Mocka Savannah Two Drawer Bedside User manual

Savannah Two Drawer Bedside
1
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Thank you for your purchase.
Please follow the instructions below for correct assembly.
A
Hardware Supplied
bolt
x12
F
large screw
x12
K
plate
x4
L
screw
x16
G
left rail
x2
H
right rail
x2
I
screw
x4
J
handle
x2
B
locking nuts
x12
C
dowel
x4
D
small screw
x20
E
medium screw
x8
Phillips & Flathead screwdrivers required.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
P
wall strap
x1
Q
washer
x2
R
wall plug
x1
N
0.14 screw
x1
WARNING: Any furniture that is not anchored to a wall has the
potential to tip over in certain circumstances, ie. if a child attempts
to climb on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall.
We supply a free safety wall anchor with all furniture sold and we
recommend these are used to prevent your product tipping. The
fixing device provided should fit most wall types, but please note
that different wall materials may require different fixing devices from
those supplied.

12
Savannah Two Drawer Bedside
2
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Attach 4 x bolts (A) to panel [1]. Tighten with a screwdriver. Attach 2 x left rails (G) and 2 x right rails (H) to panels [3] and [4] and
secure with 12 x screws (D). Tighten with a screwdriver.
A
A
A
A
A
1
D
D
D
D
D
D
D
D
D
D
D
D
G
G
H
H
D
D
D
G
D
D
D
H
D
3
4

3
3
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Attach panels [3] and [4] to panel [1] and secure with 4 x locking nuts
(B). Tighten with a screwdriver.
Slide panel [5] into position as shown.
Savannah Two Drawer Bedside
4
B
B
B
B
B
1
3
4
1
3
4
5

5
4
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Attach panel [2] to panels [3], [4] and [5] and secure with 4 x dowels (C)
and 4 x screws (F). Tighten with a screwdriver.
Attach 1 x plate (K) to panel [6] as shown and secure with 2 x screws
(F). Attach panel [6] to panel [2] and secure with 16 x screws (L).
Tighten with a screwdriver.
Savannah Two Drawer Bedside
6 x4
4
5
2
6
2

7x2
5
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Attach 1 x left rail (G) and 1 x right rail (H) to panels [8] and [9] and
secure with 4 x screws (D). Attach 4 x bolts (A) and 1 x handle (J) to
panel [7] and secure with 2 x screws (I). Tighten with a screwdriver.
Attach panel [8] and [9] to panel [10] and secure with 4 x screws (E).
Tighten with a screwdriver.
Savannah Two Drawer Bedside
8x2
7
8
9
乙
8
9
10

9x2
6
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Slide panel [11] into position as shown. Attach panel [7] to assembled frame and secure with 4 x locking nuts
(E). Tighten with a screwdriver.
Savannah Two Drawer Bedside
10 x2
11
8
9
1
7
8
9
11

11
7
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Slide assembled drawers into position as shown.
Savannah Two Drawer Bedside
12
7
7
Once assembled lift furniture into place, do not drag. Attach 1 x wall
straps (P) to unit with 1 x screws (N) and 1 x washers (Q). Use a drill to
create a small hole lining up with the wall strap (P). Fasten to wall using
1 x wall anchor (R), 1 x wall screw (N) and 1 x washers (Q). Tighten
with a screwdriver. Ensure unit is balanced and steady before use.
You’re done, enjoy!
N
N
Q
Q
R
R
P
P
