ASSEMBLY INSTRUCTIONS
Leon Dining Chair
Thank you for purchasing Leon Dining Chair. Please follow the
manufacturer’s assembly instructions in detail.
HARDWARE SUPPLIED
A
x6
45mm screw
B
x4
25mm screw
C
x10
spring
washer
D
x4
screw pin
E
x4
washer
F
x4
dowel
G
x4
bracket
H
x8
screw
I
x1
allen key
J
x4
wood button
Phillips screwdriver required.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
Read instruction carefully. Remove all wrapping material, staples and straps from the
carton. See Hardware and Furniture Parts List for guidance. Be sure you have all parts
before you start assembling. Place all wooden furniture part a clean and flat soft
surface, such as carpet or rug to prevent from being scratched.
CAUTION :
KEEP ALL HARDWARE PART OUT OF REACH OF CHILDREN.
K
felt pads
x4

mocka.co.nz I mocka.com.au I
ASSEMBLY INSTRUCTIONS
Leon Dining Chair
1 2
Attach 4 x dowels (F) to 2 x strechers (3F - Front) and (3B - Back) and 2 x legs
(2) as shown. Panels number 3 are marked F and B, F is the panel for the front
of the chair and Panel B is for the back of the chair.
Attach assembled frame together as shown and secure with 4 x screws (A),
4 x spring washers (C) and 4 x screw pins (D). Tighten with an Allen Key (I).
R
L
F
2
IA
C
D
3B
3F
2

mocka.co.nz I mocka.com.au I
ASSEMBLY INSTRUCTIONS
Leon Dining Chair
3 4
Attach 1 x backrest (1) to assembled frame as shown and secure with
4 x screws (B), 4 x spring washers (C) and 4 x washers (E). Tighten with an Allen
Key (I). Once tightened insert 4 x wood buttons (J) as shown.
Attach 1 x seat (4) to assembled frame, 4 x felt pads (K) as shown and secure
with 2 x screws (A) and 2 x spring washers (C). Tighten with an Allen Key (I).
J
B
CE
1
4
I
A
C
I
K
K
K

Attach 1 x seat (4) to assembled frame and secure with 4 x brackets (G) and 8 x
screws (H). Tighten with a screwdriver.
5 6
mocka.co.nz I mocka.com.au I
ASSEMBLY INSTRUCTIONS
Leon Dining Chair
Once assembled lift furniture into place, do not drag. Ensure unit is
balanced and steady before use. You’re done, enjoy!
H
G
4
