Mocka Porto User manual

WARNING: Any furniture that is not anchored to a wall has the potential to tip over
in certain circumstances, i.e. if a child attempts to climb up on the furniture or in the
event of an earthquake. Accordingly, we recommend that all furniture is anchored to
a wall. We supply a free safety wall anchor with all furniture sold and we recommend
these are used to prevent your product tipping. The fixing device provided should fit
most wall types, but please note that different wall materials may require different
fixing devices from those supplied.
A B C D
Phillips screwdriver required
Hardware Supplied
35mm
screw x16
12mm
screw x8
60mm
screw x4
feet
x4
E F G H
14mm
screw x2
wall
anchor x2
safety
strap x2
25mm
screw x2
Porto Console
1
mocka.co.nz | mocka.com.au
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.

12
Attach 4x feet (D) to the bottoms of the main panels. Attach the connecting panels to the main panels using 12x 35mm screws
(B) and 8x 12mm screws (C) as shown. Tighten with a screwdriver.
D
D
D
D
B
BB
B
B
B
B
B
B
B
B
B
C
CC
C
C
C
C
C
Porto Console
2
mocka.co.nz | mocka.com.au
Assembly Instructions

12
Attach 4x feet (D) to the bottoms of the main panels. Attach the connecting panels to the main panels using 12x 35mm screws
(B) and 8x 12mm screws (C) as shown. Tighten with a screwdriver.
D
D
D
D
B
BB
B
B
B
B
B
B
B
B
B
C
CC
C
C
C
C
C
34
Attach panel [1] to the frame from underneath using 4x 60mm screws
(A) and 4x 35mm screws (B) as shown. Tighten with a screwdriver.
Attach 2x safety straps (H) to the rear sides of the table and secure with
2x 14mm screws (F). Tighten with a screwdriver.
A
A
A
A
B
B
B
B
1
H
F
H
F
Porto Console
3
mocka.co.nz | mocka.com.au
Assembly Instructions

56
Lift the completed unit into place, do not drag. Screw the other end of
the straps to the wall using 2x wall anchors (G) and 2x 25mm screws
(E). Tighten with a screwdriver.
You’re done, enjoy!
E
HG
H
H
Porto Console
Assembly Instructions
4
mocka.co.nz | mocka.com.au
