of the
machine under the Main Power Switch. It has a yellow decal border.
EMERGENCY
LOWERING
BUTTOM
ART_5818
Emergency Systems and Procedures
Section 8 - Emergency Systems and Procedures

Page 11 MMAE16 - Service & Parts Manual
April 2022
Transport and Lifting Instructions
Observe and Obey:
The transport environment temperature should be within: -13°F (-25°C) ~ 131°F (55°C)
Common sense and planning must be applied to control the movement of the machine when
lifting it with a crane or forklift.
Only qualified aerial lift operators should move the machine on or off the truck.
The transport vehicle must be parked on a level surface.
The transport vehicle must be secured to prevent rolling while the machine is being loaded.
Be sure the vehicle capacity, loading surfaces and chains or straps are sufficient to withstand the
machine weight. See the serial label for the machine weight.
The machine must be on a level surface or secured before releasing the brakes.
Only qualified forklift operators should lift the machine with a forklift.
Be sure the crane capacity, loading surfaces and straps or lines are sufficient to withstand the
machine weight. See the serial plate for the machine weight.
Brake Release Operation
Chock the wheels to prevent the machine from rolling.
Pull out the platform and emergency red Emergency Stop button to the “ON” position.
Turn the key switch to the “ground” position while pressing and holding down the “Menu Enter
Button” button on the ECU panel to enter the password input screen .
Press the “Menu Enter Button” 4 times to enter the Menu screen .
Press either the “Menu Up Button” or “Menu Down Button” button to switch to the Special mode
(“ 4. Special Mode “)
Press the “Menu Enter Button” button to display the Special mode. Press either the “Menu Up
Button” or “Menu Down Button” button to switch to the manual push menu (“ 1. Brake Release “)
Press “Menu Enter Button” button to display “long press to confirm release of brake”. Press and
hold down the “Menu Enter Button” button to show “Brake Released!” Release all brakes.
If you want to close the brake release, just turn off the key switch in “ground” position.
If the machine must be towed, do not exceed 2.5 mph
(4.0km/h).
Securing to Truck or Trailer for Transit
Turn the key switch to the “OFF“ position and remove
the key before transporting.
Inspect the entire machine for loose or unsecured
items.
Securing the Chassis
Use chains of ample load capacity.
Use a minimum of 4 chains.
Adjust the rigging to prevent damage to the chains.
•
•
•
•
•
ART_5803A
•
•
•
•
•
•
•
•
•
1.
2.
3.
4.
5.
6.
7.
8.
Section 9 - Transport and Lifting Instructions
Transport and Lifting Instructions

Page 12 MMAE16 - Service & Parts Manual
April 2022Section 9 - Transport and Lifting Instructions
Lifting the Machine with a Forklift
Only qualified riggers should rig and lift the machine.
Only qualified forklift operators should lift the machine with a forklift.
Be sure the crane capacity, loading surfaces and straps or lines are
sufficient to withstand the machine weight. See the serial plate for the
machine weight.
Be sure the controls and component trays are secure. Remove all loose
items on the machine.
•
•
•
ART_5803B
Fully lower the platform. The platform must remain lowered during all loading and transport
procedures.
Position the forklift forks in position as the figure above.
Drive forward to the full extent of the forks.
Raise the machine 6 in (15 cm) and then tilt the forks back slightly to keep the machine secure.
Be sure the machine is level when lowering the forks.
Lifting Instructions
Fully lower the mast and jib boom. Remove all loose items on the machine.
Attach the rigging only to the designated lifting points on the machine. There
are two lifting points on the top of the mast.
Adjust the rigging to prevent damage to the machine and to keep the machine
level.
ART_5803C

Page 13 MMAE16 - Service & Parts Manual
April 2022
Pre-start Inspection Report
Be sure that the operator’s manual is complete and legible.
Be sure that all decals are legible and in place. See Decals section.
Check for battery fluid leaks and proper fluid level. Add distilled water if needed. See Maintenance section.
Check the following components or areas for damage, improperly installed or missing parts and
unauthorized modifications:
Electrical components, wiring and electrical cables
Battery and connections
Drive motors
Wear pads
Wheels
Lifting chains and idler wheels
Mast and mast braces
Limit switches, alarms and horn
Nuts, bolts and other fasteners
Platform entry gate
Alarms and beacons (if equipped)
Platform Control Panel
Pothole guard
Check entire machine for:
Cracks in welds or structural components
Dents or damage to machine
Be sure that all structural and other critical components are present and all associated fasteners and pins
are in place and properly tightened
NEVER perform work or inspection on the machine with the platform
elevated without first supporting the platform with either a forklift or
a crane. Alternatively, use a 2”×4” or recommended a 4”×4” a piece of
wood to support the mast section that is attached to the platform.
See page 7 for instructions.
Section 10 - Maintenance Pre-start Inspection Report

Page 14 MMAE16 - Service & Parts Manual
April 2022Section 10 - MaintenanceMaintenance Inspection Report
MMAE Series (All Electric Mast Lifts)
Fleet Equipment Number Date
Inspector Name Inspector Co.
Model Number Address
Serial Number
Hour Meter Signature
Machine Owner & address
Maintain all service records in accordance with ANSI A92.24-2019
*If an inspection receives an “N”, remove from service. Once repaired, place an R in the box.
*Refer to the proper service manual for specific information, settings and torque specifications.
Key Y = Yes, Acceptable N= No, Remove from Service R= Repaired 0= Not Applicable
QUARTERLY - Inspect only those marked “Q” ANNUAL - Inspect all items
Q/A Y/N/O R Q/A Y/N/O R
DECALS: X X X WHEELS: X X X
Legible - undamaged/readable Q Tire, damage, excessive wear Q
Capacity decal correct for model Q Lug nuts (Wheel mounting) torqued correctly Q
RAILS: X X X King Pins lubed A
Not damaged, all in place Q COMPONENT AREA (Under Cover): X X X
All rail fasteners secure Q Motor Controller - cables tight, no corrosion Q
Entry gate secure, closes properly Q Wires not damaged - Plugs tight Q
Manual box in good condition Q Limit Switches - adjustment, operation, lubed Q
Operators Manual in manual box Q Cleanliness - All debris, excessive dirt removed Q
PLATFORM EXTENSION: X X X Batteries properly filled and cables clean Q
Rolls in and out freely Q Battery switch cuts battery feed Q
Lock holds deck in place Q Cover Doors secure, locks operate correctly Q
Release Pin moves freely, retains platform Q Fasteners present and tight Q
ELEVATING ASSEMBLY: X X X BASE: X X X
Mast Slide Blocks, lubed Q Fasteners present and tight Q
Mast structures: Straight, no cracks Q Cover panels secure Q
Welds: secure, no cracks Q Welds A
Cables tensioned correctly Q OPERATIONAL INSPECTION: X X X
Chains secure, not stretched A All functions, operate smooth and quiet Q
Lift Actuator no visible damage A All functions, speeds correct Q
ELECTRICAL: X X X Upper control box, operates correctly Q
GFCI operates correctly Q Emergency Down, operates correctly Q
Wire harnesses good cond, secure A Limit switches slows drive when elevated Q
Comm cable no damage, secure A Indoor/outdoor limit swtch set test Q
Retractile Cord Reel operational Q Pothole switch test Q
Emergency stop, stops power/operation Q Battery Charger operation Q

Page 15 MMAE16 - Service & Parts Manual
April 2022Section 10 - Maintenance Daily Maintenance
The following maintenance should be done daily.
1) Inspect the Manuals and Decals
Keeping the operator’s manual in good condition is essential to safe machine operation.A operator’s
manual is included with each machine. An illegible or missing manual will not provide safety and
operational information necessary for a safe operating condition.
In addition, maintaining all of the safety and instructional decals in good condition is mandatory
for safe machine operation. Decals alert operators and personnel to the many possible hazards
associated with using this machine. They also provide users with operation and maintenance
information. An illegible decal will fail to alert personnel of a procedure or hazard and could result in
unsafe operating conditions.
Check to make sure that the operator’s manual is present and complete in the storage container
on the platform.
Examine the pages of the manual to be sure that they are legible and in good condition.
Result: The operator’s manual is appropriate for the machine and the manual is legible and
in good condition.
Result: The operator’s manual is not appropriate for the machine or the manual is not in
good condition or is illegible. Remove the machine from service until the manual is replaced.
Open the operator’s manual to the decals inspection section. Carefully and thoroughly inspect all
decals on the machine for legibility and damage.
Result: The machine is equipped with all required decals, and all decals are legible and in
good condition.
Result: The machine is not equipped with all required decals, or one or more decals are
illegible or in poor condition. Remove the machine from service until the decals are replaced.
Always return the manual to the storage container after use.
2) Perform Pre-operation Inspection
Completing a Pre-operation Inspection is essential to safe machine operation. The Pre-operation
Inspection is a visual inspection performed by the operator prior to each work shift. The inspection
is designed to discover if anything is apparently wrong with a machine before the operator performs
the function tests. The Pre-operation Inspection also serves to determine if routine maintenance
procedures are required.
Complete information to perform this procedure is available in the appropriate operator’s manual.
Refer to the Operator’s Manual for your machine.
3) Perform Function Tests
Completing the function tests is essential to safe machine operation. Function tests are designed
to discover any malfunctions before the machine is put into service. A malfunctioning machine must
never be used. If malfunctions are discovered, the machine must be tagged and removed from
service.
Complete information to perform this procedure is available in the appropriate operator’s manual.
1.
2. •
•
3.
•
•
4.

Page 16 MMAE16 - Service & Parts Manual
April 2022Section 10 - Maintenance
Refer to the Operator’s Manual for your machine.
4) Perform 30 Day Service
Tools will be required to perform this procedure.
New parts will be required to perform this procedure.
The 30 day maintenance procedure is a one time procedure to be performed after the first 30 days
or 40 hours of usage. After this interval, refer to the rest of the maintenance section for continued
scheduled maintenance.
Perform the following Quarterly Maintenance procedures:
Inspect the Tires, Wheels and Castle Nut Torque (See page 18)
•
•
1. •
