Arlo Entertainment Unit
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
1
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall anchor
with all furniture sold and we recommend these are used to prevent your product tipping. The fixing device
provided should fit most wall types, but please note that different wall materials may require different fixing
devices from those supplied.
Phillips & Flathead screwdrivers required.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
bolt
x8
screw
x4
ABCD
GH
F
Hardware Supplied
dowel
x8
locking
nut x8
E
screw
x14
Allen key
x1
Cover
x4
Felt pad
x4
Wall Strap
x2
washer
Z
Y
wall
anchor
x1
X
safety
strap x1
WV
screw
x1
wall
screw
x1

Arlo Entertainment Unit
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
2
12
Insert 4x bolts (C) into panel [1], and tighten with a screwdriver. Attach panels [3] and [4] to panel [1] with 4x dowels (A) . Secure with
4x locking nuts (D) and tighten with a screwdriver. Insert 4x covers (G)
into the holes of panels [3] and [4].
C
C
C
C
A
A
D
D
A
A
1
4
3
1
D
G
G
D
G

Arlo Entertainment Unit
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
3
34
Attach panel [2] to panels [3] and [4] with 4x dowels (A), and secure
with 4x screws (B). Tighten with an Allen key.
Insert 2x bolts (C) into each panel [5]. Attach panels [5] to panels [6] and
secure with 4x locking nut (D). Tighten with a screwdriver.
B
A
A
B
F
B
F
2
4
3
C
X2
D
D
D
D
5
6
5
5
6
B
B
C
D

Arlo Entertainment Unit
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
4
56
Attach the leg panels [5] and panels [6] to the bottom panel [2] with
14x screws (E). Tighten with a screwdriver.
Apply 4 x felt pads (H) to the end of panel [5] as shown.
2
E
E
5
6
5
H
E
E
E
E
EE
E
E
E
E
H
H
H
E
E

Arlo Entertainment Unit
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
5
78
Attach 1x safety strap (V) to the top panel [1] of the back side of the unit as
shown using 1x washer (Z) and 1x screw (W). Tighten with a screwdriver.
Once assembled lift furniture into place, do not drag. Attach the other end
of the safety strap (V) to the wall using 1x screw (Y), 1x wall plug (X) and
1x washer (Z). Tighten with a screwdriver.You’re done, enjoy!
V
ZW
screw
strap
washer
X
Y
Z
wall
plug
screw
strap
washer
1
