Mocka Eros Buffet User manual

mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
Eros Buet
Thank you for your purchase.
Please follow the instructions below for correct assembly.
A
14 x
bolt
B
14 x
locking
nut
C
32 x
dowel
W
1x
safety
strap
HARDWARE SUPPLIED
D
8 x
long
screw
E
6 x
small
screw
40 mm
12 mm
G
6x
H
11 x
long screw
J
8 x
wedge
45 mm
1x
long
screw
XY
Z
1x
wall
anchor
1x
screw
1x
washer
Hinge
I
3x
Push to
open system
36 x
small
screw
14 mm
K
F
12 x
Shelf
plug
*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
Phillips & Flathead screwdrivers and hammer required
WARNING: Any furniture that is not anchored to a wall has the potential to
tip over in certain circumstances, i.e. if a child attempts to climb up on the
furniture or in the event of an earthpuake. Accordingly, we recommend that
all furniture is anchored to a wall. We supply a free safety wall anchor with
all furniture sold and we recommend these are used to prevent your product
tipping. The fixing device provided should fit most wall types, but please note
that dierent wall materials may require dierent fixing devices from those
supplied.

mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
Eros Buet
1 2
Insert 8 x dowels (C) into panels [3], [4], [5] and [6]. Attach panels [3], [4], [5] and [6]
to panel [1] and secure with 8 x locking nuts (B). Tighten with a screwdriver.
A
A
A
A
A
A
A
A
E
E
E
I
I
I
W
Y
E
E
I
E
E
Attach 3 x push to open systems (I) to panel [1], secure with 6 x small
screws (E). Insert 8 x bolts (A) into panel [1]. Attach 1 x wall strap (W)
to panel [1] using 1 x screw (Y). Tighten with a screwdriver.
3
5
6
4
1
B
B
C
CC
CC
C
C
C
B
BB
B
B
B
1
B

mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
Eros Buet
3 4
1
7
7
8
4
6
5
3
Slide panels [7] and [8] between the grooves on panels [3], [4], [5] and [6] to
form the back of the unit as shown.
Insert 8 x dowels (C) into panels [3], [4], [5] and [6]. Attach panel [2] to panels
[3], [4], [5] and [6], securing with 8 x long screws (D).
D
D
D
D
D
DD
D
C
C
C
C
C
C
C
C
4
6
5
3
2

mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
Eros Buet
56
Panel piece x 2
A
A
A
A
10
Attach 6 x bolts (A) into panels [10]. Tighten with a screwdriver.
Insert 12 x dowels (C) to panels [11] and attach panels [10]. Insert 6 x
locking nuts (B) into panels [11]. Tighten with a screwdriver.
B
B
C
C
C
C
C
C
C
C
B
B
B
B
C
C
C
C
B
10
10
11
11
11

mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
Eros Buet
7
Attach 6 x hinges (G) to panels [9] and secure with 12 x small screws (K).
Tighten with a screwdriver.
Insert 4 x dowels (C) into panels [10] and [11]. Attach panels [10] and [11] to
panel [2] and secure with 11 x long screws (H). Tighten with a screwdriver.
4
3
2
10
11
C
C
C
C
H
H
H
H
H
H
H
H
H
H
H
8
9
G
G
KK
KK
G
KK
Panel x 3

mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
Eros Buet
9
Attach panels [9] to panels as shown. Secure with 24 x screws (K).
Tighten with a screwdriver.
NOTE: If the doors are
uneven or there is a gap in
the middle, loosen or tighten
the screw on the hinge until
they are sittng flush.
Kx4
G
9
9
9
3
4
1

9
mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
Eros Buet
10 11
Attach 12 x wedges (J) to panels [7] and [8]. Tighten woth a screwdriver.
3
9
4
12
12
12
4
6
5
F
Fx4
Fx4
Fx4
J
J
J
J
J
J
J
J
J
J
J
J
J
J
47
8
7
Insert 12 x shelf plugs (F) to panels [3], [4], [5] and [6]. Attached panels
[12] to panels [3], [4], [5] and [6] as shown.

mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
Eros Buet
12
Once assembled lift furniture into place, do not drag. Use a drill to create a
small hole lining up with the top of the safety stap (W). Fasten to wall using
wall anchor (X), washer (Z) and screw. Ensure the unit is balaced and steady
before use. You’re done, enjoy!
Strap
Washer
Wall
anchor
Wall
screw
X
Z
Wall
screw
