Mocka Parker 6 Drawer User manual

Parker 6 Drawer
1
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
WARNING: Any furniture that is not anchored to a wall has the
potential to tip over in certain circumstances, ie. if a child attempts
to climb on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall.
We supply a free safety wall anchor with all furniture sold and we
recommend these are used to prevent your product tipping. The
fixing device provided should fit most wall types, but please note
that different wall materials may require different fixing devices from
those supplied.
Thank you for your purchase.
Please follow the instructions below for correct assembly.
A
Hardware Supplied
Wall Strap
bolt &
locking nut
x36
F
14mm screw
x2
E
rails
x12
G
18mm screw
x10
H
bracket
x10
I
pin
x2
B
50mm screw
x8
C
30mm screw
x8
D
50mm screw
x24
Phillips & Flathead screwdrivers required.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
K
handle
x6
L
25mm screw
x2
M
wall plug
x2
N
E1 E2
E3 E4
J
dowel
x12
F
14mm screw
x48
wall strap
x2

Parker 6 Drawer
2
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Attach 2 x rails (E1) and 2 x rails (E3) to panels [3] and [4] and secure
with 8 x screws (F). Insert 8 x locking nuts (A) into panels [3] and [4].
Tighten with a screwdriver.
Attach 2 x rails (E3) secure with 4 x screws (F) to panel [5] and insert
4 x locking nuts (A) into panel [5]. Overturn panel [5] and attach 3 x
rails (E1) and secure with 6 x screws (F). Tighten with a screwdriver.
AA
12

3
3
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Insert 6 x dowels (J) into panel [2] as shown. Attach panels [3], [5] and
[4] to panel [2] and secure with 6 x bolts (A). Tighten with a screw
driver.
Slide panel [6] into position as shown.
Parker 6 Drawer
4
A
3
2
54
A
J
3
654
2

5
4
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Attach 1 x rail (E1) and 2 x rails (E3) to panels [3], [4] and [5] and
secure with 6 x screws (F). Tighten with a screwdriver. Insert 6 x dowels (J) into panels [3], [4] and [5]. Attach panel [1] to panels [3], [4] and [5] and secure with 6 x bolts (A). Tighten with a
screwdriver.
Parker 6 Drawer
6
A
1
354
A
J

78
Parker 6 Drawer
5
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Attach 2 x pins (I) as shown. Attach 10 x brackets (H) to assembled
frame and secure with 10 x screws (G). Tighten with a screwdriver. Attach steel frame [13] to steel frame [14] and secure with 8 x
screws (B). Tighten with a screwdriver.
H
G
I
IB
B
13
13
14
14

9
6
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Attach base to assembled frame as shown and secure with 8 x screws
(C). Tighten with a screwdriver. Insert 6 x handle (K) into panels [7] and [8].
Parker 6 Drawer
10 x 3
2
C
K
7
K
8

11 x 3
7
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Parker 6 Drawer
12 x 3
A
A
Attach panels [9], [10], [11], [8] together and secure with 12 x screws
(D), 12 x bolts (A) and 12 x locking nuts (A). Tighten with a screwdriver.
Attach panels [9], [10], [11], [7] together and secure with 12 x screws
(D), 12 x bolts (A) and 12 x locking nuts (A). Tighten with a screwdriver.
7
8

13 x 6
8
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Attach 6 x rail (E2) to panel [9] and secure with 12 x screws (F).
Tighten with a screwdriver. Attach 6 x rail (E4) to panel [10] and secure with 12 x screws (F). Tighten with a screwdriver.
Parker 6 Drawer
14 x 6
F
F
E2
9
F
E 4
10
F

15 16
Parker 6 Drawer
9
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Slide drawers into position as shown, ensuring alignment with rails. Once assembled lift furniture into place, do not drag. Use a drill
to create a small hole lining up with the top of the 2 x safety strap (N).
Fasten to the wall using 2 x wall anchors (M), 2 x screws (L) and 2 x
screws (F). Ensure unit is balanced and steady before use.
78
78
78
M
N
F
N
L

17
10
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
You’re done, enjoy!
