Midtronics JDT-1 WM User manual

Users Guide
November 2019
167-000938EN-A
JDT-1 WM
Battery Diagnostic
Service System
For testing 6- and 12-volt automotive /
12-volt and 24-volt charging systems.
For Technical Support call:
[phone]

Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527
www.midtronics.com 3
JDT-1
1: Introduction 5
Personal Precautions 5
Symbols Conventions 5
Description 5
Accessories 5
Tester Components 5
Charging Dock 6
Test Preparation 6
Inspecting the Battery 6
Testing Out-of-Vehicle 6
Testing In-Vehicle 6
Connecting To A Battery 7
Setting User Preferences 7
Initial Power Up 7
Intial Tool Setup 7
Main Menu 7
Main Menu Icons 7
2: In Vehicle Test 8
Battery Test 8
Battery Test Results 9
System Test 9
System Test Results 9
3: Out Of Vehicle Test 10
Battery Test Results 10
4: After New Battery Install 11
Battery Test 11
Reset Electronics 11
Battery Test Results 11
5: History 12
Tool History 12
Totals By Test Decision 12
Totals By Test Type 12
Totals By Date And Location 12
Vehicle History 12
Vehicle Select Option 12
6: Messages 13
Accessing Messages 13
Message Types 13
7: Settings 14
WiFi 14
Adding A Network 14
Deleting A Network 14
Email 14
Add Address (Admin Only) 14
Edit Address (Admin Only) 14
Deleting An Address (Admin Only) 14
Server Settings 14
Languages 15
System Language 15
Test Result Language 15
Email Language 15
Print Language 15
Display 15
Brightness 15
Auto Brightness 15
Sleep Time 15
Dim Time 15
BMIS 15
Shop Information 15
Shop Information 15
Date/Time Settings 15
Test Settings 16
Accessories 16
Software Update 16
About 16
Factory Preset 16
About 16
Appendix A:Screen Descriptions 17
Appendix B:Test Results Decision Tables 18
Battery Test Results 18
Starter Test Results 19
Alternator Test Results 19
Diode Test Results 19
Appendix C: Recommended Test Procedure 20
VIN Scanning 20
Scanning Tips 20
Contents

Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527
www.midtronics.com 5
1: IntroductionJDT-1
Personal Precautions
Risk of explosive gases.
Never smoke or allow a spark or
ame in the vicinity of a battery.
Batteries can produce a highly explosive mix
of hydrogen gas and oxygen, even when the
battery is not in operation. Always work in a
well-ventilated area.
Wash hands after handling.
REQUIRED BY CALIFORNIA PROP. 65: Battery posts,
terminals, and related accessories contain lead and lead
compounds, chemicals known to the state of California to
cause cancer and birth defects or other reproductive harm.
Inspect the battery for damage and check the electrolyte level.
If the electrolyte level is too low, replenish it and fully charge
the battery. Always use the necessary safety precautions when
working with batteries to prevent severe injury or death.
Follow all manufacturers’instructions and BCI (Battery Council
International) safety recommendations, which include the
following precautions:
Battery acid is highly corrosive. If acid enters your eyes,
immediately ush them thoroughly with cold running
water for at least 15 minutes and seek medical attention.
If battery acid gets on your skin or clothing, wash imme-
diately with a mixture of water and baking soda.
Always wear proper safety glasses or face shield when
working with or around batteries.
Keep hair, hands, and clothing as well as the analyzer
cords and cables away from moving engine parts.
Remove any jewelry or watches before you start servicing
the battery.
Use caution when working with metallic tools to prevent
sparks or short circuits.
Never lean over a battery when testing, charging, or jump
starting.
Symbols Conventions
Symbol Description
!The safety symbol indicates instructions for
avoiding hazardous conditions and personal injury.
The safety symbol with the words CAUTION,
WARNING, or DANGER indicates instructions for
avoiding hazardous conditions and personal injury.
The wrench symbol indicates procedural notes and
helpful information.
Description
The analyzer uses function-specific applications accessed
through a series of menus and icons to guide users through the
battery testing process for consistent testing implementation
and accuracy. These are accessed using the tester’s touch
screen display. Test results can be displayed on the full-color
screen, printed, or wirelessly emailed.
Accessories
A033 Lead Post Adapters
Tester Components




 Carrying Handle
 Charging LED / Display
Light Sensor
 Power Button: Hold for
2 seconds to turn the
tester on and o.
 Touch Screen: Primary
user interface. Startup
screen displayed.


 Temperature Sensor: For measuring battery temperature.
Camera & Flashlight: For VIN scanning and identication.
1: Introduction

Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527 www.midtronics.com
6
1: Introduction JDT-1

 Macro-USB Port/Power Supply Connection: Use the
Macro-USB Port for updating and servicing the tester
when a WiFi network is not available.
 
Clamp Storage Mounts: Use to keep the test clamps
protected when the tester is not in use.
Charging Dock
Place the Charging Dock in the oce or customer cash wrap
counter area.
IMPORTANT: The JDT must be placed in the Dock at
the end of each business day.


Tester Pod Charging
Contacts
 Power Supply
Connection
Test Preparation
Inspecting the Battery
Before starting the test visually inspect the battery for:
•Cracked, buckled, or leaking case. If you see any of these
defects, replace the battery.
•Corroded, loose, or damaged cables and connections. Re-
pair or replace them as needed.
•Corrosion on the battery terminals, and dirt or acid on the
case top. Clean the case and terminals using a wire brush
and a mixture of water and baking soda.
•Low electrolyte level. If the electrolyte level is too low, add
distilled water to ll up to ½ above the top of the plates
and fully charge the battery. Do not overll.
•Corroded or loose battery tray and hold-down xture.
Tighten or replace as needed.
Testing Out-of-Vehicle
The preferred battery test location is in the vehicle. However, if
you plan to test out of the vehicle:
•Always disconnect the negative cable from the battery
rst and reconnect it last.
•Always use a carry tool or strap to lift and transport the
battery.
Failure to properly install lead terminal adapters,
or using adapters that are dirty or worn, may
cause false test results.
When testing side-post or Group 31 batteries, always use lead
terminal adapters provided with the tester—do not test at
the battery’s steel bolts. To avoid damage, never use a wrench
to tighten the adapters more than ¼ turn.
Testing In-Vehicle
The preferred test position is at the battery posts. If you must
test at a remote-post location, it should have both a positive
and negative post. Otherwise, you must remove the battery
and perform an out-of-vehicle test.
At the start of the test, make sure all vehicle accessory loads
are o, the key is not in the ignition, and the doors are closed.

Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527
www.midtronics.com 7
1: IntroductionJDT-1
Connecting To A Battery
Do not connect the tester to a voltage source
greater than 30 Vdc.
Connect the clamps to the tester: the red clamp to the positive
(+) terminal and the black clamp to the negative (–) terminal.
If the clamps are connected with the wrong polarity (positive
to negative or negative to positive), the tester displays
CLAMPS REVERSED! Reconnect the clamps.
To make sure both sides of the clamps are gripping the
terminals, rock the each clamp back and forth. A poor
connection will prevent testing, and the tester will display the
message CHECK CONNECTION. If the message reappears after
you have correctly reconnected the clamps, clean the terminals
and reconnect.
Setting User Preferences
Before starting your test you may want to customize the use
of your analyzer by setting preferences in the Settings ( )
Menu. The Settings Menu is described in Chapter 7.
Initial Power Up
1. Plug in Charging Dock.
2. Place JDT-1 in the Dock.
3. Charge 30 seconds, then power on.
4. Undock the JDT and complete tool setup.
Intial Tool Setup
1. Select the System language.
2. Select a WiFi network from the displayed list (Walmart-
wi_2.4 preferred, or Walmartwi).
3. Tap Next at the WiFi successfully connnected screen.
4. Select Time Zone.
5. Select the correct Date & Time.
6. Select the correct Walmart store from the displayed list.
7. Conrm the store information is correct and tap Next.
8. Tap Done at the "Congratulations" screen.
IMPORTANT: The JDT must be placed in the Dock at
the end of each business day.
Main Menu
<93%
In Vehicle Test Out of Vehicle
Test
Aer New
Baery Install
History
Messages Sengs


Menu Bar
<Go back one screen
Bluetooth connectivity
status
WiFi signal strength
93% Tester internal battery
level
Tester internal battery
status
Application
Selection Area
A scroll bar is displayed when more information is available
than can be displayed on the tester screen.
Main Menu Icons
Icon Description
In Vehicle Test
Automates battery testing for quickly testing
vehicles using the fewest steps.
Out of Vehicle
Test
For testing customer batteries brought into the
store.
Aer New
Baery Install
For the installation of a new battery in a vehicle
and reset procedures for the vehicle's electronics.
History
Access archived test history by VIN or by Team
Member.
Messages
Displays alerts and notications for upcoming
tests and activities including scheduled tests, tool
software updates and maintenance opportunities.
Sengs
Setup/adjust: WiFi, email settings, user
information, default language, display and sound
settings, BMIS information, shop information,
and connected devices. Also access to the tester
software version information.

Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527 www.midtronics.com
8
2: In Vehicle Test JDT-1
In Vehicle Test
Use In Vehicle Test to perform Battery Tests
on in-vehicle batteries using test parameters
determined by vehicle VIN or year, make, and
model of the vehicle being tested. A System
Test function is also available.
NOTE: An In Vehicle Test test will always associate the
in-vehicle battery with the VIN of the vehicle in which
it is installed.
At any time during the test tap <to return to the previous
screen or to return to the Main Menu.
Battery Test
1. At the Main Menu tap In Vehicle Test. The Acquire VIN
screen is displayed.
2. Use the built-in camera on the back of the tester to scan
the VIN bar code.
Fill the viewnder with the VIN bar code.
Flashlight
Camera
Tester (Rear View)
Drivers Door Frame
Windshield
The VIN bar code usually located in the right corner of the
front windshield or on the driver’s side door frame.
NOTE: In low light situations, tap to turn on
the tester ashlight. Tap to turn it o.
NOTE: Refer to Appendix B for recommended
scanning procedures and VIN scanning help.
Manual Entry: Use the on-screen keypad to manually type
the 17-digit VIN and tap Next.
1234567890
W E R T Y U P
A S D F G H J K L
Z X C V B NM

Back Next
The displayed digit counter will count up the alphanumeric
characters as they are being entered on the keypad.
YMM: Use the scrolling lists to select the year, make, and
vehicle model. If applicable, a list of optional original
equipment is displayed.
Use Manual Entry if the battery being tested is not listed.
Tap >to continue to the Edit Battery Information screen.
3. Connect the tester clamps to the battery.
4. The Edit Battery Information screen displays vehicle and
battery information based on the VIN.
If the displayed information is correct, tap Next to begin
the Battery Test. Tap on the corresponding box to edit the
parameter information.
Battery Application VIN
Battery Type Vehicle Year
Test Location Vehicle Make
Rating Units Vehicle Model
Battery Rating Vehicle Technology
Battery Installation
See Appendix A at the back of this manual for complete
parameter descriptions.
5. Use the Viewing Window to align the temperature sensor
over the battery and tap Next. The test begins once the
temperature is successfully captured.
2: In Vehicle Test

Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527
www.midtronics.com 9
2: In Vehicle TestJDT-1
Battery Test Results
Send test results via
email.
Continue to System
Test
6Print test results Return to Main Menu
Icons are color-coded to indicate status.
Battery Test Starter Test Alternator Test
Green:
All test parameters were completed and have passed.
Yellow: Some test parameters may require further testing.
Red: The battery has failed the test.
Gray: Insufcent data to perform the test.
Refer to Appendix B: DecisionTables for a complete explaination
of the possible test results.
System Test
1. Tap to proceed with the System Test.
2. Start the engine and let it idle.
3. Tap Next. The analyzer tests the alternator output.
4. When prompted, rev the engine to between 2000 to 3000
rpm and hold it there while the analyzer tests the alterna-
tor output again.
5. When prompted Idle the engine and then turn it o.
6. Tap Next to display the test results.
Refer to Appendix B: DecisionTables for a complete explaination
of the possible test results.
System Test Results
Tap the icons at the top of the screen to view specic test
results.
Battery Test Starter Test Alternator Test
Send test results via
email. Return to Main Menu
6Print test results
Refer to Appendix B: DecisionTables for a complete explaination
of the possible test results.

Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527 www.midtronics.com
10
3: Out Of Vehicle Test JDT-1
Out Of Vehicle
Test
For testing customer batteries brought into the
store.
At any time during the test tap <to return to the previous
screen or to return to the Main Menu.
1. Connect the tester clamps to the battery.
2. At the Main Menu tap Out Of Vehicle Test.
3. At the Edit Battery Information screen enter the battery
information and tap Next to begin the Battery Test. Tap on
the corresponding box to edit the parameter information.
Battery Application VIN
Battery Type Vehicle Year
Test Location Vehicle Make
Rating Units Vehicle Model
Battery Rating Vehicle Technology
Battery Installation
4. Use the Viewing Window to align the temperature sensor
over the battery and tap Next. The test begins once the
temperature is successfully captured.
Battery Test Results
Send test results via
email.
Continue to System
Test
6Print test results Return to Main Menu
Icons are color-coded to indicate status.
Battery Test Starter Test Alternator Test
Green:
All test parameters were completed and have passed.
Yellow: Some test parameters may require further testing.
Red: The battery has failed the test.
Gray: Insufcent data to perform the test.
Refer to Appendix B: DecisionTables for a complete explaination
of the possible test results.
3: Out Of Vehicle Test

Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527
www.midtronics.com 11
4: After New Battery InstallJDT-1
Aer New
Baery Install
For the installation of a new battery in a
vehicle and reset procedures for the vehicle's
electronics.
At any time during the test tap <to return to the previous
screen or to return to the Main Menu.
Battery Test
1. At the Main Menu tap After New Battery Install. The Ac-
quire VIN screen is displayed.
2. Use the built-in camera on the back of the tester to scan
the VIN bar code.
Fill the viewnder with the VIN bar code.
Flashlight
Camera
Tester (Rear View)
Drivers Door Frame
Windshield
The VIN bar code usually located in the right corner of the
front windshield or on the driver’s side door frame.
NOTE: In low light situations, tap to turn on
the tester ashlight. Tap to turn it o.
NOTE: Refer to Appendix B for recommended
scanning procedures and VIN scanning help.
Manual Entry: Use the on-screen keypad to manually type
the 17-digit VIN and tap Next.
1234567890
W E R T Y U P
A S D F G H J K L
Z X C V B NM

Back Next
The displayed digit counter will count up the alphanumeric
characters as they are being entered on the keypad.
YMM: Use the scrolling lists to select the year, make, and
vehicle model. If applicable, a list of optional original
equipment is displayed.
Use Manual Entry if the battery being tested is not listed.
Tap >to continue to the Edit Battery Information screen.
3. Connect the tester clamps to the battery.
4. The Edit Battery Information screen displays vehicle and
battery information based on the VIN.
If the displayed information is correct, tap Next to begin
the Battery Test. Tap on the corresponding box to edit the
parameter information.
Battery Application VIN
Battery Type Vehicle Year
Test Location Vehicle Make
Rating Units Vehicle Model
Battery Rating Vehicle Technology
Battery Installation
See Appendix A at the back of this manual for complete
parameter descriptions.
5. Use the Viewing Window to align the temperature sensor
over the battery and tap Next. The test begins once the
temperature is successfully captured.
Reset Electronics
Use this function as a checklist for resetting vehicle electronics
following a new battery installation. Options displayed are
determined by the VIN of the vehicle tested.
Option
All models:
Electric windows and
sunroof:
Additional systems:
Battery Test Results
Send test results via
email.
Continue to System
Test
6Print test results Return to Main Menu
Refer to Appendix B: DecisionTables for a complete explaination
of the possible test results.
4: After New Battery Install

Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527 www.midtronics.com
12
5: History JDT-1
History
Use History to access the tool usage history, a
vehicle history based on VIN, and user histories.
The search function can also be used nd test
records for specic vehicles and technicians.
At the Main Menu, tap History. By default the Tool History
screen is displayed.
Tool History ∑Totals
Vehicle History
Tool History
Use Tool History to view test total history as well as
in vehicle and out of vehicle test totals. Individual
test results are also displayed.
Tap on a vehicle displayed in the list to view specic test results.
Tap ∑to view Total By Test Decision, Total By Test Type, and
Total By Date And Location.
Tap Done to return to the Tool History screen.
Totals By Test Decision
The totals are displayed by possible results for all battery
chemistries and potential test results.
Good Battery BC Open Or Load Fail
Replace
Good Recharge Broken Weld Replace
Charge & Retest Temp Sensor Failed
Replace Battery Aborted
Badcell Short Replace Invalid Test
Totals By Test Type
Displays test totals by test type.
In Vehicle Test After New Battery Install
Out of Vehicle Test
Totals By Date And Location
Displays test totals by time interval. Also displays the number
of tests performed in and out of vehicle.
Last 7 Days In Vehicle
Last 30 Days Out Vehicle
Last 90 Days
Vehicle History
Vehicle History displays test totals conducted on
specic vehicles based on the VIN. It is also possible
to enter a VIN to search for test records for a specic
vehicle by tapping the displayed buttons.
Tap on the vehicle records to view the individual test results.
Vehicle Select Option
Tap to select vehicle search option.
Manual Lookup: Use the on-screen keypad to manually type
the 17-digit VIN and tap Next.
VIN Scan: Use the camera built into the Controller to capture
a VIN barcode, usually located in the right corner of the front
windshield or on the driver’s side door frame..
Search: Search records by Vehicle Year, Make, and Model.
Last Tested Vehicle: Display results from the last vehicle tested.
5: History

Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527
www.midtronics.com 13
6: MessagesJDT-1
Messages
The Messages function displays alerts and
notications for upcoming tests and activities.
This includes scheduled testing as well as
tool software updates and maintenance
opportunities.
Mark Read Or Unread Delete Notication
Perform Message
Action
Tap to return to the previous screen or to return to the
Main Menu.
Accessing Messages

A number is displayed next to the Messages
icon when the analyzer has received any critical
messages. The number does not include non-
critical Notications.
Unread Critical Messages
Read Critical Messages
1. Tap Messages on the Main Menu screen.
2. Tap to read a message.
Tap to perform the message action item.
Tap to delete a message.
3. Tap ∧to collapse a list of messages or ∨to expand the
list.
Message Types
Critical: An important action cannot be performed and may
require user action.
Notications: Indicates an action has been performed or data
has been sent.
6: Messages

Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527 www.midtronics.com
14
7: Settings JDT-1
Sengs
Use the Setup options to setup and adjust WiFi,
printer setup and selection, email settings, user
information, default language, display settings,
sound settings, BMIS login information, shop
information, user management, connected
accessories, and device information.
Tap to return to the previous screen or to return to the
Main Menu.
WiFi
Use WiFi to view, add, and delete wireless networks.
Tap on the WiFi icon to display a list of detected and congured
WiFi networks.
Add Network Delete Selected
Network
Connect Highlighted
Network ∑Refresh Network List
Adding A Network
1. Tap to add a WiFi network.
A list of detected wireless networks is displayed with 
next to the selected network.
2. Tap >to access the network Security and IP Settings.
Security None
WEP
WPA/WPA2 PSK
IP Address DHCP
Static
3. Tap to congure the selected network.
4. Once the network has been successfully congured, tap
to return to the list of available congured networks. A
indicates the selected network.
Deleting A Network
1. Tap a displayed network.
2. Tap to delete the network and tap Yes to conrm.
Email
Displays all entered email addresses. Addresses
can be added, edited, and deleted (Admin Only).
Entered email accounts are added to the email
address book. Frequently used email addresses can
be selected from the displayed address list rather
than being re-typed each time.
Add Address Server Settings
Edit Address Address Book
Delete Selected
Address Send Test Email
Add Address (Admin Only)
1. Tap to add an email address.
2. Use the displayed keypad to enter the contact name and
email address.
3. Tap Add to add the address to the email list or Cancel to
exit and return to the email list.
Edit Address (Admin Only)
1. Select a displayed email address by tapping it.
2. Tap to edit the address.
3. Use the displayed keypad to edit the contact name and
email address.
4. Tap Add to add the address to the email list or Cancel to
exit and return to the email list.
Deleting An Address (Admin Only)
1. Select the email address by tapping it.
2. Tap to delete the address and tap Yes to conrm or
Cancel to exit and return to the email list.
Server Settings
Enter and edit the email settings for sending outgoing email.
1. Tap to access the email sever settings.
2. Tap to enter or modify existing server settings includ-
ing Host, Port, Login, Password, SMTP Authorization, En-
able TLS, and From Email Address information.
3. Tap to clear all server settings.
4. Tap to return to the email Address Book.
7: Settings

Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527
www.midtronics.com 15
7: SettingsJDT-1
Languages
Use the Language & Input function to select the
default system language used by the tool. User
defaults also include Test Results, Email, and Print
languages.
System Language
Select the default standard language for the analyzer to use
on the tester.
Test Result Language
Select the default language for the analyzer to use for all tests
and results displayed on the tester.
Email Language
Select the default standard language for the analyzer to use for
all tests and results sent via email.
Print Language
Select the default standard language for the analyzer to use for
all tests and results printed using a networked printer.
Display
Adjust the tester display including the Brightness,
Sleep Time, and DimTime. Auto Brightness can also
be turned on and o.
Brightness
Adjust the display Brightness by tapping and holding the
slider, then moving it right or left to make the screen brighter
or darker.
Auto Brightness
Enable and disable Auto Brightness by taping on the check box.
Sleep Time
Adjust the amount of elapsed time before the tester goes into
a power saving (Sleep) mode. Default = 2 minutes.
Dim Time
Adjust the amount of elapsed time before the tester goes into
a power saving (Dim) mode. Default = 1 minute.
BMIS
Enter and edit BMIS Login and Password information.
Log into a BMIS account.
User Name [email protected]
Password • • • • • •
Shop Information
Access default Shop Information including Store
Name, address, and phone number. Also access
battery test defaults including rating, temperature
units, and decimal separator. Use also to adjust the
tester date and time settings.
Settings Home Date/Time Settings
Test Settings ∑Create MDCA Log File
Shop Information
Use the onscreen keypad to enter the store name, address, and
phone number.
Store Name
Midtronics
State
IL
Street Address
7000 Monroe
Zipcode
60527
Street Address 2 Phone #
1-630-323-2800
City
Willowbrook
Date/Time Settings
1. Tap to access the Date/Time setting defaults.
Select Time Format
12 Hour
Set Date
Select Date Format
3/18/2018
Set Time
Select Time Zone
EST
Select Time Format
12 or 24 Hour Format
Select Date Format
Month/Day/Year, Day/Month/Year, or Year/Day/Month
Select Time Zone
Time zone in which the analyzer will be operated.
Set Date
Tap or to enter the month, day, and year. Tap Set to
save the date or Cancel to exit without saving.

Sep 17 2015
Oct 18 2016
Nov 19 2017

CANCEL SET

Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527 www.midtronics.com
16
7: Settings JDT-1
Set Time
Tap or to enter the hours, minutes, and AM/PM. Tap
Set to save the date or Cancel to exit without saving.

9 50 AM
10 51 PM
11 52

CANCEL SET
2. Tap to return to the Shop Information screen.
Test Settings
1. Tap to access the test setting defaults. Tap the boxes or
icons to change the values.
Battery Rating
CCA
Temperature Units
0F
Decimal Separator
00.00
Create MDCA Log File
Battery Rating
Default battery rating units used when testing batteries.
Temperature Units
Default temperature units used when measuring battery
temperature.
Decimal Separator
Default number display using commas or periods
separators.
Create MDCA Log File
The MDCA function is used by Midtronics technical support.
2. Tap to return to the Shop Information screen.
Accessories
Displays connected and linked accessory devices.
Additional devices can also be detected and linked
to the analyzer.
Add Refresh
Delete Paired Device Enabled
About
Use About to display the device serial number, WiFi
MAC Address, internal software data, and operating
system version.
Factory Reset ©About
Serial Number Tester SW Version
WiFi MAC Address Data Version
Conguration Version OS Version
Controller SW Version
Factory Preset
Use this function to return the tool to the original as built
conguration including all history and test settings.
IMPORTANT: All previous modications to the
original settings will be overwritten.
About
Displays software attribution information via the Midtronics
website. The analyzer must be connected to the Internet.

Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527
www.midtronics.com 17
Appendix A:Screen DescriptionsJDT-1
Edit Baery Informaon 93%
VIN Baery Applicaon
Vehicle Year Baery Post
Vehicle Make Test Locaon
Vehicle Model Baery Type
Vehicle Technology Baery Units
Baery Installaon Baery Rang
Back Find Baery Next
VIN A unique code, including a serial number,
used by the automotive industry to identify
individual motor vehicles, motorcycles,
scooters and mopeds, as dened in ISO
3833.
Vehicle Year Model year that a vehicle was
manufactured.
Vehicle Make Vehicle manufacturer
Vehicle Model Vehicle name or number
Vehicle
Technology
Hybrid, Gasoline, Electric, Start-Stop,
Hybrid Start-Stop, Diesel
Battery
Installation
Single Battery or Dual Batteries
Battery
Application
Automotive, Marine, Powersport, Group 31 ,
Commercial 4D/8D, Lawn and Garden
Battery Post Top Post, Side Post, Dual Post
Test Location Top Post, Side Post, Remote Post
Battery Type Flooded, AGM (Absorbed Gas Mat), AGM
Spiral, Gel, Enhanced Flooded
Battery Units CCA Cold Cranking Amps:
Battery current at 0 ºF
(–17.8 ºC).
100 to
3000
CA Cranking Amps:
Battery
current at 32°F (0 ºC).
100 to
3000
JIS Japanese Industrial
Standard: Usually
printed on battery label.
26A17 to
245H52
DIN(A) Deutsche Industrie-
Norm
100 to
1000
SAE(A) European labeling of
CCA
100 to
3000
IEC(A) International
Electrotechnical
Commission
100 to
1000
EN(A) Europa-Norm 100 to
1700
EN2(A) Europa-Norm 100 to
1700
Battery Rating Enter the Battery Rating Units value.
Appendix A:Screen Descriptions

Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527 www.midtronics.com
18
Appendix B:Test Results Decision Tables JDT-1
Battery Test Results
Decision Cranking
Health
Reserve
Capacity SOH Message RC Message
Good
Battery
Good Good The battery shows good cranking performance. Test the battery again
at next service opportunity.
The battery has good reserve capacity. The
battery is able to provide power for the electronics
systems in the vehicle.
Good
Recharge
Good
Recharge
The battery shows good cranking performance but low charge.
Fully charge the battery for optimal performance and life. Check the
starting and charging systems for causes of low charge.
Charge &
Retest
Charge
and Retest
Charge the battery and retest to determine condition.
Replace
Battery
Warning The battery shows low cranking performance. Replace the battery to
prevent a no-start situation in your vehicle.
Warning The battery shows low cranking performance. Replace the battery to
prevent a no-start situation in your vehicle.
Good Warning The battery shows good cranking performance but low reserve
capacity performance. Low reserve capacity will compromise the
battery's ability to provide power to the vehicle and hold a charge
over time.
The reserve capacity of the battery is low. Low
reserve capacity of the battery could impact the
ability of the battery to provide power for the
electronics systems in the vehicle. The battery
should be replaced.
Good
Recharge
The battery shows good cranking performance but low charge and low
reserve capacity performance. Low reserve capacity will compromise
the battery's ability to provide power to the vehicle and hold a charge
over time. Check the starting and charging systems for causes of low
charge.
Charge
and Retest
The battery shows low charge and low reserve capacity performance.
Low reserve capacity will compromise the battery's ability to provide
power to the vehicle and hold a charge over time.
Warning The battery shows low cranking performance. Replace the battery to
prevent a no-start situation in your vehicle.
Warning The battery shows low cranking performance. Replace the battery to
prevent a no-start situation in your vehicle.
Good
Battery
Good No Test The battery shows good cranking performance. Test the battery again
at next service opportunity.
System conditions have prevented a test of the
battery reserve capacity in this vehicle. Before
attempting any retest, ensure that all vehicle
accessory loads are off, the key is not in the
ignition, and the doors are closed.
Good
Recharge
Good
Recharge
The battery shows good cranking performance but low charge.
Fully charge the battery for optimal performance and life. Check the
starting and charging systems for causes of low charge.
Charge &
Retest
Charge &
Retest
Charge the battery and retest to determine condition.
Replace
Battery
Warning The battery shows low cranking performance. Replace the battery to
prevent a no-start situation in your vehicle.
Warning The battery shows low cranking performance. Replace the battery to
prevent a no-start situation in your vehicle.
Appendix B:Test Results Decision Tables

Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527
www.midtronics.com 19
Appendix B:Test Results Decision TablesJDT-1
Starter Test Results
Decision Action
Cranking
Normal
The starter voltage is normal and the battery is fully charged.
Low Voltage
The starter voltage is low and the battery is fully charged.
Charge Battery
The starter voltage is low and the battery is discharged. Fully
charge the battery and repeat the starter system test.
Replace Battery
(If the battery test result was (REPLACE or BAD CELL.) The
battery must be replaced before testing the starter.
Low Current
The starter voltage is high but the cranking amps are low.
No Start
The engine didn’t start and the test was aborted or the
vehicle’s starting prole was not detected and the Starter
Test was skipped.
Alternator Test Results
Decision Action
CHARGING
NORMAL
The output from the alternator is normal.
NO OUTPUT
No output detected. Check belts to ensure alternator is
rotating when engine is running.
√Check all alternator connections including to the
battery. Clean or replace if necessary and retest.
√If the belts and connections are in good working
condition, replace alternator or external voltage
regulator.
LOW OUTPUT
Alternator not providing enough current to power electrical
loads and charge the battery.
√Check belts to ensure the alternator is rotating with the
engine running.
√Check alternator connections to and from the battery.
If loose or heavily corroded, clean or replace the cable
and retest.
HIGH OUTPUT
Alternator voltage to the battery exceeds normal limits of a
functioning regulator.
√Check for loose and normal ground connections. If no
connection problems are found, replace the regulator.
The normal high limit of a typical automotive regulator is 14.5
volts +/–0.5. Refer to the manufacturer specications for the
correct limit, which may vary by vehicle type.
Diode Test Results
Decision Action
EXCESSIVE
RIPPLE
One or more diodes in the alternator are not functioning or
there is stator damage, which is shown by an excessive
amount of AC ripple current supplied to the battery.
√Make sure the alternator mounting is sturdy and that
the belts are in good shape and functioning properly.
If the mounting and belts are good, replace the
alternator.
OPEN PHASE
Replace the alternator.
OPEN DIODE
SHORTED
DIODE

Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527 www.midtronics.com
20
Appendix C: Recommended Test Procedure JDT-1
The Conductance Proling™ technology determines battery
cranking and Reserve Capacity testing. This additional process,
can take up to 60 seconds to complete.
IMPORTANT: Always begin each test by connecting
the Tester Pod clamps to the battery being tested . The
test begins as soon as the clamps are connected.
VIN Scanning
The JDT-1 uses a camera built into the Controller handle to
scan the VIN of the vehicle being tested. This number is then
cross referenced with the original equipment manufacturer's
battery specications stored in the tester's database and
displayed on the Controller screen.
Scanning Tips
•Camera: Located in the upper left portion on the back of
the Controller handle.
Flashlight
Camera
•Hold Steady: Hold Controller steady when scanning the
VIN barcode. This allows the user to clearly see the bar-
code and allows the camera to focus on it.
Acquire VIN 93%
Flashlight
Fill the viewnder with the VIN and center it along the red line.
Or enter VIN using:
Back Manual Entry Yr/Make/Model
•Fill Viewnder: Make sure the entire barcode is visible.
Keeping the entire VIN barcode visible while slowly mov-
ing the camera closer or further away will help capture.
•Clean Barcode/Window: Surface dirt can interfere with
the scanning process. If necessary wipe the VIN barcode
with a cloth or your nger remove any surface dirt.
•Lighting/Glare: The built-in ashlight will automatically
turn on In low light situations. If the ashlight, or sunlight,
is shining directly onto the VIN barcode, try pivoting the
camera up or down slightly to reduce any glare.
Appendix C: Recommended Test Procedure
