Mocka Mischa User manual

Mischa Tallboy
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
Hardware Supplied
dowel
x22
bolt
x46
screw
x28
locking
nut x46
small
screw x60
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
1
A B CD E
NM
L
K
J
I
H
G
F
wedge
x8
screw
x8
long screw
x5
screw
x8
T
Wall Strap
Z
Y
XWV
slide rail
x6
slide rail
x6 safety
strap
x1
screw
x1
wall
anchor
x1
wall
screw
x1
washer
x2
slide rail
x6
slide rail
x6
small bolt
x16
O
handle
bolt x12
handle
x6
P Q R S
felt
pad x4
leg bracket
x4
Allen key
x1
long bolt
x4
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall anchor
with all furniture sold and we recommend these are used to prevent your product tipping. The fixing device
provided should fit most wall types, but please note that different wall materials may require different fixing
devices from those supplied.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
Phillips & Flathead screwdrivers
and hammer required

Mischa Tallboy
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
2
12
Attach 5x slide rails (F) to panel [3] and secure with 15x small screws (E).
Attach 5x slide rails (G) to panel [4] and secure with 15x small screws (E).
Tighten with a screwdriver.
33
4
4
Insert 12x bolts (C) into panels [3] and [4]. Tighten with a screwdriver.
G
CR
E
F
CL
E
E
G
G
F
F
F
F
F
G
G
G
E
EE
E
EE
E
EE
E
EE
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
CC
CC
CC
C
C
CC
C
C

Mischa Tallboy
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
3
3 4
Attach panels [6], [7], [8] and [9] to panel [3] with 6x dowels (A) and
secure with 6x locking nuts (D). Tighten with a screwdriver.
3
6
7
7
9
9
8
5
5
Attach 1x slide rail (F) to panel [5] as shown with 3x screws (E).
Flip the panel [5], attach 1x slide rail (G) to panel [5] as shown
with 3x screws (E). Tighten with a screwdriver.
G
CR
E
F
CL
E
A
D
A
A
A
D
D
D
E
G
F
E
E
E
E
E
FLIP
D
D

Mischa Tallboy
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
4
6
9
10
9
4
9
5
Slide panel [10] down along the grooves between the panels [9]. Attach panel [4] to the unit with 6x dowels (A) and secure with 6x locking
nuts (D). Tighten with a screwdriver.
D
D
A
A
A
A
D
D
3
9
3
7
6
7
8

Mischa Tallboy
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
5
7 8
10
Slide panel [10] down along the grooves between the panels [3] and [4]. Attach panel [2] to the unit with 4x dowels (A) and secure with 4x long
screws (M). Tighten with a screwdriver.
33
2
4
4
M
M
A
M
M
A
A
M

Mischa Tallboy
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
6
910
3
4
10
Attach a leg bracket (Q) to each leg [11] using 2x screws (T) and 1x long
bolt (S). Tighten with a screwdriver and an Allen key (R). Attach each leg
[11] to panel [2] using 4x small bolts (J) as shown. Tighten with the Allen
key (R). Attach 4x felt pads (P) to the ends of the legs.
Slide panel [10] down along the grooves between the panels [3] and [4].
front
back
S
Q
TT
front
R
R
J
P
2
11
11
11
11
J
J
J
J
P
P
P
P

Mischa Tallboy
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
7
1211
1
1
5
Insert 6x bolts (C) to panel [1].Tighten with a screwdriver. Attach panels [5] to panel [1] with 2x dowels (A) and
secure with 2x locking nuts (D). Tighten with a screwdriver.
C
C
C
C
C
C
A
A
D
D

3
4
1
Mischa Tallboy
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
8
13 14 Drawer x2
Attach panel [1] to the unit with 4x dowels (A) and secure with 4x
locking nuts (D). Tighten with a screwdriver. Attach panel [5] to
panel [6] and secure with 1x long screw (M). Tighten with a screwdriver.
Insert 4x bolts (C) into panel [12].Attach panels [13] and [14] to panel
[12] and secure with 4x locking nuts (D). Tighten with a screwdriver.
Slide panel [15] along the grooves between the panels [13] and [14] to
form the base of the drawer.
AD
D
M
D
A
A
CC
CC
DD
DD
12
12
13
13
14
15
14
3
5
3
6

CC
Mischa Tallboy
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
9
15 Drawer x2 16 Drawer x4
Attach panels [13], [14] and [16] as shown using 4x screws (B). Tighten
with a screwdriver. Attach slide rail (I) and slide rail (H) to the underside
of the side panels as shown. Secure with 4x screws (E) and tighten with
a screwdriver. Attach 1x handle (O) to panel [12] secure with 2x handle
bolts (N).Tighten with a screwdriver.
Insert 5x bolts (C) to panel [17].Attach panels [13], [14] and [18] to front panel [17]
with 5x locking nuts (D). Tighten with a screwdriver.
17
17
18
BB
B
B
E
E
E
H
I
E
O
N
N
C
C
C
DD
D
D
D
12
13
13
13
16
14
14
14

B
B
BB
B
E
E
E
E
H
I
O
N
N
Mischa Tallboy
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
10
17 Drawer x4 18 Drawer x4
Slide panel [19] along the grooves between the panels [13] and [14]
to form the base of the drawer. Attach panels [13], [14] and [20] as
shown using 5x screws (B). Tighten with a screwdriver.
Attach slide rail (I) and slide rail (H) to the underside of the side panels
as shown. Secure with 4x screws (E) and tighten with a screwdriver. Attach
1x handle (O) to panel [17] secure with 2x handle bolts (N).Tighten with
a screwdriver.
17
13
13 20
13
14
14
14
19

V
Z
W
K
L
V
Z
W
Mischa Tallboy
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
11
19 20
Insert the assembled drawers into the corresponding compartments
as shown. Ensure the drawers slide easily along the rails.
Attach 8x wedges (K) into the corners of the back of the unit and secure
with 8x screws (L). Tighten with a screwdriver.Attach 1x safety strap (V)
to the top of the back side of the unit as shown using 1x washer (Z) and
1x screw (W). Tighten with a screwdriver.
12
12
17
17
17
17
10
10

Mischa Tallboy
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
12
21 22
Once assembled lift furniture into place, do not drag. Use a drill to create
a small hole lining up with the top of the safety strap (V). Fasten to wall
using 1x washer (Z), 1x wall anchor (X) and 1x screw (Y). Ensure unit is
balanced and steady before use.
You’re done, enjoy!
X
Y
Z
wall
anchor
screw
strap
washer
