MJ LED LIGHTNING MJ-1006B3 User manual

ZOOM LED MOVING HEAD LIGHT
MJ-1006B3-4IN1
User Manual
======PROFESSIONAL LED LIGHTING ========
Thank you for choosing our LED zoom moving head light. For the sake of your safety, Please
read and follow these instructions carefully and keep this manual in a safe place for future
reference.

2
Catalogue
Chapter Page
Safe Usage Of The Product -----------------------------------------------------------------------------------------3
Install The Equipment ------------------------------------------------------------------------------------------------4
Power Code Connection ---------------------------------------------------------------------------------------------4
DMX Connection ------------------------------------------------------------------------------------------------------5
DMX Terminator -------------------------------------------------------------------------------------------------------6
Function Set --------------------------------------------------------------------------------------------------------------6
Operation Menu ---------------------------------------------------------------------------------------------------------7
Control panel of LED display information------------------------------------------------------------------------------9
Maintenance -------------------------------------------------------------------------------------------------------------10
Keeping The Product Clean -----------------------------------------------------------------------------------------10
Trouble Shooting--------------------------------------------------------------------------------------------------------10
Equipment and Appendix---------------------------------------------------------------------------------------------10
Channel List---------------------------------------------------------------------------------------------------------------11
Technical Parameters---------------------------------------------------------------------------------------------------13
☆Important notice:
·In this instruction for use contains about the installment and the use aspect important information of the LED moving
head. When installing and using, you need to look this usage instruction strictly.
·Before open the LED moving head and if you want to do the repair work, please make sure the power source is at the
separation condition.
·Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and the unit are
in good condition before installation and use. Should there be any damage caused by transportation, consult your dealer
and do not use the unit. Any damage caused by improper use will not be assumed by the manufacturer or dealer.
Attention: Unceasingly carries on the product improvement about our company the policy, in this instruction booklet
carries the data will have the possibility to be able to change in the future, when no longer separate notice change matters
concerned. Our company retains when the product improvement changes the related specification the authority. This
instruction booklet publisher cannot be responsible regarding this instruction booklet in information accuracy, also cannot
the related consequence which causes regarding these information be responsible.

3
SAFE USAGE OF THE PRODUCT
When unpacking and before disposing of the carton, check there is no transportation damage before
using the product. Should there be any damage caused by transportation, consult your dealer and do
not use the apparatus.
The product is for indoor use only, IP20. Use only in dry locations. Keep this device away from rain
and moisture, excessive heat, humidity and dust. Do not allow contact with water or any other
liquids.
The product is not designed or intended to be mounted directly on to inflammable surfaces
The product is only intended for installation, operation and maintenance by professional person.
The product must be installed in a location with adequate ventilation, at least 50cm from adjacent
wall surfaces. Be sure that no ventilation slots are blocked.
Do not product the beam onto inflammable surfaces, minimum distance is 5m.
Avoid direct exposure to the light from the lamp. The light is harmful to the eye.
Do not attempt to dismantle or modify the projector in any way.
Electrical connection must only be carried out by qualified personnel.
Before installation, ensure that the voltage and frequency of power supply match the power
requirements of the projector.
It is essential that each projector is correctly earthed and that electrical installation conforms to all
relevant standards.
Do not connect this device to any other types of dimmer apparatus.
Make sure that the power-cord is never crimped or damaged by sharp edges. Never let the
power-cord come into contact with other cables. Only handle the power-cord by the plug. Never pull
out the plug by tugging the power-cord.
Keep the optical system clean. Do not touch the LED lens with bare hands.
The product should always be installed with a secondary safety fixing. On the projector base brink,
there is a hole for the safety cord provided. It should be attached as shown in “installing the projector”
section.
LED lens shall be changed if they have become visibly damaged to such an extent that their
effectiveness is impaired, for example by cracks or deep scratches.
Exterior surface temperatures of the luminaire after 5 minutes operation is 40°C，when steady state is
achieved 50°C.
There is no user serviceable parts inside the projector, do not open the housing and never operate the
product with the covers removed.
If you have any questions, don’t hesitate to consult your dealer or manufacturer.
★Always disconnect from the mains, when the device is not in use or before cleaning it or
before attempting any maintenance work !

4
Install The Equipment:
Use 1pcs clamp and safety cord(need to purchase).Use clamp fix with light hook which in the
packing box with light, then use screw install to the bottom of lamp. Hang the fixture on the structure
and fasten the screws attached to each clamp. Make sure the light is installed reliable, and confirm
the light which you fixed is strong enough for hanging the light. Base on safety reason, please
according to the above picture using safety wire cross the light to make it strong enough again.
Warning!
1．Hook and clamp only use for hanging the light. Do not use clamp as a tool to move fixtures.
2．Base on safety reason, please use the safety cord which can afford the weight ten times of lamp
through Insurance hole for auxiliary hanging.
3．Don't use the handle of the moving head light to fixed or lift!
Power Code Connection:
Connect the power cord as follows:
L (live) =brown
E (earth) =yellow/green
N (neutral) =blue
Use the plug provided to connect the mains power to the projector paying attention to the voltage and
frequency marked on the panel of the projector. It is recommended that each projector be supplied
separately so that they may be individually switched on and off.
★It is essential that each projector is correctly earthed and the electrical installation conforms
to all relevant standards.

5
DMX Connection:
Connection between the controller and a projector and between one projector and another must be
made with a 2 core-screened cable, with each core having at least a 0.5mm diameter. Connection to
and from the projector is via cannon 3 pin (which are included with the projector) XLR plugs and
sockets. The XLR's are connected as shown in the figure above.
Note: Care should be taken to ensure that none of the pins touch the metallic body of the plug or each
other. The body of the plug is not connected in any way. The XLED 590 accepts digital control
signals in protocol DMX512 (1990).
Connect the controller’s output to the first fixture’s input, and connect the first fixture’s output to the
second fixture’s input and connect the rest fixtures in the same way. Eventually connect the last
fixture’s output to a DMX terminator as shown in the figure below.

6
DMX Terminator:
In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a
DMX terminator. This prevents electrical noise from disturbing and corrupting the DMX control
signals.
The DMX terminator is simply an XLR connector with a 120Ω (ohm) resistor connected across pins
2 and 3, which is then plugged into the output socket on the last projector in the chain. The
connections are illustrated below.
Function Set:
Touch Operation
Picture 1 picture 2
Touch LCD into the main menu, when the LCD is off.
When the LCD display the main menu,touch the menu into sub menu.(as picture 1)
Touch LCD display, can set the address code and function code easily.
Set or browse function setting of lamp, touch UP or DOWN buttons.(as picture 2)
Touch OK key to save your changes, Touch UP or DOWN can change value(Plus or reduce
number).
According to the Back key to return to the last menu.
Up
Ok
Down
Back
Set Up Manual System Advanced
180
中／ＥＮ

7
Operation Menu:
Menu Structure chart
Main Menu Sub Menu
Setting
Run Mode
Auto Mode
Sound Mode
Reset
Pan
Red 1
Focus
Blue 1
Green 1
Tilt
DMX Mode
Auto1
－
Auto6
OK/CANCEL
0
－
255
0
－
255
0
－
255
0
－
255
0
－
255
0
－
255
White 1
0
－
255
Load Default
OK / CANCEL
Channel Mode
Pan-Tilt Swap
Invert Tilt
8/16/28CH
ON/OFF
ON/OFF
No DMX Signal
Dimmer Delay
Pan-Tilt Encoder
KEEP/CLEAR
ON/OFF
DIM1/DIM2/DIM3/DIM4/OFF
Display DMX address/LOGO/OFF/Black
Random Mode
Back
DMX Address set
0-255
Invert Pan
ON/OFF
Manual
Back
Dimmer
0
－
255

8
Main Menu
Touch the screen to into setting.
Sub Menu
Sub menu include Setting, Manual, System, Advance, language, display Rot.. Touch the menu picture to
do each setting.
1) Setting menu: after you finished the setting, then you need to touch “ OK” button to keep the
address code and return to main menu.
Back :Back to main menu
Run Mode:
1. DMX mode: When the light in the DMX mode, then also can be slave mode. If the light
connect to the DMX control signal, then it is DMX mode. If you connect the light is
Master signal, then it is running slave mode.
2. Auto mode: Auto mode also can be master mode. It have 11 kinds of mode.
3. Sound mode: When the light in sound mode, it can’t be control by sound and master
mode.
4.Random Mode: The light is running by random
DMX Address: after you finished the setting, then you need to touch “ OK” button to keep
the address code and return to main menu.
Channel Mode: It can choose the channel which you need.
Pan reverse set
Tilt reverse set
Soft Ver.
System
System Errors
Total Fixture Hours
Partial Fixture Hours
*****H**M
T008B-M3C12-A001
No error
*****H**M
Factory set
Advance
Red 2
Blue 2
Green 2
0
－
255
0
－
255
0
－
255
White 2
0
－
255
Red 3
Blue 3
Green 3
0
－
255
0
－
255
0
－
255
White 3
0
－
255

9
Pan and Tilt Swap
Pan-Tilt Encoder
Dimmer Delay: No function
No DMX Signal: when there is no dmx signal, it can keep or clear the memory.
Display:It can show the dmx address and logo, the display can be on and off.
Load Default: it will be clean out your Settings
2) Manual: after you finished the setting, then you need to touch “ OK” button to keep the address
code and return to main menu.
Back :Back to main menu
Reset: The light reset
Pan: Pan setting by hand
Tilt: Tilt setting by hand
Focus: Zoom setting by hand
Dimmer: Main dimmer setting by hand
Red 1: Red 1 setting by hand
Green 1: Green 1 setting by hand
Blue 1: Blue 1 setting by hand
White 1: White 1 setting by hand
Red 2: Red 2 setting by hand
Green 2: Green 2 setting by hand
Blue 2: Blue 2 setting by hand
White 2: White 2 setting by hand
Red 3: Red 3 setting by hand
Green 3: Green 3 setting by hand
Blue 3: Blue 3 setting by hand
White 3: White 3 setting by hand
3) System:display related information on system
Ver.: current versions of software
System Errors: It is show the light errors
Total Fixture Hours: Total time of using this light
Partial Fixture Hours: The current time when you power on it
4) Advance :This setting only for factory
Control panel of LED display information:
Green
On
DMX signal ok
Off
No DMX signal
Flash
DMX signal error
Red
On
Error

10
Maintenance:
To prolong the life of the projector, some maintenance work has to be done to ensure the LED optical system in
good condition. If the projector does not function, check the fuses on the power
socket of the projector, they should only be replaced by fuses of the same specification. Should these be damaged,
call a qualified technician before replacement. The projector has thermal protection device that will switch off the
projector in case of overheating. Should either of these operate, check that the fans are not blocked, and if they are
dirty, clean them before switching on the projector again. Check that the fans are operational, if not, call a
qualified technician.
☆Any maintenance work should only be carried out by qualified technicians.
Keeping The Product Clean:
To ensure the reliability of the projector, it should be kept clean. It is recommended that the fans should be cleaned
every 15 days. LED lens should also be regularly cleaned to maintain an optimum light output.
Cleaning frequency depends on the environment in which the fixture operates: damp, smoke or particularly dirty
surroundings can cause greater accumulation of dirt on the unit's optics. A soft cloth and typical glass cleaning
products should be used for cleaning. It is recommended to clean the external optics at least once every 15 days.
☆Do not use any organic solvent, e.g. alcohol, to clean housing of the apparatus.
Trouble Shooting:
Problem
Answer
The LED moving head light doesn’t switch on. Check the fuse the power socket
Although shines, but the LED moving head lamp
doesn’t accept the instruction of the controller.
Check the digital start address and also check the
connection situation of the communication control
line
LED moving head lamp only can work
intermittently.
Inspect the power supply and voltage is whether
normal.
Do not receive the DMX512 signal. Whether the signal lines do contact
well or broken.
The light beam appears gloomily. Check that the heat dissipation system is running
normally or Inspect the optics part is whether clean.
☆Other maintain work should by the specialist which has the experience to carry on.
Equipment and Appendix:
The packing list of this light as follows:
☆LED zoom moving head light 1pcs
☆Power Cable 1pcs
☆XLR Connecter 1unit
☆Light Hook 1pcs
☆M10 Screw 2pcs
☆The Product of Instruction 1pcs

11
Channel List:
8CH MODE
Channel Value Function
CH 1
0-255
Pan
CH 2
0-255
Tilt
CH 3
0-255
Zoom
CH 4
0-255
Red all dimmer
CH 5 0-255 Green all dimmer
CH 6 0-255 Blue all dimmer
CH 7 0-255 White all dimmer
CH 8 0-99 No function
100-255 Motor Reset after 5 second
16CH MODE
Channel
Value
Function
CH 1
0-255
Pan
CH 2
0-255
Pan fine（16Bit）
CH 3
0-255
Tilt
CH 4
0-255
Tilt fine（16Bit）
CH 5
0-255
X / Y motor speed from quick to slow
CH 6
0-255
Main dimming
CH 7
0-255
Red all dimmer
CH 8
0-255
Green all dimmer
CH 9
0-255
Blue all dimmer
CH 10
0-255
White all dimmer
CH 11
0
Off
1-255
Strobe from slow to quick
CH 12
0-255
Color mixing
CH 13
(Macro)
0-9
No function
10-19
Show 1
20-39
Show 2
40-59
Show 3
60-79
Show 4
80-99
Show 5
100-119
Show 6
120-139
Show 7
140-159
Show 8
160-179
Show 9
180-199
Show 10
200-219
Show 11
220-239
Show 1 to Show 11
240-255
Sound
CH 14
0-255
Macro speed from slowly to fast
CH 15
0-255
Zoom
CH 16
0-99
No function
0-255
Motor Reset after 5 second

12
28CH MODE
Channel
Value
Function
CH 1
0-255
Pan
CH 2
0-255
Pan fine
（
16Bit
）
CH 3
0-255
Tilt
CH 4
0-255
Tilt fine
（
16Bit
）
CH 5
0-255
X / Y motor speed from quick to slow
CH 6
0-255
Main dimming
CH 7
0-255
Red all dimmer
CH 8
0-255
Green all dimmer
CH 9
0-255
Blue all dimmer
CH 10
0-255
White all dimmer
CH 11
0
Off
1-255
Strobe from slow to quick
CH 12
0-255
Color mixing
CH 13
(Macro)
0-9
No function
10-19
Show 1
20-39
Show 2
40-59
Show 3
60-79
Show 4
80-99
Show 5
100-119
Show 6
120-139
Show 7
140-159
Show 8
160-179
Show 9
180-199
Show 10
200-219
Show 11
220-239
Show 1 to Show 11
240-255
Sound
CH 14
0-255
Macro speed from slowly to fast
CH 15
0-255
Zoom
CH 16
0-99
No function
100-255
Motor Reset after 5 second
CH 17
0-255
Red 1 dimmer
CH 18
0-255
Green 1 dimmer
CH 19
0-255
Blue 1 dimmer
CH 20
0-255
White 1 dimmer
CH 21
0-255
Red 2 dimmer
CH 22
0-255
Green 2 dimmer
CH 23
0-255
Blue 2 dimmer
CH 24
0-255
White 2 dimmer
CH 25
0-255
Red 3 dimmer
CH 26
0-255
Green 3 dimmer
CH 27
0-255
Blue 3 dimmer
CH 28
0-255
White 3 dimmer

13
Technical Parameters:
Construction: Composite plastic, die-casting aluminum,
Voltage: AC100V-240V; 50/60Hz
Power Consumption: 400W (220V)
LED Bulbs: 4IN1*36pcs 10W LEDs
LED Current: 500mA
LED Lifetime: 50000Hours
Colors: RGBW color mixing
Adjusts the light: 0-100 electron adjusts the light, various colors may alone move also may mix the
color tone
Strobe: 1-25/second high speed strobe, but single color Mixes the color strobe
Head Movement: Pan 540°, Tilt 270°, with auto position correction and electronic replacement
function.
Zoom Angle: 10-60°
Control mode: DMX 512, Stand –alone mode, Self-test mode, Sound, Master/slave
DMX Channel: 8/16/28CH
Control Panel: Touch LCD display panel
IP Grade: IP20
Work Environment Temperature:-20°C~40°C
Other Functions:Pan and Tilt speed adjustable; LCD Display and light use time; Menu inversion,
Screen protection,Each circle can be controlled separately.
Net weight:10KG
Gross Weight: 12 kg
Package Size: 420 x 330x 460cm
Light Size(see it below)
