Mocka Tahoe User manual

M
long
screw x2
shelf
plug x2
A B C D E
FH I JG
Phillips & Flathead screwdrivers and hammer required
Hardware Supplied
dowel
x24
bolt
x21
locking
nut x21
small
screw x8
long
screwx 5
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
Tahoe Entertainment Unit
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
x18
long screw
1
L + R
slide rail
x 2
L + R
slide rail
x 2
mocka.co.nz | mocka.com.au
2
WARNING: Any furniture that is not anchored to a wall has the potential to tip
over in certain circumstances, i.e. if a child attempts to climb up on the furniture
or in the event of an earthquake. Accordingly, we recommend that all furniture
is anchored to a wall. We supply a free safety wall anchor with all furniture sold
and we recommend these are used to prevent your product tipping. The fixing
device provided should fit most wall types, but please note that different wall
materials may require different fixing devices from those supplied.
*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
Please clear any loose wood from the locking nut holes before inserting the nut to ensure it locks 100%.
40
nut
x 4
long
screw x 4
K L
hinge
x 4
screw
x24
4
N
cover
x 4
O
X
Z
Y
W
safety
strap
x1
screw
x1
long
screw
x1
wall
anchor
x1
washer
x1

2
12
Tahoe Entertainment Unit
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au
A
Curved panel piece x 2
5
5
5
1
A
A
A
A
Insert 8 x bolts(A) into panels [5]. Tighten with a screwdriver.
Insert 4 x locking nuts(B) into panel [1]. Attach 4 x bolts (A) into panel [1].
Attach 4 x dowels(C) to panel [1] and secure with [5].
A
A
B
BC
C
B
B
C
C
A
A
YW
Attach 1 x wall strap
(W) to panel [1] using 1x screw (Y). Tighten with a screwdriver.

3
34
Tahoe Entertainment Unit
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au
6
9
A
A
AA
Tighten with a screwdriver.Insert 4 x bolts (A) into panels [6] and [9].
9
6
10
B
B
B
B
C
C
B
Insert 4 x dowels (C) into panel [10]. Attach panel [10] to panels [6] and [9]
and secure with 4 x locking nuts (B). Tighten with a screwdriver.
EE
G
EE
G
G
G
Attach 1 x left slide rail (G) to panel [6] and secure with 2 x small screws (E).
Attach 1 x right slide rail (G) to panel [9] and secure with 2 x small screws(E).

4
56
Tahoe Entertainment Unit
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au
9
6
10
B
3
4
1BC
C
C
C
C
C
B
B
B
C
C
Insert 8 x dowels (C) into panel [1]. Attach panel [1] to panels [3], [4],[6] and [9]
and secure with 8 x locking nuts (B).
12
13
11
Slide panel [11], [12] and [13] between the grooves on panels [3],[4], [6] and
[9] to form the back of the unit as shown.Tighten with a screwdriver.
3
6
9
4
B
x4
1
2I
O
O
Cover locking nuts (B) with 4 x covers (O).

5
78
Tahoe Entertainment Unit
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au
I
I
8
8
7
7
I
J
J
J
J
II
with 4 x long bolts (J). Tighten with a screwdriver.
Insert 4 x nuts (I) into panels [8] . Attach panels [7] to panels [8] and secure
3
4
6
9
2
CC
CC
C
C
C
Tighten with a screwdriver.
Insert 8 x dowels(C) into panel
Attach paneles [2] to panel
and secure with 8 x long screws (D).
B
D
D
D
D
D
D
D
D
[3], [4], [6] and [9].
[3], [4], [6] and [9]
C

6
910
Tahoe Entertainment Unit
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au
8M
2
Attach panels [8] to panel [2] with 10 x long screws (D). Attach 2 x centre support
(N) to panel [2]. Attach 2 x long screws (M) to centre support (N) as
N
N
M
M
D
D
D
D
D
D
D
D
D
D
shown.
LL
LL
K
K
K
K
LL
LL
19
20
K
L
Attach 4x hinges(K) to panels [19] and [20] and secure with 8 x small screws (L).

7
11 12
Tahoe Entertainment Unit
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au
15
14
17
B
B
B
B
A
A
A
A
Tighten with a screwdriver.
Insert 5 x bolts (A) into panel [17] .Attach panels [14] and [15] to panel [17]
secure with 5 x locking nuts (B).
Slide panels [16] between the grooves on panels
[14] and [15] to form the base of the drawer as shown.
21
15
14
21
H
H
E
E
E
17
Attach panel [21] to panels [14] and [15] secure with 5 x medium screws (F).
Attach 2 x slide rails (H) to panels [14] and [15] and secure with 4 x small screws (E).
Tighten with a screwdriver.
18
16
B
17 14
15
FF
F
F
14
15
18
16
F
A

8
13 14
Tahoe Entertainment Unit
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au
17
19
20
NOTE: If the doors are
uneven or there is a gap in
the middle, loosen or tighten
the screw on the hinge until
K
Attach panels [19] and [ 2 0 ] to panel as shown. Secure with 16 x screws (L).
Tighten with a screwdriver.
W
X
Z
Move the unit into the desired location up against a wall. Use a drill to
create a small hole lining up with the top of the 2x safety strap (W).
Fasten to the wall using 1x wall anchor (X), 1x washer (Z) and 1x long
screw. Ensure the unit is balanced and steady before use. You’re done,
enjoy!
