Mocka Zara User manual

Zara Console Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
1
Wall Strap
x2
washer
Z
Y
wall
anchor
x1
X
safety
strap x1
WV
screw
x1
wall
screw
x1
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall anchor
with all furniture sold and we recommend these are used to prevent your product tipping. The fixing device
provided should fit most wall types, but please note that different wall materials may require different fixing
devices from those supplied.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
bolt
x14
x4
A B C D EFGHJ
KLMN
I
O P Q R
Hardware Supplied
dowel
x12
screw
x26
slide
rail x2
slide
rail x2
slide
rail x2
slide
rail x2
locking
nut x14
screw
x6 x4
wedge
screw spring
washer
x8
x2
bracket
x8
washer
cover
x2
seal
x2
Phillips & Flathead screwdrivers
felt
pad
x4
bolt
x8
S
screw
x8
T
key x1
Allen

Zara Console Table
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
2
12
Insert 4x bolts (C) into panel [1] and tighten with a screwdriver. Attach 1x slide rail (F) and 1x slide rail (G) to panels [3] and [4]
as shown and secure with 6x screws (E). Tighten with a screwdriver.
.
C
C
C
C
C
C
E
E
EG
E
E
E
F
G
CR
E
F
CL
E
1
4
3

Zara Console Table
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
3
3 4
Attach 1x slide rail (G) to panel [5] as shown and secure with 3x
screws (E). Flip the panel [5], attach 1x slide rail (F) to panel [5]
as shown and secure with 3x screws (E). Tighten with a screwdriver.
Attach panels [3], [4] and [5] to panel [1] with 6x dowels (A) and
secure with 6x locking nuts (D). Tighten with a screwdriver.
E
E
EG
E
E
E
F
FLIP
G
CR
E
F
CL
EA
A
A
A
A
A
D
D
D
D
5
5
1
5
3
4
D

Zara Console Table
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
4
65
Slide panel [6] along the grooves between the side panel [3]
and [4] to form the back of the unit.
Attach 2x bracket (M) to panel [2] and secure with 4x screws (E).
Tighten with a screwdriver. Place 2x cover (N) over the bracket (M)
as shown.
EE
EE
N
MM
The round head
is aligned with the
direction of the arrow.
M
EE
M
3
4
6
2

Zara Console Table
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
5
7 8
Attach panel [2] to the unit with 6x dowels (A) and secure with 6x
screws (B). Tighten with a screwdriver.
Attach legs [7] to panel [2] and secure with 8x bolt (R), 8x washer (P),
8x spring washer (Q). Tighten with an Allen key (T). Attach 4x felt pads (L)
to legs [7] as shown.
A
B
A
B
B
A
B
B
A
2
5
3
4
B
7
7
7
7
P
Q
R
7
P
Q
R
L
L
L
L
2
T

Zara Console Table
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
6
10 Drawers x29 Drawers x2
Insert 4x bolts (C) into panel [8]. Attach 1x seal (O) to panel [8] and
secure with 1x screw (E). Tighten with a screwdriver.
Attach panel [9] and panel [10] to panel [8] and secure with 4x locking
nuts (D). Tighten with a screwdriver.
C
C
C
C
E
O
8
D
D
D
D
9
10
8

Zara Console Table
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
7
12 Drawers x211 Drawers x2
Slide panel [11] along the grooves between the side panels [9] and [10]. Attach panels [9], [10] and [12] as shown using 4x screws (S).
Tighten with a screwdriver.
8
9
10
11 9
10
12
S
S
S
S
8

Zara Console Table
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
8
1413 Drawers x2
Attach slide rail (I) and slide rail (H) to the underside of the side panels
as shown. Secure with 4x screws (E) and tighten with a screwdriver.
Insert the assembled drawers into the corresponding compartments
as shown. Ensure the drawers slide easily along the rails. If the door
is not catching or sitting flush, twist the end of the cover (N) until it
catches on the seal (O).
.
H
E
E
E
E
I
9
10
8
N
8
8

Zara Console Table
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
9
1615
Once assembled lift furniture into place, do not drag. Use a drill to
create a small hole lining up with the top of the safety strap (V).
Fasten to the wall using 1x washers (Z), 1x wall anchor (X) and
1x screws (Y). Ensure unit is balanced and steady before use.
You’re done, enjoy!
Attach 4x wedges (J) into the corners of the back of the unit and secure with
4x screws (K). Tighten with a screwdriver. Attach 1x safety straps (V) to the
top of the back side of the unit as shown using 1x washers (Z) and 1x screws
(W). Tighten with a screwdriver.
K
J
K
J
V
Z
W
V
Z
W
X
Y
Z
wall
anchor
screw
strap
washer
6
1
