medi Circaid Juxtafit Essentials User manual

ESSENTIALS
JFE-AS-DFU-112612-01
CircAid Medical Products, Inc.
9323 Chesapeake Drive, Suite B2
San Diego, CA 92123 U.S.A.
01-858-576-3550
MDSS
Schigraben 41
30175 Hannover, Germany
EC REP
CompoNENTS of JUXTA-fIT™ ARmSLEEVE: Nylon, Polyurethane, Spandex, Silver
LAbELS: Polyvinyl Chloride Plastisol or Satin Acetate
CompoNENTS of ComfoRT CoVERUp™: Nylon, Spandex
ThIS pRodUCT CoNTAINS SILVER. ThIS pRodUCT doES NoT CoNTAIN LATEX.
INdICATIoNS foR USE: Lymphedema.
CAUTIoNS: Decreased or absent sensation in the arm, Sensitivity to product components.
CoNTRAINdICATIoNS: Severe arterial insuciency, acute infection.
*This garment is designed to provide measurable gradient compression based on average compression levels at the wrist. When
bands are placed in parallel they should slightly overlap, leaving no space between bands. This garment is not designed to be cut
or modied in anyway. Doing so will void the six month limited warranty.
CircAid Medical Products, Inc. assumes no liability for injury or damages resulting from contraindicated use of its products. CircAid
is a registered trademark and BPS, Built-In Pressure System, Juxta-Fit, and Comfort CoverUp are trademarks of CircAid Medical
Products, Inc. ©2012 CircAid Medical Products, Inc. All Rights Reserved.
One (1) Juxta-Fit™ Essentials Armsleeve
One (1) Removable Juxta-Fit™ Elbow Band
One (1) Comfort CoverUp™
One (1) Built-In Pressure System™ (BPS™) Card
One (1) Instructional DVD
**To extend the life of the Juxta-Fit™ Armsleeve hand wash and drip or at dry. However, the garment can also
be machine washed using a gentle cycle and dried on a low heat setting. If doing so, it is recommended that
the garment be placed in a pillow case to keep the hook material lint free and to prevent possible damage to
other clothing. Should lint collect on the tabs, it can be removed with tweezers.
If any of these items are missing, please contact CircAid® Customer Service
by phone at (800)-CIRCAID (247-2243) or by email at [e-mail].
Instructional videos are available at www.circaid.com.
m
‹
’
Â
ˆ
HAND WASH  WARM**
DRIP DRY OR FLAT DRY**
DO NOT BLEACH
DO NOT IRON
DO NOT DRY CLEAN
DO NOT WRING
CARE AND MAINTENANCE
Juxta-Fit™ Essentials Armsleeve
ARMSLEEVE
THIS PACKAGE INCLUDES:
10-20, 20-30, 30-40 or 40+ mmHg*
Juxta-Fit™ Essentials Armsleeve

If further assistance is required, please contact Customer Service by phone at (800) CIRCAID (247-2243) or by email at [e-mail]
We recommend you apply any necessary nger dressings before applying the Armsleeve.
1. ALIGN ARMSLEEVE
Slide the armsleeve all the way up to the underarm. Ensure that:
• The thin elastic material running down the center of the armsleeve
rests against the inside of the arm and elbow crease. The widest
portion of the thin material is centered at the elbow crease.
• The seam on the back of the armsleeve should run along the back
side of the arm. (The sleeve may feel tight initially. Slide sleeve on
and o to loosen.)
• If wearing a hand piece, don the hand piece. If wearing a Juxta-Fit™ Glove or
Gauntlet see their Directions for Use.
2. FASTEN THE BANDS
• Disengage the armsleeve band closest to the wrist. Pull the band up and across
the thin elastic material on the inside of the arm and fasten the hook to the
opposing side with rm and comfortable compression.
• Detach the second band and do the same, this time pulling the band in the
opposite direction as the rst and attach with rm and comfortable compression.
Do the same with the remaining two bands on the forearm, alternating the
direction in which the bands are pulled.
• If using the elbow band, pull it up and across the thin elastic
material and attach to the opposing side of the elbow with rm
and comfortable compression. The position of the elbow band
may need to be adjusted to maximize comfort and ensure that
no gaps are present between the bands.
• Attach the remaining top two bands with rm and comfortable
compression. Ensure that the hook tab on the top most band is
completely covered and will not rub the skin or cause discomfort.
3. APPLYING THE COMFORT COVERUP™ (OPTIONAL)
• Ensure that all tab ends of the armsleeve are securely fastened to the garment.
• Slide the Comfort CoverUp™ over your compression garment.
• Fasten the hook tabs of the Comfort CoverUp™ to the armsleeve.
4. REMOVAL
• Starting from the top, detach each of the tab ends and fold the bands back onto themselves. This will
help make reapplication easy and aid in keeping the hook tabs from collecting lint and catching on
other materials.
• Do the same with the bands on the gauntlet/glove and slide the hand piece o the hand.
• Slide o the armsleeve. Once complete, it should resemble its starting position.
5. ALIGN ELBOW BAND (OPTIONAL)
The elbow band will be pre-applied in its proper position for ease of use, however some adjusting to
maximize comfort and coverage may be needed. If the elbow band is removed and needs to be reapplied:
• Locate the widest point at the elbow.
• Apply the elbow piece, placing the two hook tabs 1cm away from the medial edge of the
widest elbow point. Ensure that the hook is not making contact with the thin elastic material,
and the two short tabs should be set with one above, and one below the center of the elbow.
• The band should be oriented so that it can be pulled across the thin elastic material and
connected to the other side.
• Use of the elbow band will assure continuous compression throughout the entire arm. However,
if additional mobility is needed within the elbow region, the elbow band may be easily removed
for increased exibility. Note: The elbow band is symmetrical, so either end may be used for alignment.
STEP 1: Locate the BPS™ card in your packaging.
STEP 2: Starting with the bottom band, line up the pressure guide line on the garment
with the line on card marked with

.
STEP 3: Note where the second pressure guide line on the garment is in relation to the
correct color coded pressure range on the card. (Fig. A, B, and C)
STEP 4: If the pressure guide line on the garment either falls short (Fig. B) or goes beyond the correct pressure range (Fig. C),
readjust the band as necessary so the second guideline is aligned with the prescribed pressure range (Fig. A). Completely
loosen band before reapplying if too much tension has been applied.
STEP 5: Repeat BPS™ Steps 2-4 for each band going up the arm. Be sure to adjust to the SAME tension on the BPS™ card scale as
the bottom band. Bands may need adjusting throughout the day to maintain the prescribed pressure range.
REmEmbER: The Juxta-Fit™ Armsleeve should never hurt. It should feel rm but comfortable. If pressure
increases or decreases noticeably during wear, loosen or tighten any bands. Always ensure, however, that
the correct prescribed pressure range is being applied. Slightly loosen the bands of the armsleeve for
night time wear. Each set of vertical guidelines may be at a dierent location on the arm depending on
the size and shape of the arm. They do not need to be aligned down the front center of the arm or in any
other specic location on the arm.
IF EXPERIENCING ANY PAIN, IMMEDIATELY REMOVE
THE ARMSLEEVE AND CONSULT YOUR PHYSICIAN.
~ fig. A Correctly Adjusted for 20-30mmHg
~ fig. b Not enough tension for 20-30mmHg ~ fig. C Too much tension for 20-30mmHg,
Set to 40mmHg+
Align Armsleeve
Fasten 1st Band
Fasten Remaining Bands
Finished View
Align
Elbow
Band
DIRECTIONS FOR USE Pull bands to rm and comfortable
compression, or if directed by a
Healthcare Professional, follow
steps below to set compression
to the prescribed level.
USING THE BUILT-IN PRESSURE SYSTEM™ (BPS™):
