Mocka Jolt Six Drawer - Wide User manual

Jolt Six Drawer - Wide
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
1
Wall Strap
x2
washer
ZY
wallwall
anchor
x1
X
wall
strap x1
WV
screw
x1
r/washer
screw
x1
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall anchor
with all furniture sold and we recommend these are used to prevent your product tipping. The fixing device
provided should fit most wall types, but please note that different wall materials may require different fixing
devices from those supplied.
Hardware Supplied
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
Phillips & Flathead screwdrivers
and hammer required
A B C D E F G
HJ K L M N
IO
dowel
x31
screw
x36 bolt
x13
small bolt
x30
locking
nut x13
small
screw x60
small
locking nut
x30
L + R slide
rail x6
L + R slide
rail x6
long
screw x4
plastic
glide x6 long
dowel x6
nail
x28

Jolt Six Drawer - Wide
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
2
12
E
F
E
EF
E
E
E
E
E
EF
2
G
G
G
E
E
E
E
E
E
E
E
E
3
To begin assembly attach 3x slide rails (F) & (G) in place
on each of the panels [2] and [3] using 3x small screws (E)
in each rail bracket. Fasten all screws with a screwdriver.
E
E
A
A
A
A
A
A
C
C
3
C
A
A
A
A
A
A
C
C
C
2
Screw 6x bolts (C) and insert 18x dowels (A) into
corresponding holes in panels [2] and [3].

Jolt Six Drawer - Wide
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
3
3 4
E
E
EF
E
E
EFE
EF
E
4
E
E
E
E
E
E
E
E
E
G
G
G
4
Attach 3x slide rails (F) and (G) into each side of panel
[4] using 18x small screws (E). Fasten all screws with a
screwdriver.
E
E
D
A
C
3
5
5
5
6
Slot 3x panels [5] into the dowels in panel [3]. Place a bolt (C) and
dowel (A) into panel [6] and attach connecting parts with a locking
nut (D). Tighten with a screwdriver.
A
C
D

Jolt Six Drawer - Wide
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
4
65
D
4
3
6
Connect panel [4] to panel [6] with a locking nut (D)
and tighten with a screwdriver.
N
N
N
4
3
5
5
5
Connect remaining 3x panels [5] with 6x long dowels (N) on panel [4].

Jolt Six Drawer - Wide
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
5
7 8
You’re done, enjoy!
D
D
3
4
7
8
Attach panels [7] and [8] to panel [3] using 2x
locking nuts
(D) and.
tighten with a screwdriver.
DM
M
L
L
M
M
M
M
D
D
3
2
6
Use 4x long screws (L) to secure panels [7] and [8]. Attach panel [2] with
3x locking nuts (D). Hammer 6x plastic glides (M) into base.

Jolt Six Drawer - Wide
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
6
910
Assembly Instructions
D
D
C
C
A
A
A
2
3
Insert 6x bolts (C) and 6x dowels (A) into top panel [1].
Slot together with rest of the cabinet. Place 6x locking nuts (D)
into corresponding holes and tighten with a screwdriver.
1
O
9
9
O
x28
Attach both back panels [9] to the cabinet using 28x nails (O) and
a hammer.

Jolt Six Drawer - Wide
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
7
1211
A
K
K
K
K
K
JJ
12
10
16
13
11
Assemble the drawers by screwing 4x small bolts (J) into the
front panel [10]. Attach to side panels [12] and [13] using 4x
small locking nut (K). Attach the support panel [16] with a
dowel (A), small bolt (J) and locking nut (K) into panel [10]/[11].
BB
B
12
12
10
13
13
14
15
11
10 11
Sllide the base panel [14] into place in the grooves on side
and front panel, and in bteween the support panel. Fasten
back panel [15] into place using 6x screws (B) into the holes
on the side and support panels
Drawers x6

Jolt Six Drawer - Wide
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
8
1413
E
E
H
I
E
E
13
12
Flip drawer over and attach slide rails (H) and (I) to both left and
right underside of the drawer using 4x screws (E).
10
11
Slide all six drawers into place on the rails in the cabinet unit as
shown, making sure all panel 10 drawer fronts are on the left side
and all panel 11 drawer fronts are on the right. Ensure all drawers
slide easily open and closed.

Jolt Six Drawer - Wide
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
9
1615
V
r/washer
screw
V
Y
Z
Z
Attach 1x safety strap (V) to the top of the back side of the
unit as shown using 1x washer (Z) and 1x screw (Y). Tighten
with a screwdriver.
wall
anchor
wall
screw
Washer
Strap
V
X
Z
W
Once assembled lift furniture into place, do not drag. Attach the
other end of the safety strap (V). Fasten to wall using 1x washer
(Z), 1x wall anchor (X) and 1x wall screw (W). Ensure unit is
balancedand steady before use. You’re done, enjoy!
