Mocka Luna Cube 4 User manual

For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
C
dowel
x16
Hardware Supplied
*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
Please clear any loose wood from the locking nut holes before inserting the nut to ensure it locks 100%.
A B
bolt
x16
locking
nut x16
Phillips & Flathead screwdrivers required
WARNING: Any furniture that is not anchored to a wall has the potential to tip
over in certain circumstances, i.e. if a child attempts to climb up on the
furniture or in the event of an earthquake. Accordingly, we recommend that all
furniture is anchored to a wall. We supply a free safety wall anchor with all
furniture sold and we recommend these are used to prevent your product
tipping. The fixing device provided should fit most wall types, but please note
that different wall materials may require different fixing devices from those
supplied.
Z
Y
X
safety
strap x2
W
Wall Strap
wall
screw x2
wall
anchor x2
r/washer
screw x2
washer
x2
Luna Cube 4
1
mocka.co.nz | mocka.com.au
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.

12
Slot one panel [3] into the groove of panel [4] to form the internal walls. Insert 2x bolts (A) and 2x dowels (C) into the side panel [2]. Attach to
panel [4] with 2x locking nuts (B) and tighten with a screwdriver.
3
A
B
A
4
4
2
C
Luna Cube 4
2
mocka.co.nz | mocka.com.au
Assembly Instructions

34
Insert 2x bolts (A) and 2x dowels (C) into the side panel [2]. Attach the
rest of the unit with 2x locking nuts (B) and tighten with a screwdriver.
Insert 6x bolts (A) and 6x dowels (C) into the top panel [1], and 6x bolts
(A) and 6x dowels (C) into the bottom panel [5].
A
AA
A
A
A
A
AA
A
A
A
B
B
A
A
32
C
1
C
C
C
C
CC
C
C
C
C
CC
Luna Cube 4
3
mocka.co.nz | mocka.com.au
Assembly Instructions

56
Attach the bottom panel to the main unit with 6x locking nuts (B) and
tighten with a screwdriver.
Attach the top panel to the main unit with 6x locking nuts (B) and tighten
with a screwdriver.
BB
B
B
B
B
B
B
B
B
Luna Cube 4
Assembly Instructions
4
mocka.co.nz | mocka.com.au

Jolt Wardrobe
ASSEMBLY INSTRUCTIONS
5
mocka.co.nz | mocka.com.au
56
Attach the bottom panel to the main unit with 6x locking nuts (B) and
tighten with a screwdriver.
Attach the top panel to the main unit with 6x locking nuts (B) and tighten
with a screwdriver.
BB
B
B
B
B
B
B
B
B
78
Once assembled lift furniture into place, do not drag. Attach the 2x
safety straps (W) to the top of the back side of the unit using 2x
r/washer screws (Y). Tighten with a screwdriver.
Use a drill to create a small hole lining up with the top of the safety
straps (W). Fasten to the wall using 2x wall anchors (X), 2x washers (Z)
and 2x wall screws (not supplied). Ensure the unit is balanced and
steady before use. That’s it, you’re done. Enjoy!
Wall Strap
Y
W
Y
W
X
Z
wall
screw
wall
anchor
wall
screw
Washer
Strap
Y
W
X
Z
Luna Cube 4
Assembly Instructions
5
mocka.co.nz | mocka.com.au
