micro-trak 17445 User manual

SPLICE
SWITCH SUPPLIED BY USER
(SWITCH CLOSED = RUN)
OPTIONAL RUN/HOLD CONNECTION
CUT JUMPER AND WIRE TO
SWITCH AS SHOWN
MOTOR
BLUE – ORANGE +
RUN/HOLD
DUST COVER W/JUMPER
P/N 13100
3-PIN M/P 150 SHROUD
BATTERY
WHITE
(+12 VDC)
TO FUSE TO
POSITIVE BATTERY
BLACK
(GROUND)
ORANGE
(+12 VDC)
BLACK
(GROUND)
TO NEGATIVE
BATTERY
POWER CABLE
P/N 17444
10 FT.
MOTOR CABLE
P/N 17448
20 FT.
BLACK - TO NEGATIVE
PUMP LEAD
WHITE - TO POSITIVE
PUMP LEAD
25A Manual Controller
Installation Instructions
© 2019 Micro-Trak Systems, Inc. •P/N 50236 •113021
OPTIONAL 2-PIN M/P 280 MOTOR
EXTENSION CABLES
P/N 17445 10' CABLE
P/N 17446 20' CABLE
IMPORTANT!
Do not connect the motor
leads to the battery or power
supply. Resulting damage to
controller will not be covered
under warranty.
Optional Pressure Gauge Bracket
also available - P/N 14799
LED STATUS INDICATOR CODES
Light on steady
Unit is turned on and operating normally
Steady Flashing
Unit in HOLD. Check Run/Hold jumper or remote
switch for correct operation.
1 Flash/pause
Open circuit detected. Check motor connections for
open circuit.
2 Flashes/pause
Output short circuit detected. Check motor wir-
ing.
3 Flashes/pause
Over-current condition. Check total load.
NOTE: Cycle power with the ON/OFF switch to clear a fault code
Front View
Cabling Details
Other Side
1305 Stadium Rd.
Mankato, MN 56001-5355
Web: www.micro-trak.com
Phone: [phone]
Toll-Free: [phone]
Email: [email protected]

PN17448 Motor Cable
PN17444 Power Cable
PN13100 Dust Cover w/jumper
3-Pin MetriPack 150 Shroud
Jumper Wire:
Cut wire here to add switch for
Run/Hold function.
Switch Closed = Run
