Mercia Garden Products 01OVEABKSTR-V2 Instruction manual

01OVEABKSTR-V2
N/A
Overlap
Cladding
Shiplap
Cladding
Solid Sheet
Roof
T&G Roof
Solid Sheet
Floor
T&G Floor
Fixed
Windows
Opening
Windows
No
Windows
Overlap Bike Store
For Assistance Please
Contact Customer Care on
01636 880514
2mm Drill bit
x2
Winter = High Moisture = Expansion
Summer = Low Moisture = Contraction
All building’s should be erected by two
adults
For ease of assembly, you must pilot
drill all screw holes and ensure all
screw heads are countersunk.
BEFORE YOU START PLEASE READ INSTRUCTIONS CAREFULLY
- Check the pack and make sure you have all the parts listed.
- When you are ready to start, make sure you have the right tools at hand
(not supplied) including a Phillips screwdriver, Stanley knife, wood saw,
step ladder and drill with 2mm bit.
- Ensure there is plenty of space and a clean dry area for assembly.
TIMBER
As with all natural materials, timber can be aected during various weather
conditions. For the duration of heavy or extended periods of rain, swelling of the
wood panels may occur. Warping of the wood may also occur during excessive
dry spells due to an interior moisture loss. Unfortunately, these processes cannot
be avoided but can be helped. It is suggested that the outdoor building is
sprayed with water during extended periods of warm sunshine and sheltered as
much as possible during rain or snow.
Our buildings are pre treated with a water based treatment**; this only helps to
protect the product during transit and for upto 3 months against mould. To
validate your guarantee and ensure longevity of the product, it is ESSENTIAL the
building is treated with a wood preserver within the rst three months of
assembly and thereafter in accordance with the manufactures recommenda-
tions. Care must be taken to ensure the product is placed on a suitable base.
BUILDING A BASE
When thinking about where the building and base is going to be constructed:
Ensure that there will be access to all sides for maintenance work and annual
treatment.
Whilst all products manufactured are made to the
highest standards of Safety and in the case of childrens
products independently tested to EN71 level, we cannot
accept responsibility for your safety whilst erecting or
using this product.
Mercia Garden Products Limited, Sutton On Trent, Newark, Nottinghamshire, NG23 6QN
www.merciagardenproducts.co.uk
CAUTION
Every eort has been made during the
manufacturing process to eliminate the
prospect of splinters on rough surfaces
of the timber. You are strongly advised
to wear gloves when working with or
handling rough sawn timer.
**Protim Fentex E5**
Biocidal Product Regulation (EU 528/2012) Article 58 Information
Protim Fentex E2 preserved wood is a“treated article”which incorporates biocidal products.
Wood correctly preserved with Protim Fentex E2 is protected against mould in storage.
Contains: IPBC (3-iodo-2-propynyl-N-butyl carbamate) and propiconazole.
Wear gloves when handling freshly treated wood.
Avoid breathing dust when cutting treated or untreated wood.
Dispose of o-cuts responsibly – do not burn.
Ensure the base is level and is built on rm ground, to prevent distortion. Refer
to diagrams for the base dimensions, The base should be slightly smaller than
the external measurement of the building, i.e. The cladding should overlap the
base, creating a run o for water. It is also recommended that the oor be at
least 25mm above the surrounding ground level to avoid ooding.
TYPES OF BASE
- Concrete 75mm laid on top of 75mm hard-core.
- Slabs laid on 50mm of sharp sand.
Please retain product label and instructions for future reference
P 1
General Instructions
01BIK0703-V1
Shiplap Bike Store
Refer to the instructions pages for you specic product code

Pre drill
hole
1
4
4
5
5
P 2
01OVEABKSTR-V2 & 01BIK0703-V1
Overall Dimensions:
Length = 816mm
Width = 2010mm
Height = 1788mm
Base Dimensions:
Length = 795mm
Width = 1982mm
Please retain product label and instructions for future reference
Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN
1 2 3 4 56
7
8
9
10
11
12
13
14
15
Door Gable Plain
Side
QTY 2
Plain
Gable
Door
QTY 2
Floor
QTY 2
Roof
QTY 2
Fascia 1095mm QTY 4
Eaves 825mm QTY 2
Roof Support 744mm
Bolt Block 132mm QTY 4
Turn Button QTY 2
L Bracket QTY 2
T-Hinge QTY 4
Pad Bolt
Felt
Nail Bag
Felt Tacks x 30
30mm Black Screw x 2
30mm Screw x 92
40mm Screw x 10
50mm Screw x 30
Remove transportation
blocks from the bottom
of each panel before
beginning assembly. Each
Panel should have two
Pre Assembly
30mm
screw
Attach the doors to the
door gable with the
hinges, using 7x30mm
screws per hinge.
28x30mm Screws.
Step 1
Position the floor section
as shown in the diagram.
fix together using
4x50mm screws;
alternate the fixing
position along the length
of the floor.
4x50mm Screws.
Pre drill
hole
50mm
screw
13
01OVEABKSTR-V2
01BIK0703-V1

P 3
Please retain product label and instructions for future reference
Step 2
Position the plain gable
and 1x plain side onto the
floor. Fixing together
using 3x50mm screws.
Do not attach to
floor until roof is
fixed in place
Fix the second plain side
and the door gable into
position using 9x50mm
screws.
Step 3
Fix the L Bracket’s onto
the central vertical
framing of the door and
plain gables using
4x30mm screws.
Rest the support bar onto
the L Brackets. Fix in place
using 4x30mm screws.
Step 4
Attach the eaves to the
roof sheets using
3x30mm screws per
panel.
Secure the roof into place
using 8x30mm screws,
ensure to screw roof
sheets into the panel
framing.
b
b
b
b
b
b
b
b
b
b
3x50mm Screws.
Pre drill
hole
50mm
screw
9x50mm Screws.
Pre drill
hole
50mm
screw
12 9
8x30mm Screws.
Pre drill
hole
30mm
screw
6
8
22x30mm Screws.
Pre drill
hole
30mm
screw

Felt
tacks
30mm
screw
P 4
Please retain product label and instructions for future reference
Step 5
Roll the felt across the roof
from left to right, leaving a
50mm overhang. Secure
with 28x felt tacks at 100mm
intervals.
28x Felt Tacks.
Step 6
Secure the building to the
floor using 12x50mm screws.
12x50mm Screws.
Pre drill
hole
50mm
screw
Step 7
Fix the fascias and finials into
place (front and back) using
16x30mm screws.
16x30mm Screws.
Pre drill
hole
Step 8
Attach the bolt blocks to
the doors using 2x40mm
per block as shown in
the diagram. Screw
through the cladding
into the blocks.
40mm
screw
8x40mm Screws.
Pre drill
hole
7
16 7
10
10
10
10

30mm
screw
It is ESSENTIAL that you apply wood
treatment immediately after the building
has been assembled.
P 5
Please retain product label and instructions for future reference
Step 9
Fix the turn buttons to
the top and bottom
blocks using 2x30mm
Black Screws.
2x30mm Black Screws.
Pre drill
hole
Step 9
Fix the pad bolt to the
door using 8x30mm
screws. Ensure the pad
bolt lines up with the
block on the back.
Attach the retainer to the
opposite door in-line
with the bolt using
4x30mm screws.
11
16x30mm Screws.
Pre drill
hole
30mm
screw
