Mocka Maisie Scalloped Six Drawer User manual

mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
Maisie Scalloped Six Drawer
Thank you for yourpurchase. Please follow the instructions for correct
assembly.While we took great eort to ensure these assembly instructions
were correct at the time of printing, sometimes updates are required post
production. For the most up to date versions please refer to the product
page on our website.mocka.com.au/mocka.co.nz

Partlist
Maisie Scalloped Six Drawer
mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
x1
1Top Panel
x1
x6
2
10
Bottom Panel
Left Drawer Side
x1
x6
3
11
12
left Side Panel
Right Drawer Side
x6
Back Panel
x1
4Right Side Panel
x1
5Divider
x2
6Slats
x6
14 Drawer Base
13 x6
Drawer Front
Panel Layout
x6
x1
7Slats
x3
8Back Panel
x2
16 Back Slats
x2
15 Bootom Frame
x1
9Back Panel
1
15
2
3
4
5
66
8
88
9
7
10
11
12
13 14
16
16

Maisie Scalloped Six Drawer
mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
HARDWARE SUPPLIED
A B C D
I J K
EF
bolt
x44
medium screw
x30
small screw
x4
dowel
x16
locking
nut x 44
small screw
x48
handle
x6
long screw
x2
long screw
x1
40 mm
10 mm
30 mm
CL
CR
DL
DR
L+R
slide rail
x12
L+R
slide rail
x12
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall
anchor with all furniture sold and we recommend these are used to prevent your product tipping.
The fixing device provided should fit most wall types, but please note that dierent wall materials
may require dierent fixing devices from those supplied.
Z
V
wall
anchor x 1
screw
x 1
safety
strap x 1
wall
screw x 1
washer
x 1
XYW
WALL STRAP
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
Phillips & Flathead screwdrivers
and hammer required
L N O
cover
x24
shelf plug
x1
small screw
x10
30 mm
12 mm

1Hardware Needed
Hardware Needed
2
x4
A
Maisie Scalloped Six Drawer
mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
x6
E
x3
CR
A
x4
A
x6
E
x3
CL
CL
E
3
E
E
E
E
E
E
A
A
A
A
CL
CL
CL
CR
E
4
CR
CR
CR
A
A
A
A
E
E
E
E

Maisie Scalloped Six Drawer
3
4
mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
Hardware Needed
Hardware Needed
E x6
CL x3
x6
E
x3
CR
CL
E
5
CR
E
E
E
E
E
E
E
CR
CR
CR
CL
CL
CL
5
E
EE
E
E
E

Maisie Scalloped Six Drawer
5
Hardware Needed
6
x4
J
mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
5
2
7
J
J
J
J
6
6

Maisie Scalloped Six Drawer
7
Hardware Needed
8
mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
Hardware Needed
C x2
x2
D
5
2
2
B x4
C x4
B
B
B
B
C
C
C
C
3
6
6
B
D
D
C
C

Maisie Scalloped Six Drawer
9
10
mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
Hardware Needed
B x4
C x4
4
2
B
B
B
B
CC
C
C
8
8
8
9
4
2
5
3
16
16
6
6

Maisie Scalloped Six Drawer
11
12
mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
Hardware Needed
B x6
C x6
A x6
Hardware Needed
Y x1
Wx1
W
Y
A
A
A
A
A
A
1
1
3
5
4
B
B
B
B
BB
C
C
C
C
C
C

13
14
mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
Hardware Needed
Drawers x 6
Fx30
Hardware Needed
N x10
K
Maisie Scalloped Six Drawer
8
9
K
L
8
8x1
L
x1
K
2
N
N
N
N
N
N
N
N
N
N
F
12
10
11
14
F
F
F
F

Maisie Scalloped Six Drawer
15
16
mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
Hardware Needed
Drawers x 6
B
Drawers x 6
A x30
I x6
A
A
A
A
A
A
I
15
I
13
10
11

Maisie Scalloped Six Drawer
17
18
mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
B x30
Hardware Needed
O x24
B
BO
x 24
Drawers x 6
E x24
Hardware Needed
Drawers x 6
DL x6
DR x6
11
E
DR
11
15
B
B
B
B
B
11 15
DR
E
E
DL
E
E
10

Maisie Scalloped Six Drawer
19
20
mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
X x1
Hardware Needed
C
DL
CL
CR
DR
Strap
Washer
Wall
anchor
Wall
screw
X
Z
Wall
screw
V x1
Carefully insert the drawers
into the unit by gently guiding
the runners into the tracks.
Note: Seek advice from a qualified
trades person on how to attach this
safety strap to your specific wall.
Z x1
Once assembled lift furniture into
place, do not drag.
15
15
15
15
15
15
V
