The MT-3405 F is an electronic monitoring and control system that can help you achieve maximum yields and operate more
cost-effectively by providing the information you need to maintain proper application rates of liquid chemicals and fertilizer.
The MT-3405 F has been designed for easy installation and operation. However, since each installation will vary depending
on your equipment, please take time to familiarize yourself with this manual and the actual components before beginning.
Following the procedures described in this manual will ensure proper performance and help avoid problems or questions once
you are in the field.
This manual is written for the MT-3405 F Model MT34F-99-LR, which may be used for either English or Metric measurement.
Please read the manual carefully and follow the instructions as they apply to your usage.
If you do encounter a problem that cannot be corrected by reviewing this manual, consult your dealer or distributor, or contact
a Micro-Trak technician for assistance.
